In addition, an LSI command-line configuration program is available from
http://www.ibm.com/servers/eserver/support/xseries/index.html/.
Consider the following information when using the LSI Configuration Utility program
to configure and manage arrays:
v The integrated SAS/SATA controller with RAID capabilities supports the following
v Hard disk drive capacities affect how you create arrays. The drives in an array
v If you use an integrated SAS/SATA controller with RAID capabilities to configure
v If you install a different type of RAID controller, see the documentation that
To start the LSI Configuration Utility program, complete the following steps:
1. Turn on the server.
2. When the message <<< Press <CTRL-C> to start LSI Configuration Utility
3. Use the arrow keys to select a controller (channel) from the list of adapters;
4. To change the settings of the selected items, follow the instructions on the
See the User's Guide on the IBM System x Documentation CD for more information
about the LSI Configuration Utility program.
46
System x3200 Type 4362 and 4363: Installation Guide
features:
– Integrated Mirroring (IM) with hot-spare support (also known as RAID 1)
Use this option to create an integrated array of two disks plus an optional hot
spare. All data on the primary disk can be migrated.
– Integrated Mirroring Enhanced (IME) with hot-spare support (also known as
RAID 1E)
Use this option to create an integrated mirror enhanced array of three to eight
disks, including an optional hot spare.
– Integrated Striping (IS) (also known as RAID 0)
Use this option to create an integrated striping array of two to eight disks. All
data on the array disk will be deleted.
can have different capacities, but the RAID controller treats them as if they all
have the capacity of the smallest hard disk drive.
a RAID 1 (mirrored) array after you have installed the operating system, you will
lose access to any data or applications that were previously stored on the
secondary drive of the mirrored pair.
comes with the controller for information about viewing and changing SAS
settings for attached devices.
>>> is displayed, press Ctrl-C. If an administrator password has been set, you
are prompted to type the password.
then, press Enter.
screen. If you select Raid Properties, SAS Topology, or Advanced Adapter
Properties, additional screens are displayed.
