Page 15: General
1.0 General 1.1 Introduction This document describes the specifications of the Deskstar 7K400, a 3.5-inch, 7200-rpm hard disk drive with the following model numbers: • HDS724040KLAT80 / HDS724040KLSA80 (400 GB) These specifications are subject to change without notice. 1.2 References •...
Page 16 1,000,000,000 bytes ground hexadecimal hard disk drive Hertz Input integrated lead suspension Input/Output International Standards Organization 1,000 bytes Kbpi 1000 bits per inch kgf-cm kilogram (force)-centimeter kilohertz logical block addressing unit of A-weighted sound power meter maximum 1,000,000 bytes Mbps 1,000,000 bits per second megahertz Machine Level Control...
Page 17: Caution
reset read/write second SELV secondary low voltage S.M.A.R.TSelf-Monitoring, Analysis, and Reporting Technology tracks per inch track transistor-transistor logic Underwriters Laboratory volt Verband Deutscher Electrotechniker watt 3-state transistor-transistor tristate logic 1.4 Caution • Do not apply force to the top cover. •...
Page 18 Deskstar 7K400 Hard Disk Drive Specification...
Page 19: General Features Of The Drive
2.0 General features of the drive • Formatted capacities of 400 GB • Spindle speeds of 7200 RPM • Fluid Dynamic Bearing motor • Enhanced IDE interface / Serial ATA interface • Sector format of 512 bytes/sector • Closed-loop actuator servo •...
Page 20 Deskstar 7K400 Hard Disk Drive Specification...
Page 21 Part 1. Functional specification Deskstar 7K400 Hard Disk Drive specification...
Page 22 Deskstar 7K400 Hard Disk Drive Specification...
Page 23: Fixed-Disk Subsystem Description
3.0 Fixed-disk subsystem description 3.1 Control electronics The drive is electronically controlled by a microprocessor, several logic modules, digital/analog modules, and var- ious drivers and receivers. The control electronics performs the following major functions: • Controls and interprets all interface signals between the host controller and the drive. •...
Page 24 Deskstar 7K400 Hard Disk Drive Specification...
Page 25: Drive Characteristics
4.0 Drive characteristics 4.1 Default logical drive parameters Table 1: Formatted capacity HDS724040KLAT20 / HDS724040KLSA80 Physical Layout Label capacity (GB) Bytes per sector Sectors per track 567-1170 Number of heads Number of disks Data sectors per cylinder 5670-11700 Data cylinders per zone 1200 - 4900 Logical layout Number of heads...
Page 26: Data Sheet
Areal density - max (Gbits/in Number of data bands Upper 271 KB is used for firmware 4.3 World Wide Name Assignment Table 3: World Wide Name Assignment Description Organization Hitachi Global Storage Technologies Manufacturing Site Prachiburi, Thailand Product Deskstar 7K400 000CCAh SHBU Block Assignment...
Page 27: Cylinder Allocation
This cylinder contains the user data which can be sent and retrieved via read/write commands and a spare area for reassigned data. Spare cylinder The spare cylinder is used by Hitachi Global Storage Technologies manufacturing and includes data sent from a defect loca- tion. Deskstar 7K400 Hard Disk Drive specification...
Page 28: Performance Characteristics
4.5 Performance characteristics Drive performance is characterized by the following parameters: • Command overhead • Mechanical head positioning Seek time Latency • Data transfer speed • Buffering operation (Look ahead/Write cache) All the above parameters contribute to drive performance. There are other parameters that contribute to the performance of the actual system.
Page 29: Mechanical Positioning
4.5.2 Mechanical positioning 4.5.2.1 Average seek time (including settling) Table 6: Mechanical positioning performance Command type Typical (ms) Max (ms) Read Write 10.2 Read (Quiet Seek mode) 19.5 20.5 Write (Quiet Seek mode) 20.5 21.5 The terms “Typical” and “Max” are used throughout this document and are defined as follows: Typical The average of the drive population tested at nominal environmental and voltage conditions.
Page 30: Drive Ready Time
4.5.2.3 Head switch time (head skew) Head switch time-typical (ms) Head switch time is defined as the amount of time required by the fixed disk to complete a seek of the next sequential track after reading the last sector in the current track 4.5.2.4 Cylinder switch time (cylinder skew) Cylinder switch time is defined as the amount of time required by the fixed disk to access the next sequential block after read- ing the last sector in the current cylinder.
Page 31: Data Transfer Speed
4.5.4 Data transfer speed Table 11: Data transfer speed Data transfer speed (Mbytes/sec) Disk-Buffer transfer (Zone 0) Instantaneous - typical 72.1 Sustained - read typical 61.5 Disk-Buffer transfer (Zone 29) Instantaneous - typical 34.9 Sustained - read typical 29.8 Buffer - host (max) 133 (PATA), 150 (SATA) •...
Page 32: Throughput
4.5.5 Throughput 4.5.5.1 Simple sequential access The following table illustrates simple sequential access for the enclosure. Table 12: Simple Sequential Access performance Operation Typical (sec) Max (sec) Sequential Read (Zone 0) 0.32 Sequential Read (Zone 29) 0.63 The above table gives the time required to read a total of 8000h consecutive blocks (16,777,216 bytes) accessed by 128 read commands.
Page 33: Operating Modes
4.5.6 Operating modes 4.5.6.1 Description of operating modes Table 14: Description of operating modes Operating mode Description Start up time period from spindle stop or power down. Spin-up Seek operation mode Seek Write operation mode Write Read operation mode Read Spindle rotation at 7200 RPM with heads unloaded.
Page 34 Deskstar 7K400 Hard Disk Drive Specification...
Page 35: Defect Flagging Strategy
5.0 Defect flagging strategy Media defects are remapped to the next available sector during the Format Process in manufacturing. The mapping from LBA to the physical locations is calculated by an internally maintained table. Shipped format • Data areas are optimally used. •...
Page 36 Deskstar 7K400 Hard Disk Drive Specification...
Page 37: Specification
6.0 Specification 6.1 Electrical Interface 6.1.1 Connector location Refer to the following illustration to see the location of the connectors: PATA Model SA TA M odel Deskstar 7K400 Hard Disk Drive Specification...
Page 38: Dc Power Connector
6.1.2 DC Power connector The DC power connector is designed to mate with AMP part number 1-480424-0 using AMP pins part number 350078-4 (strip), part number 61173-4 (loose piece), or their equivalents. Pin assignments are shown in the figure below. Voltage +12 V 6.1.3 AT signal connector...
Page 39: Signal Definitions (Pata Model)
6.2 Signal definitions (PATA model) The pin assignments of interface signals are listed as follows: Table 17: Signal definitions SIGNAL Type SIGNAL Type RESET- 3–state DD08 3–state 3–state DD09 3–state 3–state DD10 3–state 3–state DD11 3–state 3–state DD12 3–state 3–state DD13 3–state 3–state...
Page 40: Signal Descriptions
6.3 Signal descriptions Table 18: Special signal definitions for Ultra DMA Special Definition Conventional (for Ultra DMA) Definition DDMARDY- IORDY Write Operation HSTROBE DIOR- STOP DIOW- HDMARDY- DIOR- Read Operation DSTROBE IORDY STOP DIOW- DD00–DD15 A 16-bit bi-directional data bus between the host and the drive. The lower 8 lines, DD00-07, are used for Regis- ter and ECC access.
Page 41 DASP- This is a time-multiplexed signal which indicates that a drive is active or that device 1 is present. This signal is driven by an Open-Drain driver and internally pulled up to 5 volts through a 10 kW resistor. During a Power-On initialization or after RESET- is negated, DASP- shall be asserted by Device 1 within 400 ms to indicate that device 1 is present.
Page 42 DMACK- This signal shall be used by the host in response to DMARQ to either acknowledge that data has been accepted, or that data is available. This signal is internally pulled up to 5 Volt through a 15kΩ resistor with a resistor tolerance value of –50% to +100%.
Page 43: Interface Logic Signal Levels (Pata Model)
6.4 Interface logic signal levels (PATA model) The interface logic signals have the following electrical specifications: Input High Voltage 2.0 V min Inputs Input Low Voltage –0.8 V max. Output High Voltage 2.4 V min. Outputs: Output Low Voltage 0.5 V max. 6.4.1 Signal definition (SATA model) SATA has receivers and drivers to be connected to Tx+/ - and Rx +/- Serial data signal defines the signal names of I/O connec- tor pin and signal name.
Page 44: Out Of Band Signaling (Sata Model)
6.4.1.1 TX+ / TX These signal are the outbound high-speed differential signals that are connected to the serial ATA cable. 6.4.1.2 RX+ / RX These signals are the inbound high-speed differential signals that are connected to the serial ATA cable. The following standard shall be referenced about signal specifications.
Page 45: Signal Timings (Pata Model)
6.5 Signal timings (PATA model) 6.5.1 Reset timings Table 22: System reset timing chart RESET- BUSY PARAMETER DESCRIPTION Min (µs) Max (µs) RESET low width RESET high to not BUSY Deskstar 7K400 Hard Disk Drive Specification...
Page 46: Pio Timings
6.6 PIO timings The PIO cycle timings meet Mode 4 of the ATA/ATAPI-6 description. Table 23: PIO cycle timings chart CS(1:0)- DA(2:0) DIOR-, DIOW - W rite data DD(15:0) Read data DD(15:0) t7(*) t8(*) IOCS16-(*) IORDY (*) Up to ATA-2 (mode-0,1,2) PARAMETER DESCRIPTION MIN (ns) MAX (ns)
Page 47: Read Drq Interval Time
