Summary of Contents for Gateway FPD1785
- Page 1 USER GUIDE Gateway FPD1785/FPD1985 Monitor...
-
Page 3: Table Of Contents
Using Your Gateway Flat Panel Monitor ........ - Page 4 Contents www.gateway.com...
-
Page 5: Using Your Gateway Flat Panel Monitor
Using Your Gateway Flat Panel Monitor • Connecting the monitor • Adjusting the stand • Starting the monitor • Adjusting monitor settings • Windows controls • Power management • Maintenance • Troubleshooting • Specifications... -
Page 6: Connecting The Monitor
- OR - If your computer has a digital video connector (DVI), connect a DVI video cable (not included) to the white connector under the back of the monitor. You can buy a DVI video cable from www.gateway.com. www.gateway.com... - Page 7 Warning Because lifting your monitor off the desktop surface takes weight off from the stand, the stand will extend suddenly, possibly causing damage to equipment or injury to yourself. To avoid injury, always lift the monitor so that the stand adjusts to its full height before moving the monitor or turning it around.
-
Page 8: Adjusting The Stand
Using Your Gateway Flat Panel Monitor www.gateway.com Adjusting the stand Rotates 90° for portrait or landscape orientation Tilts from -5° to 35° Pans 31° left and right Vertical height adjusts five inches... -
Page 9: Rotating The Screen Image
Themes (if necessary), Display, the Settings tab, Advanced, then click the graphics card-specific tab. The stand is factory adjusted to maintain the adjusted height for Gateway 17-inch and 19-inch flat-panel monitors. If you use this stand with a lighter monitor without adjusting the weight setting of the stand, the stand will raise your monitor, and if you use a heavier monitor, the stand will lower your monitor. -
Page 10: Adjusting Tilt (Vertical Viewing Angle) Tension
Using Your Gateway Flat Panel Monitor Adjusting tilt (vertical viewing angle) tension Adjust the height tension screw so raising and lowering forces are equal. After the forces are equalized, turn the tension screw clockwise 2 to 4 turns to slightly decrease the lifting tension. -
Page 11: Ergonomic Guidelines
Adjusting the stand Ergonomic guidelines The recommended mounting heights, the range of adjustability required to provide comfortable use by a range of users, and the forces required for making adjustments to the monitor are based upon the following guildelines. These guidelines are based on available scientific literature and published standards. -
Page 12: Starting The Monitor
Using Your Gateway Flat Panel Monitor Starting the monitor Important The appearance of your monitor may vary from that shown. Important When adjusting the monitor settings, always press the Auto button before entering the OSD. This will automatically adjust the monitor image to the ideal settings for the current screen resolution. -
Page 13: Adjusting Monitor Settings
Adjusting monitor settings Monitor buttons Important The appearance of your monitor may vary from that shown. Use the monitor controls (located on the monitor itself) and computer controls (accessible through Windows) to adjust the monitor image. For more information about computer controls, see “Windows controls” on page 12. -
Page 14: On-Screen Display Options
Using Your Gateway Flat Panel Monitor On-screen display options Tips & Tricks While the OSD is active, on-screen labels appear next to the buttons to help you identify them. Adjusting OSD settings To adjust the OSD settings: Press the Auto button. The monitor image is automatically adjusted to the ideal settings for your current screen resolution. - Page 15 OSD Menu Main menu Main Menu Auto Picture Geometry Advanced Reset Picture menu Picture Brightness Contrast Gamma Geometry menu Geometry H-Position V-Position Clock Phase OSD menus Description Auto—Automatically adjusts your monitor to its optimum settings. Picture—Opens the Picture menu, where you can adjust brightness, contrast, and gamma.
-
Page 16: Windows Controls
Using Your Gateway Flat Panel Monitor OSD Menu Advanced menu Advanced Color Language LED Brightness Information Windows controls Help & Support For more information about adjusting monitor settings, click Start, then click Help and Support. Type the phrase changing display settings in the Search box, then click the arrow. - Page 17 Help & Support For more information about adjusting screen resolution, click Start, then click Help and Support. Type the phrase changing screen resolution in the Search box, then click the arrow. Click the Settings tab. Click the arrow button to open the Color quality list, then click the color depth you want.
