M
O D E L S
Remote Insight Board/PCI
LAN+NA Modem
294013-001
LAN+PanEuro Modem
294013-B31
LAN+Serial Card
294013-B22
LAN Only
294013-B23
LAN+Japanese Modem
294013-291
LAN+Japanese Serial
294013-292
O
P T I O N S
Upgrade modems
North American Modem
294031-001
Pan-European Modem
294031-B31
Upgrade serial card
Serial Card
294031-B22
Highly-intelligent management
board providing continuous in-
band and out-of-band
communication and alert
delivery for monitoring of
business-critical servers
Q
S
UICK
PECS
. .
. .
LAN Network Connectivity
. .
. .
All versions include an onboard Ethernet connection, providing Network Administrators with a full time network
. .
. .
connection to the managed server. Remote Insight provides in-band notification in case of server problems at the
. .
. .
Central Site management station on a real-time basis, without needing to maintain separate telephone connections or
. .
modem sharing devices.
. .
. .
. .
Browser Accessible
. .
. .
. .
Remote Insight is accessible with Netscape Navigator or Microsoft Internet Explorer. This allows easy access to
. .
Remote Insight board features to perform remote management tasks using a familiar user interface.
. .
. .
. .
Remote Insight Console
. .
. .
. .
Remote Insight Console provides a remote connection to managed servers, allowing a remote PC to display all
. .
. .
phases of server activity (including post sequences and OS load) without loss of connection.
. .
. .
Remote Insight provides Remote Graphical Console capabilities for Windows NT servers utilizing standard graphics
. .
based terminal emulation software tools such as Carbon Copy 32 and pcAnywhere 32.
. .
. .
. .
Remote Reboot
. .
. .
. .
Allows the remote administrator to reboot the server on demand; when the system is functioning properly, the system
. .
performs a graceful shutdown prior to reset; when the system is not responding, a cold reboot will be issued in order
. .
. .
to bring the server back on-line
. .
. .
. .
PC Card Modem
. .
. .
. .
Models 294013-001, 294013-B31 and 294013-291 provide integrated modem communications through a 33.6 Kb/s
. .
PC Card modem, with localized support for country-specific telecommunications requirements.
. .
. .
. .
Serial Communications
. .
. .
Models 294013-B22 and 294013-292 provide an RS-232 serial port for connecting an external customer supplied
. .
. .
modem.
. .
. .
. .
NiMH Rechargeable Battery Backup
. .
. .
. .
Integrated, user-replaceable battery provides at least 30 minutes of operation to guarantee alert delivery in the event
. .
of a server power failure.
. .
. .
. .
Reset and Failure Sequence Replay
. .
. .
. .
Captures and stores server video text to assist in locating startup problems and causes of failure; information is
. .
available for replay on demand
. .
. .
. .
Compaq Insight Manager Integration
. .
. .
. .
Fully integrates with Compaq Insight Manager under key operating environments providing hardware-based
. .
asynchronous server manageability; supports full out-of-band SNMP management
. .
. .
. .
Integrated with SmartStart
. .
. .
. .
Fully configurable through the SmartStart interview process
. .
. .
. .
Integration with Compaq Survey
. .
. .
Utilizing industry-standard browsers, users can access the Compaq Survey configuration file, providing the latest
. .
. .
server configuration information to assist in the diagnostic process.
. .
. .
. .
User Administration
. .
. .
Supports up to 12 users with customizable access rights, each with individual log in, password and call back to
. .
. .
ensure security.
. .
. .
. .
Alert Administration
. .
. .
. .
Provides support for alphanumeric or numeric paging, as well as SNMP trap delivery to an Insight Manager console.
. .
With network only access, the board cannot send paging alerts. Access is required either with the onboard modem or
. .
. .
an external modem for the administrator to receive paging alerts.
. .
. .
. .
. .
. .
. .
1
DA-10122-01-003 — 01.24.2000
Compaq Remote Insight
Board/PCI
