GA-K8VT800-RH
AMD Socket 754 Processor Motherboard
User's Manual
Rev. 2001
12ME-K8VT800R-2001R
* The WEEE marking on the product indicates this product must not be disposed of with user's other household waste
and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!
* The WEEE marking applies only in European Union's member states.
Advertisement
Table of Contents
Related Manuals for Gigabyte AMD Socket 754 Processor Motherboard GA-K8VT800-RH
Summary of Contents for Gigabyte AMD Socket 754 Processor Motherboard GA-K8VT800-RH
- Page 1 GA-K8VT800-RH AMD Socket 754 Processor Motherboard User's Manual Rev. 2001 12ME-K8VT800R-2001R * The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!! * The WEEE marking applies only in European Union's member states.
- Page 3 Gigabyte's prior written permission. Specifications and features are subject to change without prior notice. Product Manual Classification In order to assist in the use of this product, Gigabyte has categorized the user manual in the following: For quick installation, please refer to the "Hardware Installation Guide" included with the product.
-
Page 4: Table Of Contents
Table of Contents Item Checklist ... 6 Optional Accessories ... 6 GA-K8VT800-RH Motherboard Layout ... 7 Block Diagram ... 8 Chapter 1 Hardware Installation ... 9 Considerations Prior to Installation ... 9 Feature Summary ... 10 Installation of the CPU and Heatsink ... 12 1-3-1 Installation of the CPU ... - Page 5 Chapter 3 Drivers Installation ... 47 Install Chipset Drivers ... 47 Software Application ... 48 Software Information ... 48 Hardware Information ... 49 Contact Us ... 49 Chapter 4 Appendix ... 51 Unique Software Utilities ... 51 4-1-1 Xpress Recovery Introduction ... 51 4-1-2 Flash BIOS Method Introduction ...
-
Page 6: Item Checklist
Item Checklist IDE Cable x 1 & FDD Cable x 1 2 Ports SATA Power Cable x 1 2 Ports USB2.0 Cable x 1 SATA Cable x 2 I/O Shield * The items listed above are for reference only, and are subject to change without notice. Optional Accessories 2 Ports USB2.0 Cable (Part Number: 12CR1-1UB030-51/R) 8-Channel Audio Combo Kit (Part Number: 12CR1-1SPAUD-21/21R) -
Page 7: Ga-K8Vt800-Rh Motherboard Layout
GA-K8VT800-RH Motherboard Layout KB_MS ATX_12V AUDIO F_AUDIO 8100C CODEC CD_IN BIOS SPDIF_IO SUR_CEN CPU_FAN Socket 754 VIA K8T800 PCI1 PCI2 PCI3 PCI4 PCI5 F_USB1 - 7 - BATTERY IDE1 IDE2 SATA1 SATA0 VIA VT8237R SYS_FAN / VT8237R+ CLR_CMOS PWR_LED F_USB2 F_PANEL... -
Page 8: Block Diagram
Block Diagram AGP slot CPUCLK+/- (200MHz) 4X/8X Athlon AGPCLK processor (K8) (66MHz) System Bus DDR400/333/266/200 DIMM 800MHz DDR RAM K8T800 AGPCLK66MHz 5 PCI RJ45 33 MHz 14.318 MHz 48 MHz RTL8100C PS/2 KB/Mouse VT8237R / VT8237R+ Floppy IT8705F LPT Port BIOS 2 SATA 24 MHz... -
Page 9: Chapter 1 Hardware Installation
2. Damage as a result of violating the conditions recommended in the user manual. 3. Damage due to improper installation. 4. Damage due to use of uncertified components. 5. Damage due to use exceeding the permitted parameters. 6. Product determined to be an unofficial Gigabyte product. - 9 - Hardware Installation... -
Page 10: Feature Summary
Feature Summary Socket 754 for AMD Athlon 1600MT/s system bus Chipset Northbridge: VIA K8T800 Southbridge: VIA VT8237R / VT8237R+ Memory 3 DDR DIMM memory slots (supports up to 3GB) Supports DDR 400/333/266/200 DIMMs Slots 1 AGP slot supports 8X/4X(1.5V) mode 5 PCI slots IDE Connections 2 IDE connection (UDMA 133/100/66/33), allows connection... - Page 11 Onboard SATA RAID Onboard VT8237R / VT8237R+ chipset (SATA0, SATA1) supports data striping (RAID 0) or mirroring (RAID 1) function supports JBOD function supports data transfer rate of up to 150 MB/s supports a maximum of 2 SATA connections BIOS Use of licensed AWARD BIOS Supports Q-Flash Additional Features...