6.6.2 Read DRQ interval time For read sectors and read multiple operations the interval from the end of negation of the DRQ bit until setting of the next DRQ bit is as follows: • In the event that a host reads the status register only before the sector or block transfer DRQ interval, the DRQ interval 4.2 µs •...
Page 48: Multi Word Dma Timings
6.7 Multi word DMA timings The Multiword DMA timings meet Mode 2 of the ATA/ATAPI-6 description. Table 24: Multiword DMA cycle timing chart CS0-/CS1- tLR/tLW DMARQ DMACK- tKR/tKW DIOR-/DIOW- READ DATA WRITE DATA Table 25: Multiword DMA cycle timings PARAMETER DESCRIPTION MIN (ns) MAX (ns) Cycle time...
Page 49: Ultra Dma Timings
6.8 Ultra DMA timings The Ultra DMA timings meet Mode 0, 1, 2, and 4 of the Ultra DMA Protocol. 6.8.1 Initiating Read DMA Table 26: Ultra DMA cycle timing chart (Initiating Read) DMARQ DMACK- tACK tENV STOP tACK tENV t2CYC HDMARDY- tZIORDY...
Page 50: Host Pausing Read Dma
6.8.2 Host Pausing Read DMA Table 28: Ultra DMA cycle timing chart (Host pausing Read) DMARQ DMACK- STOP HDMARDY- tRFS DSTROBE Table 29: Ultra DMA cycle timings (Host pausing Read) MODE 0 MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 PARAMETER DESCRIPTION (all values in ns)
Page 51: Host Terminating Read Dma
6.8.3 Host Terminating Read DMA Table 30: Ultra DMA cycle timing chart (Host terminating Read) DMARQ tMLI DMACK- tACK STOP tACK HDMARDY- tRFS tIORDYZ DSTROBE xxxxxxxxxxxxxxxxxx RD Data xxxxxxxxxxx DD(15:0) tZAH Device drives DD Host drives DD Table 31: Ultra DMA cycle timings (Host terminating Read) MODE 0 MODE 1 MODE 2...
Page 52: Device Terminating Read Dma
6.8.4 Device Terminating Read DMA Table 32: Ultra DMA cycle timing chart (Device terminating Read) DMARQ tMLI DMACK- tACK STOP tACK HDMARDY- tIORDYZ DSTROBE xxxxxx xxxxxxxxxxxxxxxxxx xxxxxxxxxx DD(15:0) tZAH Host drives DD Device drives DD Table 33: Ultra DMA cycle timings (Device Terminating Read) MODE 0 MODE 1 MODE 2...
Page 53: Initiating Write Dma
6.8.5 Initiating Write DMA Table 34: Ultra DMA cycle timing chart (Initiating Write) DMARQ DMACK- tENV tACK STOP tZIORDY t2CYC DDMARDY- tCYC tCYC tACK HSTROBE DD(15:0) xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx WT Data WT Data WT Data Host drives DD Table 35: Ultra DMA cycle timings (Initiating Write) MODE 0 MODE 1 MODE 2...
Page 54: Device Pausing Write Dma
6.8.6 Device Pausing Write DMA Table 36: Ultra DMA cycle timing chart (Device Pausing Write) DMARQ DMACK- STOP DDMARDY- tRFS HSTROBE Table 37: Ultra DMA cycle timing chart (Device Pausing Write) PARAMETER MODE 0 MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 DESCRIPTION...
Page 55: Device Terminating Write Dma
6.8.7 Device Terminating Write DMA Table 38: Ultra DMA cycle timing chart (Device Terminating Write) DMARQ tMLI DMACK- tACK STOP tIORDYZ DDMARDY- tACK tRFS HSTROBE xxx WT Data xxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxx DD(15:0) Host drives DD Table 39: Ultra DMA cycle timings (Device terminating Write) PARAMETER MODE 0 MODE 1...
Page 56: Host Terminating Write Dma
6.8.8 Host Terminating Write DMA Table 40: Ultra DMA cycle timing chart (Host Terminating Write) DMARQ tMLI DMACK- tACK STOP tIORDYZ DDMARDY- tACK HSTROBE xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxx DD(15:0) Host drives DD Table 41: Ultra DMA cycle timings (Host Terminating Write) PARAMETER MODE 0 MODE 1 MODE 2...
Page 57: Addressing Of Registers
6.9 Addressing of registers The host addresses the drive through a set of registers called a Task File. These registers are mapped into the host's I/O space. Two chip select lines (CS0– and CS1–) and three address lines (DA0–2) are used to select one of these registers, while a DIOR–...
Page 58 Deskstar 7K400 Hard Disk Drive Specification...
Page 59: Jumper Settings
7.0 Jumper Settings 7.1 Connector location Jumper pins 7.1.1 Jumper pin identification Pin I Pin A DERA001.prz Pin B Deskstar 7K400 Hard Disk Drive Specification...
Page 60: Jumper Pin Assignment
7.1.2 Jumper pin assignment There are four jumper settings as shown in the following sections: • 16 logical head default (normal use) • 15logical head default • 32 GB clip • Power up in standby Within each of these four jumper settings the pin assignment selects Device 0, Device 1, Cable Selection, or Device 1 Slave Present as shown in the following figures.
Page 61 Notes: 1. To enable the CSEL mode (Cable Selection mode) the jumper block must be installed at E-F. In the CSEL mode the drive address is determined by AT interface signal #28 CSEL as follows: • When CSEL is grounded or at a low level, the drive address is 0 (Device 0). •...
Page 62: Table 43. Jumper Positions For Capacity Clip To 2Gb/32Gb
7.1.3.3 Capacity clip to 32GB The figure below shows the jumper positions used to select Device 0, Device 1, Cable Selection, or Device1 (Slave) Present while setting the drive capacity down to 32 GB for the purpose of compatibility. Table 43: Jumper positions for capacity clip to 2GB/32GB DEVICE 0 (M aster) DEVICE 1...
Page 63 Notes: 1. These jumper settings are used for limiting power supply current when multiple drives are used. 2. Command to spin up is SET FEATURES (subcommand 07h). Refer to 12.28 Set Features. 3. To enable the CSEL mode (Cable Selection mode) the jumper block must be installed at E-F. In the CSEL mode the drive address is determined by AT interface signal #28 CSEL as follows: •...
Page 64: Environment
7.2 Environment 7.2.1 Temperature and humidity Table 45: Temperature and humidity Operating conditions Temperature 5C to 55ºC (See note below) Relative humidity 8 to 90%, non-condensing Maximum wet bulb temperature 29.4ºC, non-condensing Maximum temperature gradient 15ºC/hour Altitude –300 to 3,048 m Non-operating conditions Temperature –40C to 65ºC...
Page 65: Corrosion Test
7.2.2 Corrosion test The drive shows no sign of corrosion inside and outside of the hard disk assembly and is functional after being sub- jected to seven days at 50°C with 90% relative humidity. 7.3 DC power requirements Damage to the drive electronics may result if the power supple cable is connected or disconnected to the legacy power connector while power is being applied to the drive (no hot plug/unplug is alloweed).
Page 66: Power Supply Generated Ripple At Drive Power Connector
Table 49: Power supply current of SATA model Power supply current of SATA +5 Volts [mA] +12 Volts [mA] Total model (values in milliamps. RMS) Pop Mean Std Dev Pop Mean Std Dev Idle average Idle ripple (peak-to-peak) Low RPM Idle Low RPM Idle Ripple Unload Idle average Unload Idle Ripple...
Page 67: Reliability
7.4 Reliability 7.4.1 Data integrity No more than one sector is lost at Power loss condition during the write operation when the write cache option is disabled. If the write cache option is active, the data in write cache will be lost. To prevent the loss of customer data, it is recommended that the last write access before power off be issued after setting the write cache off.
Page 68: Mechanical Specifications
7.5 Mechanical specifications 7.5.1 Physical dimensions and weight 2 5 .4 } 0 .4 1 0 1 .6 } 0 .4 1 4 6 } 0 .6 B R E A T H E R H O L E (*) D ia .
Page 69: Mounting Hole Locations
7.5.2 Mounting hole locations The mounting hole locations and size of the drive are shown below. All dimensions are in mm. (6X) Max. penetration 4.5 mm Side View I/F Connector Bottom View (4X) Max. penetration 4.0 mm Figure 1: Mounting hole locations Thread 6-32 UNC 41.28±0.5...
Page 70: Connector Locations
7.5.3 Connector locations PA TA m odel SATA model 42.73 13.43 (3X) 33.39 5.08+/-0.1 Deskstar 7K400 Hard Disk Drive Specification...
Page 71: Drive Mounting
7.5.4 Drive mounting The drive will operate in all axes (6 directions). Performance and error rate will stay within specification limits if the drive is operated in the other orientations from which it was formatted. For reliable operation, the drive must be mounted in the system securely enough to prevent excessive motion or vibration of the drive during seek operation or spindle rotation, using appropriate screws or equivalent mounting hardware.
Page 72: Vibration And Shock
7.6 Vibration and shock All vibration and shock measurements recorded in this section are made with a drive that has no mounting attach- ments for the systems. The input power for the measurements is applied to the normal drive mounting points. 7.6.1 Operating vibration 7.6.1.1 Random vibration The test is 30 minutes of random vibration using the power spectral density (PSD) levels shown below in each of...
Page 73: Operating Shock
The overall RMS (root mean square) level of vibration is 1.04 G. 7.6.2.2 Swept sine vibration • 2 G (zero-to-peak), 5 to 500 to 5 Hz sine wave • 0.5 oct/min sweep rate • 3 minutes dwell at two major resonances 7.6.3 Operating shock The drive meets the following criteria while operating in the conditions described below.
Page 74: Nonoperating Rotational Shock
7.6.4.2 Sinusoidal shock wave The shape is approximately half-sine pulse. The figure below shows the maximum acceleration level and duration. Table 55: Sinusoidal shock wave Acceleration level (G) Duration (ms) 7.6.5 Nonoperating rotational shock All shock inputs shall be applied around the actuator pivot axis. Table 56: Rotational shock Duration Rad/sec...
Page 75: Acoustics
7.8 Identification labels The following labels are affixed to every drive: • A label containing the Hitachi logo, the Hitachi Global Storage Technologies part number and the statement " Made by Hitachi Global Storage Technologies Inc." or Hitachi Global Storage Technol- ogies approved equivalent.
Page 76: Safety
