Tripp Lite SU60K Specification

Model #: SU60K
SmartOnline 60kVA Modular 3-Phase UPS System, On-line Double-Conversion UPS for North America
Description
Tripp Lite's SU60K (60kVA) SmartOnline Modular 3-Phase Intelligent, True On-Line UPS System provides 100% system availability with N+1
modular architecture and 1+1 parallel capability. In an N+1 configuration, the SU60K features three self-contained, redundant 20kVA power modules
that can be hot-swapped (with the load powered) if maintenance is required. Connect two SU60K models in parallel (1+1 configuration) to provide
fail-safe redundancy (two 60kVA models supporting a 60kVA load) or to increase capacity (two 60kVA models supporting an 120kVA load).
The SU60K provides mission-critical equipment with the highest level of power protection available. Large capacity 60,000VA/48,000 watt UPS
continually converts incoming AC power into filtered DC power, and then resynthesizes it back into AC power with a pure sine wave. Perfectly
regulated, continuous sine wave output with zero transfer time offers compatibility with all equipment types. The SU60K's high input power factor,
advanced IGBT inverter technology and Digital Signal Processor (DSP) technology create less than 3% input Total Harmonic Distortion (THDi). With
SU60K's low THDi, generators run cooler and last longer, allowing managers to save installation costs by installing a generator with a capacity equal
to their equipment load (a 1:1 ratio). Extremely efficient operation (up to 96%) saves money by lowering electricity consumption. Hardwire input and
output connections support a variety of permanent or PDU style power connections. SU60K features 120/208V AC, 3-phase, 4-wire (plus ground),
wye input and output. It also features a wide input voltage correction range: 94-150/163-260V AC. Frequency is 50 or 60 Hz (auto-selectable).
SU60K features a single small-footprint tower power module. A stand-alone hardwired external battery module (Models BP480V26B or BP480V40C
with matching battery cabinets, available separately) is required for operation and to provide battery backup support. Additional external
BP480V26B or BP480V40C battery modules can be connected for extended runtime. Additional battery cabinets for extended runtime solutions also
available; contact Tripp Lite for more information. A manual bypass breaker as well as an automatic bypass function ensure 100% availability of
connected equipment by safely passing through AC power if the UPS requires maintenance. A built-in RS-232 communication port works with
included PowerAlert Software to provide shutdown commands and reporting on a single server. An accessory slot accepts an optional internal SNMP
card (model # SNMPWEBCARD) for remote shutdowns, reboots and more. Front panel combination LCD/LED display alerts users to a variety of
UPS operational modes and conditions. The LCD display includes a real-time event log screen with up to 500 events listed. A dynamic battery
management screen optimizes battery function to lengthen service life and allows cold restart of UPS during a prolonged blackout to utilize its
batteries for periodic system access or data retrieval. An Emergency Power Off button turns UPS output OFF and disables Bypass output. Built-in
Emergency Power Off (EPO) dry-contact interface supports remote emergency shutdown in large facilities. A
to enhance the reliability of the installation.
Package Includes
SU60K UPS System
Highlights
60,000 VA (60kVA) tower UPS with 3 hot-swappable power modules
N+1 redundant modular architecture helps ensure 100% availability
1+1 parallel capability allows for system redundancy or increased capacity
Low THDi saves installation costs by allowing 1:1 generator sizing
3-phase hardwire (120/208VAC) input/output. Wide input voltage correction
range (94-150VAC/163-260VAC)
On-line, double-conversion operation with zero transfer time; IGBT
technology; extremely efficient operation (up to 96%)
Runtime is expandable via external battery cabinet options
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
start-up service program is recommended
Tripp Lite
