Acer Veriton 7600GTR Service Manual

Hide thumbs Also See for Veriton 7600GTR:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Veriton 7600GTR/7600GT/7600V
Veriton 5600GT/5600V
Veriton 3600GT/3600V
Service Guide
Service guide files and updates are available
on the AIPG/CSD web; for more information,
please refer to
http://csd.acer.com.tw
SERVICE CD PART NO.: VD.V03V3.001 ''
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Acer Veriton 7600GTR

Summary of Contents for Acer Veriton 7600GTR

  • Page 1 Veriton 7600GTR/7600GT/7600V Veriton 5600GT/5600V Veriton 3600GT/3600V Service Guide Service guide files and updates are available on the AIPG/CSD web; for more information, please refer to http://csd.acer.com.tw SERVICE CD PART NO.: VD.V03V3.001 ‘‘ PRINTED IN TAIWAN...

  • Page 2: Revision History

    Revision History Please refer to the table below for the updates made on Veriton 7600GTR/GT/V, 5600GT/V and 3600GT/V service guide. Date Chapter Updates...
  • Page 3 Copyright Copyright © 2003 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 Conventions The following conventions are used in this manual: Screen messages Denotes actual messages that appear on screen. NOTE Gives bits and pieces of additional information related to the current topic. WARNING Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 7: Table Of Contents

    Rear Panel for Veriton 5600GT/V ........9 Front Panel for Veriton 7600GTR/GT/V ....... . . 11 Rear Panel for Veriton 7600GTR/GT/V .
  • Page 8 FRU (Field Replaceable Unit) List Veriton 7600GTR/GR/V Exploded Diagram ......109 Veriton 5600GR/V Exploded Diagram ....... . . 110 Veriton 3600GR/V Exploded Diagram .
  • Page 9 Table of Contents...

  • Page 10: System Specifications

    Chapter 1 System Specifications Overview ® The Veriton 7600GTR/7600GT/7600V, 5600GT/5600V and 3600GT/3600V supports Intel Pentium 4 processor with Hyper-Threading (HT) Technology, adding intelligence to help manage and prioritize multiple threads received from the microprocessor. This highly flexible and scalable solution meets a broad range of demanding computing needs. The 865G/...

  • Page 11: Features

    Features Performance ® Intel Pentium 4 supporting FSB up to 800 MHz or ® Intel Celeron supporting FSB up to 400 MHz ® Intel Hyper-Threading Technology supported on 3.06 GHz and higher Pentium 4 system Intel 865G + ICH5R (for VT7600GTR), Intel 865G + ICH5 (for VT7600GT/5600GT/3600GT), Intel 865GV + ICH5 (for VT7600V/5600V/3600V) chipset Integrated VGA 8X AGP expansion slot (for Intel 865G chipset)

  • Page 12: Front Panel For Veriton 3600Gt/V

    Front Panel for Veriton 3600GT/3600V The computer’s front panel consists of the following: Label Icon Description Floppy drive LED Floppy drive eject button Optical drive Stop/Eject Button Power button Chapter 1...
  • Page 13 Label Icon Description Power LED LAN activity LED Hard disk drive activity LED One button recovery slot USB ports Headphone-out port Microphone-in port (front)* NOTE: *The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time.

  • Page 14: Rear Panel For Veriton 3600Gt/V

    Rear Panel for Veriton 3600GT/3600V Label Icon Color Description Light blue Audio-in/Line-in jack Lime Audio-out/Line-out jack Pink Microphone-in jack (rear)* Chapter 1...
  • Page 15 Label Icon Color Description Black USB ports White Network port Blue CRT/LCD monitor port** Burgundy Parallel/printer port Teal or Turquoise Serial port Black USB ports Purple PS/2 keyboard port Green PS/2 mouse port Power cord socket NOTE: * The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time.

  • Page 16: Front Panel For Veriton 5600Gt/V

    Front Panel for Veriton 5600GT/5600V The computer’s front panel consists of the following: Label Icon Description Floppy drive eject button Floppy drive LED One button recovery slot Headphone-out port Microphone-in port (front)* USB ports Power button Power LED LAN activity LED Hard disk drive activity LED Chapter 1...
  • Page 17 Label Icon Description Optical drive Stop/Eject Button NOTE: *The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time. The default setting for your system enables the microphone-in port in front and disables the one at the back.

  • Page 18: Rear Panel For Veriton 5600Gt/V

    Rear Panel for Veriton 5600GT/5600V Label Icon Color Description Pink Microphone-in jack (rear)* Lime Audio-out/Line-out jack Light blue Audio-in/Line-in jack Black USB ports White Network port Blue CRT/LCD monitor port** Burgundy Parallel/printer port Teal or Turquoise Serial port Black USB ports Chapter 1...
  • Page 19 Label Icon Color Description Green PS/2 mouse port Purple PS/2 keyboard port Power cord socket NOTE: * The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time. The default setting for your system enables the microphone-in port in front and disables the one at the back.

  • Page 20: Front Panel For Veriton 7600Gtr/Gt/V

    Front Panel for Veriton 7600GTR/7600GT/7600V The computer’s front panel consists of the following: Label Icon Description USB ports Microphone-in port (front)* Speak-out/line-out port Chapter 1...
  • Page 21 Label Icon Description Optical drive Stop/Eject Button Optical drive Stop/Eject Button Floppy drive LED Floppy drive eject button One button recovery slot Power button Power LED LAN activity LED Hard disk drive activity LED NOTE: *The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time.

