Printekmobile FieldPro RT43 Quick Setup Manual

FieldPro Model RT43 Quick Setup Guide
Paper
Rear
Detail Other Side
Paper Door Battery
Release Release
1

Charge the Battery

2
Connect Power Source
(PN 91373 AC Adapter, or
PN 91410 In-Vehicle Adapter)
3
Perform Printer Test
1
Start with Power Off
2
Hold Feed Button,
then Press Power Button
PN 6355 Rev A
PrintekMobile Group, Printek Inc.
Paper
Top
Exit
Door
I/O Port
Power Input
Cover
Port
1
3
LED Should Illuminate
4
Charge Until
(Approximately 2-3 hours)
3
Continue to Hold Feed Button
until Printer Beeps Twice.
LED will Flash, Test Page will Print
4
Printer will Prompt You to Press
if You Want to Enter Setup Menu
(More on Setup Menu, See Reverse)
Telephone: 888-211-3400
Use this guide to configure your new FieldPro printer prior to use.
Printers may also be ordered from PrintekMobile pre-configured, if desired.
Front
Carrying
Strap
Install Battery *
(Loosen Carrying
Strap if necessary)
LED Goes Out **
(Tear Direction)
More detailed instructions can be found in the Operator's Manual, available at www.printekmobile.com
Page 1
Power Power Battery
Button LED LED
2

Load Paper

Drop in
Paper ***
Paper Guide
*
FieldPro printers may be operated directly from an external power
source without a battery present. If no battery is to be used, battery
charging may be skipped. (A battery compartment cover is available
from PrintekMobile).
** Maximum battery capacity is reached only after completing three
complete charge and discharge cycles. PrintekMobile recommends
completing three cycles before deploying your printer for best
results.
*** With media rolls of less than 4" width we recommend addition of a
second paper guide. See reverse for details.
© 2006 Printek, Inc. All rights reserved.
1517 Townline Road, Benton Harbor, MI 49022
Fault Feed
LED Button
Close Door
Depress Door
Release Lever
