Summary of Contents for Alcatel ONE TOUCH OT-E801C
-
Page 3: Table Of Contents
Content Safety and Use ............8 1. Your Mobile .............18 1.1 Layout............18 1.2 Basic Information ........20 1.3 Keypad...........21 1.4 Idle Screen Icons........23 1.5 Main Menu Icons........25 2. Getting Started ..........26 2.1 Set-up.............26 2.2 Charging the battery ......27 2.3 Headset ..........29 2.4 Micro SD card ........30 3. - Page 4 3.3 Answering Calls........33 3.4 Setting during Conversation ....33 3.5 USB modem ..........34 4. Contact.............34 4.1 Contact menu.........34 4.2 Consulting your contact (“View”) ..35 4.2.1 Available options in the contacts list ............35 4.2.2 Making the call ......36 4.2.3 Group ..........36 4.2.4 Searching for a name by its first letter .............36 5.
- Page 5 5.8 Memory Status........41 6. Call Record ............41 6.1 Missed Calls ..........41 6.2 Incoming Calls........42 6.3 Outgoing Calls........42 6.4 Duration ..........43 6.5 Delete Record ........43 7. Profiles.............43 7.1 Normal ...........43 7.2 Meeting..........44 7.3 Outdoor..........44 7.4 Silent............45 8. Entertainment...........45 8.1 MP3 player ..........45 8.2 Play list ..........46 8.3 MP3 Setting ...........47 8.4 example.mp3..........48...
- Page 6 9. Setting..............48 9.1 Display...........48 9.1.1 Wallpaper ........49 9.1.2 Brightness ........49 9.1.3 Backlight........49 9.1.4 Keypad backlight ......49 9.2 Call ............49 9.2.1 Call waiting.........49 9.2.2 Call Forward .......50 9.3 Phone .............51 9.3.1 Language ........51 9.3.2 Time Format........51 9.3.3 Date Format ........51 9.3.4 Auto Key Lock......51 9.3.5 Answer Mode......52 9.3.6 Min.
- Page 7 10.2 Memo...........56 10.3 Calculator..........56 10.4 Stopwatch ..........56 10.5 World time ...........57 10.6 USB disk..........57 11 Game...............58 11.1 Tetris ............58 11.2 Push box..........59 12 Gallery ............60 12.1 SD Card ..........60 12.2 Memory Status........61 13. Characters and Symbols Table.......61 14. Warranty ............63 15.
-
Page 8: Safety And Use
Safety and Use Thank you for purchasing this product. We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. •TRAFFIC SAFETY：... - Page 9 interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem: - do not place your phone on top of the dashboard or within an airbag deployment area, - check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from mobile phone RF energy.
- Page 10 To avoid hearing impairment, pick up the call before holding your phone to your ear. Also move the handset away from your ear while using the “hands-free” mode because the amplified volume might cause hearing damage. Do not let small children use the phone without supervision. When replacing the cover please note that your phone may contain substances that could create an allergic reaction.
- Page 11 Use only Alcatel batteries, battery chargers, and accessories that are compatible with your phone model. (See Accessories List, page 65). T&A Mobile Phones Limited and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries.
- Page 12 precautions: - Take a minimum of a 15-minute break hourly. - Play in a room in which all lights are on. - Play at the farthest distance possible from the screen. When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body.
- Page 13 these items of equipment - Collection bins at points of sale. They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused. In European Union countries: These collection points are accessible free of charge. All products with this sign must be brought to these collection points.
- Page 14 store it at temperatures above 60 °C. Batteries must be disposed of in accordance with locally applicable environmental regulations. Only use the battery for the purpose for which it was designed. Never use damaged batteries or those not recommended by T&A Mobile Phones Limited and/or its affiliates.
- Page 15 the radiofrequency (RF) exposure thresholds recommended by international requirements (ICNIRP) and by the Council of the European Union (Recommendation 1999/519/EC) These limits are part of a set of requirements and establish authorized radiofrequency levels for the public. These limits were established by independent groups of experts on the basis of regular and detailed scientific assessments.
- Page 16 transmitting at their maximum power level over the entire range of frequency bands. Although the SAR was established at the highest certified level, the actual SAR level for the mobile phone during use is generally much lower than the maximum values. In fact, since mobile phones are designed to operate at many different power levels, they only use the minimum level of power required to provide a connection to the network.
