4. After exiting from "RAID Level", it goes directly to "Stripe Size" item. Because all
four disks are selected for RAID10, so there is no need to go to Disks option.
5. Use Up or Down arrow key to select the desired strip size when entering "Strip
Size" menu. The default value is 64K.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
6. In "Capacity" item, use the default value, and press <Enter>. The default value is
twice the smallest hard disk size, that is, 74.5GB * 2 = 149GB.
7. Select "Create Volume" and press <Enter>. A warning message will appear :
Press <Y> to create the volume and return to the main menu.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1 . Create RAID Volume
2 . Delete RAID Volume
RAID Volume :
ID Name
0 TryRAID10
Physical Disks:
Port Drive Model
0 Hitachi HDS72161
1 ST380811AS
2 SAMSUNG HD161HJ S0V3J9APA30524
3 ST380815AS
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
The following are typical values:
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume ? (Y/N) :
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
1. Create RAID Volume
5. Exit
[ DISK/VOLUME INFORMATION ]
Level Stripe
RAID10(0+1) 64KB 149.1GB Normal Yes
Serial #
PVF904Z21G2JZM
5PS1TAGW
5RW1CA37
TryRAID10
RAID10(RAID0+1)
Select Disks
128K
64KB
149.1 GB
N/A
Create Volume
[ HELP ]
RAID0 - 128KB
RAID10 - 64KB
RAID5 - 64KB
[ MAIN MENU ]
3. Reset Disks to Non-RAID
4. Recover Volume Options
Size Status Bootable
Size Type/Status(Vol ID)
149.0GB
74.5GB
149.0GB
74.5GB
86
Member Disk(0)
Member Disk(0)
Member Disk(0)
Member Disk(0)
