Model No. WCTL942410
USER'S MANUAL
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Monday through Friday 8h00 to
18h30 EST (excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
Visit our website at
this equipment. Save this manual
for future reference.
www.weslo.com
Advertisement
Table of Contents
Related Manuals for Weslo Crosstrainer 505s Treadmill
Summary of Contents for Weslo Crosstrainer 505s Treadmill
- Page 1 1-888-936-4266 Monday through Friday 8h00 to 18h30 EST (excluding holidays). CAUTION Read all precautions and instruc- tions in this manual before using Visit our website at this equipment. Save this manual for future reference. www.weslo.com...
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Failure to use a properly functioning surge that all users of this treadmill are adequately suppressor could result in damage to the con- informed of all warnings and precautions. - Page 4 21. When folding or moving the treadmill, make maintenance and adjustment procedures de- sure that the storage latch is fully closed. scribed in this manual. Never remove the motor hood unless instructed to do so by an 22. Inspect and properly tighten all parts of the authorized service representative.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO ® CADENCE 1-888-936-4266, Monday through Friday 8h00 until 505s treadmill. The CADENCE 505s treadmill combines 18h30 eastern time (excluding holidays). To help us advanced technology with innovative design to help you... -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 2. With the help of another person, carefully lower the Uprights (69) as shown. Note: It may be helpful to place one foot on one of the Extension Legs (63) as you tip the Uprights. Make sure that the Extension Legs remain in the Uprights.
- Page 8 4. Hold the Console Base (47) near the Left Handrail (71). Attach the end of the ground wire on the Console Base to the indicated small hole in the Left Handrail with the Ground Silver Ground Screw (75). Wire Small Hole 5.
- Page 9 7. Press the Upright Wire (42) into the slot in the underside of the Console Base (47) in the indicated area. Cover the Upright Wire with the Right Grip Plate (36). Be careful not to pinch the Upright Wire. Tighten three 1/2” Screws (48) into the Right Grip Plate and the Console Slot Ground...
-
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate outlet that is properly installed and grounded in Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. - Page 11 CONSOLE DIAGRAM Displays Pulse Sensor Note: If there is a thin sheet of plastic on the console, remove the plastic. Clip Next, stand on the foot rails of the treadmill. Find the CAUTION: clip attached to the key (see the drawing above), and Before operating the slide the clip onto the waistband of your clothes.
- Page 12 To stop the walking belt, press the Stop button. while inserting the key The Time/Distance display will begin to flash. into the console. An “E” for English miles or an Note: During the first few minutes that the treadmill “M” for metric kilometers will appear in the Speed is used, inspect the alignment of the walking belt, display.
- Page 13 HOW TO USE THE HAND WEIGHTS To exercise your upper body as you walk on the treadmill, hold the 2-pound (0.9 kg) weights at your sides or press the weights above your head. To increase the intensity of your exercise, use the 3-pound (1.4 kg) or 5-pound (2.3 kg) weights.
-
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. - Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Press the storage latch to the left. Pivot the treadmill down until the frame and foot rail are past the storage latch. Storage Latch Catch...
-
Page 16: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call 1-888-936-4266. PROBLEM: The power does not turn on SOLUTION: a. Make sure that the power cord is plugged into a surge suppressor, and that the surge suppressor is plugged into a properly grounded outlet (see page 10). - Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
-
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian. -
Page 19: Ordering Replacement Parts
To order replacement parts, call toll-free 1-888-936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • the MODEL NUMBER OF THE PRODUCT (WCTL942410) • the NAME OF THE PRODUCT (WESLO CADENCE 505s treadmill) ®... -
Page 20: Limited Warranty
LIMITED WARRANTY ICON OF CANADA, INC., (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of one (1) year from the date of purchase. This warranty extends only to the original purchaser. ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product through one of its authorized service centers. - Page 21 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 22 PART LIST—Model No. WCTL942410 R1104A No. Qty. Description No. Qty. Description No. Qty. Description Hood 2 1/2” Bolt Hand Weight (5 lbs) 3/4” Screw Washer Incline Motor Motor Belt 1” Tek Screw Bolt (upper) Motor Tension Bolt Handrail Bracket Reset/Off Switch Foot Rail Screw 5/32”...