  • Page 22: Rear Panel For Veriton 7600Gtr/Gt/V

    Rear Panel for Veriton 7600GTR/7600GT/7600V Label Icon Color Description Light blue Audio-in/Line-in jack Lime Audio-out/Line-out jack Chapter 1...
  • Page 23 Label Icon Color Description Pink Microphone-in jack (rear)* White Network port Black USB ports Blue CRT/LCD monitor port** Burgundy Parallel/printer port Teal or Turquoise Serial port Black USB ports Purple PS/2 keyboard port Green PS/2 mouse port Power cord socket Power cord socket NOTE: * The system has two microphone-in ports (front and rear).

  • Page 24: System Block Diagram

    System Block Diagram Block Diagram VRM 10 Intel mPAG478B Processor ST L6710 2-Phase PWM 4X/8X AGP 1.5V Connector 64bit DDR Analog 4 DDR Channel 1 Springdale Video DIMM 64bit DDR Modules Channel 2 (1+1) PCI BUS UltraDMA 33/66/100 IDE Primary PCI BUS IDE Secondary ICH5R...

  • Page 25: Keyboard

    Keyboard The keyboard has full-sized keys that include separate cursor keys, two Windows keys, and twelve function keys. Lable Description Puts the system to sleep when pressed this button. Sleep button Internet/E-mail/Search Consist of three buttons: keys • Web browser : launches the browser application that came bundled with your system.
  • Page 26 Lable Description Scroll Lock Key When activated, the screen moves one line up or down when you press the up arrow or down arrow respectively. Take note that may not work with some applications. When activated, the keypad is set to numeric mode, i.e., the keys function Num Lock Key as a calculator (complete with arithmetic operators such as +, -, * and /).

  • Page 27: Hardware Specifications And Configurations

    Hardware Specifications and Configurations Processor Item Specification Type Intel® Pentium 4 1.8 ~ 3.2GHz FSB400/533/800MHz Intel® Celeron 2.0 ~ 2.6GHz and above Slot Socket 478 Speed Internal: 1.4 ~ 3.2GHz+ External: 400/533/800MHz Data Bus Frequency for Springdale-G. Minimum operating speed 0 MHz (If Stop CPU Clock in Sleep State the BIOS Setup is set to Enabled.) Voltage Processor voltage can be detected by the system without setting any jumper.
  • Page 28 Cache Memory Item Specification First-Level Cache Configurations Cache function control Enable/Disable by BIOS Setup (Advanced options) Second-Level Cache Configurations: Below information is only applicable to system with installed Pentium 4 processor. L2 Cache RAM size Pentium IV processor: 512 KB for Northwood L2 Cache RAM speed The same with the processor core clock frequency L2 Cache function control...
  • Page 29 Floppy disk drive Interface Item Specification Vendor & Model Name Panasonic JU-256A048P Mitsumi D353M3D-R694005 NEC FD1231T-STD-R2 Floppy Disk Specifications Media Recognition 1.44 MB Cylinders Tracks Rotational speed (RPM) Read/write heads Encoding method MFM/FM Power requirement (max) Startup (peak) 290mA Maximum Seeking (RMS) 710mA Voltage tolerance (V) +5V +/- 10%...

  • Page 30: Environmental Requirements

    USB Port Items Specifications Universal UHCI USB 1.1 Universal EHCI USB 2.0 USB Class Support legacy keyboard for legacy mode Main Board Major Chips Item Controller North Bridge Intel 865G/865GV South Bridge Intel ICH5R/ICH5 Super I/O controller SMSC LPC 47M192 Audio Codec Realtek ALC202 A LAN controller...
  • Page 31 A-2 Input voltage Nominal Voltage Variation Range 100 - 120 VRMS 90-132 VRMS 200 - 240 VRMS 180-264 VRMS A-3 Input current Input Current Measuring Range 90 -132 VRMS 180 - 264 VRMS (This is 200W power supply) This “4A” includes the outlet supply current: 2A Measure at line input 90 VRMS and maximum load condition.

  • Page 32: Memory Channel Mode

    Memory Channel Mode Single Channel / Dual Channel Virtual Single Channel DIMM Population No restrictions Matching DIMM pairs Rank(Row) Size Size of one side of the DIMM 2x the size of one side of the DIMM populated in the channel populated in the channel(A or B) (64MB - 512MB) (128MB - 1GB)
  • Page 33 DIMM 1 DIMM 2 DIMM3 DIMM4 Total 128MB~1GB 128MB~1GB 256MB~2GB 128MB~1GB 128MB~1GB 256MB~2GB 128MB~1GB 128MB~1GB 128MB~1GB 128MB~1GB 512MB~4GB The following conditions must be met: Matched DIMM configuration in each channel Same Density (128MB, 256MB, 512MB, etc.) Same DRAM technology (128Mb, 256Mb, or 512Mb) Same DRAM bus width (x8 or x16) Both either single-sided or dual-sided Matched in both Channel A and Channel B memory channels...
  • Page 34 Maximizing Performance Optimal configurations for highest performance: Matched, DDR400, Double-sided DIMMs Dual Channel Mode (Symmetrical DIMM population) Lightly Loaded Config Ch B Ch B Ch A Ch A Ch B Ch B Ch A Ch A Matched, DDR400, Dual Channel Mode Fully Loaded Config Ch B Ch B...

