- Page 1 User Manual Washing Machine EWF 8040 W - EWF 10040 W...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual.
-
Page 4: Table Of Contents
4 contents electrolux Contents Safety information......5 Product description ......7 Control panel ........8 Use............9 Washing hints ........15 International wash code symbol ..18 Washing programme ....19-20 Programme information ....21 Care and cleaning ......22 Something not working....25 Techical data ........29 Consumption values ......30 Installation ........31... -
Page 5: Safety Information
5 ● Safety Information Wash small items such as socks, laces, washable belts etc in a washing bag or pillow case as it is possible for such items to slip down between the tub and the inner drum. - Page 6 6 safety information electrolux ● ● If the appliance is installed in a Never use the washing machine if location subject to frost, please read the power supply cable, the control the “dangers of freezing”chapter. panel, the working surface or the base are damaged so that the inside ●...
-
Page 7: Product Description
7 Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. The ECO valve system allows total use of detergent and reduces water consumption so saving energy. -
Page 8: Control Panel
8 electrolux control panel Control panel Programme selector dial Spin reduction button Options button Extra Rinse button Start/Pause button Delay Start button Programme progress display... -
Page 9: Use
9 Measure out the detergent and the fabric softener Pull out the dispenser drawer until it First Use stops. Measure out the amount of detergent required, pour it into the main wash compartment and, if you wish to carry out the “prewash” phase, pour Ensure that the electrical and water ●... - Page 10 10 electrolux use Select the required programme Programme Option buttons Turn the programme selector dial to the Depending on the programme, different required programme. functions can be combined. These must The light Start/Pause starts to flash. be selected after choosing the desired programme and before depressing the Start/Pause button.
- Page 11 11 Select the Daily , Light Night Cycle : by selecting this Quick options option, the machine will not drain the water of the last rinse, so as not to Press the Options button wrinkle the laundry. repeatedly, to select the desired option.
- Page 12 12 electrolux use Select the Start/Pause Cottons Daily Light Quick Normal temp. mins. mins. mins. mins. 95° 60° 50° 40° 30° Synthetics 60° To start the selected programme, press 50° the Start/Pause” button; the 40° corresponding green pilot light stops 30°...
- Page 13 13 Select the Delay start The Delay Start can not be selected with Drain programme. Programme progress display Before you start the programme, if you wish to delay the start, press the Delay Start button repeatedly, to select the desired delay.
- Page 14 14 electrolux use emptied out. Start the new programme At the end of the programme by depressing the Start/Pause button The machine stops automatically. again. If the “Rinse Hold” or “Night Cycle” option has been selected, the Interrupting a programme phase lights “end”...
-
Page 15: Washing Hints
15 Washing hints Rub particularly soiled areas with a special detergent or detergent paste. Treat curtains with special care. Remove hooks or tie them up in a bag or net. Sorting the laundry Maximum loads Follow the wash code symbols on each Recommended loads are indicated in garment label and the manufacturer’s... - Page 16 16 electrolux washing hints Oil based paint: moisten with benzine Detergents and additives stain remover, lay the garment on a soft Good washing results also depend on cloth and dab the stain; treat several the choice of detergent and use of the times.
- Page 17 17 Follow the product manufacturer’s recommendations on quantities to use and do not exceed the «MAX» mark in the detergent dispenser drawer. Quantity of detergent to be used The type and quantity of detergent will depend on the type of fabric, load size, degree of soiling and hardness of the water used.
-
Page 18: International Wash Code Symbol
18 electrolux International wash code symbol International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature... -
Page 19: Washing Programme
19 Washing programmes Programme/ Description of Type of laundry Options Temperature programme White cotton (heavy soiled cotton items): Main wash at 95°C e.g. sheets, 3 rinses Cottons 95° tablecloths, household Long spin linen. White and fast coloured cotton Main wash at 60°C... - Page 20 20 electrolux washing programmes Washing programmes Programme/ Description of Type of laundry Options Temperature programme Synthetic or mixed Main wash at 60°- fabrics, underwear, Synthetics 50°-40°-30°C coloured garments, 60°-50°-40°-30° 3 rinses non-shrink shirts, Short spin blouses. Main wash at 40°- Delicate fabrics, for 30°C...
