INSTRUCTION MANUAL
COLOR
TELEVISION
DTY
-29Z9
DTY
-29Z9

Advertisement

Table of Contents
loading

Related Manuals for Daewoo DTY-29Z9

Summary of Contents for Daewoo DTY-29Z9

  • Page 1 INSTRUCTION MANUAL COLOR TELEVISION -29Z9 -29Z9...

  • Page 2: Table Of Contents

    Table of contents Important safeguards Watching Double Window INTRODUCTION To display double window Features Various double window operation Installation Watching Picture-in-picture To connect the aerial To display a sub-picture To prepare the remote control Various Picture-in-Picture operations Identification of controls Watching POP(Picture-out-picture) Remote control To display a POP(Picture-out-Picture) and various...

  • Page 3: Important Safeguards

    Important Safeguards For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions, and instructions on the appliance, or the one described in the operating instructions and adhere to them.
  • Page 4 - Never place the set in a confined space such as Power-Cord Protection - Route the power cord - Do not place the set near, over a radiator a bookcase, or built-in cabinet, unless proper so that it is not likely to be walked on or pinched or heat register, or where it is exposed to ven-tilation is provided.

  • Page 5: Introduction

    INTRODUCTION Features Double Window You can enjoy two programs simultaneously by splitting the screen in two. 16:9 screen You can select a desired 16:9 screen mode for movies as well as the normal 4:3 picture mode. A variety of AV terminals for external equipment connection. Two sets of video/audio inputs on the rear and one set on the side.

  • Page 6: To Connect The Aerial

    Installation To connect the aerial Optimum reception of color requires a good signal and will generally mean that an outdoor aerial must be used. The exact type and positioning of the aerial will depend upon your particular area. Notes When using an outdoor aerial, disconnect the leads of the indoor aerial, if connected, from the aerial terminal socket.

  • Page 7: Identification Of Controls

    Identification of controls * The following describes the name of each part of the TV and remote control. FRONT Main power switch POWER POWER indicator ON TIMER indicator Infrared sensor...
  • Page 8 SIDE VIDEO 3 input terminals (S-VIDEO, VIDEO, AUDIO L, R) Use this Jack when listening to the sound outputted to the speaker with the headphone, and you can listen to the sound of the right side screen(sub-screen) when the double window on the picture-in-picture mode is selected.

  • Page 9: Remote Control

    Remote Control TEXT use identified by ( POWER ON/OFF SURROUND ON/OFF (HOLD) ENTER (STORE) RECALL DIGIT SELECT (BROWSE) (REVEAL) PR UP ( PAGE UP) VOLUME DOWN VOLUME UP PR DOWN (PAGE DOWN) (TV/TEXT) MENU (INDEX) SOUND MUTE SELECTABLE TV/VIDEO PICTURE INPUT SELECT (CONTRAST MENU) (MIX)

  • Page 10: Turning The Power On/Off

    Turning the Power ON/OFF The following describes how to turn the TV on/off using the main switch and the remote control. To turn the power on/off To turn the power on/off 1. Press the main power switch. The power indicator lit up red or amber. It displays the standby mode that the power indicator is lit up red.

  • Page 11: Watching Tv Programmes

    Watching TV Programmes You can watch TV programmes being broadcast on the preset programme number. To watch a TV Programme To select a TV programme 1. Select the desired programme. Using the direct select buttons * To select a one-digit programme number: press the -/-- button to display - , and 0~9 to select a num-...

  • Page 12: Tuning In

    Tuning in First, use the AUTO SEARCH function to preset all active programmes in your area automatically. Then, memory the preset programmes at desired programme numbers with SORT, SEARCH, MFT(Manual Fine Tuning) and SKIP functions. To preset programmes (Auto Search) Warning: This television has been factory pretuned to channels 2, 7, 9, 10 and 28.
  • Page 13 To preset programmes (Auto Search) After presetting You can preset programmes, broadcast system (color/sound) at the 100 programme numbers. (0~99) Check the preset programmes by pressing the PR / buttons. * If the color or sound of a certain programme is abnor- mal, automatic color/sound system selection(AUTO) may malfunction.

  • Page 14: To Preset Programmes(Sort)

    After presetting AUTO SEARCH, Sort the programmes with SORT menu and then you can memory programmes at the desired programme numbers. To preset programmes(SORT) Sorting 1. Press the menu button to select SETUP SETUP and then to be displayed AUTO SEARCH SEARCH on the right appearance.