United Nations Environment Program Montreal Protocol, and as ratified by the member nations. Material to be controlled include CFC-11, CFC-12, CFC-113, CFC-114, CFC-115, Halon 1211, Halon 1301 and Halon 2402. Although not specified by the Protocol, CFC-112 is also controlled. In addition to the Protocol Hitachi Global Stor- age Technologies requires the following: •...
Page 77: Electromagnetic Compatibility
The product is declared to be in conformity with requirements of the following EC directives under the sole responsibility of Hitachi Global Storage Technologies Japan Ltd: Council Directive 89/336/EEC on the approximation of laws of the Member States relating to electromagnetic compatibility.
Page 78 Deskstar 7K400 Hard Disk Drive Specification...
Page 79: General
8.0 General 8.1 Introduction HDS724040KLAT80 / HDS724040KLSA80 This specification describes the host interface of . This is the main inter- face specification which includes the common host interface to both Parallel ATA and Serial ATA (SATA). The interface unique to ProductNameSATA Serial ATA model is described in the "Addendum for Serial ATA" of this specification. The interface conforms to the Working Document of Information technology - AT Attachment with Packet Interface Extension (ATA major revision ATA generation) Revision 4 dated on 23 December 2003 with certain limitations described in 2.0, "Deviations From Standard."...
Page 80 Deskstar 7K400 Hard Disk Drive Specification...
Page 81: Registers
9.0 Registers 9.1 Register set Table 59: Register Set Addresses Functions CS0- CS1- READ (DIOR-) WRITE (DIOW-) Data bus high impedance Not used Control block registers Data bus high impedance Not used Data bus high impedance Not used Alternate Status Device Control Device Address Not used...
Page 82: Alternate Status Register
9.2 Alternate Status Register Table 60: Alternate Status Register DSC/ SERV This register contains the same information as the Status Register. The only difference between this register and the Status Register is that reading the Alternate Status Register does not imply an interrupt acknowledge or a clear of a pending interrupt.
Page 83: Data Register
9.6 Data Register This register is used to transfer data blocks between the device data buffer and the host. It is also the register through which sector information is transferred on a Format Track command and the configuration information is transferred on an Identify Device command.
Page 84: Drive Address Register
9.8 Drive Address Register Table 62: Drive Address Register -WTG -DS1 -DS0 This register contains the inverted drive select and head select addresses of the currently selected drive. Definitions High Impedance. This bit is not a device and will always be in a high impedance state. -WTG Write Gate.
Page 85: Error Register
9.10 Error Register Table 64: Error Register IDNF ABRT TK0NF AMNF This register contains the status from the last command executed by the device or a diagnostic code. At the comple- tion of any command, except Execute Device Diagnostic, the contents of this register are always valid even if ERR = 0 is in the Status Register.
Page 86: Sector Number Register
9.13 Sector Number Register This register contains the starting sector number for any disk data access for the subsequent command. The sector number is from one to the maximum number of sectors per track. In LBA mode, this register contains Bits 0–7. At the end of the command this register is updated to reflect the cur- rent LBA Bits 0–7.
Page 87 Index. IDX=1 once per revolution. Because IDX=1 only for a very short time during each revolu- tion, the host may not see it set to 1 even if the host is continuously reading the Status Register. Therefore the host should not attempt to use IDX for timing purposes. Error.
Page 88 Deskstar 7K400 Hard Disk Drive Specification...
Page 89: General Operation
10.0 General operation 10.1 Reset response ATA has the following three types of resets: The device executes a series of electrical circuitry diagnostics, spins up the Power On Reset (POR) head disk assembly, tests speed and other mechanical parametric, and sets default values.
Page 90: Register Initialization
10.2 Register initialization After a power on, a hard reset, or a software reset, the register values are initialized as shown in the table below. Table 67: Default Register Values Register Default Value Error Diagnostic Code Sector Count Sector Number Cylinder Low Cylinder High Device/Head...
Page 91: Diagnostic And Reset Considerations
10.3 Diagnostic and Reset considerations For each Reset and Execute Device Diagnostic, the diagnostic is done as follows: Power On Reset DASP– is read by Device 0 to determine if Device 1 is present. If Device 1 is present, Device 0 shall read PDIAG– to determine when it is valid to clear the BSY bit and whether Device 1 has powered on or reset without error, otherwise Device 0 clears the BSY bit whenever it is ready to accept commands.
Page 92: Sector Addressing Mode
10.4 Sector Addressing Mode All addressing of data sectors recorded on the device's media is done by a logical sector address. The logical CHS address for HDS7240xxKLATx0 is different from the actual physical CHS location of the data sector on the disk media.
Page 93 The only commands that may be overlapped are NOP (with 01h subcommand code) (’00’h) Read DMA Queued (’C7’h) Service (’A2’h) Write DMA Queued (’CC’h) For the READ DMA QUEUED and WRITE DMA QUEUED commands, the device may or may not perform a bus release.
Page 94: Power Management Features
10.6 Power management features The power management feature set permits a host to modify the behavior in a manner which reduces the power required to operate. The power management feature set provides a set of commands and a timer that enables a device to implement low power consumption modes.
Page 95: Interface Capability For Power Modes
10.6.4 Interface capability for power modes Each power mode affects the physical interface as defined in the following table: Table 70: Power conditions Mode Interface active Media Active Active Idle Active Standby Inactive Sleep Inactive Ready (RDY) is not a power condition. A device may post ready at the interface even though the media may not be accessible.
Page 96: Function
10.7 S.M.A.R.T. Function The intent of Self-monitoring, analysis, and reporting technology (S.M.A.R.T.) is to protect user data and prevent unscheduled system downtime that may be caused by predictable degradation and/or fault of the device. By monitoring and storing critical performance and calibration parameters, S.M.A.R.T. devices employ sophisticated data analysis algorithms to predict the likelihood of near-term degradation or fault condition.
Page 97: Error Log
10.7.7 Error log Logging of reported errors is supported. The device provides information on the last five errors that the device reported as described in the SMART error log sector. The device may also provide additional vendor specific information on these reported errors. The error log is not disabled when SMART is disabled. Disabling SMART disables the delivering of error log information via the SMART READ LOG SECTOR command.
Page 98: Security Mode Feature Set
10.8 Security Mode Feature Set Security Mode Feature Set is a powerful security feature. With a device lock password, a user can prevent unauthorized access to a device even if it is removed from the computer. New commands are supported for this feature as listed below: Security Set Password ('F1'h) Security Unlock...
Page 99: Passwords
10.8.3 Passwords This function can have two types of passwords as described below. Master Password When the Master Password is set, the device does NOT enable the Device Lock Function, and the device CANNOT be locked with the Master Password, but the Master Password can be used for unlocking the locked device.
Page 100 10.8.4.3 Operation from POR after user password is set When Device Lock Function is enabled, the device rejects media access command until a Security Unlock command is successfully completed. Device Locked mode Unlock CMD Erase Prepare Media Access Non-media Access Command (*1) Command (*1) Erase Unit...
Page 101: User Password Lost
10.8.4.4 User Password lost If the User Password is forgotten and High level security is set, the system user cannot access any data. However the device can be unlocked using the Master Password. If a system user forgets the User Password and Maximum security level is set, data access is impossible. However the device can be unlocked using the Security Erase Unit command to unlock the device and erase all user data with the Master Password.
Page 102: Command Table
10.8.5 Command table This table shows the device's response to commands when the Security Mode Feature Set (Device lock function) is enabled. Table 71: Command table for device lock operation Device Mode Device Mode Command Command Locked Unlocked Frozen Locked Unlocked Frozen Check Power Mode...
Page 103: Host Protected Area Feature
10.9 Host Protected Area Feature Host Protected Area Feature provides a protected area which cannot be accessed via conventional methods. This protected area is used to contain critical system data such as BIOS or system management information. The contents of the main memory of the entire system may also be dumped into the protected area to resume after a system power off.
Page 104: Security Extensions
