DSL-G624M Wireless 108G MIMO ADSL2/2+ Router User's Guide
PPPoE and PPPoA Connections for WAN
Follow the instructions below to configure the Router to use a PPPoA (For most United Kindgom Users) or PPPoE (For
most mainland European Users) for the Internet connection. Make sure you have all the necessary information before
you configure the WAN connection.
1. Select the PPP option under the Wan Type field and then choose the PPPoE or PPPoA option from the
Connection Type field. PPPoE/PPPoA is selected by default if you are configuring the Router for the first time.
2. The VPI/VCI settings at the top of the menu should not be changed unless you have been instructed to change
them. However, if you are instructed to change the VPI or VCI values, type in the values assigned for your
account.
3. If you selected PPPoA as the connection type, you can choose LLC or VcMux as the encapsulation type by
clicking the click-box beside the Encap. field − as instructed by your ISP.
4. Under the PPP heading, type the User Name and Password used for your ADSL account. A typical User Name
will be in the form user1234@isp.co.uk, the Password may be assigned to you by your ISP or you may have
selected it when you set up the account with your ISP.
5. The default valus of MTU (Maximum Transmission Unit) is 1400 Bytes for compatibility. If your ISP supports a
higher value you can change it for better performance (Maximum useable value of 1500 Bytes). An incorrect
MTU will cause your Internet browser to lose connection.
6. Most users will not need to change Use DNS settings Default Enabled.
7. When you are satisfied that all the WAN settings are configured correctly, click on the Apply button.
25
