Service Manual
Refrigerator
Model: FR-2701
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : FR27010010
FR-2702
Advertisement
Table of Contents
Related Manuals for Daewoo FR-2701
Summary of Contents for Daewoo FR-2701
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
-
Page 2: Table Of Contents
CONTENTS 1. Specification -----------------------------------------------------------------------------------------------1 2. External view ----------------------------------------------------------------------------------------------2 3. Wire diagram ---------------------------------------------------------------------------------------------3 4. Name of parts---------------------------------------------------------------------------------------------4 5. Air flow diagram-----------------------------------------------------------------------------------------5 6. Refrigerant cycle diagram ----------------------------------------------------------------------------6 7. Machine room view and part list-------------------------------------------------------------------7 8. Main components ---------------------------------------------------------------------------------------8 9. Door color specification -------------------------------------------------------------------------------11 10. -
Page 3: Specification
1. SPECIFICATION MODEL NAME FR-2701 FR-2702 120g 120g Refirgerant R134a 105g 105g Cooling System Fan Cooling Convection Type Refrigeration System Air Forced Convection Defrost System Forced Fin-enaporator Type Defrost Operation Automatic Start & Stop Cold Control Adjustable Dial Freezer Capacity... -
Page 4: External View
2. EXTERNAL VIEW FR-2701 FR-2702... -
Page 5: Wire Diagram
3. WIRE DIAGRAM BLACK BLACK L/BL COMPRESSOR BLACK BLACK BLACK BLUE BLUE PINK PINK TEMP. LAMP WHITE BLUE BI-METAL FUSE 77ûC P-RELAY WHITE YELLOW D HEATER WHITE GRAY BROWN BROWN PINK BROWN THERMOSTAT WHITE POWER GR/YW YELLOW CORD WH-BL BROWN YELLOW WHITE DEFROST TIMER... -
Page 6: Name Of Parts
4. NAME OF PARTS 1 Case Icing 2 Freezer Shelf (Removable) 3 Freezer Temperature Control Knob 4 Case Ice 5 Case Child 6 Lamp Cover (Shade R) 7 Refrigerator Temperature Controller 8 Refrigerator Shelf (Removable) 9 Glass Shelf (Cover Case Vegetable) 10 Case Vegetable 11 Freezer Pocket (Pocket F *T) -
Page 7: Air Flow Diagram
5. AIRE FLOW DIAGRAM Air circulation in the freezer compartment Cold air flow comes out from the upper hole and comes into the lower hole in louver. Freezer room Do not put in any breakable -18 C bottle -18 C -18 C Freezer compartment door pocket Do not store ice cream or frozen... -
Page 8: Refrigerant Cycle Diagram
6. REFRIGERANT CYCLE DIAGRAM SIDE PLATE PIPE SUC.PIPE ACCUM CAPI-TUBE DRYER AS PIPE CON(DEL) COMP PIPE CON(SUC) -
Page 9: Machine Room View And Part List
7. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME CABINET AS COMPRESSOR FOOT ADJ COVER CAB AS PIPE SERVICE CASE VAPORI BASE CAB AS SWITCH P-RELAY AS HARNESS TIMER AS PIPE HOT CLAMP RELAY COVER BRACKET EARTH PIPE *S PLT COVER P-RELAY WIRE EARTH... -
Page 10: Main Components
8. MAIN COMPONENTS 1. COMPRESSOR Refrigerant Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Comp. model EL19J-1 FL19J-2 KL19J-5 PL19J-4 SL21YE-5 Part code 3953119330 3951119320 3958119350 3956119340 3954121A50 Strating type RSCR RSIR CSIR RSCR RSIR Refrigerant R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz... - Page 11 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec. 3210DWNFQ-1 3210DWNFO-1 3210DWNFP-1 3210DWNFR-1 Part code 3015900430 3015900410 3015900420 3015900400 6. DEFROST HEATER (FR-2701, 2702) Refrigerant R12, R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec. 110V/110W...
- Page 12 POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011315000 CP-2PIN FOR EUROPEAN COUNTRY 401RA17200 CP-2PIN FOR OTHER COUNTRY 4006D17101 KP-30 FOR AMERICA 401PD17101 KP-211 FOR JAPAN & TAIWAN 3011300801 BP-3PIN 3011303010 #267 FOR CHILE 3011315310 FOR ISRAEL FOR U.K, MIDDLE ASIA 3011303050 BS-1363A...
-
Page 13: Door Color Specification
9. DOOR COLOR SPECIFICATION 9. CABINET AND DOOR COLOR SPECIFICATION 1. ASSEMBLY URETHAN FREEZER DOOR (FR-2701) 1) FR-2701 Refrigerant R134a Dull lamina High glossy High glossy Dull lamina High glossy High glossy Color type Normal PCM Normal PCM sheet lamina sheet... - Page 14 COLOR TABLE 1. PCM type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) '97 BEIGE (BE215)
- Page 15 2. Lamina sheet type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) S/GOLD G/GREEN...
-
Page 16: Exploded View And Parts List
10. EXPLODED VIEW AND PARTS LIST 1. Exploded view... - Page 17 2. Parts list Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) PART CODE PART NAME...
- Page 18 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 6-1-2 7112401611 SCREW TAPPING T1 TRS 4 X16 MFZN 6-1-3 4010Y36211 BUSHING R HNDL 3012306100 GASKET F DR AS PVC+MAGENT 3019007800 POCKET F *T GPPS 3019007900 POCKET F *U GPPS ASSY R DOOR DOOR R URT AS PRE+URT REFER TO # 11...
