GE GNSV70FBL Owner's Manual And Installation Instructions
  1. Manuals
  2. Brands
  3. GE Manuals
  4. Water Filtration Systems
  5. SmartWater GNSV70FBL
  6. Owner's manual and installation instructions

GE GNSV70FBL Owner's Manual And Installation Instructions

Ge water filtration system specification sheet
Hide thumbs Also See for GNSV70FBL:

Advertisement

Table of Contents

Safety Instructions
. . . . . . . . . . . . .2
System Overview
. . . . . . . . . . . .3-5
Battery Installation . . . . . . . . . . . .13
Faucet Installation . . . . . . . . . . . . . .9
Feed Water Supply . . . . . . . . . . . .6-8
Filter Replacement . . . . . . . . . . . .14
Flush Procedure . . . . . . . . . . . . . .15
System Installation . . . . . . . . . .10, 11
System Startup . . . . . . . . . . . . . . . .14
Tubing Connection . . . . . . . . . . . .12
Consumer Support
Consumer Support . . . . .Back Cover
Parts List/Catalog . . . . . . . . . . . . .17
Warranty . . . . . . . . . . . . . . . . . . . .18
GNSV70FBL and GNSV75FWW are Tested and Certified by
NSF International against NSF/ANSI Standard 42 for the
reduction of Chlorine: Taste and Odor and Particulate Class I
and Standard 53 for the reduction of Lead, Cyst, Turbidity,
Asbestos, Mercury, Lindane, Atrazine, Benzene and VOC.
ge.com
. . . . .5-15
. . . . . . . . .16
Owner's Manual and
Installation Instructions
GNSV70FBL
GNSV75FWW
184D1069P002
49-50197
01-06 JR

Advertisement

Table of Contents
loading

Related Manuals for GE GNSV70FBL

Summary of Contents for GE GNSV70FBL

  • Page 1: Table Of Contents

    Parts List/Catalog ... . .17 Warranty ....18 GNSV70FBL and GNSV75FWW are Tested and Certified by NSF International against NSF/ANSI Standard 42 for the...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING: For your safety, the information in this manual must be followed to minimize the risk of property damage or personal injury. SAFETY PRECAUTIONS I Use the Water Filtration system on a potable, safe-to-drink, home COLD water supply only. The filter canisters will not purify the water, or make it safe to drink.
  • Page 3 Specifications Guidelines. The Water Filtration System Uses the Following Canisters Models GNSV70FBL and GNSV75FWW FQSVF Filter (160 gallon capacity) Filter—White canisters with green band • Reduces dirt, rust and sediment • Reduces Chlorine: Taste and Odor • Reduces Lead • Reduces filterable Cysts (such as cryptosporidium and giardia) •...

  • Page 4: Performance Data Sheet

    Performance Data Sheet. SmartWater Filtration System GNSV70FBL and GNSV75FWW Using Filter FQSVF I This System has been tested according to NSF/ANSI 42 and 53 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42 and 53.
  • Page 5 Performance Data Sheet. Contaminant Alachlor Atrazine Benzene Carbofuran Carbon Tetrachloride Chlorobenzene Chloropicrin 2,4-D Dibromochloropropane (DBCP) o-Dichlorobenzene p-Dichlorobenzene 1,2-Dichloroethane 1,1-Dichloroethylene cis-1,2-Dichloroethylene trans-1,2-Dichloroethylene 1,2-Dichloropropane cis-1,3-Dichloropropylene Dinoseb Endrin Ethylbenzene Ethylene Dibromide (EDB) Haloacetonitriles (HAN): Bromochloroacetonitrile Dibromoacetonitrile Dichloroacetonitrile Trichloroacetonitrile Influent challenge levels are average influent concentrations determined in surrogate qualification testing. µg/L means Micrograms Per Liter.