  • Page 15: To Preset Programmes(Search)

    Use the SEARCH function if desired programmes cannot be preset with AUTO SEARCH or if you would like to preset the desired programmes to specific programme numbers one by one To preset programmes(SEARCH) SEARCH 1. Select the desired programmes number with PR / buttons or - / - -, direct select buttons.
  • Page 16 To preset programmes(SEARCH) SEARCH 5. When the desired programme is SETUP shown, select the MEMORY with AUTO SEARCH SEARCH the PR / buttons. When you PROGRAM MEMORY FINE TUNE press the buttons SORT SELECT ACTIVATE MEMORY on the display turn red EXIT MENU momentarily, and the pro-...

  • Page 17: Mft(Manual Fine Tuning)

    Use this function if desired programmes cannot be preset with the AUTO SEARCH and SEARCH, or if the pic- ture and sound of a certain programme are not good. MFT(Manual Fine Tuning) To operate the manual fine tuning(MFT) 1. Select the programme number you want to fine-tune with the PR / or - / - -, direct select...

  • Page 18: To Skip Unnecessary Programme Numbers

    After presetting the programmes, when you press the PR / buttons, you may skip unnecessary programme numbers so that you can see programmes that you want to watch, which are selected. To skip unnecessary programme numbers To skip a programme number 1.

  • Page 19: To Watch Video

    To watch VIDEO The connection method is referred on page 39. Selecting outside input Selecting TV and outside input 1. Pressing button, TV--> 1--> 2--> --> 4(option) --> TV would be selected by the order. (option) 2. To select the desired TV programme in outside input: * In case of programme of one figure, press the “- /- -”...

  • Page 20: Enjoying Wide Picture

    Enjoying Wide Picture You can enjoy 16:9 picture with TV. In addition to regular TV screen size you can choose from wide screen mode for viewing video in their true cinema proportions. 16:9 Screen To select the 16:9 screen 1. By pressing the 16:9 button in remote control, the following two modes change cyclically.

  • Page 21: Convenient Picture And Sound Controls

    Convenient Picture and Sound Controls You can select and adjust the picture and sound quality as you like Sound muting and on-screen recalling To mute the sound The muting function is convenient when you need to pay attention to surround sounds, answer a phone call, receive a visitor, etc.

  • Page 22: Selectable Picture

    You can select the picture quality instantly among two preset modes and one user-set mode. Selectable picture To select the picture mode 1. Press the button at remote control to select the desired pic- ture quality. MEMORY(user set), MILD, STANDARD can be select- MEMORY ed cyclically.
  • Page 23 Selectable picture Pressing Item contrast weaker stronger brightness darker lighter color paler deeper tint * purplish greenish sharpness softer sharper * for NTSC only ** except the double window mode 3. Select the item with the PR / ADJUSTMENT buttons and press the CONTRAST BRIGHTNESS buttons to adjust level.
  • Page 24 Selectable picture To reduce the picture noise If the signal being received is weak and the picture is blurry, activate the noise reducer to improved the pic- ture. Press the menu button to select PICTURE the PICTURE and then to be dis- AUTO MEMORY ADJUSTMENT NOISE REDUCER...

  • Page 25: Selectable Sound

    You can select the sound quality instantly among three preset modes and one use -set. Selectable sound To select the sound mode Press the button in the remote control to select the desired sound quality. MEMORY(user set), MOVIE, MEMORY MUSIC, NEWS can be selected cyclically.
  • Page 26 Selectable sound pressing Item 0.1kHz decrease 100Hz level increase 100Hz level 0.3kHz decrease 330Hz level increase 330Hz level 1.0kHz decrease 1kHz level increase 1kHz level 3.0kHz decrease 3.3kHz level increase 3.3kHz level 10kHz decrease 10kHz level increase 10kHz level The adjusted level is stored in the MEMORY position.
  • Page 27 Selectable sound To adjust the sound balance Press the MENU button to select SOUND the SOUND and then to be dis- AUTO MEMORY EQUALIZER played on the right appearance. SURROUND ON HEADPHONE BALANCE Select the BALANCE with the SUPER WOOFER ON SELECT CHANGE PR /...