  • Page 35: System Utilities

    Chapter 2 System Utilities Most systems are already configured by the manufacturer or the dealer. There is no need to run Setup when starting the computer unless you get a Run Setup message. The Setup program loads configuration values into the battery-backed nonvolatile memory called CMOS RAM. This memory area is not part of the system RAM.

  • Page 36: Entering Setup

    Entering Setup To enter Setup, press the key during the POST (Power-on self-test). NOTE: You must press simultaneously while the system is booting. The Setup Utility main menu then appears: The above screen is the BIOS Utility Basic Level screen. It allows you to view and change only the basic configuration of your system.

  • Page 37: Product Information

    Product Information The screen below appears if you select Product Information from the main menu: The Product Information menu contains general data about the system, such as the product name, serial number, BIOS version, etc. These information is necessary for troubleshooting (maybe required when asking for technical support).

  • Page 38: Standard Cmos Features

    Standard CMOS Features Select “Standard CMOS Features” from the main menu to configure the drives installed in your system. The following screen shows the Disk Drives menu: The following table describes the parameters found in this menu. Parameter Description Options Date Lets you set the date following the weekday-month-day- Weekday: Sun, Mon..Sat...
  • Page 39 Parameter Description Options IDE Channel 1 Slave Lets you configure the hard disk drive connected to the (Show the Status:) slave port of IDE channel 1. None HDD or CD-ROM Number To enter the IDE Channel 1 Slave setup, press The IDE CD-ROM is always automatically detected.

  • Page 40: Ide Channel 0 Master/Slave And Ide Channel 1 Master/Slave Setup

    IDE Channel 0 Master/Slave and IDE Channel 1 Master/Slave Setup The following screen appears if you select any of the IDE drive parameters: The following table describes the parameters found in this menu. Parameter Description Options IDE HDD Auto-Detection Auto-detects your hard disk drive. Press Enter IDE Channel 0 Master/Slave Displays the device type...

  • Page 41: Advanced Bios Features

    Advanced BIOS Features The following screen shows the Advanced BIOS Features. The following table describes each Advanced BIOS Features parameter. Settings in boldface are the default and suggested settings. Parameter Description Options Hard Disk Boot Priority Selects the hard disk boot priority. Press [Enter] Show Hard Disk Name 1/2/3/4/5/6/7/8...
  • Page 42 Parameter Description Options Quick Power On Self Test This parameter speeds up POST by skipping some Enabled items that are normally checked. Disabled First Boot Device This parameter allows you to specify the system Floppy, LS120, Hard Disk, boot up search sequence. CD-ROM, ZIP100, LAN (on board LAN-- Boot from LAN), Disabled...
  • Page 43 Parameter Description Options MPS Version Control For OS This field allows you to select which MPS (Multi- Processor Specification) version to be used for the operating system. OS Select For DRAM > 64MB This item is only required if you have installed more Non-OS2 than 64MB of memory and you are running the OS/ 2 operating system.

  • Page 44: Advanced Chipset Features

    Advanced Chipset Features The following screen shows the Advanced Chipset Features. The following table describes each Advanced Chipset Features parameter. Settings in boldface are the default and suggested settings. Parameter Description Options DRAM Timing Selectable Selects whether DRAM timing is controlled by the By SPD SPD (Serial Presence Detect) EEPROM on the Manual...
  • Page 45 Parameter Description Options DRAM RAS# Precharge This item controls the number of cycles for Row 2T, 3T, 4T Address Strobe (RAS) to be allowed to precharge. If insufficient time is allowed for the RAS to accumulate its charge before DRAM refresh, refresh may be incomplete and DRAM may fail to retain data.

  • Page 46: Integrated Peripherals

    Integrated Peripherals The following table describes each Integrated Peripherals parameter. Settings in boldface are the default and suggested settings. OnChip IDE Device Press [Enter] to enter the sub-menu and the following screen appears: Parameter Description Options IDE HDD Block Mode Block mode is also called block transfer, multiple Enabled commands, or multiple sector read/write.

  • Page 47: Onboard Device

    Parameter Description Options IDE Primary Master UltraDMA Ultra DMA/33 implementation is possible only if Auto your IDE hard drive supports it and the operating IDE Primary Salve UltraDMA Disables environment includes a DMA driver. If your hard IDE Secondary Master UltraDMA drive and your system software both support Secondary Slave UltraDMA Ultra DMA/33, Ultra DMA/66 and Ultra DMA/100...

  • Page 48: Superio Device

    Parameter Description Options USB Mouse Support This item lets you enable or disable the USB Enabled mouse driver within the onboard BIOS. The Disabled keyboard driver simulates legacy mouse command and lets you use a USB mouse during POST or after boot if you do not have a USB driver in the operating system.

  • Page 49: Power Management Setup

    Power Management Setup The Power Management menu lets you configure the system power-management feature. It works only in APM mode. IMPORTANT:If an ACPI-aware operating system such as Windows 98 or Windows 2000 is installed in ACPI mode, the operating system will use the ACPI interfaces. Then the settings in Power Management page is non-effective.
  • Page 50 The following table describes the parameters found in this menu. Parameter Description Options ACPI Function Enabled/Disable ACPI Function. Enabled Disabled ACPI Suspend Type This item specifies the power saving modes for S1/POS ACPI function. Options are: S3/STR S1/POS: The S1 sleep mode is a low power state.
  • Page 51 Parameter Description Options Suspend Mode If system activity is not detected for the length Disabled, 1 Min, 2 Min, 4 Min, 8 of time specified in this field, all devices except Min, 12 Min, 20 Min, 30 Min, 40 CPU will be shut off. Min, 1 Hour HDD Power Down If HDD activity is not detected for the length of...

