GE JGBP35CEACC Datasheet

GE Appliances
JGBP35CEACC—GE Spectra
Dimensions (in inches) and Installation Information
30
46-1/2
28-1/4*
46-3/8
*Depth including handle
26-1/4"—Depth to front of closed oven door
25-1/4"—Depth to front top edge of cooktop
Specification Created 7/01
™ 30" Free-Standing XL44
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
36 1/4
and shut-off valve
For answers to your Monogram,
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
™ Gas Range
Recommended common area
for gas outlet and electrical
outlet for GE free-standing gas
range models
30
C L
2-1/2
8
4
24
2
9
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
® GE Profile ™ or
® service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
CERTIFIED
of the range.
Optional Gas Range
Accessory Drip Pans for Sealed
and Standard Burner Models
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-848-7722
Optional Gas Range
Wok Accessory
(Available at additional cost)
JXWK—Wok accessory sits on
top of burner grate to hold a
round-bottom wok.
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