-
Page 12: Installation Of The Cpu And Heatsink
Installation of the CPU and Heatsink Before installing the CPU, please comply with the following conditions: Please make sure that the motherboard supports the CPU. Please take note of the one indented corner of the CPU. If you install the CPU in the wrong direction, the CPU will not insert properly. -
Page 13: Installation Of The Heatsink
1-3-2 Installation of the Heatsink Fig.1 Before installing the heat sink, please first add an even layer of heat sink paste on the surface of the CPU. Install all the heat sink components (Please refer to the heat sink manual for detailed installation instructions). Fig.2 Please connect the heat sink power connector to the CPU_FAN connector located on the motherboard so that the heat sink can properly function to... - Page 14 Fig.1 The DIMM socket has a notch, so the DIMM memory module can only fit in one direction. Insert the DIMM memory module vertically into the DIMM socket. Then push it down. Fig.2 Close the plastic clip at both edges of the DIMM sockets to lock the DIMM module.
-
Page 15: Installation Of Expansion Cards
Installation of Expansion Cards You can install your expansion card by following the steps outlined below: Read the related expansion card's instruction document before install the expansion card into the computer. Remove your computer's chassis cover, screws and slot bracket from the computer. Press the expansion card firmly into expansion slot in motherboard. -
Page 16: I/O Back Panel Introduction
I/O Back Panel Introduction PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. COMA, COMB (Serial Port) Connects to serial-based mouse or data processing devices. -
Page 17: Connectors Introduction
Connectors Introduction 1) ATX_12V 2) ATX (Power Connector) 3) CPU_FAN 4) SYS_FAN 5) FDD 6) IDE1 / IDE2 7) SATA0 / SATA1 8) PWR_LED 9) F_PANEL 10) F_AUDIO 11) CD_IN 12) SPDIF_IO 13) SUR_CEN 14) F_USB1 / F_USB2 15) I R 16) CLR_CMOS 17) BATTERY - 17 -... - Page 18 1/2) ATX_12V / ATX (Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.
- Page 19 3/4) CPU_FAN / SYS_FAN (Cooler Fan Power Connector) The cooler fan power connector supplies a +12V power voltage via a 3-pin power connector and possesses a foolproof connection design. Most coolers are designed with color-coded power connector wires. A red power connector wire indicates a positive connection and requires a +12V power voltage.
- Page 20 5) FDD (FDD Connector) The FDD connector is used to connect the FDD cable while the other end of the cable connects to the FDD drive. The types of FDD drives supported are: 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB. Before attaching the FDD cable, please take note of the foolproof groove in the FDD connector.
- Page 21 7) SATA0/ SATA1 (Serial ATA Connector) Serial ATA can provide up to 150MB/s transfer rate. Please refer to the BIOS setting for the Serial ATA and install the proper driver in order to work properly. 8) PWR_LED PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode.
- Page 22 F_PANEL (Front Panel Jumper) Please connect the power LED, PC speaker, reset switch and power switch etc of your chassis front panel to the F_PANEL connector according to the pin assignment below. HD (IDE Hard Disk Active LED) (Blue) SPEAK (Speaker Connector) (Amber) RES (Reset Switch) (Green)
- Page 23 10) F_AUDIO (Front Audio Panel Connector) If you want to use Front Audio connector, you must remove 5-6, 9-10 Jumper. In order to utilize the front audio header, your chassis must have front audio connector. Also please make sure the pin assigment on the cable is the same as the pin assigment on the MB header. To find out if the chassis you are buying support front audio connector, please contact your dealer.
- Page 24 12) SPDIF_IO (SPDIF In / Out Connector) The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder. Use this feature only when your stereo system has digital input and output function.