  • Page 52: Pnp/Pci Configurations

    PnP/PCI Configurations The table below describes each PnP/PCI configuration parameter. Settings in boldface are the default and suggested settings. Parameter Description Options PNP OS Installed When set to [Yes], BIOS will only initialize the PnP cards used for booting (VGA, IDE, SCSI). The rest of the cards will be initialized by the PnP operating system like Windows 98.
  • Page 53 Parameter Description Options IRQ Resources The items are adjustable only when Resources Controlled By is set to Manual. Press <Enter> DMA Resources and you will enter the sub-menu of the items. Legacy ISA for devices compliant with the original PC AT bus specification, PCI/ISA PnP for devices compliant with the Plug and Play standard whether designed for PCI or ISA bus architecture.

  • Page 54: Pc Health Status

    PC Health Status Parameter Description Options Chassis Intrusion Detect The field enables or disables the feature of Disabled recording the chassis intrusion status and issuing Enabled a warning message if the chassis is once opened. To clear the warning message, set the field to Reset.

  • Page 55: Frequency Control

    Frequency Control The following table describes the parameters found in this menu. Parameter Description Option CPU Clock Ratio Core Clock Frequency to System Bus Ratio (RO) Auto Detect PCI CLK This option allows you to enable/disable the feature of auto Enabled detecting the clock frequency of the installed PCI bus.

  • Page 56: Load Optimized Settings

    Load Optimized Settings You need to reload the BIOS default settings every time you make changes to your system hardware configuration (such as memory size, CPU type, hard disk type, etc.); otherwise, BIOS will keep the previous CMOS settings. Selecting this option displays the following dialog box: Choosing Yes enables BIOS to automatically detect the hardware changes that you have made in your system.

  • Page 57: System Security

    System Security The Setup program has a number of security features to prevent unauthorized access to the system and its data. Set Supervisor Password To set a password: At the prompt, type your password. Your password can be up to 8 alphanumeric characters. When you type the characters, they appear as asterisks on the password screen box.

  • Page 58: Set User Password

    Set User Password IMPORTANT:To show the “Set User Password”: 1. Choose “Set Supervisor Password” and press 2. Type the password and then press 3. Confirm the password, and then press 4. The screen as below with “Set User Password” enabled will be shown. To set a password: At the prompt, type your password.
  • Page 59 Clear CMOS Follow these steps to bypass the password: Reset CMOS, by adjusting JBAT1 to 2-3 Reboot the system. Adjust the JP2 back to 1-2 Please refer to the following NOTE: JBAT1: Clear CMOS CMOS Check Normal Clear CMOS Chapter 2...

  • Page 60: Save & Exit Setup

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu.

  • Page 61: Exit Without Saving

    Exit Without Saving Highlight this item and press <Enter> to discard any changes that you have made in the Setup Utility and exit the Setup Utility. When the Exit Without Saving dialog box appears, press <Y> to discard changes and exit, or press <N> to return to the main menu.

  • Page 62: Intel Serial Ata Raid Introduction

    Intel Serial ATA RAID Introduction The southbridge ICH5R provides a hybrid solution that combines two independent SATA ports for support of up to two Serial ATA (Serial ATA RAID) drives. Serial ATA (SATA) is the latest generation of the ATA interface. SATA hard drives deliver blistering transfer speeds of up to 150MB/sec.
  • Page 63 Combined Mode: S-ATA devices and P-ATA devices. Maximum of 2 devices each, thus total 4 devices at maximum. Chapter 2...

  • Page 64: Native Mode

    Native Mode: In this mode, system BIOS will search all available IRQs to use for HDD. New OS that support switch to Native Mode (WinXP, Windows .NET Server) can set SATA and PATA to Native Mode. Comprehend both Legacy and/or Native Modes. Maximum 6 ATA devices to connect (4 for P-ATA &...

