ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included hex keys, assembly requires a phillips screwdriver
wrenches , a rubber mallet
Use the chart below to identify the small parts used in assembly. The number in parentheses below each part is
the key number of the part, from the PART LIST on page 18. The number after the key number is the quantity
needed for assembly. Note: Some parts may have been preattached for shipping. If a part is not in the
parts bag, check to see if it has been preattached.
M10 Split
Washer (59)–2
M8 Nylon
Locknut (38)–6
M10 x 76mm Button Bolt (67)–2
M8 x 45mm Button
Bolt (50)–4
1. Identify the Front Stabilizer (10). While another per-
son lifts the front of the Frame (1), attach the Front
Stabilizer to the Frame with two M10 x 75mm
Carriage Bolts (34) and two M10 Nylon Locknuts
(33). Make sure that the Front Stabilizer is turned
so the Wheels (22) are not touching the floor.
, and a pair of pliers
Wave Washer
(43)–2
M4 x 12mm
M10 Nylon Screw (42)–4
Locknut (33)–6
M8.5
Washer (55)–2
M4 x 19mm Flange
Screw (36)–6
M10 x 75mm Carriage Bolt (34)–4
Pedal Arm Bolt Set (40)–2
1
10
22
34
5
, two adjustable
.
M8.5 Large
Washer (35)–2
M8 x 25mm Patch
Screw (56)–2
22
1
33
