GE CVM2072SMSS Dimension Manual

CVM2072SMSS
GE Café 2.0 Cu. Ft. Over-the-Range Microwave Oven
Dimensions and Installation Information (in inches)
Note: Requires 120V grounded outlet. Electrical receptacle must be
located in cabinet above Spacemaker microwave oven. No additional
wiring, venting or cabinet rebuilding necessary in many cases. Complete
detailed, easy-to-follow installation instructions and convenient full-size
templates are packed with the Spacemaker microwave oven.
Important Information: When installing the Spacemaker microwave
oven over a range, allow minimum of 2" from bottom of Spacemaker
microwave oven to top of range backguard to allow for removal
of light covers.
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
or
™
service,
2070 Dimensions (in inches)
24-1/2
105°
Door open
29-7/8
66" MIN.
30"
Mounting
MIN.
height
width
from
required
floor
12"
MIN.
15-7/16
16-11/32
(rear)
16-11/32
Specification Created 4/07
Exhaust outlet
connects to
3-1/4" X 10" duct
Listed by
Underwriters
Laboratories
240261