3. Conventional usage without system software support Since the drive works as a 6.2 GB device, there is no special care required for normal use of this device. 4. Advanced usage using protected area The data in the protected area is accessed by the following steps. i.
Page 105: Seek Overlap
10.10 Seek overlap HDS7240xxKLATx0 provides an accurate method for measuring seek time. The seek command is usually used to measure the device seek time by accumulating the execution time for a number of seek commands. With typical implementation of seek command this measurement must include the device and host command overhead. To eliminate this overhead the drive overlaps the seek command as described below.
Page 106: Write Cache Function
10.11 Write cache function Write cache is a performance enhancement whereby the device reports the completion of the write command (Write Sectors, Write Multiple, and Write DMA) to the host as soon as the device has received all of the data into its buffer. The device assumes the responsibility for subsequently writing the data onto the disk.
Page 107: Reassign Function
10.12 Reassign function The Reassign function is used with read commands and write commands. The sectors of data for reassignment are prepared as the spare data sector. This reassignment information is registered internally and the information is available right after completing the Reassign function.
Page 108: Power-Up In Standby Feature Set
10.13 Power-Up in Standby feature set The Power-Up In Standby feature set allows devices to be powered-up into the Standby power management state to minimize inrush current at power-up and to allow the host to sequence the spin-up of devices. This feature set will be enabled and disabled via the SET FEATURES command or the use of a jumper.
Page 109: Advanced Power Management Feature Set (Apm)
10.14 Advanced Power Management feature set (APM) This feature allows the host to select an advanced power management level. The advanced power management level is a scale from the lowest power consumption setting of 01h to the maximum performance level of FEh. Device performance may increase with increasing advanced power management levels.
Page 110: Automatic Acoustic Management Feature Set (Aam)
10.15 Automatic Acoustic Management feature set (AAM) This feature set allows the host to select an acoustic management level. The acoustic management level ranges the setting of 80h to FEh. Device performance and acoustic emanation may increase with increasing acoustic management levels.
Page 111: Address Offset Feature
10.16 Address Offset Feature Computer systems perform initial code loading (booting) by reading from a predefined address on a disk drive. To allow an alternate bootable operating system to exist in a system reserved area on a disk drive this feature provides a Set Features function to temporarily offset the drive address space.
Page 112: Enable/Disable Address Offset Mode
10.16.1 Enable/Disable Address Offset Mode Set Features subcommand code 09h Enable Address Offset Mode offsets address Cylinder 0, Head 0, Sector 1, LBA 0, to the start of the non-volatile protected area established using the Set Max Address command. The offset condition is cleared by Subcommand 89h Disable Address Offset Mode, Hardware reset or Power on Reset.
Page 113: 48-Bit Address Feature Set
10.17 48-bit Address Feature Set The 48-bit Address feature set allows devices with capacities up to 281,474,976,710,655 sectors. This allows device capacity up to 144,115,188,075,855,360 bytes. In addition, the number of sectors that may be transferred by a single command are increased by increasing the allowable sector count to 16 bits. Commands unique to the 48-bit Address feature set are •...
Page 114: Streaming Commands
• Write Stream PIO • Read Stream DMA • Write Stream DMA • Read Log Ext Support of the Streaming feature set is indicated in Identify Device word 84 bit 4. Note that PIO versions of these commands limit the transfer rate (16.6 MB/s), provide no CRC protection, and limit status reporting as compared to a DMA implementation.
Page 115: Read Continuous Bit
10.18.5 Read Continuous bit If the Read Continuous bit is set to one for the command, the device shall transfer the requested amount of data to the host within the Command Completion Time Limit even if an error occurs. The data sent to the host by the device in an error condition is vendor specific.
Page 116 Deskstar 7K400 Hard Disk Drive Specification...
Page 117: Command Protocol
11.0 Command protocol The commands are grouped into different classes according to the protocols followed for command execution. The command classes with their associated protocols are defined below. For all commands, the host must first check to see if BSY = 1, and should proceed no further unless and until BSY = 0.
Page 118: Pio Data Out Commands
e. The host reads one sector (or block) of data via the Data Register. f. The device sets DRQ = 0 after the sector (or block) has been transferred to the host. 4. For the Read Long command: a. The device sets BSY = 1 and prepares for data transfer. b.
Page 119: Non-Data Commands
• Write Multiple • Write Multiple Ext • Write Sector(s) • Write Sector(s) Ext • Write Stream PIO Execution includes the transfer of one or more 512 byte (> 512 bytes on Write Long) sectors of data from the host to the device.
Page 120 • Device Configuration RESTORE • Execute Device Diagnostic • Flush Cache • Flush Cache Ext • Idle • Idle Immediate • Initialize Device Parameters • • Read Native Max ADDRESS • Read Native Max ADDRESS Ext • Read Verify Sector(s) •...
Page 121: Dma Commands
11.4 DMA commands The following are DMA commands: • Read DMA • Read DMA Ext • Read Stream DMA • Write DMA • Write DMA • Write Stream DMA Data transfers using DMA commands differ in two ways from PIO transfers: •...
Page 122: Dma Queued Commands
11.5 DMA queued commands DMA queued commands are • Read DMA Queued • Read DMA Queued Ext • Service • Write DMA Queued • Write DMA Queued Ext 1. Command Issue a. the host writes any required parameters to the Features, Sector Count, Sector Number, Cylinder, and Device/Head registers.
Page 123: Command Descriptions
12.0 Command descriptions The table below shows the commands that are supported by the device. Table 76: “Command Set (subcommand)” on page 111 shows the subcommands that are supported by each command or feature. Table 74: Command Set (1 of 2) Code Binary Code Bit Protocol...
Page 124: Table 74. Command Set (2 Of 2)
Table 75: Command Set (2 of 2) Proto- Command Binary Code Bit Code (Hex) 7 6 5 4 3 2 1 0 Security Freeze Lock 1 1 1 1 0 1 0 1 Security Set Password 1 1 1 1 0 0 0 1 Security Unlock 1 1 1 1 0 0 1 0 Seek...
Page 125: Table 75. Command Set (Subcommand)
Commands marked * are alternate command codes for previously defined commands Protocol: 1 : PIO data IN command 2 : PIO data OUT command 3 : Non data command 4 : DMA command 5 : DMA queued command + : Vendor specific command Table 76: Command Set (subcommand) Command Feature...
Page 126 The following symbols are used in the command descriptions. Output registers This indicates that the bit must be set to 0. This indicates that the bit must be set to 1. The device number bit. Indicates that the device number bit of the Device/Head Register should be specified. Zero selects the master device and one selects the slave device.
Page 127: Check Power Mode (E5H/98H)
12.1 Check Power Mode (E5h/98h) Table 77: Check Power Mode command (E5h/98h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 128: Configure Stream (51H)
12.2 Configure Stream (51h) Table 78: Configure Stream Command (51h) Command Block Output Command Block Input Registers Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - - Data High...
Page 129 Feature Previous The default Command Completion Time Limit (CCTL). The value is calculated as follows: (Default CCTL) = ((content of the Features register)* (Identify Device words (99:98))) micriseconds. This time shall be used by the device when a streaming command with the same stream ID and a CCTL of zero is issued.
Page 130: Device Configuration Overlay (B1H)
12.3 Device Configuration Overlay (B1h) Table 79: Check Power Mode Command (E5h/98h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 131: Device Configuration Identify (Subcommand C2H)
12.3.3 DEVICE CONFIGURATION IDENTIFY (Subcommand C2h) The DEVICE CONFIGURATION IDENTIFY command returns a 512 byte data structure via PIO data-in transfer. The content of this data structure indicates the selectable commands, modes, and feature sets that the device is capable of supporting. If a DEVICE CONFIGURATION SET command has been issued reducing the capabilities, the response to an IDENTIFY DEVICE or IDENTIFY PACKET DEVICE command will reflect the reduced set of capabilities, while the DEVICE CONFIGURATION IDENTIFY command will reflect the entire set of selectable capabilities.
Page 132: Table 80. Device Configuration Overlay Data Structure
Table 81: Device Configuration Overlay Data structure Word Content 0001h Data Structure revision Multiword DMA modes supported 15-3 Reserved 1 = Multiword DMA mode 2 and below are supported 1 = Multiword DMA mode 1 and below are supported 1 = Multiword DMA mode 0 is supported Ultra DMA modes supported 15-7 Reserved...
Page 133: Table 81. Dco Error Information Definition
Table 82: DCO error information definition Cylinder high invalid word location Cylinder low invalid bit location (bits 15:8) Sector Number Invalid bit location (bits 7:0) Sector count error reason code description DCO feature is frozen Device is now Security Locked mode Device's feature is already modified with DCO User attempt to disable any feature enabled Device is now SET MAX Locked or Frozen mode...