- Page 18 Using Your Gateway Flat Panel Monitor Click the Settings tab. Drag the Screen resolution slider to the size you prefer. Click OK, then click Yes to save your changes. Clarifying screen fonts You can change the display fonts to ClearType for smoother screen fonts.
- Page 19 Click the Appearance tab. Click the Effects button. The Effects dialog box opens. Click to select the Use the following method to smooth the edges of screen type check box. Click the arrow to open the list, then click ClearType.
-
Page 20: Video Modes
Using Your Gateway Flat Panel Monitor Video modes Your monitor supports several video modes. If you do not use the best mode for the monitor, the monitor image may look slightly “fuzzy.” 17-inch monitor Mode Mode name and resolution VGA 720 × 400 VGA 640 ×... -
Page 21: Power Management
VESA 1280 × 1024 ® As an ENERGY STAR Partner, Gateway has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This monitor complies with the EPA’s International ENERGY STAR Program, which is a program designed to encourage manufacturers of computer equipment to build circuitry into their products to reduce energy consumption during time of non-use. -
Page 22: Maintenance
Using Your Gateway Flat Panel Monitor Maintenance Caution Do not use any type of abrasive pad or glass cleaner. You will permanently scratch the screen. Troubleshooting Important Make sure that the monitor has warmed up for approximately 30 minutes before making any judgments about the picture quality. -
Page 23: No Picture
No picture Monitor colors are wrong Picture has shadows or “ghosts” Press the Input button to make sure that you have selected the correct ■ video source. Make sure that the power cord is connected correctly to both the back of ■... -
Page 24: Color Is Not Uniform
LCD screens. Gateway’s inspection standards keep these to a minimum. If you feel these pixels are unacceptably numerous or dense on your monitor, contact Gateway Customer Care to identify whether a repair or replacement is justified based on the number of pixels affected. -
Page 25: 17-Inch Monitor
17-inch monitor Brightness and contrast ratio Connections and inputs 17 inches (diagonal) Panel size Panel type 17-inch viewable TFT with anti-glare coating 1280 × 1024 (native) Pixel resolution Pixel pitch 0.0104 × 0.0104 inches (0.264 mm × 0.264 mm) -
Page 26: 19-Inch Monitor
Using Your Gateway Flat Panel Monitor 19-inch monitor Brightness and contrast ratio Connections and inputs 19 inches (diagonal) Panel size Panel type 19-inch viewable TFT with anti-glare coating 1280 × 1024 (native) Pixel resolution Pixel pitch 0.0116 × 0.0116 inches (0.294 mm × 0.294 mm) -
Page 27: Safety, Regulatory, And Legal Information
Safety, Regulatory, and Legal Information • Important safety information • Environmental information • Regulatory compliance statements • Notices... -
Page 28: Important Safety Information
Your Gateway product is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed. -
Page 29: Recycling
When your electrical or electronic equipment is no longer useful to you, “take it back” to your local or regional waste collection administration for recycling. ■ In some cases, your “end of life” product may be “traded in” for credit towards the purchase of new Gateway equipment. Call Gateway to see if this program is available in your area. ■... -
Page 30: Regulatory Compliance Statements
Regulatory compliance statements Regulatory compliance statements United States of America Caution Changes or modifications not expressly approved by Gateway could void the FCC compliance and negate your authority to operate the product. California Proposition 65 Warning This product contains chemicals,... -
Page 31: Trademark Acknowledgments
Due to continuing system improvements, Gateway is not responsible for inaccurate information which may appear in this manual. For the latest product updates, consult the Gateway Web site at www.gateway.com. In no event will Gateway be liable for direct, indirect, special, exemplary, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 32 Notices www.gateway.com...
- Page 34 MAN FPD1785/1985 USR GDE R0 4/06...