- Page 25 14) F_ USB1 / F_USB2 (Front USB Connector) Be careful with the polarity of the front USB connector. Check the pin assignment carefully while you connect the front USB cable, incorrect connection between the cable and connector will make the device unable to work or even damage it.
- Page 26 16) CLR_CMOS (Clear CMOS) You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily short 1-2 pin. Default doesn't include the "Shunter" to prevent from improper use this jumper. 17) BATTERY GA-K8VT800-RH Motherboard Open: Normal Short: Clear CMOS Danger of explosion if battery is incorrectly replaced.
- Page 27 - 27 - Hardware Installation...
- Page 28 GA-K8VT800-RH Motherboard - 28 -...
-
Page 29: Chapter 2 Bios Setup
BIOS needs to be reset to its original settings. If you wish to upgrade to a new BIOS, either GIGABYTE's Q-Flash or @BIOS utility can be used. Q-Flash allows the user to quickly and easily update or backup BIOS without entering the operating system. -
Page 30: The Main Menu (For Example: Bios Ver. : E8)
The BIOS Setup menus described in this chapter are for reference only and may differ from the exact settings for your motherboard. The Main Menu (For example: BIOS Ver. : E8) Once you enter Award BIOS CMOS Setup Utility, the Main Menu (as figure below) will appear on the screen. - Page 31 Load Optimized Defaults Optimized Defaults indicates the value of the system parameters which the system would be in best performance configuration. Set Supervisor Password Change, set, or disable password. It allows you to limit access to the system and Setup, or just to Setup.
-
Page 32: Standard Cmos Features
Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Date (mm:dd:yy) Time (hh:mm:ss) IDE Channel 0 Master IDE Channel 0 Slave IDE Channel 1 Master IDE Channel 1 Slave IDE Channel 2 Master IDE Channel 3 Master Drive A Drive B Floppy 3 Mode Support Halt On... - Page 33 Capacity Capacity of currently installed hard disk. Hard drive information should be labeled on the outside drive casing. Enter the appropriate option based on this information. Cylinder Number of cylinders Head Number of heads Precomp Write precomp Landing Zone Landing zone Sector Number of sectors If a hard disk has not been installed, select NONE and press <Enter>.
-
Page 34: Advanced Bios Features
Advanced BIOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Hard Disk Boot Priority First Boot Device Second Boot Device Third Boot Device Password Check : Move Enter: Select F5: Previous Values Hard Disk Boot Priority Select boot sequence for onboard(or add-on cards) SCSI, RAID, etc. Use <... -
Page 35: Integrated Peripherals
Integrated Peripherals CMOS Setup Utility-Copyright (C) 1984-2004 Award Software IDE DMA transfer access OnChip IDE Channel 0 OnChip IDE Channel 1 OnChip Serial ATA SATA Mode AC97 Audio USB 1.1 Controller USB 2.0 Controller USB Keyboard Support USB Mouse Support Onboard H/W LAN OnBoard LAN Boot ROM Onboard FDC Controller... - Page 36 USB 2.0 Controller Disabled Disable USB 2.0 controller. Enabled Enable USB 2.0 controller. (Default value) USB Keyboard Support Enabled Enable USB keyboard support. Disabled Disable USB keyboard support. (Default value) USB Mouse Support Enabled Enable USB mouse support. Disabled Disable USB mouse support. (Default value) Onboard H/W LAN Enabled Enable onboard LAN chip function.
- Page 37 UR2 Duplex Mode This feature allows you to select IR mode. This function is available only when UART Mode Select is not set to Normal. Half IR Function Duplex Half. (Default value) Full IR Function Duplex Full. Onboard Parallel Port Disabled Disable onboard LPT port.
-
Page 38: Power Management Setup
Power Management Setup CMOS Setup Utility-Copyright (C) 1984-2004 Award Software ACPI Suspend Type x USB Device Wake-Up From S3 Soft-Off by PWRBTN AC BACK Function Keyboard Power On Mouse Power On PME Event Wake Up Modem Ring Resume Resume by Alarm x Date (of Month) Alarm x Time (hh:mm:ss) Alarm : Move... - Page 39 PME Event Wake Up This feature requires an ATX power supply that provides at least 1A on the 5VSB lead. Disabled Disable this function. Enabled Enable PME as wake up event. (Default value) Modem Ring Resume An incoming call via modem can awake the system from any suspend state. Disabled Disable Modem Ring Resume function.