- Page 17 193). Additional information about electromagnetic fields and public health are available Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid touching it or damaging it. Note & Warning Note： To help you to better use the phone Warning：...
-
Page 18: Your Mobile
1. Your Mobile 1.1 Layout Forward key Play/Pause key Backward key Micro-SD Card Slot... - Page 19 Left softkey： Navigation key： Access the menu Message Confirm an option Contact Send key： Pickup / Send call Right softkey： Call record（short Contact/delete/back keypress） Number key 1-9 End key： Speeddial（long Switch on/off/ end call/ keypress） Back to idle screen Lock/Unlock keypad （long keypress）...
-
Page 20: Basic Information
1.2 Basic Information Item Spec Dimension 96.5mm*45mm*17.5mm (L*W*H) Weight 80g（including battery） Display 65k, CSTN,128×128 User 1.05MB available memory External Micro –SD card up to 1GB memory Contact Call Record Battery Capacity：800mA Voltage：3.7V Talk time： 100-180 mins Standby time： 60-120 hours... -
Page 21: Keypad
Item Spec Working Temperature：-10℃~+55℃ Note： Talk time and standby time are network dependent. 1.3 Keypad Function Menu / Confirm (ok ) (Left Soft Key) Return to the previous screen To end calls when calling To close popup menu (Right Soft Key) In edition mode: Delete a character ( short keypress) Delete all characters (long keypress) - Page 22 Function Switch on / off (long keypress) End call / Back to idle screen Terminate data modem connection In idle screen： Press to access SMS Navigation keys Press to access Contact In other status: move the Up and Down keys to choose / ：...
-
Page 23: Idle Screen Icons
Function In edition mode ： change input method (short keypress) In dialing mode：input “P” (long keypress) In idle screen ： activate or deactivate vibrator (long keypress) In main menu: go to right function Note： （1）Long keypress means no less than 2 seconds. Short keypress means less than 2 seconds. - Page 24 Missed call Roaming In conversation Data modem activated New SMS SMS is full Normal mode activated Meeting mode activated Outdoor mode activated Silent mode activated Headset inserted Play in background with headset inserted Play in background Alarm programmed Call firewall activated SMS firewall activated Call and SMS firewall activated Micro SD card...
-
Page 25: Main Menu Icons
Battery charge level 1.5 Main Menu Icons 1，Gallery 2，Call Record 3，Tools 4，Profiles 5，Message 6，Entertainment 7， Games 8，Setting 9，Contact Note： In main menu you can press key to go up and down, key to go left and right, or you can press number 1-9 to directly access to the function. -
Page 26: Getting Started
2. Getting Started 2.1 Set-up Inserting the UIM card (If any, since some operators are using NON-UIM version) Fit the UIM card with the chip facing downloads. Slide the UIM card into its compartment. Push the UIM card with your finger to release it. -
Page 27: Charging The Battery
Align the tab on top of the battery with the slot in the battery compartment of your phone. Press down the battery until the latch is securely in place. Note： Long press the key to power off the phone. Pls wait for 10 seconds before you take out the battery to avoid any damage to the phone memory. - Page 28 Please firstly insert the cable (included in the package) into the charger and after insert the cable, the charger can be plugged to the phone with a jack. (Please only use Alcatel chargers) The phone supports PC charging: connect the phone and computer...
