Class HC Fitness Product Model No. RETL14000 USER'S MANUAL Serial No. Serial Number Decal CUSTOMER INFORMATION If you have any questions regard- ing assembly, use, or maintenance of your treadmill, please contact our Customer Service Department at the numbers or addresses below: Call us: +44 (0)870 33 000 24...
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
Page 3
15. Never start the treadmill while you are 20. Inspect and tighten all parts of the treadmill standing on the walking belt. Always hold every three months. the handrails while using the treadmill. 21. Never drop or insert any object into any 16.
And when you’re not treadmill (see the front cover of this manual for the lo- exercising, the unique RT500 can be folded up, requir- cation). ing less than half the floor space of other treadmills.
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 6
3. Hold one of the Handrails (1) at an angle as shown and insert the upper end as far as possible into the right Upright (11). Keep the lower end of the Handrail away from the treadmill to avoid scratching the finish. Next, rotate the lower end of the Handrail to the position shown by the dotted line.
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPOR- TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 8
CONSOLE DIAGRAM Note: If there is a thin sheet of clear plastic on the face of the console, remove it before oper- ating the console. Battery CAUTION: Before operating the Cover console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power.
Page 9
SPEED display—This dis- Insert the key fully into the power switch. play shows the speed of the walking belt. Inserting the key will not turn on the displays. The displays will turn on when the ON/ RESET button is pressed or TIME display—This display when the walking belt is shows the elapsed time.
HOW TO SELECT KILOMETRES AND MILES Screws The console can display distance and speed in either kilometres or miles. To change the unit of measure- ment, first UNPLUG THE POWER CORD. Next, re- move the six screws attaching the console to the con- Switch sole base (see the drawing at the right).
Page 11
HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described above. Make sure that the stor- age latch is closed fully over the catch. 1. Hold the upper ends of the handrails. Place one foot on the base as shown.
TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. 1. SYMPTOM: THE POWER DOES NOT TURN ON a.
Page 13
4. SYMPTOM: THE WALKING BELT SLOWS WHEN WALKED ON a. If an extension cord is needed, use only a 3-conductor, 14-gauge (1mm ) cord that is no longer than 1.5 meters. b. If the walking belt is overtightened, treadmill performance may decrease and the walking belt may be permanently damaged.
CONDITIONING GUIDELINES stored fat calories for energy. If your goal is to burn fat, adjust the speed and incline of the treadmill until your WARNING: Before beginning heart rate is near one of the lower two numbers in your this or any exercise program, consult your training zone.
Page 15
A Cool-down EXERCISE FREQUENCY Finish each workout with 5 to 10 minutes of stretching To maintain or improve your condition, complete three to cool down. This will increase the flexibility of your workouts each week, with at least one day of rest be- muscles and will help to prevent post-exercise problems.
Product or problem and a copy of your proof of purchase if you believe the service is covered by warranty. REEBOK FITNESS EQUIPMENT is not responsible or liable for indirect, special or consequential damages arising out of or in con- nection with the use or performance of the Product or damages with respect to any economic loss, loss of property, loss of rev- enues or profits, loss of enjoyment or use, costs of removal, installation or other consequential damages of whatsoever nature.
Page 17
REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
Page 18
PART LIST—Model No. RETL14000 R0800A Incline Wheel Qty. Description Extension Leg Screw Receptacle Handrail Motor Pivot Sleeve Key/Clip Catch Screw Screw Frame Pivot Washer Battery Cover Frame Pivot Bolt Foot Rail Grommet Lift Motor Motor Belly Pan Frame Guide Cable Tie Clamp Speed Potentiometer Rear Platform Screw Speed Control Knob...