-
Page 21: Programme Information
21 Programme information This programme can be selected for slightly or normally soiled cotton items. The temperature will decrease and the washing time will be extended. This allows to obtain a good washing efficiency by saving energy. -
Page 22: Care And Cleaning
22 electrolux care and cleaning Care and cleaning Cleaning the dispenser drawer The washing powder and additive dispenser drawer should be cleaned regularly. Remove the drawer by pressing the You must DISCONNECT the appliance catch downwards and by pulling it out. - Page 23 23 electrolux care and cleaning • Remove any objects from the pump Cleaning the pump impeller by rotating it. The pump should be inspected if • the machine does not empty and/or spin • the machine makes an unusual noise during draining due to objects such as safety pins, coins etc.
- Page 24 24 electrolux care and cleaning Never remove the pump cover during a wash cycle, always wait until the appliance has finished the cycle, and is Important! empty. When replacing the cover, ensure Every time you drain the water through it is securely retightened so as to stop...
-
Page 25: Something Not Working
25 Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. - Page 26 26 electrolux something not working Malfunction Possible cause Solution The machine does not The drain hose is squashed Check the drain hose ● ● empty and/or does not spin: or kinked. (Red Start/ connection. Pause pilot light flashes) The drain pump is clogged.
- Page 27 27 Malfunction Possible cause Solution The machine vibrates or is The transit bolts and Check the correct ● ● noisy: packing have not been installation of the appliance. removed. The support feet have not Check the correct levelling ●...
- Page 28 28 electrolux something not working If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information.
-
Page 29: Techical Data
29 Technical data Dimensions Width 60 cm Height 85 cm Depth 63 cm Electrical connection Voltage Information on the electrical connection is given on - Overall power - Fuse the rating plate on the inner edge of the appliance... -
Page 30: Consumption Values
30 electrolux Consumption value Consumption values Programme Programme Energy Water duration consumption consumption (in minutes) (in kWh) (in litres) Cottons 95° 0,85 Cottons 60°+ Cottons 60° Cottons 40°+ Cottons 95°+ 2,05 Cottons 60°+ 1,35 Synthetics 60° 0,75 Delicates 40° Wool 40°... -
Page 31: Installation
31 Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the 4. Unscrew and remove the two large... - Page 32 32 electrolux installation 6. Open the porthole, take out the inlet Accurate levelling prevents vibration, hose from the drum and remove the noise and displacement of the machine polystyrene block fitted with the during operation.Never place cardboard, adhesive tape on the door seal.
- Page 33 33 After positioning the inlet hose, be sure to tighten the ring nut again to prevent leaks. 4. Connect the hose to a tap with a 3/4” thread. Always use the hose supplied with the appliance. The inlet hose must not be lengthened.
- Page 34 34 electrolux installation Electrical connection This machine is designed to operate on a 220-230 V, single-phase, 50 Hz supply. Check that your domestic electrical installation can take the maximum load required (2.2 kW), also taking into account any other appliances in use.
-
Page 35: Environment Concerns
35 Environment concerns Ecological hints Packaging materials To save water, energy and to help protect the environment, we recommend that you follow these tips: The materials marked with the symbol • Normally soiled laundry may be are recyclable. -
Page 36: Guarantee Conditions
36 electrolux guarantee conditions European guarantee This appliance is guaranteed by Electrolux, in each of the countries listed in the following page, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of these... -
Page 37: Customer Service Centres
Suomi +35 8 26 22 33 00 Konepajanranta 4, 28100 Pori Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm Tarlabași caddesi no : 35 Taksim Istanbul Türkiye +90 21 22 93 10 25 Россия... - Page 40 ANC number: 132 975 483-00-032009...
