Sanyo PLC-XU45 Service Manual

Multimedia projector
Hide thumbs Also See for PLC-XU45:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual

SERVICE MANUAL

PRODUCT CODE
1 122 181 00
(ME3A)
1 122 182 00
(PE3A)
1 122 182 02
(PE3C)
Multimedia Projector
PLC-XU46
1 122 183 00
(MF3A)
1 122 184 00
(PF3A)
1 122 184 02
(PF3C)
FILE NO.
Model No. PLC-XU45
Original Version
Chassis No. ME3-XU4500
MF3-XU4600
NOTE: Match the Chassis No. on the unit's
back cover with the Chassis No. in the
Service Manual.
If the Original Version Service
Manual Chassis No. does not match
the
unit's,
additional
Literature is required.You must refer to
"Notices" to the Original Service
Manual prior to servicing the unit.
REFERENCE NO.
PLC-XU46
U.S.A., Canada,
Europe, Asia, Africa
U.K
PLC-XU45
Service
SM
5110464

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-XU45

Summary of Contents for Sanyo PLC-XU45
