American Standard DAZZLE T028.50X Installation Instructions

DAZZLE
BATH AND SHOWER TRIM KITS
Thank you for selecting American-Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--
please read these instructions carefully before
you begin.
Required Tools
Phillips Screwdriver
ROUGHING-IN DIMENSIONS
To assure proper positioning in relation to wall, note
roughing-in dimensions.
FINISHED WALL
5-1/8" REF.
74" FOR HEAD
CLEARANCE
18" OPTIONAL
TOP OF TUB RIM
BOTTOM OF TUB
Installation
Instructions
Flat Blade Screwdriver
Plumbers' Putty or Caulking
1/2" NPT
1-5/8"
to
3-1/4"
7-7/8" REF.
7-1/8"
1-1/2"
REF.
1/2" NPT
5" REF.
T028.50X
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 80''
4"
f f
O
t
o
H
Certified to comply with ANSI A112.18.1
Channel Locks
INLETS
1/2" NOM.
COPPER
INLETS
SWEAT
4-1/16"
SHR. 1/2" NOM.
COPPER SWEAT
SWEAT
INLETS
2"
TUB 1/2" NOM.
COPPER SWEAT
SWEAT
INLETS (STOPS)
5-7/8"
SHR. 1/2" NOM.
COPPER SWEAT
TUB 1/2" NOM.
COPPER SWEAT
INLETS
1/2" NOM.
COPPER
SWEAT
INLETS 1/2" NPT
3-3/8"
3-3/8"
OUTLETS
1/2" NPT
THREADED INLETS
OUTLETS
1/2" NPT
5-7/8"
3-3/8"
THREADED INLETS (STOPS)
M 9 6 8 8 3 4 R E V 1 . 4
Teflon Tape
4-1/16"
4-1/16"
INLETS
1/2" NPT
