Internal Connectors - Gigabyte GA-H81M-S2PV User Manual

1-7

Internal Connectors

11
3
4
8
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA3 0/1
6) SATA2 2/3
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1
10 9 7
7) F_PANEL
8) F_AUDIO
9) F_USB1/F_USB2
10) LPT
11) BAT
12) CLR_CMOS
- 12 -
2
6
5
12