-
Page 29: Headset
Note： （1）Before connecting to the charger, make sure the battery is inserted correctly； （2）Do not force the plug into the socket （3）To achieve the best performace of the battery we suggest you charge the battery for12 to 14 hours for the first 3 times. （4）The battery will be auto discharged if not being used for long time. -
Page 30: Micro Sd Card
please disconnect the charger first since they share the same jack. Once the headset is inserted will appear on the idle screen. The headset can be used to listen to the music, adjust volume for FM Radio answer and end the phone call by long pressing the button in the headset. -
Page 31: Basic Function
3. Basic Function 3.1 Power On/Off Long press the key to power on and off. If phone password or PIN code is activated you have to input the right password before you can use the phone. Please go to [Menu / Setting/ Security] to set [PIN] code and [Phone password]. -
Page 32: By Call Records
(The Number is the record index in the [Contact]) and then press key to make calls. 3.2.3 By call records In idle screen, press key to access Call Records. to pick up the number and then press key to make call. 3.2.4 By speeddial In idle screen, long press key 1 to 9 to call speeddial numbers. -
Page 33: Answering Calls
3.3 Answering Calls For incoming calls, if the name and number have been saved, the name and number will be displayed, otherwise only number will be displayed. Press to answer the incoming call. You can also set other keys to answer the incoming calls, please refer to [Menu/ Setting/ Phone /Answer Mode]. -
Page 34: Usb Modem
3.5 USB modem After installing the driver you can use the phone as a modem to connect internet. Please refer to the USB Modem User Guide in the CD Rom for the detailed operation 4. Contact The [Contact] allows you to store phone numbers and names either in the UIM memory and/or the phone memory. -
Page 35: Consulting Your Contact ("View")
URL, Remark, Incoming call ringtone and Group) Group: group together names by category: [Family], [Business], [Friends], [VIP], [Schoolmates], [Phone Records] and [UIM Records]. Speed Dial: to set speed dial numbers for number key 1 to 9 Copy All: to copy all the records in phone to UIM card or all the record in UIM card to phone Delete All: to delete all the records in phone or in UIM card My Number: to enter your own phone numbers for future reference. -
Page 36: Making The Call
Call: to call the number you have selected Send Message: to create a message to send to the selected contact. Edit: to edit the data of the selected contact. Delete: to delete the selected contact. Copy to Phone/ UIM: Copy the file to the phone or UIM contact. 4.2.2 Making the call Press the key when the name is selected to make a call or... -
Page 37: Message
with the first letter of his/her name. For instance, if you press twice on “1” key in Eng Mode, names starting with “B” will be displayed. 5. Message From your phone, you can read, write, send and receive SMS message and share them with other phones. -
Page 38: Inbox
current SMS to [Drafts] and [Contact] to choose destinations (up to 9 receivers). Save：to save the current SMS to [Drafts] Text Template：to choose one text template to insert into current SMS. Smiley：to choose one smiley to insert into current SMS. Domain：to choose one net symbol to insert into current SMS Contact：to choose one contact name from [Contact] to insert into current SMS. -
Page 39: Outbox
Forward：to edit and send the current SMS to someone else Call：to call the sender 5.3 Outbox The [Outbox] includes sent and unsent messages. Press the left softkey to access the following list: View： to check the detailed information about current SMS and then, by pressing left softkey, to delete or forward it Forward：to edit and send the current SMS to someone else Delete：to delete the current SMS... -
Page 40: Text Template
Delete all：to delete all the SMS in [Drafts] 5.5 Text Template Lists of predefined messages are available. Select one, edit it if required, and then send it. 5.6 Smiley Lists of predefined smiley are available. Select one, edit it if required, and then send it. -
Page 41: Memory Status
Priority：to choose [Normal], [Interactive], [Urgent] or [Emergency] 5.8 Memory Status To check the memory status in phone and UIM card. 6. Call Record From the idle screen, press the key and your phone displays a call list. Each call is displayed with an icon indicating the type of the call (Missed calls, Incoming calls, and Outgoing calls). -