-
Page 40: Pnp/Pci Configurations
PnP/PCI Configurations CMOS Setup Utility-Copyright (C) 1984-2004 Award Software PCI 1/5 IRQ Assignment PCI 2 IRQ Assignment PCI 3 IRQ Assignment PCI 4 IRQ Assignment : Move Enter: Select F5: Previous Values PCI 1/5 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 2 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 3 IRQ Assignment... -
Page 41: Pc Health Status
PC Health Status CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Vcore DDR25V +3.3V +12V Current CPU Temperature Current CPU FAN Speed Current SYSTEM FAN Speed CPU FAN Fail Warning SYSTEM FAN Fail Warning : Move Enter: Select F5: Previous Values Current Voltage(V) Vcore / DDR25V / +3.3V / +12V Detect system's voltage status automatically. -
Page 42: Frequency/Voltage Control
Frequency/Voltage Control CMOS Setup Utility-Copyright (C) 1984-2004 Award Software K8 CPU Clock Ratio Auto Detect DIMM/PCI Clk Spread Spectrum CPU Clock CPU OverVoltage Control AGP OverVoltage Control DIMM OverVoltage Control : Move Enter: Select F5: Previous Values Incorrect using these features may cause your system broken. For power end-user use only. K8 CPU Clock Ratio Default Set CPU clock ratio to default. -
Page 43: Top Performance
DIMM OverVoltage control Auto Supply DIMM voltage as DIMM required. (Default value) +0.1V Increase DIMM voltage +0.1V. +0.2V Increase DIMM voltage +0.2V. Please note that by overclocking your system through the increase of the DDR voltage, damage to the memory may occur. Top Performance CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features... -
Page 44: Load Optimized Defaults
2-10 Load Optimized Defaults CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status Frequency/Voltage Control Esc: Quit F8: Q-Flash Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automati- cally detects. -
Page 45: Save & Exit Setup
2-12 Save & Exit Setup CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status Frequency/Voltage Control Esc: Quit F8: Q-Flash Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS. Type "N"... - Page 46 GA-K8VT800-RH Motherboard - 46 -...
-
Page 47: Chapter 3 Drivers Installation
Chapter 3 Drivers Installation Pictures below are shown in Windows XP. Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the Setup.exe. -
Page 48: Software Application
Software Application This page displays all the tools that Gigabyte developed and some free software, you can choose anyone you want and press "install" to install them. Software Information This page lists the contents of software and drivers in this CD-title. -
Page 49: Hardware Information
Hardware Information This page lists all device you have for this motherboard. Contact Us Please see the last page for details. - 49 - Drivers Installation... - Page 50 GA-K8VT800-RH Motherboard - 50 -...
-
Page 51: Chapter 4 Appendix
Once you have completed this step, subsequent access to Xpress Recovery can also function by pressing the F9 key during computer power on. Verifying DMI Pool Data Boot from CD: Xpress Recovery V1.0 (C) Copy Right 2003. GIGABYTE Technology CO. , Ltd. 1. Execute Backup Utility 2. Execute Restore Utility 3. Remove Backup Image 4. - Page 52 Press DEL to enter SETUP / Q-Flash, F9 For Xpress Recovery 08/16/2002-I845GE-6A69YG01C-00 Xpress Recovery V1.0 (C) Copy Right 2003. GIGABYTE Technology CO. , Ltd. If you have already entered Xpress Recovery by booting from the CD-ROM, you can enter Xpress Recovery in the future by pressing the F9 key.
- Page 53 1. Execute Backup Utility: Press B to Backup your System or Esc to Exit The backup utility will automatically scan your system and back up data as a backup image in your hard drive. Not all systems support access to Xpress Recovery by pressing the F9 key during computer power on.
