Cut rail
Cut the rail out of finished material:
for filler
• The width should match cabinet opening width.
panel
• The height of the top rail should be enough to
• The height of the bottom rail should be enough to
• The height of both the top and bottom rails should
Cut appearance
Use drawer fronts for appearance panels or cut
panel
finished material and finish raw edges.
• The appearance panel width should match drawer
• Make the appearance panel appropriate height to
Determine
location
of cleats
• To find the exact position of the cleats, place the
securely attach the rail to the appearance panel,
plus 1/4" oven trim overlap.
securely attach the rail to the appearance panel,
plus 7/8" oven trim overlap.
be adjusted depending upon the height of the gap
to be filled or to enhance appearance.
fronts or doors.
fill the gap above or below the oven, allowing for
reveals and overlaps to match existing drawers or
doors.
appearance panel onto the cabinet in desired
position and align to match the other drawers and
doors.
Cabinetry Modification Suggestions
30" Built-In Convection Oven s
• Use a pencil to mark the back side of the panel
where it meets the cabinet corners.
14