  • Page 65: Raid Bios Configuration

    RAID BIOS Configuration The Intel RAID Option ROM should be integrated with the system BIOS on all motherboards with a supported Intel chipset. Please use + <I> keys to enter the “Intel(R) RAID for Serial ATA” status screen, which should appear early in system boot-up, during the POST (Power-On Self Test). Using the Intel RAID Option ROM Creating, Deleting and Resetting RAID Volumes: The Serial ATA RAID volume may be configured using the RAID Configuration utility stored within the...
  • Page 66 (1) Create RAID Volume: Select this option and press . The following screen appears: Specify a RAID Volume name and then press the key to go to the next field. Select the strip value for the RAID 0/1 array by scrolling through the available values by using the keys and pressing the key to select and advance to the next field.
  • Page 67 NOTE: RAID 1 can not select Strip Size. From the Strip size, press the key to advance to the Create Volume prompt. The window will appear as follows: Then Press to create the specified volume and the following prompt will show: Chapter 2...
  • Page 68 Press <Y> to confirm the selection or press <N> to create the RAID volume again. Then you will return to the main menu with an updated status as follows: Scroll to option 4 Exit and press to exit the RAID Configuration utility. The following prompt appears: Chapter 2...
  • Page 69 Click <Y> to confirm the exit. (2) Delete RAID Volume: Here you can delete the RAID volume, but please be noted that all data on RAID drives will be lost. NOTE: If your system currently boots to RAID and you delete the RAID volume in the Intel RAID Option ROM, your system will become unbootable.
  • Page 70 Select the volume and press key to delete the RAID volume. The following prompt appears: Press <Y> key to accept the volume deletion. (3) Reset Disks to Non-RAID: Select option 3 Reset Disks to Non-RAID and press to delete the RAID volume and remove any RAID structures from the drives.
  • Page 71 RAID 0 RAID 0 uses an algorithm to break files into smaller files of the user defined size called the stripe size. Once a file is broken down into these stripes, each drive in the array receives one or more of these fragments. For example, if there are two drives in a RAID 0 array with a 64KB stripe size and the RAID controller gets a command to write a single 128KB file, the file is broken down into two 64KB stripes.
  • Page 72 RAID 1 RAID 1 works by writing identical sets of information to two drives in an array. When the controller is sent a 64KB file to be written to a two disk RAID 1 array, the controller sends identical copies of this 64KB file to both disks in the array.

  • Page 73: Machine Disassembly And Replacement

    Chapter 3 Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the Veriton 7600GTR/GT/V, 5600GT/V and 3600GT/V desktop computer for maintenance and troubleshooting. To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge...

  • Page 74: General Information

    General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system. Chapter 3...

  • Page 75: Disassembly Procedure Flowchart

    Disassembly Procedure Flowchart The flowchart on the succeeding page gives you a graphical representation on the entire disassembly sequence and instructs you on the components that need to be removed during servicing. Veriton 7600GTR/GT/V Chapter 3...
  • Page 76 Veriton 5600GT/V Chapter 3...
  • Page 77 Veriton 3600GT/V Chapter 3...

  • Page 78: Disassembling The Veriton 7600Gtr/Gr/V

    Disassembling the Veriton 7600GTR/GT/V Opening the Housing This section tells you how to open the housing cover when you need to install additional components inside the system unit. CAUTION: Before you proceed, make sure that you have turned off the system and all peripherals connected to it.
  • Page 79 Disconnect the HDD cable and HDD power cable from the HDD. Pull the ODD lock and then detach the ODD from the frame. Pull the FDD lock and then detach the FDD from the frame. Press the right and left HDD holders and then detach the HDD carefully. Remove the left ODD holder.
  • Page 80 Removing the Internal Cables/Connectors and Memory Disconnect the main power connector from the main board. Disconnect the 12-voltage power connector from the main board. Disconnect the FDD cable, ODD cable and HDD cable from the main board. Press the leavers on the both sides of the DIMM socket outward to release the DIMM, and then gently pull the DIMM out to remove it.
  • Page 81 Disconnect the internal speaker connector from the main board. Disconnect the LAN LED connector from the main board. Disconnect the one button recovery connector, chassis intrusion switch connector, front panel connectors, and system fan connector from the main board. Removing the CPU Fan Sink, CPU and System Fan Disconnect the CPU fan connector from the main board.
  • Page 82 Remove the four screws holding the system fan. Take out the system fan. Removing the Power Supply and Main Board Remove the four screws holding the power supply on the rear side. Detach the power supply from the housing carefully. Remove the eight screws holding the main board as the picture shows.
  • Page 83 Detach the upper cover from the housing carefully. Remove the four screws holding the daughter board plate. Remove the daughter board plate. Remove the daughter board top cover as the picture shows. Cut the cable clamp holding the two front USB cables and front panel audio cable. Remove the daughter board module from the upper cover.
  • Page 84 Removing the Intrusion Alarm and LCD Module Remove the two screws holding the intrusion alarm, and then take out the intrusion alarm Remove one screw holding the LED module holder. Remove the LED module as the picture shows. Remove one screw holding the reset button holder as the picture shows. Pull out the reset cable carefully.

  • Page 85: Disassembling The Veriton 5600Gr/V

    Disassembling the Veriton 5600GT/V Opening the Housing This section tells you how to open the housing cover when you need to install additional components inside the system unit. CAUTION: Before you proceed, make sure that you have turned off the system and all peripherals connected to it.
  • Page 86 Disconnect the FDD power cable and FDD cable from the FDD. Pull the FDD lock and then detach the FDD from the frame. Disconnect the HDD cable and HDD power cable from the HDD. Press the right and left HDD holders and then detach the HDD carefully. Remove the right ODD holder.
  • Page 87 Removing the Internal Cables/Connectors and Memory Disconnect the main power connector from the main board. Disconnect the 12-voltage power connector from the main board. Disconnect the FDD cable, ODD cable and HDD cable from the main board. Press the leavers on the both sides of the DIMM socket outward to release the DIMM, and then gently pull the DIMM out to remove it.
  • Page 88 Pull the socket lever up to 90 degree and then pull out the CPU from the socket. Put the socket lever back to the original position. Removing the Internal Cables/Connectors and Memory Disconnect the front panel audio connector from the main board. Disconnect the two front USB connectors from the main board.
  • Page 89 Remove the four screws holding the power supply on the rear side. Detach the power supply from the housing carefully. Remove the eight screws holding the main board as the picture shows. Detach the main board from the lower case carefully. Removing the LED Module and Daughter Board Module Remove one screw holding the LED module holder.
  • Page 90 Remove one screw holding the daughter board bracket. Remove the daughter board module as the picture shows. Disconnect the front panel audio connector from the daughter board. Disconnect the two front USB connectors from the daughter board. Remove the two screws holding the daughter board. Remove the daughter board from the daughter board bracket.

