Thank you for choosing AOpen AX4B Max / AX4B U2 motherboard. AX4B Max / AX4B U2 is Intel
based on the ATX form factor featuring the
Max / AX4B U2 motherboard can support Intel
the AGP performance, it has one AGP slot which supports 1.5V AGP interface with 4x SBA/Data Transfer and 2x/4x Fast Write
capability and pipelined spilt-transaction long burst transfer up to 1056MB/sec. According to different customer's requirements,
the Intel 845 chipset memory interface supports DDR SDRAM devices with densities of 64, 128, 256, 512Mb and 1Gb DDR
SDRAM DIMM modules and the maximum memory size can be up to 2GB. The onboard IDE controller supports
33/66/100 mode and the transfer rate up to 100MB/s. Further flexibility can be achieved by taking advantage of the
Communication and Network Riser (CNR)
LAN configuration on a single baseboard design. Besides, the AX4B Max /
AX4B U2 has an AC97 CODEC
performance and magic surround stereo sound to let people enjoy
working with it. Now, let's enjoy all features from AOpen AX4B Max /
AX4B U2 motherboard.