Page 134: Download Microcode (92H)
12.4 Download Microcode (92h) Table 83: Download Microcode Command (92h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 135: Execute Device Diagnostic (90H)
12.5 Execute Device Diagnostic (90h) Table 84: Execute Device Diagnostic command (90h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 136: Flush Cache (E7H)
12.6 Flush Cache (E7h) Table 85: Flush Cache command (E7h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 137: Flush Cache Ext (Eah)
12.7 Flush Cache Ext (EAh) Table 86: Flush Cache Ext Command (EAh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 138: Format Track (50H)
12.8 Format Track (50h) Table 87: Format Track command (50h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 139: Format Unit (F7H)
12.9 Format Unit (F7h) Table 88: Format Unit command (F7h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 140: Identify Device (Ech)
12.10 Identify Device (ECh) Table 89: Identify Device command (ECh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 141: Table 89. Identify Device Information (Part 1 Of 7)
Table 90: Identify device information (Part 1 of 7) An asterisk (*) in next to the Content field indicates the use of those parameters that are vendor specific. Word Content Description 045AH or drive classi- bit assignments 045Eh fication 15(=0) 1=ATAPI device, 0=ATA device 14 - 8 retired...
Page 142: Table 90. Identify Device Information (Part 2 Of 7)
Table 91: Identify device information (Part 2 of 7) An asterisk (*) in next to the Content field indicates the use of those parameters that are vendor specific Word Content Description 0000H Reserved XF00H Capabilities, bit assignments: 15-14(=0) Reserved Standby timer (=1) Values as specified in ATA standard are supported (=0)
Page 143: Table 91. Identify Device Information (Part 3 Of 7)
Table 92: Identify device information (Part 3 of 7) Word Content Description 0003H Flow Control PIO Transfer Modes Supported 15- 8(=0) Reserved 7- 0(=3) Advanced PIO Transfer Modes Supported '11' = PIO Mode 3 and 4 Supported 0078H Minimum Multiword DMA Transfer Cycle Time Per Word 15- 0(=78h) Cycle time in nanoseconds (120 ns, 16.6 MB/s) 0078H Manufacturer's Recommended Multiword DMA Transfer Cycle Time...
Page 144: Table 92. Identify Device Information (Part 4 Of 7)
Table 93: Identify device information (Part 4 of 7) Word Content Description 7FEBH Command set supported 15-14(=01) Word 83 is valid 13(=1) FLUSH CACHE EXT command supported 12(=1) FLUSH CACHE command supported 11(=1) Device Configuration Overlay command supported 10(=1) 48-bit Address Feature Set supported 9(=1) Automatic Acoustic mode 8(=1)
Page 145 XXXXH Command set/feature enabled Reserved NOP command READ BUFFER command WRITE BUFFER command Reserved Host Protected Area Feature Set DEVICE RESET command SERVICE interrupt RELEASE interrupt LOOK AHEAD WRITE CACHE PACKET Command Feature Set Power Management Feature Set Removable Feature Set Security Feature Set SMART Feature Set Deskstar 7K400 Hard Disk Drive Specification...
Page 146: Table 93. Identify Device Information
Table 94: Identify device information (Part 5 of 7 Word Content Description XXXXH Command set supported 15-14 Reserved FLUSH CACHE EXT command supported FLUSH CACHE command supported Device Configuration Overlay command supported 48-bit Address Feature Set supported Automatic Acoustic Management enabled SET Max Security extension enabled Set Features Address Offset Feature mode Set Features subcommand required to spin-up after...
Page 147 0x7FH Ultra DMA transfer modes 15- 8(=xx Current active Ultra DMA transfer mode Reserved (=0) Mode 6 1=Active 0=Not Active Mode 5 1=Active 0=Not Active Mode 4 1=Active 0=Not Active Mode 3 1=Active 0=Not Active Mode 2 1=Active 0=Not Active Mode 1 1=Active 0=Not Active...
Page 148: Table 94. Identify Device Information (Part 6 Of 7)
Table 95: Identify device information (Part 6 of 7) Word Content Description XXXXH Hardware reset result. Bit assignments 15-14 (=01) Word 93 is valid CBLID- status 1=above Vih 0=below Vil 12- 8 Device 1 hardware reset result Device 0 clear these bits to 0 Reserved PDIAG- assertion 1 = asset 0 = not assert...
Page 149 98-99 xxxxH Streaming Performance Granularity These words define the fixed unit of time that is used in Identify Device words (97:96) and (104),and Set Features subcommand 43h, and in the Streaming Performance Parameters log, which is accessed by use of the Read Log Ext command, and in the Command Completion Time Limit that is passed in streaming commands.
Page 150: Table 95. Identify Device Information (Part 7 Of 7)
Table 96: Identify device information (Part 7 of 7) An asterisk (*) in next to the Content field indicates the use of those parameters that are vendor specific Word Content Description xxxxH Current Set Feature Option. Bit assignments 15-4 Reserve Auto reassign 1= Enabled Reverting...
Page 151: Idle (E3H/97H)
12.11 Idle (E3h/97h) Table 97: Idle command (E3h/97h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 152: Idle Immediate (E1H/95H)
12.12 Idle Immediate (E1h/95h) Table 98: Idle Immediate command (E1h/95h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 153: Initialize Device Parameters (91H)
12.13 Initialize Device Parameters (91h) Table 99: Initialize Device Parameters command (91h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 154: Nop (00H)
12.14 NOP (00h) Table 100: NOP Command (00h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 155: Read Buffer (E4H)
12.15 Read Buffer (E4h) Table 101: Read Buffer (E4h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 156: Read Dma (C8H/C9H)
12.16 Read DMA (C8h/C9h) Table 102: Read DMA command (C8h/C9h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 157 Sector Number This indicates the sector number of the last transferred sector. (L = 0). In LBA mode this register contains the current LBA bits 0–7. (L = 1) Cylinder High/Low This indicates the cylinder number of the last transferred sector. (L = 0). In LBA mode this register contains the current LBA bits 8–15 (Low) and bits16–23 (High).
Page 158: Read Dma Ext (25H)
12.17 Read DMA Ext (25h) Table 103: Read DMA Ext Command (25h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 159 Cylinder High Current LBA (23:16) Cylinder High Previous LBA (47:40) Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24)of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8)of the address of the first unrecoverable error.
Page 160: Read Dma Queued (C7H)
12.18 Read DMA Queued (C7h) Table 104: Read DMA command (C8h/C9h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 161 Input parameters from the device on command complete Sector Count Bits 7 - 3 (Tag) contain the Tag of the completed command. Bit 2 (REL) is cleared to zero. Bit 1 (I/O) is set to one. Bit 0 (C/D) is set to one. Sector Number, Cylinder High/Low, H Sector address of unrecoverable error (applicable only when an unrecoverable error has occurred.) Cleared to zero...
Page 162: Read Dma Queued Ext (26H)
12.19 Read DMA Queued Ext (26h) Table 105: Read DMA Ext Command (25h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 163 Input parameters from the device on bus release Sector Count (HOB=0) Bits 7 - 3 (Tag) contain the Tag of the completed command. Bit 2 (REL) is cleared to zero. Bit 1 (I/O) is set to one. Bit 0 (C/D) is set to one. Sector Number, Cylinder High/Low n/a Cleared to zero when the device performs a bus release.
Page 164: Read Log Ext (2Fh)
12.20 Read Log Ext (2Fh) Table 106: Read Log Ext Command (2Fh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 165: Table 106. Log Address Definition
Table 107: Log Address Definition Log Address Content Feature set Type Log directory Read Only Extended Comprehensive SMART error log SMART error logging Ready Only SMART self-test log SMART self-test See Note Extended SMART self-test log SMART self-test Read Only Streaming Performance log Streaming Read Only...
Page 166: General Purpose Log Directory
12.20.1 General Purpose Log Directory The figure below defines the 512 bytes that make up the General Purpose Log Directory. Table 108: General Purpose Log Directory Description Bytes Offset General purpose logging version Number of sectors in the log at log address 01h (7:0) Number of sectors in the log at log address 01h (15:8) Number of sectors in the log at log address 01h (7:0) Number of sectors in the log at log address 01h (15:8)
Page 167: Extended Comprehensive Smart Error Log
12.20.2 Extended Comprehensive SMART Error Log The figure below defines the format of each of the sectors that comprise the Extended Comprehensive SMART error log. Error log data structure shall not include errors attributed to the receipt of faulty commands such as com- mand codes not implemented by the device or requests with invalid parameters or in valid addresses.
Page 168: Table 110. Command Data Structure
12.20.2.3.2 Data format of command data structure Table 111: Command data structure Description Bytes Offset Device Control register Features register (7:0) (see Note) Features register (15:8) Sector count register(7:0) Sector count register(15:8) Sector number register(7:0) Sector number register(15:8) Cylinder Low register (7:0) Cylinder Low register (15:8) Cylinder High register (7:0) Cylinder High register (15:8)
Page 169: Extended Self-Test Log Sector