Page 42: Incoming Calls
View：to check the detailed information of the current record Save：to save the number to [Contact] Call：to call this number Send Message: to send SMS to the current number Delete：to delete the current record 6.2 Incoming Calls You can check all the incoming calls here. Press left softkey to access the following list: [View], [Save], [Call], [Send Message] and [Delete]. -
Page 43: Duration
6.4 Duration To check the duration for [Last Call], [Total incoming], [Total outgoing] and [Total duration]. Press key choose, left softkey to check the duration. 6.5 Delete Record To delete the records for [Missed Calls], [Incoming Calls], [Outgoing Calls] and [Delete All]. Press key to choose, left softkey to delete. -
Page 44: Meeting
Alert mode： to choose [Ringtone], [Vibrate], [Ring+Vibrate] or [Close] Ringtone：to [Activate] or [Deactivate] the Ringtone for [Incoming call], [SMS alert], [Alarm Tone], [key beep], [Power On/Off tone] and [Warning Tone] Note： You can deactivate the [Power On / Off tone] in [Ringtone] for each profile. -
Page 45: Silent
7.4 Silent You can [Activate] the [Silent] profile or [Customize] it. Please refer to [Normal] for detailed operation. 8. Entertainment You can access the MP3 player directly by pressing side key in idle screen. 8.1 MP3 player If the play list is empty, press right softkey to exit and go to [Play List] to add music. -
Page 46: Play List
there’s MP3 song in the play list). 8.2 Play list To display all the available music. If the list is empty press left softkey to [Add Single Clip] or [Add Folder ]; if the list is not empty press left softkey to [Play], [Add Single Clip], [Add Folder ], [Delete] or [Delete All]. -
Page 47: Mp3 Setting
Note： Please only save the mid or MP3 files in [MUSIC] file or root directory of Micro SD card. The phone can’t identify the mid or MP3 files in other folders of Micro SD card. The Vimicro 968 MP3 chip (the MP3 chip of this phone) supports： both ISO 11172-3 and ISO 13818-3 layer III audio;... -
Page 48: Example.mp3
8.4 example.mp3 The example embedded in the phone for testing. 8.5 FM Radio Please insert the headset before using this function. The volume can be adjusted from headset and by pressing key Press key to choose channel automatically or press key 4 or 6 to choose manually (by 0.1 MHz). -
Page 49: Wallpaper
[Brightness], [Backlight] and [Keypad backlight] 9.1.1 Wallpaper To choose the wallpaper you like from [Basic wallpaper]. 9.1.2 Brightness Press or Press key to adjust the screen brightness 9.1.3 Backlight To set the backlight on for [10 Sec], [30 Sec], [60 Sec] or [Always 9.1.4 Keypad backlight To [Activate] or [Deactivate] the keypad backlight 9.2 Call... -
Page 50: Call Forward
feature) you can answer a second call when you are already on a line. The network will remind you for the second call (the reminding way is network dependent). You can [Accept] or [End] the new call and press key to switch between the two calls. -
Page 51: Phone
9.3 Phone In idle screen, go to [Menu/Setting/Phone] to set: [Language], [Time Format], [Date Format], [Auto Key Lock], [Answer Mode] and [Min. Reminder]. 9.3.1 Language To choose one of the languages supported by the phone. Usually two languages are supported by the phone. English is available for all the versions and the second language is country dependent. -
Page 52: Answer Mode
9.3.5 Answer Mode To answer the calls by [Any Key] or [Send Key]. If [Any key] is on you can answer incoming calls by pressing any key except key 9.3.6 Min. Reminder To set [Min. Reminder] as [Close], [45 sec.], [50 sec.] or [55 sec.] 9.4 Ringtone In idle screen, go to [Menu/Setting/Ringtone] to set the ringtone for: [Incoming calls], [SMS alert], [Alarm tone], [Key beep], [Power on]... -
Page 53: Security
Power on: to choose the ringtone for power on from the embedded 5 ringtones Power off: to choose the ringtone for Power off from the embedded 5 ringtones 9.5 Security In idle screen, go to [Menu/Setting/Security] and enter the phone password (the original password: 0000) to set: [Phone password], [PIN], [Data password], [Call Firewall] and [SMS Firewall]. - Page 54 then only the numbers saved in your [Contact] can call you. For [Outgoing barring], if [All] is activated you can’t call any number except emergency numbers; if you choose [partly] and edit one set of number, e.g 021, then you can’t call any number starting with 021; if you activate [Contact only], then you can only call the numbers saved in your [Contact].
