- Page 1 F r i g o r i f i c o - C o n g e l a d o r / F r i g o r i f e r o - C o n g e l a t o r e INSTRUCTION BOOK GEBRAUCHSANWEISUNG INSTRUCCIONES DE USO ISTRUZIONI D'USO ERE3900, ERE3900X 818 20 75-06/2...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ERE3900/ERE3900X Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg holder Bottle shelf Freezer plate + accumulator Freezer drawer Ventilation grille Grid Bottle- and can holder Quick chill shelf Control Panel -- 18... -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. -
Page 5: Switching Off
Switching off Switch off the cabinet by pressing the power switch. Keep the button pressed for approx. 1 second. Power to the cabinet is completely interrupted only when the power plug is disconnected. Alarms and other features Door open alarm If the fridge door remains open for more than 5 - 18 minutes, the red warning lamp starts flashing and an... -
Page 6: Using The Freezer
The vegetable drawer has a removable plate to separate different vegetables. Quick chill shelf: The lower Quick chill shelf can be placed in one of the upper grooves. To maintain the best performance the shelf should be placed in the second groove from the top. -
Page 7: Temperature Inside The Freezer
Allow the cabinet to run for a period of 24 hours whenever the temperature setting is changed. This will allow the temperature to stabilise inside the cabinet. It is not necessary to reset the temperature when the cabinet is switched on after it has been out of use. The thermostat recalls the previously set temperature. -
Page 8: Freezing
At about -12°C: Most food products can be immediately re-frozen. Ice cream is especially sensitive to temperature changes and should be consumed as soon as possible. At -9° - -2°C: Food products should be prepared (cooked) prior to eating or re-freezing them. However, always check the quality of the food yourself to determine if it can be frozen or if it must be discarded. -
Page 9: Cabinet Interior
Cabinet interior Freezer drawers The freezer drawers make it possible to quickly and easily find the food package you want. To gain space, the drawers can be removed and the products can be put directly on the shelves. On all shelves, except the top shelf, it is possible to place products that protrude 20 mm from the front edge. -
Page 10: Food Storage
Protect the environment Food Storage · Hand over the cabinet packaging and discarded fridges and freezers to a recycling station. · To obtain the best results from your appliance, Contact your local council or Environmental neither hot foods nor liquids which may Health office for more information. -
Page 11: Defrosting The Fridge
Defrosting the fridge The fridge is defrosted automatically every time the compressor stops. Frost formation can be prevented · not putting warm foodstuff inside the cabinet. · avoiding frequently opening the door or keeping it open too long. Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. -
Page 12: Change Of Carbon Filter
Change of carbon filter To maintain the best performance the carbon filter should be changed once a year with normal usage. New carbon filters can be purchased from your local dealer. The filter is placed behind the grill and can be reached by opening the cover. - Page 13 It is too warm inside the freezer. Set a lower temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. If warm food products have been put inside the freezer, wait for a couple of hours and then check the temperature again.
-
Page 14: Customer Care Department
Service and Spare Parts SER:NO (serial number):........In the event of your appliance requiring service, or if you wish to purchase spare parts please contact Purchase date............Technical specification ERE3900/ERE3900X Model 296 l Volume Refrigerator 79 l Freezer 595 mm... -
Page 15: Remove The Transport Supports
Remove the transport supports Remove the tape and the transport supports from · the door sides · inside the door hinges · the shelves Remove the transport support on the glass shelf by pushing the support forward along the edge of the shelf until it stops. -
Page 16: Installing The Cabinet
Installing the cabinet When two appliances are placed beside each other, the distances enclosed in the plastic wrapping should be glued between the appliances. As shown in the illustration. Make sure that the power plug is not squashed or damaged by back of the product. ·... -
Page 17: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Remove and reposition it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 18 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK aÉ=bäÉÅíêçäìñ=dêçÉé=áë=ÇÉ=ÖêççíëíÉ=éêçÇìÅÉåí=íÉê=ïÉêÉäÇ=î~å=~~åÖÉÇêÉîÉå=~éé~ê~íÉå=îççê=ÖÉÄêìáâ=áå=ÇÉ=âÉìâÉåI êÉáåáÖáåÖëïÉêâò~~ãÜÉÇÉå=Éå=îççê=ÖÉÄêìáâ=ÄìáíÉåëÜìáëK=få=ãÉÉê=Ç~å=NRM=ä~åÇÉå=çîÉê=ÇÉ=ÜÉäÉ=ïÉêÉäÇ=ïçêÇÉå=áÉÇÉê=à~~ê ãÉÉê=Ç~å=RR=ãáäàçÉå=bäÉÅíêçäìñ=éêçÇìÅíÉå=Eòç~äë=âçÉäâ~ëíÉåI=ÑçêåìáòÉåI=ï~ë~ìíçã~íÉåI=ëíçÑòìáÖÉêëI=âÉííáåÖò~ÖÉå=Éå Öê~ëã~~áÉêëF=îÉêâçÅÜí=íÉê=ï~~êÇÉ=î~å=ÅáêÅ~=rpa=NQ=ãáäà~êÇK bä=dêìéç=bäÉÅíêçäìñ=Éë=Éä=ã~óçê=Ñ~ÄêáÅ~åíÉ=ÇÉä=ãìåÇç=ÇÉ=~é~ê~íçë=é~ê~=ä~=ÅçÅáå~I=äáãéáÉò~=ó=ìëç=ÉñíÉêáçêK=j•ë=ÇÉ=RR ãáääçåÉë=ÇÉ=éêçÇìÅíçë=ÇÉä=dêìéç=bäÉÅíêçäìñ=EÑêáÖçêáÑáÅçëI=ÅçåÖÉä~ÇçêÉëI=ÅçÅáå~ëI=ä~î~Ççê~ëI=~ëéáê~ÇçêÉëI=ãçíçëáÉêê~ë=ó Åçêí~ŨëéÉÇÉëF=ëÉ=îÉåÇÉå=Å~Ç~=~¥ç=éçê=ìå=î~äçê=~éêçñáã~Çç=ÇÉ=NQ=ÄáääçåÉë=ÇÉ=rpA=Éå=ã•ë=ÇÉ=NRM=é~áëÉë=ÇÉä=ãìåÇçK fä=dêìééç=bäÉÅíêçäìñ==ÉD=áä=éáìD=Öê~åÇÉ=éêçÇìííçêÉ=ãçåÇá~äÉ=Çá=~éé~êÉÅÅÜá~íìêÉ=éÉê=ä~=ÅìÅáå~I=éÉê=ä~=éìäáòá~=É=Çá ~ííêÉòò~íìêÉ==éÉê=áä=Öá~êÇáå~ÖÖáç=É=éÉê=ìëç=ÑçêÉëí~äÉK=läíêÉ=RR=ãáäáçåá=Çá=éêçÇçííá=ÇÉä=dêìééç=bäÉÅíêçäìñ==E=èì~äá=ÑêáÖçêáÑÉêáI ÅìÅáåÉI=ä~î~Äá~åÅÜÉêá~I=ä~î~ëíçîáÖäáÉI=~ëéáê~éçäîÉêÉI=ãçíçëÉÖÜÉ=É=ê~ë~ÉêÄ~=F=îÉåÖçåç=îÉåÇìíÉ=çÖåá=~ååç=áå=éáìD=Çá=NRM m~Éëá=ÇÉä=ãçåÇç=éÉê=ìå=î~äçêÉ=Çá=ÅáêÅ~=NQ=ãáäá~êÇá=Çá=Ççää~êáK MARIESTAD DT--AV...