  • Page 91: Disassembling The Veriton 3600Gr/V

    Disassembling the Veriton 3600GT/V Opening the Housing This section tells you how to open the housing cover when you need to install additional components inside the system unit. CAUTION: Before you proceed, make sure that you have turned off the system and all peripherals connected to it.
  • Page 92 Disconnect the HDD cable and HDD power cable from the HDD. Pull the ODD lock and then detach the ODD from the frame. Pull the FDD lock and then detach the FDD from the frame. Press the right and left HDD holders and then detach the HDD carefully. Remove the left ODD holder.
  • Page 93 Removing the Internal Cables/Connectors and Memory Remove the air duck as the video shows. Disconnect the HDD cable, ODD cable, and FDD cable from the main board. Disconnect the main power connector from the main board. Disconnect the 12-voltage power connector from the main board. Press the leavers on the both sides of the DIMM socket outward to release the DIMM, and then gently pull the DIMM out to remove it.
  • Page 94 Removing the Internal Cables/Connectors Disconnect the front panel audio connector from the main board. Disconnect the two front USB connectors from the main board. Disconnect the LAN LED connector from the main board. Disconnect the internal speaker connector from the main board. Disconnect the one button recovery connector, chassis intrusion switch connector, front panel connectors, and system fan connector from the main board.
  • Page 95 Pull the socket lever up to 90 degree and then pull out the CPU from the socket. Put the socket lever back to the original position. Removing the System Fan and Main Board Remove the two screws holding the system fan. Take out the system fan.
  • Page 96 Remove the front panel as the video shows. Disconnect the front panel audio connector from the daughter board. Disconnect the two front USB connectors from the daughter board. Remove one screw holding the daughter board bracket. Remove the daughter board module as the video shows. Remove the two screws holding the daughter board.
  • Page 97 Pull the internal speaker cable, front panel cables, LAN LED cable and one button recovery cable as the video shows. 10. Remove one screw holding the LED module holder. 11. Remove the LED module as the video shows. 12. Remove the reset button as the video shows. 13.
  • Page 98 Chapter 3...

  • Page 99: Troubleshooting

    Chapter 4 Troubleshooting This chapter provides troubleshooting information for the Veriton 7600GTR/7600GT/7600V, 5600GT/5600V and 3600GT/3600V. Power-On Self-Test (POST) Index of Error Message Index of Error Symptoms Undetermined Problems Chapter 4...

  • Page 100: Power-On Self-Test (Post)

    Power-On Self-Test (POST) Each time you turn on the system, the Power-on Self Test (POST) is initiated. Several items are tested during POST, but is for the most part transparent to the user. The Power-On Self Test (POST) is a BIOS procedure that boots the system, initializes and diagnoses the system components, and controls the operation of the power-on password option.
  • Page 101 Checkpoint Description Reserved 1. Blank out screen 2. Clear CMOS error flag Reserved 1. Clear 8042 interface 2. Initialize 8042 self-test 1. Test special keyboard controller for Winbond 977 series Super I/O chips. 2. Enable keyboard interface. Reserved 1. Disable PS/2 mouse interface (optional) 2.
  • Page 102 Checkpoint Description 1. Check validity of RTC value: e.g. a value of 5Ah is an invalid value for RTC minute. 2. Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value instead. 3. Prepare BIOS resource map for PCI & PnP use. If ESCD is valid, take into consideration of the ESCD’s legacy information.
  • Page 103 Checkpoint Description Test 8259 functionality Reserved Reserved Reserved Initialize EISA slot Reserved 1. Calculate total memory by testing the last double word of each 64K. 2. Program writes allocation for AMD K5 CPU. Reserved Reserved Reserved Reserved 1. Program MTRR of M1 CPU. 2.
  • Page 104 Checkpoint Description Prepare memory size information for function call: INT 15h ax=E820h Reserved Turn on L2 cache Reserved Program chipset registers according to items described in Setup& Auto-configuration table. Reserved 1. Assign resources to all ISA PnP devices. 2. Auto assign ports to onboard COM ports if the corresponding item in Setup is set to “AUTO”...
  • Page 105 Checkpoint Description 1. USB final Initialization 2. NET PC: Build SYSID structure 3. Switch screen back to text mode. 4. Set up ACPI table at top of memory. 5. Invoke ISA adapter ROMs. 6. Assign IRQs to PCI devices 7. Initialize APM 8.

  • Page 106: Post Error Messages List

    POST Error Messages List If you cannot run the diagnostics program tests but did receive a POST error message, use “POST Error Messages List” to diagnose system problems. If you did not receive any error message, look for a description of your error symptoms in “Error Symptoms List”...
  • Page 107 BIOS Messages Action/FRU Memory Test: This message displays during a full memory test, counting down the memory areas being tested. Memory test fail If POST detects an error during memory testing, additional information appears giving specifics about the type and location of the memory error.

