Page 1: Reference Manual
Personal Computer Reference Manual CF-Y2/CF-W2 Series Model No. We recommend that this Reference Manual be printed.
Page 2: Read Me First
Read Me First Some of the illustrations in this manual may differ slightly in shape from the actual items in order to make the explanation easier to understand. If the user has logged on without the administrator authority, some functions may not be executable, and some screens may not be displayed as shown in this manual.
Page 3 The terminology in ( ) is the one used in [Intel(R) 82852/82855 GM/GME Graphics Controller properties]. To display [Intel(R) 82852/82855 GM/GME Graphics Controller properties]: <CF-Y2 series> Select [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics 2 <CF-W2 series>...
Page 4: Key Combinations
Key Combinations CAUTION Do not press the following key combinations repeatedly in (quick) succession. Also, do not press different key combinations quickly one after another. Do not press the following key combinations while using the touch pad (external mouse) or other keys. NOTE Do not press the following key combinations until you log on to Windows and the hard disk drive indicator turns off.
Page 5 Fast User Switching function, this key operation may not work. In this case, log off all users and restart the computer. <Only for CF-Y2 series> Simultaneous display cannot be used until Windows startup is complete (during Setup Utility, Windows logon screen, etc.). When Fn+F3 is pressed, the screen is displayed on the external display or internal LCD.
Page 6 Key Combinations Functions Popup Window (Displayed after logging on to Windows) Fn+F4 Speaker on/off switch Pressing this key combination turns on/off audio from the internal speaker and headphone jack. (MUTE) NOTE Disabling the speakers will also disable the warning beep. Speakers connected to the USB port cannot be muted.
Page 7 Key Combinations Functions Popup Window (Displayed after logging on to Windows) Fn+F9 Remaining capacity of the battery pack When the battery pack is inserted in the computer (example) When the battery pack is not inserted in the computer Fn+F10 Shut down using the hibernation function Pressing this key combination causes the current status of the computer to be saved to the hard disk, and shuts down the computer.
Page 8 Ctrl reversed. Run the Hotkey Settings. Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings]. Set the parameters. A. Use Fn key lock Add the check mark if you want to enable the Fn key lock function. The following Fn key lock function will then be enabled.
Page 9 Key Combinations C. Disable popup Add the check mark if you want to turn the popup window display function OFF. "Full Screen" of [Command Prompt] or MPEG files may change to a window display if Fn+Fx keys are pressed. To prevent this, turn the popup window display function OFF.
Page 10: Led Indicators
LED Indicators Power status Not lit Power off / Hibernation mode Green Power on Blinking green Standby mode Battery pack status page 34 This indicator lights green when Caps Lock is Caps Lock pressed. Subsequent non-shifted input is capitalized. This indicator lights green when NumLk is NumLk pressed.
Page 11 <CF-W2 series> ScrLk Hard disk drive status This indicator lights when the hard disk drive is accessed. DVD-ROM & CD-R/RW <CF-Y2 series> drive status Light off Drive power is off. Light on Drive power is on, but the DVD-ROM & CD-R/ RW drive is not accessed.
Page 12: Touch Pad
Use the touch pad to move the cursor on the screen and perform computer operations. A. Work Surface (touch pad) B. Left Button C. Right Button (Following illustrations are CF-Y2 series) Function Operation Moving the Cursor Move the tip of your finger lightly over the work surface.
Page 13: How To Scroll
Touch Pad NOTE Refer to [Mouse Properties] for information on basic operations other than the above. To display [Mouse Properties]: Select [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse]. Sensitivity when touching the touch pad can be adjusted. ( page When an external mouse is connected and the cursor does not operate properly: In the [Main] menu of the Setup Utility, set [Touch Pad] to [Disable].
Page 14 Hints for Easier Touch Pad Operation You can change various touch pad settings using the following procedure: [start] - [All Programs] - [Panasonic] - [Touch Pad utility settings] Settings can be changed for the following functions: • Use Touch Pad function (On/Off) •...
Page 15 [Exit]. is not displayed on the taskbar: In [start] - [All Programs] - [Panasonic] - [Touch Pad utility settings] - [General settings], add a check mark for [Display icon in task tray] and select [OK].