-
Page 54: Flash Bios Method Introduction
Updating BIOS with Q-Flash Utility on Dual BIOS Motherboards. Some of Gigabyte motherboards are equipped with dual BIOS. In the BIOS menu of the motherboards supporting Q-Flash and Dual BIOS, the Q-Flash utility and Dual BIOS utility are combined in the same screen. - Page 55 Entering the Q-Flash utility: Step1: To use Q-Flash utility, you must press Del in the boot screen to enter BIOS menu. CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status MB Intelligent Tweaker(M.I.T.) ESC: Quit...
- Page 56 Using the Q-Flash utility: This section tells you how to update BIOS using the Q-Flash utility. As described in the "Before you begin" section above, you must prepare a floppy disk having the BIOS file for your motherboard and insert it to your computer.
- Page 57 3. Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be displayed. Please do not take out the floppy disk when it begins flashing BIOS. 4.
- Page 58 6. Press Del to enter BIOS menu after system reboots. When you are in BIOS menu, move to Load Optimized Defaults item and press Enter to load BIOS Optimized Defaults. Normally the system redetects all devices after BIOS has been upgraded. Therefore, we highly recommend reloading the BIOS defaults after BIOS has been upgraded.
- Page 59 Exploring the Q-Flash utility screen The Q-FlashBIOS utility screen consists of the following key components. Flash Type/Size...SST 49LF003A Task menu for Q-Flash utility Enter : Run Task menu for Q-Flash utility: Contains the names of three tasks. Blocking a task and pressing Enter key on your keyboard to enable execution of the task.
- Page 60 Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be shown at the same time. Flash Type/Size...SST 49LF003A >>>>>>>>>>>>>>>>>>>... Enter : Run Don't Turn Off Power or Reset System Press any keys to return to the Q-Flash menu when the BIOS updating procedure is completed.
- Page 61 Please search for BIOS unzip file, downloading from internet or any other methods (such as: K8VT800.F1). Complete update process following the instruction. Utility Fig 2. Installation complete and run @BIOS Click Start/ Programs/ GIGABYTE/@BIOS Fig 4. Select the desired @BIOS server - 61 - Appendix...
- Page 62 III. In method I, if the BIOS file you need cannot be found in @BIOS website for downloading and updating it according to method II. IV. Please note that any interruption during updating will cause system unbooted. GA-K8VT800-RH Motherboard server, please go onto Gigabyte's - 62 -...
-
Page 63: Serial Ata Bios Setting Utility Introduction
4-1-3 Serial ATA BIOS Setting Utility Introduction RAID Levels RAID (Redundant Array of Independent Disks) is a method of combining two hard disk drives into one logical unit. The advantage of an Array is to provide better performance or data fault tolerance. Fault tolerance is achieved through data redundant operation, where if one drives fails, a mirrored copy of the data can be found on another drive. - Page 64 6) Complete RAID utility installation. More information on steps below is provided. (For more detailed setup information, please visit "Support\ Motherboard\ Technology Guide section" on our website at http:\\www.gigabyte.com.tw to read or download the information you need.) Configuring the VIA VT8237R / VT8237R+ RAID BIOS The VIA VT8237R / VT8237R+ SATA RAID BIOS setup lets you choose the RAID array type and which hard drives you want to make part of the array.
- Page 65 A. Create RAID Array (Create Array): In the main screen, select Create Array and press <Enter> to access the RAID configuration screen where you can select RAID type (refer to Figure 3). VIA Tech. VT8237 SATA RAID BIOS Ver 2.31 Auto Setup For Performance Array Mode RAID 0 (Striping) Select Disk Drives...
- Page 66 After returning to the RAID configuration screen, you have to select whether you want the RAID array to be configured automatically or manually. Auto Setup allows BIOS to select the disk drives, block size and create arrays automatically. Auto Setup: Select Auto Setup For Performance and press <Enter>.
- Page 67 B.Delete a RAID array (Delete Array)¡G To delete a RAID array, select Delete Array and press <Enter>. After confirming the RAID array to be deleted, press <Enter> and the The selected array will be destoried. Are you sure? Continue? Press Y/N message will appear.
