Behringer EUROCOM AX6220 Specifications page 2

AX6240/AX6220
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
2900/2000-Watt Low-Impedance amplifier
Product Overview
The Eurocom AX6240 and AX6220 are professional
high-performance 2-channel power amplifiers featuring
digital signal processing and Ethernet/USB control.
The AX6240 delivers up to 1500 watts RMS per channel
into loads down to 2 Ω, and up to 2900 watts RMS in
bridged mono mode (4Ω). The AX6220 delivers up to
1000 watts RMS per channel into loads down to 2 Ω,
and up to 2000 watts RMS in bridged mono mode (4 Ω).
Both models utilize transformerless Class-H topology
and state-of-the-art switch-mode power technology to
provide low noise and superior transient response while
reducing amplifier energy costs. Dual variable-speed fans
create back-to-front ventilation to keep racks running
cool, and ˝zero-attack˝ limiters combine with independent
DC and thermal overload protections to safeguard the
amplifiers and connected speaker systems.
Featuring 24-bit/96 kHz converters to ensure flawless
signal integrity, the AX6240/AX6220 processing section
maintains an extremely broad dynamic range while
offering sophisticated DSP options including delay,
crossover, dynamics, and both parametric (8-band) and
dynamic (2-band) EQ. Parameters may be set and stored
using intuitive front-panel controls and the amber backlit
LCD, which also displays meters and indicates muting,
system fault, over-current, and overdrive. The front
panel also has an illuminated master volume knob with
a clipping indicator. For remote control and monitoring,
BEHRINGER offers the powerful Amp Remote software
application which may be run on PCs connected either
locally via the front panel USB connector or remotely
via rear-panel Ethernet. Changes to settings may be
prevented with secure lockout.
Input channels accept balanced or unbalanced
microphone or line-level signals via XLR/TRS combination
jacks or 3-pin Euroblock connectors. Outputs may
be connected to speakers via professional twist-lock
connectors, banana plugs, or bare wire (binding post).
A 2-pin Euroblock socket is provided for sequential power
control and remote power on/off. All mating Euroblock
connectors are included, as are integrated rack ears and
screw covers. Designed for high-power applications
in the most demanding installations, the Eurocom
AX6240 and AX6220 offer maximum performance and
unsurpassed value.