Page 16 Touch Pad Select [Virtual Scrolling], add a check mark for the scroll functions you want to use, then select [OK]. Select [OK] at [Mouse Properties]. NOTE To begin using the Touch Pad utility again: Log on with the administrator authority. Run the setup program.
Page 17: Touch Sensitivity
Touch Pad PalmCheck ™ By dragging slide bar (A) to the [Maximum] position, you can prevent the cursor from moving unintentionally. By dragging slide bar (A) to the [Minimum] position, you can enable the cursor to move even with a light touch of the palm on the touch pad. Touch Sensitivity When slide bar (B) is dragged to the [Heavy Touch] position, the cursor will only move with a strong touch on the touch pad.
Page 18: Standby/Hibernation Functions
Standby/Hibernation Functions Starting Up Your Computer Quickly If you use the standby or hibernation function, you can shut down the computer without closing programs and documents. Upon restarting your computer from either the standby or hibernation mode, you can immediately continue working in all programs, or documents that were open at the time the computer was placed into standby or hibernation mode.
Page 19 Standby/Hibernation Functions From the shutdown screen • Standby In [start] - [Turn Off Computer], select [Stand By]. • Hibernation In [start] - [Turn Off Computer], press and hold Shift, then select [Hibernate]. NOTE If a disc formatted with B’s CLiP is inserted into the DVD-ROM & CD-R/RW drive (while is displayed on the taskbar), the computer will not enter standby or hibernation mode.
Page 20 • Using external mouse or other peripheral devices. • Connecting or disconnecting the AC adaptor. • Closing or opening the display. <Only for CF-Y2 series> • Sliding the drive power/open switch. It may take one or two minutes to enter standby or hibernation mode.
Page 21: Using The Power Switch
Standby/Hibernation Functions In standby or hibernation mode Do not insert or remove peripherals; abnormal operation may result. In standby mode, power is consumed. If PC Cards are inserted, more of that power is consumed. When all power has been consumed, all data saved at standby is lost since it is retained in memory.
Page 22: Using The Display
Standby/Hibernation Functions release it, a second beep will sound and the power will be turned off forcibly. Data not previously saved will be lost. When the speaker function is disabled, e.g., by the key combination , there will be no beep sound.
Page 23 Standby/Hibernation Functions • Shutting down or restarting Windows. • Entering either the standby or hibernation mode again. <Only for CF-Y2 series> • Sliding the drive power/open switch. Using the Power Switch Slide the power switch (A).
Page 24: Open The Display
Standby/Hibernation Functions Using the Display When [Stand by] or [Hibernate] is selected as the setting for [When I close the lid of my portable computer] ( page 22), you can resume operation using the following procedure. Open the display. Even if the display is closed after the computer has entered either the standby or hibernation mode, operation will resume when the display is opened.
Page 25: Security Measures
Security Measures To prevent unauthorized access of your computer, the various security measures are provided below. Situation Function to use You do not want the settings in the Setup Supervisor Password (See below) Utility to be changed User Password ( page SD Memory Card Security Function page...
Page 26 Security Measures Only when the Supervisor Password has been set: Enter Enter your password at [Enter Current Password] and press Enter Enter your password at [Enter New Password] and press To disable the Supervisor Password Press only Enter. Re-enter your password at [Confirm New Password] and press Enter To disable the Supervisor Password Press only Enter.
Page 27 Security Measures Setting the User Password (enabling, changing, disabling) NOTE When the Supervisor Password has not been set, the User Password can not be set. Set the Supervisor Password if you have not done so. ( page To disable the User Password, start up the Setup Utility with the Supervisor Password. Run the Setup Utility.
Page 28 Security Measures NOTE Your password will not be displayed on the screen. Only up to seven alphanumeric characters can be used. • There is no distinction between upper and lower case letters. • Use only the upper horizontal row of numeric keys to input your password. •...
Page 29 Security Measures Select [Enable] or [Disable]. To enable the Password on boot Select [Enable] and press Enter. To disable the Password on boot Select [Disable] and press Enter. Enter Press and select [Yes], then press Starting Up When the Password on boot is Set The screen shown at left is displayed.