  • Page 6: Installation Instructions

    Installation Instructions. Feed Water Adapter and Supply Valve A. PREFERRED INSTALLATION (Utilizing existing kitchen sink water supply valve [A] and removable faucet tubing [B]) For 1/2-inch and 3/8-inch installations 1. Refer to Fig. 1 to complete assembly depending on supply valve size (A). 2.
  • Page 7 Installation Instructions. Feed Water Adapter and Supply Valve 4. Assemble adapter (C) and coupling (D) as shown in Fig. 1, per your configuration. Be sure the gaskets (G) are in place before final assembly. Start installation by hand, then finish tightening with adjustable wrench. damage to threads may occur.
  • Page 8 Installation Instructions. Feed Water Adapter and Supply Valve D. REMOVAL AND RE-INSTALLATION OF INLET VALVE (This is only required if inlet valve needs to be removed to complete Step 5 on page 7.) 1. Remove inlet valve (F) from adapter (C) using adjustable wrench on valve body. See Fig. 3a for details. DO NOT USE WRENCH ON HEX NUT END OF VALVE AS LEAK MAY OCCUR.

  • Page 9: Faucet Installation

    Installation Instructions. Faucet Installation Be sure there is room underneath and above the sink to make the needed connections. Before starting, make sure there is sufficient room for the battery powered faucet base. Select one of the following places to install the faucet: 1.
  • Page 10 Installation Instructions. Mounting System Installation Pick a location under the sink to mount the system. Location should be easily accessible, with clearance between the bottom of the filter canisters and the floor or bottom of the cabinet; any less will result in difficulty of removing filter canisters (see Fig. 7). Allow enough space on either side of the system for the tubing connections.
  • Page 11 Installation Instructions. Mounting System Installation Mounting System to Screws Installed in Wall 1. Remove shrink wrap from filter system. 2. Hang the system on the previously installed screws using the openings on the back of the unit (Fig. 9). 3. If the head of the screw will not slide into the upper slot, back out the screw by 1/4 turn and try again. 4.
  • Page 12 Installation Instructions. Installing the Tubing 1. Measure 3/4″ from the end of each remaining piece of tubing (faucet end and inlet end) and mark with a pencil (Fig. 10). (Check for roundness, smoothness, cuts, nicks, flat spots and sharp edges.) 2.
  • Page 13 Installation Instructions. Battery Installation 1. Use a small flat blade screwdriver or coin to remove the battery tray (A) at the side of the faucet base. 2. Install one CR2032, 3 volt battery (B) + side down into the battery tray (A) (Fig. 12). 3.

  • Page 14: System Startup

    Installation Instructions. System Startup Procedure 1. Slowly turn on cold water supply valve (A) in Fig. 1. 2. Turn on 1/4″ inlet valve to supply water to the system. (Valve is on when handle is pointing in same direction as water line coming out of valve).
  • Page 15 Installation Instructions. Flush Procedure Whenever water of unknown quality is passed through the GE Water Filtration system, the filter canisters should be discarded and the filtration system flushed. WARNING: These systems should only be used on microbiologically safe water. Circumstances that may require flushing the system are: •...

  • Page 16: Troubleshooting Tips

    Before you call for service… Troubleshooting Tips Save time and money! Review the chart below first and you may not need to call for service. Problem Possible Causes Water contains tiny New filter canisters contain black particles activated carbon, which is a harmless black powder.
  • Page 17 Parts List. General Electric parts catalog. ITEM GE CAT. NO. WS19X10016 WS19X10015 WS22X10045 FQSVF WS03X10046 WS15X10038 WS15X10039 WS10X10028 WS10X10029 WS02X10031 WS18X10009 WS07X10020 49-50197 GNSV70FBL, GNSV75FWW To obtain replacement parts, call toll-free 800.626.2002 (U.S.), 800.663.6060 (Canada-English), 800.361.3869 (Canada-French) DESCRIPTION MANIFOLD ASSEMBLY COVER, DUAL MANIFOLD ELBOW &...
  • Page 18 This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service location for service.
  • Page 19 Notes.

  • Page 20: Consumer Support

    Caution must be exercised, since improper servicing may cause unsafe operation. Contact Us If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: Register Your Appliance Register your new appliance on-line—at your convenience! Timely product registration will allow for enhanced communication and...