  • Page 108: Error Symptoms List

    Error Symptoms List NOTE: To diagnose a problem, first find the error symptom in the left column. If directed to a check procedure, replace the FRU indicated in the check procedure. If no check procedure is indicated, the first Action/ FRU listed in right column is the most likely cause.
  • Page 109 Error Symptom Action/FRU Diskette drive LED comes on for more than 2 1. Diskette minutes when reading data. 2. Diskette drive connection/cable 3. Diskette drive 4. Main board Diskette drive LED fails to light, and the drive 1. Diskette is unable to access for more than 2 minutes. 2.
  • Page 110 Error Symptom Action/FRU Audio Audio software program invokes but no sound 1. Speaker power/connection/cable. comes from speakers. Modem Modem ring cannot wake up system from 1. For the External Modem, make sure Power on By Ring in BIOS suspend mode. Setup or Power Management is set to Enabled.
  • Page 111 Error Symptom Action/FRU Parallel/Serial Ports Execute “Load BIOS Default Settings” in BIOS Setup to confirm ports presence before diagnosing any parallel/serial ports problems. Serial or parallel port loop-back test failed. 1. Make sure that the LPT# or COM# you test is the same as the setting in BIOS Setup.

  • Page 112: Undetermined Problems

    Check all cables and connectors for proper installation. If the jumpers, switches and voltage settings are correct, remove or disconnect the following, one at a time: 10. Non-Acer devices External devices Any adapter card (modem card, LAN card or video card, if installed)

  • Page 113: Jumper And Connector Information

    Chapter 5 Jumper and Connector Information Jumpers and Connectors Refer to the following figure for the location of the jumpers and connectors on the main board: CPUFAN1 D_LED1 COM2 DDR DIMMs ATX1 Back Panel I/O FDD1 JPW1 IDE1 & IDE2 JUSB_MS JLAN LED1 SATA1, SATA2...

  • Page 114: Jumper And Connector Description

    Jumper and Connector Description Label Component Label Component JPW1 ATX 12V Power Connector JCI1 Chassis Intrusion Switch Connector CPUFAN1 Processor Fan Connector JBAT1 Clear CMOS Jumper D_LED1 JBIOS1 BIOS Flash Jumper D Bracket 2 Connector COM1 9-pin Serial Port JRECOVER System Recovery Switch Connector FDD1 FDD Connector...

  • Page 115: Main Board Layout

    Main Board Layout D_LED1 Top : mouse Bottom: keyboard COM2 USB ports SMCS LPC47M192-NC Top : Parallel Port Bottom: COM A VGA port JPW1 Intel Springdale Top: LAN jack Bottom: USB ports JUSB_MS JLAN LED1 :Line-In Line-Out B:Mic AGP Slot Broadcom BCM5705 JLAN1...
  • Page 116 Chapter 5...

  • Page 117: Chapter 6 Fru (Field Replaceable Unit) List

    Acer Corporation does not provide these parts. NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how best to dispose it, or follow the rules set by your regional Acer office on how to return it.

  • Page 118: Veriton 7600Gtr/Gr/V Exploded Diagram

    Veriton 7600GTR/7600GT/7600V Exploded Diagram Chapter 6...

  • Page 119: Veriton 5600Gr/V Exploded Diagram

    Veriton 5600GT/5600V Exploded Diagram Chapter 6...