Page 30 Security Measures The hard disk lock function only works with the internal hard disk. This function does not work with the external hard disk. Setting the Hard Disk Lock (enabling, disabling) Run the Setup Utility. ( page Using either , select [Security]. Enter Using either , select [Hard Disk Lock] and press...
Page 31: Computing On The Road
Check to see that you have your AC adaptor with you before leaving your home or office. Purchasing a following spare battery: CF-Y2 series: CF-VZSU27AU CF-W2 series: CF-VZSU27, CF-VZSU27AU (When this battery pack is attached, its capacity is 6.6 Ah.) •...
Page 32 We recommend that you fully charge the battery pack beforehand Refer to [Important Tips] as well ( page <CF-Y2 series> Minimize power consumption for the DVD-ROM & CD-R/RW drive • Power consumption for the DVD-ROM & CD-R/RW drive can be minimized using the settings in [Main] menu of the Setup Utility.
Page 33 Computing on the Road To Avoid Problems When Remaining Battery Power Is Low We recommend that you check in advance regarding battery power confirmation methods page 35) and alarm settings for warning when battery power is low ( page 38). Alarm settings can be changed.
Page 34: Battery Power
You can also view [Important Tips] using the following procedures. Select [Important Tips] in [start] - [All Programs] - [Panasonic] - [On-Line Manuals]. Use the Battery Indicator to Check the Battery Status...
Page 35 Battery Power NOTE This computer prevents overcharging of the battery by recharging only when the remaining power is less than approx. 95% of capacity after the battery is fully charged. Check the Remaining Battery Power There are three methods to check the remaining battery power. Press Fn+F9.
Page 36 Battery Power Press Fn+F9 to Check the Remaining Battery Power on the Screen (After logging on to Windows) When the battery pack is inserted in the computer (example) When the battery pack is not inserted in the computer Check the Remaining Battery Power and Remaining Time using the Windows Battery Meter Display by selecting the in the taskbar when the AC adaptor is not connected.
Page 37 Battery Power Check the Number of Lighting LED Indicators (When the power is off or in standby/hibernation mode) You can view the remaining battery capacity using the following procedure. Close the display and confirm that the latch is locked. Disconnect the AC adaptor. Slide the power switch (A) and check the number of lighting LED indicators (B).
Page 38 Battery Power When the Remaining Battery Charge Becomes Low The following is factory default setting. When remaining battery capacity falls to 10% When remaining battery capacity falls to 5% [Low battery alarm] [Critical battery alarm] Displays a message indicating the low Displays a message indicating the low battery level.
Page 39 Battery Power A. When making a setting for [When the alarm goes off, the computer will] in [Alarms] - [Alarm Action]: Add a check mark for [Force stand by or shutdown even if a program stops responding.]. B. Set the value for [Critical battery alarm] to 5% or more. This is necessary for the standby or hibernation function to be completed (assuring data is saved) when the battery level is low.
Page 40: Replacing The Battery Pack
Allow the battery pack to charge until the battery indicator turns green CF-Y2 series: Approximately 5.5 hours CF-W2 series: Approximately 4.5 hours Replacing the Battery Pack The battery pack is a consumable item and therefore will require replacement (spare battery page 31).
Page 41: Insert The Battery Pack
Battery Power Power off your computer. (⇒ Operating Instructions "Starting Up/Shutting Down") Do not shut down using the standby function. Turn your computer over and remove the battery pack. Slide the left-side latch (A) to the unlock position ( ). Slide the right-side latch (B) to the unlock position ( ), and hold the latch in that position while pushing the center of the battery pack outwards, parallel with the body of the computer.
Page 42 At [Select the Video System], select [NTSC] or [PAL]. Running the SD-MovieStage CAUTION Be sure to log on with the administrator authority when running the SD-MovieStage. Select [start] - [All Programs] - [Panasonic] - [SD-MovieStage] - [SD- MovieStage]. NOTE The screensaver may not work while SD-MovieStage is running.
