Epson EB-S18 Specifications

SPECIFICATIONS
EB-S18/W18/X18/X24
MODEL NUMBER EB-S18 EB-W18 EB-X18 EB-X24
Supplied Accessories
Projection Technology RGB liquid crystal shutter projection system (3LCD)
Power Cable: 1.8m
Specifi cations of Main Parts
Computer Cable (VGA Cable): 1.8m
LCD Size 0.55" without MLA (D7) 0.59" with MLA (D8) 0.55" with MLA (D8) 0.63" with MLA (D7)
USB Cable (Type A/B): 1.8m
Remote Control: Yes, with Alkaline AA Battery x 2
Native Resolution SVGA (800 x 600) WXGA (1280 x 800) XGA (1024 x 768)
Soft Carrying Case
Projection Lens Type No Optical Zoom / Optical Zoom (Manual) / Focus (Manual)
Focus (Manual)
F-Number 1.44 1.58 - 1.72 1.6 - 1.74 Optional Accessories
Focal Length 16.7mm 16.9 - 20.28 mm 18.4 - 22.08 mm Spare Lamp: ELPLP78
Air Filter: ELPAF32
Zoom Ratio 1.0 - 1.35 (Digital Zoom) 1 - 1.2
Wireless LAN Adaptor: ELPAP07
Throw Ratio 1.45 - 1.96 (Wide - Tele) 1.30 - 1.56 (Wide - Tele) 1.48 - 1.77 (Wide - Tele) 1.40 - 1.68 (Wide - Tele)
Quick Wireless Connection USB Key: ELPAP09
Lamp Type 200W UHE
Ceiling Mount: ELPMB23
Life (Normal / Eco) *1 5,000 hours / 6,000 hours
Screen Size (Projected Distance)
Zoom: Wide 30" - 350" [0.88 - 10.44 m] 33" - 318" [0.9 - 9.0 m] 30" - 300" [0.9 - 9.0 m] 30" - 300" [1.01 - 10.42 m]
Zoom: Tele 23" - 260" [0.88 - 10.44 m] 33" - 317" [1.08 - 10.8 m] 30" - 300" [1.08 - 10.8 m] 30" - 300" [0.84 - 8.66 m] EB-S18 / W18 / X18 / X24
Standard Size 60" screen 1.77 - 2.4 m 60" screen 1.68 - 2.02 m 60" screen 1.8 - 2.17 m 60" screen 1.71 - 2.16 m
Brightness *2
Colour Light Output 3,000lm 3,500lm
White Light Output (Normal / Eco) 3,000lm / 2,100lm 3,500lm / 2,450lm
Contrast Ratio 10,000:1
Internal Speaker(s)
Sound Output 2W Monaural
Keystone Correction
Vertical / Horizontal ±30° / ±30°
Auto Keystone Correction Yes (Vertical only)
Connectivity
Analog Input D-Sub 15pin 1 (Blue)
Component D-Sub 15pin x 1 (Blue) (common with Analog RGB connector)
Composite RCA x 1 (Yellow)
S-Video Mini DIN x 1
Digital Input HDMI 1 (HDCP supported)
Audio Input RCA (White/Red) 1 Pair
Others USB Type A 1 (USB Memory / ELPDC06 Document Camera / Wireless LAN adaptor)
USB Type B 1 (3-in-1 USB Display, Mouse, K/B, Control)
Network Wireless Optional (ELPAP07)
Wireless Specifi cations
Supported Speed For Each Mode *3 IEEE 802.11b: 11 Mbps, IEEE 802.11g: 54 Mbps, IEEE 802.11n: 130 Mbps
Wireless Lan Security WPA/WPA2-Personal (with optional Wireless LAN Unit)
©2013 Epson Singapore Pte Ltd. All Rights
Reserved. Reproduction in part or in whole,
Operating Temperature 5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)
without the written permission from Epson,
5 - 30 °C <41 - 86 °F> (over 2,286m / 7,500ft)
is strictly prohibited.
