Sennheiser SR 2000 Brochure & Specs

SR 2000
FEATURES
20 fixed frequency banks with up to
32 compatible presets in up to 75 MHz
switching bandwidth and 6 user banks
Audio loop-out jack
5 Band graphic EQ
Rugged 19" all-metal housing with
integrated power supply unit
Ethernet for monitoring and control using
Sennheiser WSM Mac or PC software
Extended AF requency response
(25... 15000 Hz)
Receivers can be configured in the trans-
mitter menu and can be synchronized
via the infrared interface
ARCHITECT'S

SPECIFICATIONS

The device shall be a stationary stereo
transmitter for use with a companion
stereo receiver as part of a high reliability
stereo wireless radio frequency transmis-
sion system. The stationary stereo trans-
mitter shall operate within a RF frequency
range of 516 – 865 MHz in 20 fixed
frequency banks and 6 user banks with a
maximum of 32 presets with a switching
bandwidth of maximum 75 MHz tunable
in 25 kHz steps; carrier frequencies shall
be maximum 3000. Frequency stability
shall be ±10 ppm. Nominal/peak deviation
shall be ±24 kHz/±48 kHz. A compander
feature shall be included and shall be
Sennheiser HDX system. The transmitter
shall include MPX pilot tone (frequency /
deviation) of 19 kHz / ±5kHz. Audio fre-
quency response shall be 25 – 15,000 Hz;
total harmonic distortion (THD) shall be
<0.9 %. Audio frequency input level shall
be +22 dBu (maximum, balanced). Signal-
to-noise ratio shall be > 90 dB.
Continued on page 2
Stereo Transmitter
Rugged, reliable, and flexible – in short: professional. With SR 2000, you can
choose from 26 frequency banks with up to 32 channels. The channels can be
user-programmed into six of the frequency banks. Three switchable RF output
powers (10, 30, and 50 mW – additionally 100 mW in the US version) provide
greatest artistic and technical freedom. A 5-band equalizer makes it possible to
individually influence the audio output signal.

TECHNICAL DATA

RF frequency range ............................................. 516 – 865 MHz
Carrier frequencies .............................................. max. 3000
Presets ................................................................... max. 32
Switching bandwidth .......................................... max. 75 MHz, tuneable in
Frequency stability .............................................. ±10 ppm
Antenna output ................................................... BNC (50 OHM)
RF Output power .................................................. typ. 10 mW (Low)
Compander ............................................................ HDX
Nominal / Peak deviation................................... ±24 kHz / ±48 kHz
MPX pilot tone (frequency / deviation) .......... 19 kHz / ± 5kHz
Frequency response ............................................ 25 – 15000 Hz
Signal-to-noise ratio ........................................... > 90 dB
THD, total harmonic distortion ......................... < 0,9 %
Max. input level .................................................... +22 dBu
Audio input ........................................................... XLR-31/4" (6,3mm) jack combo
Audio output ........................................................ 1/4" (6,3mm) jack socket, balanced
Operating temperature ...................................... –10 °C – +55 °C
Power supply ........................................................ 100 - 240 V AC, 50/60 Hz
Current consumption .......................................... max. 0,1 A
Dimensions ........................................................... 217 x 483 x 43 mm
Weight ................................................................... 2600 g
25 kHz steps
typ. 30 mW (Standard)
typ. 50 mW (High)
XP-Version: typ. 100 mW (Maximum)
socket, electronically balanced
Continued on page 2