  • Page 120: Veriton 3600Gr/V Exploded Diagram

    Veriton 3600GT/3600V Exploded Diagram Chapter 6...
  • Page 121 Picture Part Name Part Number CPU/Processor CELERON 2.0G SOCKET 478, D1 KC.DCD01.20A Celeron 2.4G Socket 478, D1 KC.DCD01.24A Celeron 2.5G Socket 478, D1 KC.DCD01.25A Celeron 2.6G Socket 478, D1 KC.DCD01.26A Celeron 2.7G Socket 478, D1 KC.DCD01.27A Celeron 2.8G Socket 478, D1 KC.DCD01.28A Northwood 2.4G Socket 478 KC.DP001.24C...
  • Page 122 Picture Part Name Part Number Hard Disk Drive HDD 80GB 7200RPM SATA SEAGATE ALPINE ST380013AS KH.08001.005 HDD 120G 7200RPM SATA SEAGATE ALPINE ST3120026AS KH.12001.005 HDD 160G 7200RPM SATA SEAGATE ALPINE ST3160023AS KH.16001.004 HDD 40GB/5400RPM/ATA-100 /SEAGATE C2 ST340015A KH.04001.002 HDD U9 80G 5400RPM SEAGARE ST380012A KH.08001.002 HDD 120GB 5400RPM ATA-100 SEAGATE U9 ST3120025A KH.12001.002...
  • Page 123 Picture Part Name Part Number For VT3600 FDD CABLE 34PIN 2CON 50.V02VF.301 HDD IDE CABLE 40PIN (SHORT) 50.V02VF.302 ODD CABLE 40PIN (LONG) 50.V02VF.303 AUDIO CABLE 10PIN 2CON 50.V02VF.304 USB CABLE 10PIN 2CON 50.V02VF.305 LED CABLE (LAN, POWER/ HDD) POWER BUTTON BOARD 50.V02VF.306 W/ BRACKET RESET CABLE...
  • Page 124 Picture Part Name Part Number Add-on Card VGA CARD RADEON 9200 64MB DDR LP W/TV-OUT NTSC/ VG.A9207.003 LP BRACKET FIC TI-4200-8X VGA CARD RADEON 9200 64MB DDR LP W/TV-OUT PAL/LP VG.A9207.004 BRACKET FIC TI-4200-8X VGA CARD FX 5200 64MB W/TW-OUT PAL LP BRACKET VG.29604.005 LEADTEK LR2967 VGA CARD FX5200 64MB W/TW-OUT NTSC LP BRACKET...
  • Page 125 Picture Part Name Part Number USB KB(GRAY), KU0355, US VER., 104KEYS KB.KUS03.026 USB KB(GRAY), KU0355, T.CHINESE VER., 104KEYS KB.KUS03.027 USB KB(GRAY), KU0355, INT'L US VER., 104 KEYS KB.KUS03.028 USB KB (GRAY), KU0355, ARABIC VER., 104 KEYS KB.KUS03.029 USB KB (GRAY), KU0355, THAI VER., 104 KEYS KB.KUS03.030 USB KB (GRAY), KU0355, GERMANY VER., 105 KEYS KB.KUS03.031...
  • Page 126 Picture Part Name Part Number USB KEYBOARD, KU0355, SPANISH/US VER., 105KEYS KB.KUS03.008 USB KEYBOARD, KU0355, CANADIAN/FRENCH VER., KB.KUS03.009 105KEYS USB KEYBOARD, KU0355, BRAZILIAN VER., 107KEYS KB.KUS03.010 USB KEYBOARD, KU0355, SWISS VER., 105KEYS KB.KUS03.011 USB KEYBOARD, KU0355, BELGIUM VER., 105KEYS KB.KUS03.012 USB KEYBOARD, KU0355, ICELAND VER., 105KEYS KB.KUS03.014 USB KEYBOARD, KU0355, NORWEGIAN VER., 105KEYS...
  • Page 127 Picture Part Name Part Number For VT3600 LEFT COVER 60.V02VF.301 FRONT BEZEL W/ ODD DOOR, FDD COVER, FDD BUTTON 60.V02VF.302 ODD DOOR W BUTTON 42.V02VF.301 FDD BUTTON 42.V02VF.302 FDD COVER W LENS 42.V02VF.303 UPPER COVER 60.V02VF.303 RETENTION MODULE W NAIL 4PCS 42.V02VF.304 IO BRACKET HOLDER 42.V02VF.305...
  • Page 128 Picture Part Name Part Number Speaker INTERNAL SPEAKER 38MM NEOSONIC SP.CRB04.001 SPEAKER 5W+5W ACTIVE 12V PHILIPS A201S SP.20101.001 Fan Sink SYSTEM FAN W AIR DUCK HEATSINK W LATCH HI.V020B.005 HEATSINK W LATCH HI.V020B.004 Foot Stand FOOT STAND (PLASTIC) 47.V02VF.301 Screws SPS SCREW 86.RC9VF.001 MAIN BOARD SCREW...
  • Page 129 Chapter 6...

  • Page 130: Appendix A Model Definition And Configuration

    Appendix A Model Definition and Configuration Veriton 7600GTR/7600GT/7600V, 5600GT/5600V, 3600GT/3600V Project Name: Trumpet Description ® Trumpet series is positioned to be the first Main Board product that supports the latest Intel Chipset Springdale-G/GV technology with DDR DIMM module and Hyper-Threading Techology. As a technology leader in the PC market, Bassoon stands for not only the image of the best performance product for Intel’s next...

  • Page 131: Appendix B Test Compatible Components

    Appendix B Test Compatible Components This computer’s compatibility is a test plan released by Acer Internal Testing Department. Once the final report is available, this chapter will be revised accordingly. Appendix B...

  • Page 132: Microsoft Windows Xp Environment Test

    Combo HLDS 48X DVD-RW Pioneer 4/2/16/8, 12/32 DVD-Dual NEC 4X DVD-Dual, Acer color, w/o Acer logo Pioneer 4X DVD-Dual, Acer color, w/o Acer logo DVD Super Multi HLDS 4X DVD Super Multi (RAM, -R, +R) Daughter board MSI USB/AUDIO Board for H80/H40/H360 MSI Front USB2.0 DB USB cable...
  • Page 133 DVI adapter card Leadtek DVI Adapter Card for 845G chipset on-die VGA Speaker Charming Standard 2.1 Channel Charming Internal speaker Neosonic 3W+3W+15W, Active AC, Acer White 002 Philips 5W+5W, ACTIVE, 12V Wireless LAN Adapter Zcom PCI 802.11 CARD Modem Adapter...
  • Page 134 Chicony Swiss, USB KB (acer 002), KUP0355, 105 keys, w/palm Chicony US ver., USB KB (acer 002), KUP0355, 104 keys, w/palm Chicony T. Chinese ver. USB KB (acer 002), KUP0355, 104 keys, w/palm Chicony Spanish/US, USB KB (acer 002), KUP0355, 105keys, w/palm...

  • Page 135: Appendix C Online Support Information

    This section describes online technical support services available to help you repair your Acer Systems. If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch office. Acer Branch Offices and Regional Business Units may access our website. However some information sources will require a user i.d.
  • Page 136 Appendix C...

This manual is also suitable for:

Veriton 7600gtVeriton 3600gtVeriton 3600vVeriton 7600vVeriton 5600gtVeriton 5600v

Table of Contents