(20% - 80% humidity, unfrozen)
EPSON and EXCEED YOUR VISION are
Operating Altitude 0 - 3,000 m <0 - 9,843 ft> (over 1,500m / 4,921ft: with high altitude mode)
registered trademarks of Seiko Epson
Direct Power On / Off Yes Corporation.
All other product names and other company
Start-Up Period About 5 seconds, Warm-up Period: 30 seconds
names used herein are for identifi cation
Cool Down Period Instant Off or 0 second purposes only and are the trademarks or
registered trademarks of their respective owners.
Air Filter Type Normal
Epson disclaims any and all rights in those
Maintenance Cycle 3,000 hours *4
marks. Projected images shown herein are
simulations. The actual product design and
Power Supply Voltage 100 - 240 V AC ±10%, 50/60 Hz
contents may vary. Specifi cations are subject to
Power Consumption (220 - 240V) change without notice and may vary between
countries. Please check with local Epson offi ces
Lamp On (Normal / Eco) 270W / 201W
for more information.
Standby (Network On / Off) 3W / 0.28W
Apple, iPad and iPhone are trademarks of Apple
Dimension Excluding Feet (D X W X H) 234 x 297 x 77 mm Inc., registered in the U.S. and other countries.
App Store is a service mark of Apple Inc.
Weight 2.4kg
Android is a trademark of Google Inc.
Fan Noise (Normal / Eco) 37dB / 29dB
*1 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time. Dealer's Stamp
*2 Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15:4;
white light output measured in accordance with ISO 21118.
*3 Maximum speed and range is achievable when used with same enhanced mode technology. Actual data rates, features and performance may vary depending on your computer
system, the environment and other factors.
*4 When used in the general offi ce environment (the amount of fl oating dust: 0.04 - 0.2 mg/m ). Based on the Epson's in-house test results. 25°C (77°F). 3
Information correct at time of printing
Printed August 2013
xxx xxx
Offi cial Partner
of Manchester United To fi nd out more, visit www.epson.com.sg/projectors or call +65 6586 3111
Epson Singapore Pte Ltd 1 Harbourfront Place, #03-02 HarbourFront Tower One, Singapore 098633. Tel: (65) 6586-5500 Fax: (65) 6271-9755
Epson Customer Care Centre 108 Pasir Panjang Road, #04-08 Golden Agri Plaza, Singapore 118535. Epson Helpdesk: 6586-3111. Operating hours: Monday - Friday, 9am - 6pm, Saturday, 9am - 1pm. Closed on Sunday and Public Holiday.
Epson Oman.indd 1-4 Epson Oman.indd 1-4
EPSON 3LCD TECHNOLOGY – FOR BRIGHT, FAITHFUL COLOURS
3LCD projectors offer brighter and more accurate colours as they This compares to projectors using single-chip technology that
produce different shades and hues by fi ltering, then mixing beams actually project individual colours sequentially by fi ltering their
of the three primary colours (red, green and blue). single white light beam through a colour wheel, and then relying on
human colour perception to combine the colours in the viewers'
In a 3LCD projector, white light is fi rst split into the three beams of minds.
primary colours. Each beam is then fi ltered through its own LCD
that will give each individual pixel of the image its exact brightness As a result, 3LCD projectors also offer greater detail, smoother
for each colour. The colour beams are then perfectly recombined in gradations, no "colour breakup" effect, are easier on viewers'
a prism before being projected out as a complete image. eyes, and consumer about 25% less power to achieve the same
brightness compared to a single-chip projector using a lamp of the
same wattage.
3LCD projector : RGB are projected at the same time, which makes the single composite image easy on the eyes.
• An independent test by projector review media ProjectorCentral.com in 2009 of about 800 projectors found that on average,
3LCD projectors use 25% less power than single-chip projectors. www.3lcd.com
• Uses just 0.28W of power in standby mode
• Projector optics employ lead-free lenses
• Unpainted plastic housing reduces the environment impact For more information on Epson's environmental programmes,
visit http://global.epson.com/SR/environment.