  • Page 28: Enjoying Stereo And Bilingual Broadcasts

    Enjoying Stereo and Bilingual Broadcasts The unit receivers both stereo and bilingual broadcasts transmitted in either the NICAM or German stereo/bilingual broadcast system. To select the stereo/bilingual mode Stereo programmes 1. When a stereo programme is received, appears. 2. Press the button to select to stereo/ monaural mode.

  • Page 29: Watching Double Window

    Watching Double Window The unit is capable of display two pictures simultaneously. This is called the Double window function. A TV picture or a picture from external source equipment such as a VTR can be displayed as another picture. You can enjoy as two TV sets by using headphone. To display double window Programme To display TV picture as double window...

  • Page 30: Various Double Window Operation

    Various double window operation Programme To watch a picture form a TV or an external source number or external 1. Press button repeatedly input number to select a the input for the main picture(the left side L e f t R i g h t picture).
  • Page 31 Various double window operation Programme If the color or sound of a certain programme is abnormal number or external The color system setting may be input number FUNCTION incorrect, the color is abnormal. LANGUAGE BLUE SCREEN L e f t R i g h t Press the MENU button to select 1 6 : 9...
  • Page 32 Various double window operation Programme To freeze the sub picture(the right picture) number or external When a double window is displayed, press the STILL input number button. L e f t R i g h t The sub picture(the right picture) will be a still picture. To return to a moving picture, press the STILL button p i c t u r e p i c t u r e...

  • Page 33: Watching Picture-In-Picture

    Watching Picture-in-Picture Watching Picture-in-Picture The unit is capable of displaying two pictures with the small sub picture simultaneously. This is called the Picture-in-Picture function. A TV picture or a picture from external source equipment such as a VTR can be displayed as another picture. To display a sub-picture To watch a TV or an external source as a sub-picture P r o g r a m m e n u m b e r...

  • Page 34: Various Picture-In-Picture Operations

    Various Picture-in-Picture operations To switch the main and sub-picture of the PIP Press the SWAP button when a picture-in-picture is displayed. The main picture(the large picture) and sub-picture(the small picture) are switched. Press the SWAP button again to switch again. To freeze the sub-picture Press the STILL button when a sub-picture is dis- played.

  • Page 35: Watching Pop(Picture-Out-Picture)

    Watching POP(Picture-out-Picture) To display a POP(Picture-out-Picture) and various POP operation POP(Multi-Strobo) select Or press the menu button to select PAP and then to be dis- TV/VIDEO P 0 0 played on the right appearance. Select the TV/VIDEO with the PR SELECT CHANGE buttons.

  • Page 36: Using Other Menus

    Using Other Menus Clock ON/OFF timer To set clock Press the menu button to select TIMER the TIMER and then to be dis- CLOCK - - : - - OFF TIME - - : - - played on the right appearance. ON TIME - - : - - ON TIME PROG.

  • Page 37: Sleep Time

    Sleep time Sleep Time Setting 1. With this button, up to 2 hours every 15 minutes can be set to the sleep timer. 2. If you press the sleep button for the first time, sign of the non set sleep-timer appears on the upper right side of the screen.

  • Page 38: To Select The Language Of The On-Screen Display

    To select the language of the on-screen display To select the on-screen display language Use this function to choose the on-screen display lan- guage 1. Press the menu button to select FUNCTION the FUNCTION and then to be dis- LANGUAGE BLUE SCREEN played on the right appearance.

  • Page 39: To Select The Blue Screen And Auto Volume

    To select the blue screen and auto volume To select the blue screen When no signal is being received, the TV will automati- cally turn blue at that time BLUE SCREEN ON. Press the menu button to select FUNCTION the FUNCTION and then to be dis- LANGUAGE BLUE SCREEN 1 6 : 9...

  • Page 40: To Connect Other Machines Like Video

    To Connect Other machines like VIDEO AUDIO SET CAMCORDER GAME PLAYER LASER DISC PLAYER Names and Functions of Connective Terminals Input/Output terminal of VIDEO4(option) (SCART JACK) S-picture video picture input terminal Input terminals of VIDEO1 (picture, sound on left, right) Output terminals Input terminals of VIDEO2 of Monitor...

  • Page 41: Connecting Video

    Connecting VIDEO When connect the VIDEO to the back of TV 1. Prepare the connective plug(separate selling) of picture/sound. 2. Connect the VIDEO picture output terminal with the TV picture input one. 3. Connect the VIDEO sound output terminal with the TV sound input one. 4.