Note: bits (7:0) refer to the contents if the register is read with bit 7 of the Device Control register cleared to zero. Bits (15:8) refer to the contents if the register is read with bit 7 of the Device Control register set to one. State shall contain a value indicating the state of the device when the command was issued to the device or the reset occurred as described below.
Page 170: Read Stream Error Log
12.20.3.1 Self-test log data structure revision number The value of this revision number shall be 01h. 12.20.3.2 Self-test descriptor index This indicates the most recent self-test descriptor. If there have been no self-tests, this is set to zero. Valid values for the Self-test descriptor index are 0 to 18.
Page 171: Write Stream Error Log
The Data Structure Version field shall contain a value of 02h indicating the second revision of the structure format. The Read Stream Error Log Count field shall contain the number of uncorrected sector entries currently reportable to the host. This value may exceed 31. The Error Log Index indicates the error log data structure representing the most recent error.
Page 172: Streaming Performance Log
Error Log Index and Write Stream Error Count cleared to zero. The Write Stream Error Log is not reserved across power cycles and hardware reset. Table 116: Write Stream Error Log Description Bytes Offset Structure Version Error Log Index Write Stream Error Log Count Reserved Write Stream Error Log Entry #1 Write Stream Error Log Entry #2...
Page 173: Table 117. Sector Time Array Entry (Linearly Interpolated)
Table 118: Sector Time Array Entry (Linearly Interpolated) Description Bytes LBA of reference location (LBA(7:0)...LBA(47:40)) (n+5) (Identify Device words (99:98))/65536 time units per (n+6) sector at the reference location (n+7) Table 119: Position Array Entry (Linearly Interpolated) Description Bytes LBA of start of region (LBA(7:0)...LBA(47:40)) (n+5) Position number in the range 0...32767 (n+6)
Page 174: Read Long (22H/23H)
12.21 Read Long (22h/23h) Table 121: Read Long (22h/23h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 175 Input parameters from the device Sector Count This indicates the number of requested sectors not transferred Sector Number This indicates the sector number of the transferred sector. (L = 0) In LBA mode, this register contains current LBA bits 0–7. (L = 1) Cylinder High/Low This indicates the cylinder number of the transferred sector.
Page 176: Read Multiple (C4H)
12.22 Read Multiple (C4h) Table 122: Read Multiple (C4h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 177 Cylinder High/Low This indicates the cylinder number of the transferred sector. (L = 0) In LBA mode, this register contains current LBA bits 8–15 (Low), 16–23 (High). (L = 1) This indicates the head number of the transferred sector. (L = 0) In LBA mode, this register contains current LBA bits 24–27.
Page 178: Read Multiple Ext (29H)
12.23 Read Multiple Ext (29h) Table 123: Read DMA Ext Command (25h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 179 Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 180: Read Native Max Address (F8H)
12.24 Read Native Max ADDRESS (F8h) Table 124: Read Native Max ADDRESS (F8h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - -...
Page 181: Read Native Max Address Ext (27H)
12.25 Read Native Max Address Ext (27h) Table 125: Read Native Max Address Ext command (27h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low...
Page 182: Read Sectors (20H/21H)
12.26 Read Sectors (20h/21h) Table 126: Read Sectors Command (20h/21h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 183 Cylinder High/Low This is the cylinder number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 8–15 (Low) and bits 16–23 (High). (L = 1) This is the head number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 24–27.
Page 184: Read Sector(S) Ext (24H)
12.27 Read Sector(s) Ext (24h) Table 127: Read Sector(s) Ext command (24h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 185 Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 186: Read Stream Dma (2Ah)
12.28 Read Stream DMA (2Ah) Table 128: Read Stream DMA Command (2Ah) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 187 Feature Current URG (bit7) URG specifies an urgent transfer request. The Urgent bit specifies that the com- mand should be completed in the minimum possible time by the device and shall be completed within the specified Command Completion Time Limit. RC (bit6) RC specifies Read Continuous mode enabled.
Page 188 Cylinder High Previous LBA (47:40). Input Parameters From The Device Sector Number LBA (7:0) of the address of the first unrecoverable error. (HOB=0) Sector Number LBA (31:24) of the address of the first unrecoverable error. (HOB=1) Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 189: Read Stream Pio (2Bh)
12.29 Read Stream PIO (2Bh) Read Stream PIO Command (2Bh) Table 129: Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 190 Output Parameters From The Device Feature Current URG (bit7) URG specifies an urgent transfer request. The Urgent bit specifies that the command should be completed in the minimum possible time by the device and shall be completed within the specified Command Completion Time Limit. RC (bit6) RC specifies Read Continuous mode enabled.
Page 191 Sector Number LBA (7:0) of the address of the first unrecoverable error. (HOB=0) Sector Number LBA (31:24) of the address of the first unrecoverable error. (HOB=1) Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error. Cylinder High LBA (23:16) of the address of the first unrecoverable error.
Page 192: Read Verify Sectors (40H/41H)
12.30 Read Verify Sectors (40h/41h) Table 130: Read Verify Sectors (40h/41h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 193 Cylinder High/Low This is the cylinder number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 8–15 (Low) and bits 16–23 (High). (L = 1) This is the head number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 24–27.
Page 194: Read Verify Sector(S) (42H)
12.31 Read Verify Sector(s) (42h) Table 131: Read Verify Sector(s) command (42h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 195 Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 196: Recalibrate (1Xh)
12.32 Recalibrate (1xh) Table 132: Recalibrate (1xh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 197: Security Disable Password (F6H)
12.33 Security Disable Password (F6h) Table 133: Security Disable Password (F6h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 198: Security Disable Password (F3H)
12.34 Security Disable Password (F3h) Table 135: Security Disable Password (F3h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 199: Security Erase Unit (F4H)
12.35 Security Erase Unit (F4h) Table 136: Security Erase Unit (F4h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 200 If the device receives a Security Erase Unit command without a prior Security Erase Prepare command the device aborts the security erase unit command. This command disables the security mode feature (device lock function), however, the master password is still stored internally within the device and may be reactivated later when a new user password is set.
Page 201: Security Freeze Lock (F5H)
12.36 Security Freeze Lock (F5h) Table 138: Security Freeze Lock command (F5h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 202: Security Set Password (F1H)
12.37 Security Set Password (F1h) Table 139: Security Set Password command (F1h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 203 Security Level Zero indicates High level. One indicates Maximum level. If the host sets High level and the password is forgotten, the Master Password can be used to unlock the device. If the host sets Maximum level and the user password is for- gotten, only a Security Erase Prepare/Security Unit command can unlock the device and all data will be lost.
Page 204: Security Unlock (F2H)
12.38 Security Unlock (F2h) Table 141: Security Unlock command (F2h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 205: Seek (7Xh)
12.39 Seek (7xh) Table 142: Seek command (7xh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 206: Service (A2H
12.40 Service (A2h) Table 143: Service command (A2h) Command Block Output Registers Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Feature - - - - - - - - Sector Count - - - - - - - - Sector Number - - - - - - - -...
Page 207: Set Features (Efh)
12.41 Set Features (EFh) Table 144: Set Features command (EFh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 208: Set Transfer Mode
Disable release interrupt Note: After the power on reset or hard reset the device is set to the following features as default. Write cache Enable ECC bytes 4 bytes Read look-ahead Enable Reverting to power on defaults Disable Release interrupt Disable 12.41.1 Set Transfer mode When the Feature register is 03h (= Set Transfer mode) the Sector Count Register specifies the transfer mechanism.
Page 209: Automatic Acoustic Management
When Low RPM standby mode is the deepest Power Saving mode and the value in Sector Count register is between 40h and 7Fh, 120 ☯y ☯435 [sec] (default: 120 [sec]) = (x − 40h) 60 +600 (600 ☯y ☯4380) [sec] When Low RPM standby mode is the deepest Power Saving Mode and the value in Sector Count register is between 01h and 3Fh, where...
Page 210: Set Maximum Host Interface Sector Time
