Page 4: Safety Hints
SAFETY HINTS - Read these instructions - Keep these instructions - Heed all warnings - Follow these instructions Caution: To reduce the risk of electrical shock, do not remove the cover. Or expose this appliance to rain or moisture. No user serviceable parts insi- de;... - Page 5 If you keep to the guidelines set out in this manual, you will soon be able to appreciate the quality of this new Warwick amplifier. Please keep this instruction booklet handy in case you need to consult it again. Please send the PASSPORT to the address indicated therein.
-
Page 6: Protective Circuits
PROTECTIVE CIRCUITS Your new Warwick amplifier is equipped with a series of circuits to prevent it from destruction in case of inadequate ope- rating conditions: Power-up delay: When the unit is switched on, the SPEAKER OUT sockets are activated with a slight delay to protect the loudspeakers. -
Page 7: Front Panel Controls
FRONT PANEL CONTROLS TUBE ROUGH/ GAIN CONTOUR SMOOTH 2ND STAGE MASTER MUTE POWER TUBEPATH 5.1 500 WATTS TUBE DRIVEN BASS AMPLIFIER INPUT BOOST BASS MID 1 SHIFT SHIFT MID 2 TREBLE BOOST PHONES INPUT Socket to plug in a bass guitar. LOW BOOST Switch + LED to boost low end. - Page 8 FRONT PANEL CONTROLS INPUT socket to plug in a bass guitar. GAIN control + CLIP LED to adjust the input level*. -10 dB PAD switch to set the range of the GAIN control. Use it with high output basses. COMPRESSOR switch + 2-colored ON/COMPRESS LED to compress the signal.
-
Page 9: Rear Panel Controls
Otherwise it is the signal after the tone controls and any connected effects devices have done their work (POST) DI OUT Balanced output for the connection to a mixing desk (PA or Studio). SPEAKER OUT Lockable Coaxial Speaker Connection and 1/4" jack socket (only X-TREME 5.1) are connected parallel. - Page 10 TECHNICAL DATA TUBEPATH 5.1 / 10.1 Input 25 mV Tubes 2x ECC 83 / 1x EL84 (2nd Stage) Poweramp fan cooled (temperature controlled) Green LED Indicates the optimal level for clean sound Gain Orange LED Indicates the tube saturation for crunch sound.
-
Page 11: Simplified Diagram
SIMPLIFIED DIAGRAM CONNECT SPEAKERS Note: The minimum load of the power amplifier is 4 ohms. Speaker Set-up Impendance Quantity 16 ohms Cabinets 8 ohms Cabinets 6 ohms Cabinet 4 ohms Cabinet... - Page 12 0dB, 600 ohms return 0dB, 10k ohms Switches Rear Groundlift, DI pre/post jack (X-Treme 5.1 only) and lockable coaxial Speaker Out 500 W / 4 ohms (X-Treme 5.1) 1.000 W / 4 ohms (X-Treme 10.1) < 0.1 % (power amp) 15.2 kg (X-Treme 5.1)
- Page 13 SIMPLFITIED DIAGRAM X-Treme CONNECT SPEAKERS FUSE: FUSE: 115 V ~ 15 ~ 15 A A 230 V 230 V ~ 8 A Note: The minimum load of the power amplifier is 4 ohms. Speaker Set-up Cabinet WCA 411 Pro (8 ohms) Impendance Quantity 16 ohms Cabinets...