-
Page 68: Installing The Raid Drivers
Installing the RAID drivers To install Windows 2000/XP onto a Serial ATA hard disk sucessfully, you need to install required driver for the SATA controller on your motherboard during OS installation. Without the driver, the hard disk may not be recognized during the Windows setup process. -
Page 69: 4- / 6- / 8- Channel Audio Function Introduction
4-1-4 2- / 4- / 6- / 8- Channel Audio Function Introduction The installation of audio software for Windows 98/ 2000/ ME/ XP is very simple. Follow the steps to install the function. (Following pictures are in Windows XP). Please note that if you want to set up an 8 channel audio configuration, you must use Audio Combo Kit (optional device). - Page 70 4 Channel Audio Setup STEP 1: Connect the Front Speakers to "Line Out", the Rear Speakers to "Line In". STEP 2: Following installation of the audio driver, you find a Sound Effect icon on the lower right hand taskbar. Click the icon to select the function. STEP 3: Click "Speaker Configuration"...
- Page 71 6 Channel Audio Setup STEP 1: Connect the Front Speakers to "Line Out", the Rear Speakers to "Line In", and the Center/Subwoofer Speakers to "MIC In". STEP 2: Following installation of the audio driver, you find a Sound Effect icon on the lower right hand taskbar. Click the icon to select the function.
- Page 72 8 Channel Audio Setup (requires Audio Combo Kit, optional device) : Audio Combo Kit includes a Surround-Kit and a SPDIF output cable (an optical and coaxial cable). If you want to set up an 8 channel configuration, you need to use the Surround-Kit. The Surround- Kit offers R/L surround, center/subwoofer output and rear surround.
- Page 73 Method 2: Connect the front channels to the "Line Out" port located on the audio panel and the rear channels to the "Line In" port. Connect the center/subwoofer channels to the "MIC In" port located on the audio panel and the R/L channels to the Surround-Kit "SUR BACK"...
- Page 74 SPDIF Output Device (Optional Device) A "SPDIF_IO" connector is available on the motherboard. The SPDIF cable with rear bracket could link to the "SPDIF_IO" connector (as picture). For the further linkage to decoder, the rear bracket provides coaxial cable and Fiber connecting port (Note1) 1.
- Page 75 Jack-Sensing and UAJ Introduction Jack-Sensing provides audio connectors error-detection function. Install Microsoft DirectX8.1 or later version before to enable Jack-Sensing support for Windows 98/ 98SE/ 2000/ ME. Jack-Sensing includes 2 parts: AUTO and MANUAL. Following is an example for 2 channels (Following pictures are in Windows XP): Introduction of audio connectors You may connect CDROM, Walkman or others audio...
- Page 76 If you set wrong with the connectors, the warning message will come out as right picture. Manual setting: If the device picture shows different from what you set, please press "Manual Selection" to set. UAJ Introduction UAJ (Universal Audio Jack) has a very smart feature: It will switch signal automatically when user plugs his audio device to the wrong jack (Line-in/ Line-out).
-
Page 77: Troubleshooting
Below is a collection of general asked questions. To check general asked questions based on a specific motherboard model, please log on to GIGABYTE's website. Question 1: I cannot see some options that were included in previous BIOS after updating BIOS. Why? Answer: Some advanced options are hidden in new BIOS version. - Page 78 GA-K8VT800-RH Motherboard - 78 -...
- Page 79 GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan TEL: +886-2-8912-4888 FAX: +886-2-8912-4003 Tech. and Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw WEB address (English): http://www.gigabyte.com.tw WEB address (Chinese): http://www.gigabyte.tw U.S.A. G.B.T. INC. TEL: +1-626-854-9338 FAX: +1-626-854-9339 Tech. Support: http://rma.gigabyte-usa.com...
- Page 80 Germany G.B.T. TECHNOLOGY TRADING GMBH WEB address : http://www.gigabyte.de U.K. G.B.T. TECH. CO., LTD. WEB address : http://www.giga-byte.co.uk The Netherlands GIGA-BYTE TECHNOLOGY B.V. WEB address : http://www.giga-byte.nl France GIGABYTE TECHNOLOGY FRANCE WEB address : http://www.gigabyte.fr Italy WEB address : http://www.giga-byte.it...