12.41.5 Set Maximum Host Interface Sector Time Sector Count Typical PIO Mode Host Interface Sector Time (7:0) LBA Low Typical PIO Mode Host Interface Sector Time (15:8) LBA Mid Typical DMA Mode Host Interface Sector Time (7:0) LBA High Typical DMA Mode Host Interface Sector Time (15:8) Subcommand code 43h allows the host to inform the device of a host interface rate limitation.
Page 211: Set Max Address (F9H)
12.42 Set Max ADDRESS (F9h) Table 145: Set Max ADDRESS command (F9h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 212 If a host protected area has been established by a Set Max Address Ext command, the device shall return command aborted. Output parameters to the device Option bit for selection whether nonvolatile or volatile. B = 0 is volatile condition. When B=1, MAX LBA/CYL which is set by Set Max LBA/CYL command is preserved by POR.
Page 213: Set Max Set Password (Feature=01H)
12.42.1 Set Max Set Password (Feature=01h) Table 146: Set Max Set Password command Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - -...
Page 214: Set Max Lock (Feature=02H)
12.42.2 Set Max Lock (Feature=02h) Table 148: Set Max Lock command Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 215: Set Max Unlock (Feature = 03H)
12.42.3 Set Max Unlock (Feature = 03h) Table 149: Set Max Unlock command (F9h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data...
Page 216: Set Max Freeze Lock (Feature = 04H)
12.42.4 Set Max Freeze Lock (Feature = 04h) Table 150: Set Max Freeze Lock (F9h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data...
Page 217: Set Max Address Ext (37H)
12.43 Set Max Address Ext (37h) Table 151: Set Max Address Ext command (37h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low...
Page 218 Output parameters to the device Option bit for selection whether nonvolatile or volatile. B=0 is volatile condition. When B=1, MAX Address which is set by the Set Max Address Ext command is preserved by POR. When B=0, MAX Address which is set by the Set Max Address Ext command will be lost by POR.
Page 219: Set Multiple (C6H)
12.44 Set Multiple (C6h) Table 152: Set Multiple command (C6h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 220: Sleep (E6H/99H)
12.45 Sleep (E6h/99h) Table 153: Sleep command (E6h/99h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 221: Function Set (B0H)
12.46 S.M.A.R.T. Function Set (B0h) Table 154: S.M.A.R.T. Function Set command (B0h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 222 12.46.1.2 S.M.A.R.T. Read Attribute Thresholds (subcommand D1h) This subcommand returns the Attribute Thresholds of the device to the host. Upon receipt of the SMART Read Attribute Thresholds subcommand from the host, the device reads the Attribute Thresholds from the Attribute Threshold sectors and then transfers the 512 bytes of Attribute Thresholds information to the host.
Page 223 Off-line mode: The device executes command completion before executing the specified routine. During execu- tion of the routine the device will not set BSY nor clear DRDY. If the device is in the process of performing its rou- tine and is interrupted by a new command from the host, the device will abort or suspend its routine and service the host within two seconds after receipt of the new command.
Page 224 12.46.1.9 S.M.A.R.T. Disable Operations (subcommand D9h) This subcommand disables all S.M.A.R.T. capabilities within the device including the attribute Autosave feature of the device. After receipt of this subcommand the device disables all S.M.A.R.T. operations. Non self-preserved Attribute Values will no longer be monitored. The state of S.M.A.R.T.—either enabled or disabled—is preserved by the device across power cycles.
Page 225: Device Attribute Data Structure
12.46.2 Device Attribute Data Structure The following defines the 512 bytes that make up the Attribute Value information. This data structure is accessed by the host in its entirety using the S.M.A.R.T. Read Attribute Values subcommand. All multibyte fields shown in these data structures are in byte ordering, that is, the least significant byte occupies the lowest numbered byte address location in the field.
Page 226 Attribute ID Numbers: Any nonzero value in the Attribute ID Number indicates an active attribute. The device supports following Attribute ID Numbers. Attribute Name Indicates that this entry in the data structure is not used Raw Read Error Rate Throughput Performance Spin Up Time Start/Stop Count Reallocated Sector Count...
Page 227 12.46.2.3 Off-Line Data Collection Status The value of this byte defines the current status of the off-line activities of the device. Bit 7 indicates an Automatic Off-line Data Collection Status. Bit 7 Automatic Off-line Data Collection Status Automatic Off-line Data Collection is disabled. Automatic Off-line Data Collection is enabled.
Page 228: Device Attribute Thresholds Data Structure
Abort/restart off-line by host bit The device will suspend off-line data collection activity after an interrupting command and resume it after a vendor specific event The device will abort off-line data collection activity upon receipt of a new command Off-line Read Scanning implemented bit The device does not support Off-line Read Scanning The device supports Off-line Read Scanning Self-test implemented bit...
Page 229: Table 156. Device Attribute Thresholds Data Structure
these data structures are in byte ordering, that is, that the least significant byte occupies the lowest numbered byte address location in the field. The sequence of active Attribute Thresholds will appear in the same order as their corresponding Attribute Values. Table 157: Device Attribute Thresholds Data Structure Description Byte...
Page 230: Log Directory
12.46.4 S.M.A.R.T. Log Directory The following table defines the 512 bytes that make up the S.M.A.R.T. Log Directory. The S.M.A.R.T. Log Direc- tory is S.M.A.R.T. Log Address zero and is defined as one sector long. Table 159: S.M.A.R.T. Log Directory Description Byte Offset...
Page 231: Table 160. Error Log Data Structure
12.46.5.4 Error log data structure The data format of each error log data structure is shown below. Table 161: Error log data structure Description Byte Offset 1st command data structure 2nd command data structure 3rd command data structure 4th command data structure 5th command data structure Error data structure 12.46.5.5 Command data structure...
Page 232: Self-Test Log Data Structure
The state field contains a value indicating the device state when command was issued to the device. Value State Unknown Sleep Standby Active/Idle S.M.A.R.T. Off-line or Self-test x5h-xAh Reserved xBh-xFh Vendor specific The value of ’x’ is vendor specific 12.46.6 Self-test log data structure The following table defines the 512 bytes that make up the Self-test log sector.
Page 233: Selective Self-Test Log Data Structure
12.46.7 Selective self-test log data structure The Selective self-test log is a log that may be both written and read by the host. This log allows the host to select the parameters for the self-test and to monitor the progress of the self-test. The following table defines the contents of the Selective self-test log which is 512 bytes long.
Page 234: Error Reporting
12.46.8 Error reporting The following table shows the values returned in the Status and Error Registers when specific error conditions are encountered by a device. Table 166: S.M.A.R.T. Error Codes Error condition Status Register Error Register A S.M.A.R.T. FUNCTION SET command was received by the device without the required key being loaded into the Cylinder High and Cylin- der Low registers.
Page 235: Standby (E2H/96H)
12.47 Standby (E2h/96h) Table 167: Standby (E2h/96h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 236: Standby Immediate (E0H/94H)
12.48 Standby Immediate (E0h/94h) Table 168: Standby Immediate (E0h/94h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 237: Write Buffer (E8H)
12.49 Write Buffer (E8h) Table 169: Write Buffer (E8h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 238: Write Dma (Cah/Cbh)
12.50 Write DMA (CAh/CBh) Table 170: Write DMA (CAh/CBh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 239 Cylinder High/Low This indicates the cylinder number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 8–15 (Low) and bits 16–23 (High). (L = 1) This indicates the head number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 24–27.
Page 240: Write Dma Ext (35H)
12.51 Write DMA Ext (35h) Table 171: Write DMA Ext Command (35h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 241 Cylinder High Current LBA (23:16) Cylinder High Previous LBA (47:40) Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error.
Page 242: Write Dma Queued (Cch)
12.52 Write DMA Queued (CCh) Table 172: Write DMA Queued Command CAh/CBh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 243 Input parameters from the device on command complete Sector Count Bits 7 - 3 (Tag) contain the Tag of the completed command. Bit 2 (REL) is cleared to zero. Bit 1 (I/O) is set to one. Bit 0 (C/D) is set to one. Sector Number, Cylinder High/Low, H Sector address of unrecoverable error (applicable only when an unrecoverable error has occurred).
Page 244: Write Dma Queued Ext (36H)
12.53 Write DMA Queued Ext (36h) Table 173: Write DMA Queued Ext Command (36h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low...
Page 245 Input parameters from the device on Bus Release Sector Count Bits 7 - 3 (Tag) contain the Tag of the command being bus released. Bit 2 (REL) is set to one. Bit 1 (I/O) is cleared to zero. Bit 0 (C/D) is cleared to zero. Sector Number, Cylinder High/Low, H n/a.