  • Page 42: Connecting With S Picture Video

    Connecting with S picture VIDEO Back connector To watch TV in clear field by inputting S picture. When repeating high-quality field VIDEO, you can enjoy clear and sharp picture by connecting it with TV S-VHS terminal. 1. Connect S-VHS connective plug(separate selling) with S-VHS output terminal of VIDEO set and S-VIDEO picture input terminal of TV set.

  • Page 43: Connecting With Video Camera(Camcorder)

    Connecting with VIDEO CAMERA(CAMCORDER) To connect VIDEO CAMERA with TV When watching the recording by VIDEO CAMERA, it s convenient to connect with TV side connector. 1. Prepare the connective plug(separate selling) of picture/sound. 2. Connect the picture/sound connective terminal to VIDEO CAMERA picture/sound output terminal and the TV side picture/sound input one.

  • Page 44: Connecting With Audio Set

    Connecting with AUDIO SET When listening the sound in AUDIO powerfully, while watching the picture on TV Connect external input terminal of AUDIO to right & left sound output of TV monitor display. RIGHT LEFT SEPARATE SELLING Recording TV Connect the picture/sound connective plug to VIDEO picture/sound input terminal, TV monitor picture, and sound output terminal.

  • Page 45: Broadcast Transmission Systems In Each Country

    Broadcast Transmission Systems in Each Country Broadcast Transmission Systems in Each Country System Area Country Color Sound Bahrain, Kuwait, Israel, Oman, Qatar, United Arab Emirates, Yemen, etc. India, Indonesia, Malaysia, Singapore, Thailand, etc. Asia China, etc. M. E. Hong Kong Iraq, Islamic Republic of lran, Lebanon, Saudi Arabia, etc.

  • Page 46: Viewing Teletext(Option)/ Use Of The Teletext Buttons

    Viewing Teletext(Option)/ Use of the Teletext Buttons The Teletext service is carried on a TV transmission signal, therefore it is only available when a TV programme can be received on your TV. Your choice of TV programme also governs which Teletext service you will receive. To view text To select the text mode First, turn on your TV SET and choose your TV pro-...
  • Page 47 To view text Index When the Index button is pressed in the FLOF mode, the Teletext decoder is set up to display the index page. Press once for Main Index Page: press again for full index. When the TV is in LIST mode, the teletext decoder is set up to display the Red Rank.
  • Page 48 To view text Hold Some Teletext pages contain more information than can be displayed simultaneously and are therefore sub-divided into a series of two or more pages. The first sub-page of a series of four sub-pages will, for example, be indicated by a 1/4 displayed on the top right hand side of the text page.
  • Page 49 To view text Subcode For Teletext information which is longer than one page, it may take some time for the automatically changing of sub- pages to reach the sub-page you require. It is possible, how- ever, to enter the sub-page you require and continue watch- ing a normal TV programme until the correct sub-page has been reached.

  • Page 50: To Adjust Teletext Characters Quality

    To adjust teletext characters quality 1. Press the button at remote control to adjust the desired ADJUSTMENT teletext characters quality and CONTRAST then the display on the right appears. CHANGE When you press the button again, the display disappears. B R O W S E H O L D 2.

  • Page 51: Troubleshooting

    Troubleshooting Sometimes some performance problems can be easily solved by checking seemingly apparent but often overlooked possibilities. Before asking for service, to check these items could save your time and money. SYMPTOM CHECK No picture or sound. • Check the TV set is plugged in. •...

  • Page 52: Specification

    Specification TV Standard PAL/SECAM, NTSC3.58/4.43(AV) Color system B/G, D/K, I, M, H Sound system Rated voltage 110-240V~, 50/60Hz Power consumption 152W (at AC 220V, 50Hz) Sound Output Power MAIN: 15W X 15W, Woofer: 15W HYPER + CHINA + IVORY COAST Channel Coverage VHF L : K1(43.25MHz)~S7(147.25MHz) VHF H : S8(154.25MHz)~S41(463.25MHz)
  • Page 53 MEMO MEMO...
  • Page 54 MEMO MEMO...
  • Page 55 MEMO MEMO...
  • Page 56 P/N:48586915E107-R0...