• The fl ame retardants used in the plastic housing do not
contain chlorine or bromine
PARTNERS IN PERFECTION
Wireless LAN Adaptor ELPAP07 Desktop Document Camera ELPDC20 Ultra-portable Document Camera ELPDC06
Supports 802.11 b/g/n 3kg / 6.6lbs Easily portable; 0.96kg / 2.11lbs
connection 2 megapixels with 30fps 1.92 megapixels with 15fps
Compatible with all Epson 12 x optical zoom 4 x digital zoom
wireless-enabled projectors
1080p output resolution USB powered
HDMI digital connectivity
BUSINESS PROJECTORS
EB-S18/W18/X18/X24
EB-S03/W03/X03
DESIGNED FOR AFFORDABILITY
AND ULTIMATE EASE OF USE.
Epson's projector series combines dynamic image quality with exceptional
versatility to deliver stunning and vivid presentations. Boasting a high
colour brightness, this versatile projector series promises vibrant and
realistic colour projections. With advanced features such as optional
Wi-Fi connectivity, Colour Universal Design, a high contrast ratio and a
sliding horizontal keystone adjuster, you'll be able to deliver vivid, sharp EB-S18/W18/X18/X24 EB-S03/W03/X03
presentations anytime, anywhere.
Wi-Fi* iProjection HDMI Horizontal Power
Keystone Savings
Adjuster
Unparalleled Performance Made for Everyone Stunning Colour Brightness
Enjoy unparalleled performance with optional Wi-Fi Designed with a Colour Universal Design for Achieve dazzling, sharp and colourful
connectivity, high contrast ratio, HDMI connection those with various types of colour vision, and images with the high Colour Light Output.
and the horizontal keystone adjuster. equipped with eco-friendly features.
*Optional
SPECIFICATIONS
EB-S03/W03/X03
MODEL NUMBER EB-S03 EB-W03 EB-X03
Supplied Accessories
Projection Technology RGB liquid crystal shutter projection system (3LCD)
Power Cable: 1.8m
Specifi cations of Main Parts
Computer Cable (VGA Cable): 1.8m
LCD Size 0.55" without MLA (D7) 0.59" with MLA (D8) 0.55" without MLA (D8)
USB Cable (Type A/B): 1.8m
Remote Control: Yes, with Alkaline AA Battery x 2
Native Resolution SVGA (800 x 600) WXGA (1280 x 800) XGA (1024 x 768)
Soft Carrying Case
Projection Lens Type No Optical Zoom / Focus (Manual) Optical Zoom (Manual) / Focus (Manual)
F-Number 1.44 1.58 - 1.72
Optional Accessories
Focal Length 16.7mm 16.9 - 20.28 mm
Spare Lamp: ELPLP78
Zoom Ratio 1.0 - 1.35 (Digital Zoom) 1 - 1.2
Air Filter: ELPAF32
Throw Ratio 1.45 - 1.96 (Wide - Tele) 1.30 - 1.56 (Wide - Tele) 1.48 - 1.77 (Wide - Tele)
Wireless LAN Adaptor: ELPAP07
Lamp Type 200W UHE
Quick Wireless Connection USB Key: ELPAP09
Life (Normal / Eco) *1 5,000 hours / 6,000 hours
Ceiling Mount: ELPMB23
Screen Size (Projected Distance)
Zoom: Wide 30" - 350" [0.88 - 10.44 m] 33" - 318" [0.9 - 9.0 m] 30" - 300" [0.9 - 9.0 m]
Zoom: Tele 23" - 260" [0.88 - 10.44 m] 33" - 317" [1.08 - 10.8 m] 30" - 300" [1.08 - 10.8 m]
EB-S03 / W03 / X03
Standard Size 60" screen 1.77 - 2.4 m 60" screen 1.68 - 2.02 m 60" screen 1.8 - 2.17 m
Brightness *2
Colour Light Output 2,700lm
White Light Output (Normal / Eco) 2,700lm / 1,890lm
Contrast Ratio 10,000:1
Internal Speaker(s)
Sound Output 1W Monaural
Keystone Correction
Vertical / Horizontal ±30° / ±30°
Auto Keystone Correction Yes (Vertical only)
Connectivity
Analog Input D-Sub 15pin 1 (Blue)