Page 43: Dvd-Rom & Cd-R/Rw Drive
Doing so could shorten the life of the drive lens. When opening/closing the disc cover <CF-Y2 series> • When the computer is on, be sure to use the drive power/open switch on the front right of the computer or perform the ejecting operation through Windows.
Page 44 In addition, after running an application involving access to a disc, do not open the DVD- ROM & CD-R/RW drive until after the application has been closed. Do not apply excessive force on the disc cover. <Only for CF-Y2 series> Do not operate the drive power/open switch.
Page 45 DVD-ROM & CD-R/RW Drive Cleaning We recommend cleaning the drive with an air puffer used for camera lenses. (Do not use any spray-type of lens cleaning products.)
Page 46: About Discs
DVD-ROM & CD-R/RW Drive About Discs Do not use any discs that have become deformed, warped, or are not completely round. Depending on the condition (record quality, a crack, dirt, modification, copy protection, etc.) of a disc, it may not be possible to be read it correctly. The following discs can be used.
Page 47 DVD-ROM & CD-R/RW Drive This drive's region code is not set at the time of shipment from the factory. Therefore, operations will differ depending on the first DVD-Video played. In the case of a DVD-Video with a specific region code: The drive will automatically be set with the same region code as the DVD-Video.
Page 48 DVD-ROM & CD-R/RW Drive When Using CD-R or CD-RW Discs When using CD-R or CD-RW discs, read the description on the disc package. When writing to CD-R/RW discs To write CD-R/RW discs, CD-R/RW writer software is required. ("B's Recorder" and "B's CLiP"...
Page 49 DVD-ROM & CD-R/RW Drive • CD-RW /High-Speed CD-RW MITSUBISHI KAGAKU MEDIA CO., Ltd. RICOH Co., Ltd. • Ultra-Speed CD-RW MITSUBISHI KAGAKU MEDIA CO., Ltd. To Avoid Damaging Discs Do not touch the data surface (the side opposite the side with the title printed on it) as it can cause the disc to become dirty or scratched.
Page 50 Setting a Disc CAUTION When inserting or removing a disc, be careful not to touch the lens of the drive. <CF-Y2 series> Slide the drive power/open switch (A) to the right while the computer's power is on. A "beep" will sound, and the disc cover will open slightly.
Page 51: Power Saving Mode
DVD-ROM & CD-R/RW Drive Removing Hold down on the center spindle (C) and gently lift up on the edge of the disc. Close the disc cover. NOTE When B's Recorder finishes writing, the disc cover opens automatically. If a hand is on the disc cover or the display is closed, and the disc cover is prevented from opening, the drive will not be accessed correctly.
Page 52: How To Switch The Drive Power On/Off
DVD-ROM & CD-R/RW Drive About the DVD-ROM & CD-R/RW Drive Power <Only for CF-Y2 series> How to switch the drive power on/off Use the drive power/open switch (A). • If you slide the switch to the right, the power will turn on, and the disc cover will open.
Page 53 [MATSHITA... can now be disconnected safely,] but the DVD-ROM & CD-R/RW drive cannot be disconnected because it is a built-in unit. About the Optical Disc Drive Power-Saving Utility <Only for CF-Y2 series> This utility automatically turns the drive power off after the DVD-ROM & CD-R/RW drive power has been turned on, or after a disc has been removed from the DVD-ROM &...
Page 54 [Manual Switching] operates regardless of whether or not a disc is set in the drive. Select [Exit] to close the Optical Disc Drive Power-Saving utility. To restart this utility, select [start] - [All programs] - [Panasonic] - [Optical Disk Drive Power-Saving Utility], or restart the computer.
Page 55 During WinDVD is running, do not perform the following. • Entering the standby or hibernation mode • Switching the display by pressing Fn + F3 • <CF-Y2 series> Turning off the DVD-ROM & CD-R/RW drive power If performing WinDVD, shut it down, then restart the computer.
Page 56 WinDVD • <CF-Y2 series> Turning off the DVD-ROM & CD-R/RW drive power If performing WinDVD, shut it down, then restart the computer. If you maximize the video display window, you can return to the original window size by double-clicking over the images.
