FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 2 REFRIGERATOR INSTRUCTION MANUAL FR-2701 MODEL NO .: Thank you for selecting this refrigerator. Before using the refrigerator, please read this manual carefully.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 1 FEATURE CHART ICE TRAY VEGETABLE CASE COVER F SHELF (MOVABLE) VEGETABLE CASE FREEZER TEMPERATURE CONTROL FREEZER POCKET KNOB FREEZER POCKET ICE BOX UTILITY POCKET CHILLED CASE EGG CASE LAMP COVER BOTTLE POCKET (LARGE)
Page 3
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 2 Here are the features of your new refrigerator. Take a moment to know all the features designed for the convenience of the user. Ice Tray Fill 3/4 of the ice tray with water, as the volume expands when the water is frozen. Place the tray in the freezer compartment.
Page 4
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 3 ¡ ¡ Æ Æ Lamp Cover To remove the lamp cover 1. Push up the bottom end of the lamp cover gently, then pull out. 2. Reverse procedure to join together. ¡ ¡ Æ Æ Vegetable case May be used for fruit and vegetable storage.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 4 METHODS OF SAFE INSTALLATION 1. SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR • Place the refrigerator on a • Place your refrigerator • Place the refrigerator in an strong and level floor. where there is no heat...
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 5 2. INSTALLATION STEPS • Select a safe place to install • Level the refrigerator by • Install the parts in their own your refrigerator. using the adjustable feet. place. Maintain ~ Level •...
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 6 3. WHAT YOU NEED TO KNOW BEFORE MOVING OR RELOCATING THE REFRIGERATOR! • Unplung the power cord. • Remove the grille with driver • Take food out of the and water from the defrost- refrigerator.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 7 4. CLEANING YOUR REFRIGERATOR • Before you clean the • The refrigerator may smell • Use a soft cloth for cleaning refrigerator, unplug the during the initial operation, the interior and exterior of power cord.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 8 How to Install Location Install the refrigerator in a convenient location away from extreme heat and cold. Allow at least 6cm clearance between the refrigerator and side wall so that the door may open for a fully usable interior and the refrigerator may have good air circulation.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 9 How to operate 1. TEMPERATURE CONTROL Temperature is controlled by thermostat automatically. The Temperature Control inside the refrigerator controls the degree of cooling for each compartment. Freezer Temperature Control Refrigerator Temperature Control WINTER TEMP.
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 10 Turn the temperature control in the refrigerator and freezer compartments toward WINTER for colder temperature and toward MIN for warmer temperature. Allow approximately 12 hours or overnight for the temperature to stabilize.
Page 12
FR-2701(¿ ) 00.11.13 5:58 PM ˘ ` 11 WHAT TO DO... When not operating for a long time Remove the power supply cord. Dry your refrigerator by opening the door for 2-3 days. When you get ready to move Securely fasten movable interior parts (or remove and pack them separately) DO NOT lay down your refrigerator horizontally, or the compressor may be damaged.
) 00.11.13 5:58 PM ˘ ` 12 REFRIGERATOR WARRANTY Daewoo Electronics Canada Inc. (also known as DECI) warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 years labour and 1 years parts, plus an additional 4 years part warranty on COMPRESSOR only, from the date of original purchase.