Component D-Sub 15pin x 1 (Blue) (common with Analog RGB connector)
Composite RCA x 1 (Yellow)
S-Video Mini DIN x 1
Digital Input HDMI 1 (HDCP supported)
Audio Input RCA (White/Red) 1 Pair
Others USB Type A 1 (USB Memory / ELPDC06 Document Camera / Wireless LAN adaptor)
USB Type B 1 (3-in-1 USB Display, Mouse, K/B, Control)
Network Wireless Optional (ELPAP07)
Wireless Specifi cations
Supported Speed For Each Mode *3 IEEE 802.11b: 11 Mbps, IEEE 802.11g: 54 Mbps, IEEE 802.11n: 130 Mbps
Wireless Lan Security WPA/WPA2-Personal (with optional Wireless LAN Unit)
©2013 Epson Singapore Pte Ltd. All Rights
Reserved. Reproduction in part or in whole,
Operating Temperature 5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)
without the written permission from Epson,
5 - 30 °C <41 - 86 °F> (over 2,286m / 7,500ft)
is strictly prohibited.
(20% - 80% humidity, unfrozen)
EPSON and EXCEED YOUR VISION are
Operating Altitude 0 - 3,000 m <0 - 9,843 ft> (over 1,500m / 4,921ft: with high altitude mode) registered trademarks of Seiko Epson
Corporation.
Direct Power On / Off Yes
All other product names and other company
Start-Up Period About 5 seconds, Warm-up Period: 30 seconds names used herein are for identifi cation
purposes only and are the trademarks or
Cool Down Period Instant Off or 0 second
registered trademarks of their respective owners.
Air Filter Type Normal
Epson disclaims any and all rights in those
Maintenance Cycle 3,000 hours *4 marks. Projected images shown herein are
simulations. The actual product design and
Power Supply Voltage 100 - 240 V AC ±10%, 50/60 Hz
contents may vary. Specifi cations are subject to
change without notice and may vary between
Power Consumption (220 - 240V)
countries. Please check with local Epson offi ces
Lamp On (Normal / Eco) 270W / 201W
for more information.
Standby (Network On / Off) 3W / 0.28W
Apple, iPad and iPhone are trademarks of Apple
Inc., registered in the U.S. and other countries.
Dimension Excluding Feet (D X W X H) 234 x 297 x 77 mm
App Store is a service mark of Apple Inc.
Weight 2.4kg
Android is a trademark of Google Inc.
Fan Noise (Normal / Eco) 37dB / 29dB
*1 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time. Dealer's Stamp
*2 Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15:4;
white light output measured in accordance with ISO 21118.
*3 Maximum speed and range is achievable when used with same enhanced mode technology. Actual data rates, features and performance may vary depending on your computer
system, the environment and other factors.
*4 When used in the general offi ce environment (the amount of fl oating dust: 0.04 - 0.2 mg/m 3 ). Based on the Epson's in-house test results. 25°C (77°F).
Information correct at time of printing
Printed August 2013
xxx xxx
Offi cial Partner
To fi nd out more, visit www.epson.com.sg/projectors or call +65 6586 3111
of Manchester United
Epson Singapore Pte Ltd 1 Harbourfront Place, #03-02 HarbourFront Tower One, Singapore 098633. Tel: (65) 6586-5500 Fax: (65) 6271-9755
Epson Customer Care Centre 108 Pasir Panjang Road, #04-08 Golden Agri Plaza, Singapore 118535. Epson Helpdesk: 6586-3111. Operating hours: Monday - Friday, 9am - 6pm, Saturday, 9am - 1pm. Closed on Sunday and Public Holiday.
8/15/13 5:03:15 PM 8/15/13 5:03:15 PM
