Boss Audio Systems 870DBI User Manual

Bluetooth-enabled - full ipod and iphone control through usb in-dash double-din mp3-compatible cd am/fm receiver with usb and sd memory card ports and front panel aux input
Hide thumbs Also See for 870DBI:
Table of Contents

Advertisement

Quick Links

10 R - 02 1397
4

Advertisement

Table of Contents
loading

Related Manuals for Boss Audio Systems 870DBI

Summary of Contents for Boss Audio Systems 870DBI

  • Page 1 10 R - 02 1397...

  • Page 2: Remove The Unit

    1. INSTALLATION The following illustration shows a typical installation. If you have any questions or require information regarding installation kits, consult your customer car audio dealer or a company suppling kits. If you are not sure how to install this unit correctly, have it installed by a qualified technician. To attach the front panel back to the unit chassis, please insert the right side of the panel in...

  • Page 3: Connecting The System

    2. CONNECTING THE SYSTEM SUBW Front Rear RCA L RCA L ANTENNA Antenna JACK Front Rear Socket RCA R RCA R CONNECTOR Figure 2 ISO CONNECTOR WIRING CHART WIRE COLOR FUNCTION/LABEL YELLOW BATTERY(+) BLUE CONNECT TO SYSTEM CONTROL TERMINAL OF THE POWER AMP OR AUTO ANTENNA RELAYCONTROL TERMINAL(max 150mA 12VDC) IGNITION(ACC)
  • Page 4 3. THE MAJOR FUNCTION OF THIS UNIT Decriptions No. Item Press to turn the unit on, press and hold turn the unit off. Power Press to Mute or restore the volume. MUTE MENU Press to access into the System Menu mode. Press to access into the Audio Menu mode to adjust the below AUDIO options: BASS(Bass Level) / TRE (Treble Level) / BAL(Balance)
  • Page 5 3. THE MAJOR FUNCTION OF THIS UNIT Decriptions No. Item TUNE UP Under Radio mode, turn these buttons to enter into the Auto Seek /DOWN mode, turn and hold these buttons to enter into the Manual Seek mode. FILE UP Under Media playback mode, turn these buttons to skip a chapter / /DOWN track / scene / file.
  • Page 6 4. ADJUST SYSTEM MENU SETTING Press MENU to access into the System Menu. Press MENU repeatedly to select the item to be adjusted, then roate Encoder Volume Knob to select a value / option. Reconnection/Disconnection This feature allows to Reconnect or Disconnect to the paired mobile phone or Bluetooth device manually. >...

  • Page 7: About Rds

    5. ABOUT RDS The RDS (Radio Data System) function operates only in areas with FM stations broadcasting RDS signals. If you tune to an RDS station, an RDS icon and information about the presenter, station or program is displayed. This unit support below RDS features: Select Program Type ( PTY ) Before tuning to RDS stations, you can select program type and let the unit search only for programs of the selected category.
  • Page 8 6. EXTERNAL CONNECTION AND MEDIA PLAYER MP3 music files are audio compression format. This unit can play MP3 directly from files contained on a USB Memory Stick, SD Card. USB DEVICE OPERATION Insert the USB Device 1. Open the cover marked USB icon on the front panel. Insert the USB device into the USB socket.
  • Page 9 7. iPod / iPhone OPERATION This unit is equipped with iPod/iPhone Ready function which allow end user to have direct control of the iPod/iPhone on the front panel control button and display iPod/iPhone song information on the unit's LCD display. Please read below for more details operation. Compatible iPod/iPhone Apple iPod and iPhone models with a 30-pin dock connector: •...

  • Page 10: Making A Call

    8. BLUETOOTH HANDS FREE & A2DP STREAMING OPERATION You can make or receive phone calls with Bluetooth-enabled phones through the unit. You can also listen to music from an A2DP Bluetooth-enabled device. Pairing a Bluetooth Device Before using the Bluetooth device, you need to pair the device to the unit. Pairing needs only to be done once. Open your mobile phone and switch bluetooth on.
  • Page 11 9. THE FUNCTIONS OF REMOTE CONTROL Decriptions No. Button Item MUTE MUTE Press this button to turn the mute On / Off. When the unit is power on, press this button to POWER ON/OFF turn Off the unit. Once the unit power off, press this button to turn On the unit.

  • Page 12: Trouble Shooting

    10. TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. No power or no sound Car engine is not on. Turn the car engine on. Cable is not correctly connected.

  • Page 13: Product Information

    11. PRODUCT INFORMATION Power Supply 12 V DC (11-14 V), Negative Ground Fuse Suitable Speaker Impedance 4 - 8 Power output 80W x 4 channels Pre-AMP output voltage 2.0 V (USB play mode; 1KHZ, 0dB,10k load) Aux-In level 300mV Radio Frequency Range 87.5 - 107.9MHz(American) 87.5 - 108MHz(Europe)
  • Page 14 ES - 1...
  • Page 15 ES - 2...
  • Page 16 ES - 3...
  • Page 17 ES - 4...
  • Page 18 ES - 5...
  • Page 19 ES - 6...
  • Page 20 ES - 7...
  • Page 21 ES - 8...
  • Page 22 ES - 9...
  • Page 23 ES - 10...
  • Page 24 ES - 11...
  • Page 25 ES - 12...
  • Page 26 ES - 13...