-
Page 55: Tools
Note： （1）The UIM card will be locked if you enter the wrong PIN code 3 time continuously. （2）You can only enter the right PUK code to unlock your phone once the UMI card is locked. Please contact you operator to get the PUK. -
Page 56: Memo
10.2 Memo In idle screen, go to [Menu/Tools/Memo] to display all the memos. If no record, press left softkey to add one memo; if there’re records, press left softkey to [View], [Edit], [Add], [Delete] or [Delete All]. View: to check the current record Edit: to edit the current record Add: to add a new record Delete: to delete the current record... -
Page 57: World Time
records). Once stopped, press left softkey to reset and right softkey to exit. 10.5 World time This feature can help you to check the time for different cities all over the world. Press to choose the city you want to check. 10.6 USB disk You can use your phone as a USB disk. -
Page 58: Game
Note： The phone can’t identify the mid and MP3 files in other folders except “Music”.Please only save them in “MUSIC” or the root directory of the removable disk. To save power please deactivae this function if you don’t use it. Since the configuration of each computer is quite diferent, to avoid any compatibility problem please only use the USB interface at the backside of the... -
Page 59: Push Box
Move right Drop the brick Pause Activate or deactivate the music effect Replay (Left Soft Key) Exit (Right Soft Key) 11.2 Push box The aim of this game is to push the box to the designated position. Function Last level Next Level Go up Go left... -
Page 60: Gallery
Go down Activate or deactivate the music effect 12 Gallery 12.1 SD Card Press the left softkey to access the following list: [Play], [Set as ringtone], [Set as SMS alert], [Set as alarm tone], [Delete], [Delete All], [Rename] and [Property]. Note：... -
Page 61: Memory Status
12.2 Memory Status To check the memory status for [Phone] and [SD Card] Characters Symbols Table To enter a word in normal mode, press the key corresponding to the desired letter several times until the letter appears. Upper Case Lower Case . - Page 62 D E F 3 d e f 3 G H I 4 g h I 4 J K L 5 j k l 5 M N O 6 m n o 6 P Q R S 7 p q r s 7 T U V 8 t u v 8 W X Y Z 9...
-
Page 63: Warranty
In dialing mode: long press to enter P (for extention) In idle screen: long press to change to vibrator In main menu: go to right function This table is given for information purposes only. It may vary depending on the language and the model. Symbols Bar: Short press key to display the symbols bar:... - Page 64 The warranty period may vary if overriding statutory provisions are applicable in your country. The life of a rechargeable Alcatel telephone battery in terms of conversation time, standby time, and total service life, will depend on the conditions of use and network configuration. Batteries being considered...
- Page 65 and labour but excludes any other costs. Repair or replacement may be carried out using reconditioned components offering equivalent functionality. Servicing under the terms of this warranty, especially repair, modification or replacement of products, shall entitle to a THREE (3) month warranty unless there are statutory provisions to the contrary.
- Page 66 the approved maintenance centre, 7) use of the equipment for a purpose other than that for which it was designed, 8) normal wear, 9) malfunctions caused by external causes (e.g., radio interference from other equipment, power or telephone line voltage fluctuations), 10) modifications made to the equipment even if required by changes in regulations and/or modification of network parameters, 11) faulty connections resulting from unsatisfactory radio transmission or...
-
Page 67: Accessories
15. Accessories Battery Data Cable （T5001985AAAA） （T5001431AAAA） Only use your phone with Alcatel batteries, chargers and accessories compatible with your model. -
Page 68: Troubleshooting
Charger Headset （T5000436**AA） （T5000361AAAA） 16. Troubleshooting Before contacting the aftersales department, you are advised to follow the instructions below: You are advised to switch off the phone from time to time to optimize its performance. You are advised to fully charge the battery ( ) for optimal operation. - Page 69 +40 Make sure your battery is inserted. It must be inserted before plugging in the charger Make sure you are using Alcatel Battery and charger UIM card error: Make sure the UIM card was correctly inserted Make sure that your UIM card is still valid Make sure the chip on your UIM card is clean, not damaged or scratched.
- Page 70 Enter PUK to unlock the phone. Unable to make outgoing calls: Make sure you have dialed a valid number For international calls, make sure you have entered the country code and area codes Make sure your phone is connected to a network, and that the network is not overloaded or unavailable Check your subscription with your operator (credit, UIM card valid, etc)
- Page 71 Check with your operator that your UIM card is still valid Try connecting at a later time if the network is overloaded. The music file in SD card can’t be identified: Number limitation In root directory of SD card: whether the number of mid file exceeds 100 In root directory of SD card: whether the number of MP3 file exceeds 100...
- Page 72 Forward key Alcatel logo and Alcatel name are trademarks of Alcatel used under license by T&A Mobile Phones Limited. All rights reserved. © Copyright 2007 T＆A Mobile Phones Limited T&A Mobile Phones Limited reserves the right, in the customer’s interest, to alter material or...