Page 246: Write Log Ext (3Fh)
12.54 Write Log Ext (3Fh) Table 174: Write Log Ext Command (3Fh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 247: Write Long (32H/33H)
12.55 Write Long (32h/33h) Table 175: Write Long (32h/33h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 248 Cylinder High/Low This indicates the cylinder number of the sector to be transferred. (L = 0) In LBA mode this register contains current the LBA bits 8–15 (Low) and bits 16–23 (High). (L = 1) This indicates the head number of the sector to be transferred. (L = 0) In LBA mode this register contains current the LBA bits 24–27.
Page 249: Write Multiple (C5H)
12.56 Write Multiple (C5h) Table 176: Write Multiple (C5h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 250 Cylinder High/Low This indicates the cylinder number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 8–15 (Low) and bits 16–23 (High). (L = 1) This indicates the head number of the last transferred sector. (L = 0) In LBA mode this register contains current the LBA bits 24–27.
Page 251: Write Multiple Ext (39H)
12.57 Write Multiple Ext (39h) Table 177: Write Log Ext Command (3Fh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 252 Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 253: Write Sectors (30H/31H)
12.58 Write Sectors (30h/31h) Table 178: Write Sectors command (30h/31h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data - - - - - - - - Data - - - - - - - - Feature...
Page 254 Cylinder High/Low This indicates the cylinder number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 8–15 (Low) and 16–23 (High). (L = 1) This indicates the head number of the last transferred sector. (L = 0) In LBA mode this register contains the current LBA bits 24–27.
Page 255: Write Sector(S) (34H)
12.59 Write Sector(s) (34h) Table 179: Write Sector(s) Command (34h) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - - Data High...
Page 256 Input parameters from the device Sector Number (HOB=0) LBA (7:0) of the address of the first unrecoverable error. Sector Number (HOB=1) LBA (31:24) of the address of the first unrecoverable error. Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 257: Write Stream Dma (3Ah)
12.60 Write Stream DMA (3Ah) Table 180: Write Stream DMA Command (3Ah) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 258 WC (bit6) WC specifies Write Continuous mode enabled. If the Write Continuous bit is set to one, the device shall not stop execution of the command due to errors. If the WC bit is set to one and errors occur in transfer or writing of the data, the device shall continue to transfer the amount of data requested and then provide ending status with BSY bit cleared to zero, the SE bit set to one, the ERR bit cleared to zero, and the type of error, ICRC, IDNF or ABRT reported in the error...
Page 259 SE (Status, bit 5) SE (Stream Error) shall be set to one if an error has occurred during the execution of the command and the WC bit is set to one, In this case the LBA returned in the Sector Number registers shall be the address of the first sector in error, and the Sector Count registers shall contain the number of consecutive sectors that may contain errors.
Page 260: Write Stream Pio (3Bh)
12.61 Write Stream PIO (3Bh) Table 181: Write Stream PIO Command (3Bh) Command Block Output Registers Command Block Input Registers Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0 Data Low - - - - - - - - Data Low - - - - - - - -...
Page 261 (bit6) WC specifies Write Continuous mode enabled. If the Write Continuous bit is set to one, the device shall not stop ex- ecution of the command due to errors. If the WC bit is set to one and errors occur in transfer or writing of the data, the device shall continue to transfer the amount of data requested and then provide ending status with BSY bit cleared to zero, the SE bit set to one, the ERR...
Page 262 Cylinder High LBA (47:40). Previous Input Parameters From The Device Sector Number LBA (7:0) of the address of the first unrecoverable error. (HOB=0) Sector Number LBA (31:24) of the address of the first unrecoverable error. (HOB=1) Cylinder Low (HOB=0) LBA (15:8) of the address of the first unrecoverable error. Cylinder Low (HOB=1) LBA (39:32) of the address of the first unrecoverable error.
Page 263: Time-Out Values
13.0 Time-out values The timing of BSY and DRQ in Status Register are shown in the table below. Table 182: Time-out values INTERVAL START STOP TIME-OUT Power On Device Busy After Power Power On Status Register BSY=1 400 ns Device Ready After Power On Status Register BSY=1 31 sec...
Page 264 Index Abbreviations ........................1 Acoustics .........................63 Actuator ..........................9 actuator lock ........................59 Address Offset ........................99 Advanced Power Management ..................97 Advanced Power Management feature set (APM) ............97 Alternate Status Register ....................70 AT signal connector ......................24 Attribute thresholds ......................84 Attribute values .......................84 Attributes ........................84 Auto Reassign .........................95 Automatic Acoustic Management ..................98 BSMI mark ........................65...
Page 265 Cylinder High Register ....................70 Data In commands ......................105 Data Out Commands .......................106 Data Register ........................71 Data Reliability .......................55 Data sheet ........................11, 12 Data transfer speed ......................17 DC power connector .......................24 DC power requirements ....................53 Defect flagging strategy ....................21 Deviations from standard ....................67 Device Pausing Write DMA ...................40 Device/Head Register .....................72 Diagnostic and Reset considerations ................79...
Page 266 Format Track (50h) ......................126 Format Unit (F7h) ......................127 Formatted capacity ......................11 Functional specification ....................7 General ..........................1 General features ......................5 General operation ......................77 German safety mark ......................64 Head disk assembly ......................9 Head disk assembly data ....................9 Heads unload ........................59 Host Terminating Write DMA ..................42 Humidity .........................52 Identification labels ......................63 Identify Device (ECh) .....................128...
Page 267 Labels, Identification ......................63 Latency, average ......................16 LBA addressing mode ....................80 Load/unload ........................55 Logical CHS addressing mode ..................80 Mechanical positioning ....................15 Mechanical specifications ....................56 Mode transition time .......................19 Mounting hole locations ....................56, 57 Mounting orientation ......................59 Non-data commands .......................108 NOP (00h) ........................142 Off-line read scanning ....................84 Operating modes ......................19 description 17...
Page 268 Power-Up ........................96 Preventive maintenance ....................55 Protected Area .........................91 Read Buffer (E4h) ......................143 Read DMA (C8h/C9h) ....................144 Read DMA Ext (25h) ......................146 Read DMA Queued (C7h) ....................148 Read DMA Queued Ext (26h) ..................150 Read Log Ext (2Fh) ......................152 Read Long (22h/23h) ......................162 Read Stream DMA (2Ah) ....................174 Read Verify Sector(s) (42h) ....................182 Reassign function ......................95...
Page 269 Set Max ADDRESS ......................199 Set Max Address Ext (37h) .....................205 Set Maximum Host Interface Sector Time ..............198 Shock ..........................60 Signal definitions ......................25 Signal descriptions ......................26 Signal timings .........................31 Sleep (E6h/99h) ......................208 Specification ........................23, 47 Standby (E2h/96h) ......................223 Standby Immediate ......................224 Standby timer ........................82 Start/stop cycles ......................55 Status Register ........................74...
Page 270 Write cache ........................94 Write DMA ........................226 Deskstar 7K400 Hard Disk Drive Specification...
Page 271 References in this publication to Hitachi Global Storage Technologies products, programs or services do not imply that Hitachi Global Storage Technologies intends to make these available in all countries in which Hitachi Global Storage Technologies operates. Product information is provided for information pur- poses only and does not constitute a warranty.

This manual is also suitable for:

Hds724040klat80 Hds724040klsa80

Hitachi 7K400 - Deskstar Hard Drive Specifications

1 General

2 General Features of the Drive

3 Fixed-Disk Subsystem Description

4 Drive Characteristics

5 Defect Flagging Strategy

6 Specification

7 Jumper Settings

8 General

9 Registers

10 General Operation

11 Command Protocol

12 Command Descriptions

Quick Links

Related Manuals for Hitachi 7K400 - Deskstar Hard Drive

Summary of Contents for Hitachi 7K400 - Deskstar Hard Drive