Page 57 WinDVD • Specify WinDVD if the DVD’s player software settings enable WinDVD to be specified for playing the DVD. • Uninstall the DVD’s player software which has been installed. (Refer to the DVD-Video’s instructions for the name of the player software which is to be uninstalled.) Uninstall the player software by selecting [start] - [Control Panel] - [Add or Remove Programs].
Page 58 WinDVD How to Access the Online Manual After starting WinDVD, you can access the Online Manual using either of the following procedures. Select "?" of the WinDVD control panel. Right-click on the WinDVD screen and select [Help]. SUPPORT INFORMATION If WinDVD does not operate properly, we recommend carefully reading the online help file first for problems with the operating environment or operations.
Page 59: B's Recorder/B's Clip
B's Recorder/B's CLiP "B's Recorder" and "B's CLiP" are CD recording software applications developed by B.H.A Corporation. Here, explanations are given on general information about B's Recorder and B's CLiP and how to access the online manual. Refer to the online manual concerning the detailed use of the software application.
Page 60 Do not add the check mark for [Enable CD recording on this drive] in [Properties] - [Recording] of the DVD-ROM & CD-R/RW drive. Be sure to shut down B's Recorder before logging off Windows. <Only for CF-Y2 series> While B's Recorder is running or is displayed on the taskbar, the DVD-ROM & CD-R/ RW drive power can not be turned off.
Page 61 B's Recorder/B's CLiP "d:" is the drive letter of the DVD-ROM & CD-R/RW drive. Change this to match the drive letter on your own computer. How to Access the Online Manual B's Recorder Select [start] - [All Programs] - [B.H.A] - [B's Recorder GOLD BASIC] - [DOC] - [User's Manual].
Page 62 PC Cards This slot conforms to the PC Card Standard; therefore, communications and SCSI devices may be utilized. The slot allows you to use one Type I or Type II card. CAUTION Check the PC Cards' specifications. Be sure the total operating current does not exceed the specified limit.
Page 63: Inserting A Pc Card
Inserting a PC Card Simply slide the PC Card right-side-up until it snaps into place. Refer to the operating instructions of each card on how to insert the card. <CF-Y2 series> After the card is inserted, bend the eject button (A). CAUTION When using a PC Card to connect a peripheral device (SCSI, IEEE 1394, etc.), install...
Page 64 PC Cards card is used to connect an external hard disk to the computer. In such cases, turn off the power from [start] menu, then remove the card. <CF-Y2 series> Disable the card function. Select on the taskbar, select the PC Card, then select [Stop].
Page 65: Sd Memory Card/Multimedia Card
SD memory card format software. (Do not use [Format] of Windows.) Formatting software can be downloaded from our web site. Address: http://panasonic.jp/support/audio/sd/download/sd_formatter_e.html When using the SD memory card with other peripheral devices, format the SD memory card using the peripheral device. For details, refer to the instruction manual for that device.
Page 66: Multimedia Card (Mmc)
• While the SD memory card indicator ( ) is lit (Note that Panasonic assumes absolutely no liability for any loss of data recorded by the user, or any other damages, direct or indirect.) We recommend backing up important data to another storage medium.
Page 67: Inserting The Card
SD Memory Card/MultiMedia Card This computer may be unable to use MultiMedia cards under some conditions; for example, if the MultiMedia card has been formatted using certain peripheral devices. Inserting/Removing the SD Memory Card/MultiMedia Card Inserting the Card Insert the card firmly with the label side facing up and with the cut corner in front.
Page 68: Removing The Card
SD Memory Card/MultiMedia Card Removing the Card Confirm the SD memory card indicator turns off completely. Do not remove the card while data is being read from or written to the card. The computer may continue to access the card for some length of time after operations such as writing to the card.
Page 69 Input [c:\util\chgsddrv\setup.exe] and select [OK], then follow the on-screen instructions. How to change drive letter Select [start] - [All Programs] - [Panasonic] - [SD Drive Letter Change Tool]. Select in [New drive letter], select the drive letter, and select [OK].
Page 70: Sd Memory Card Security Function
SD Memory Card Security Function When you initialize an SD memory card, you can insert an SD memory card instead of entering a password for following cases. When starting the computer When logging on to Windows/ resuming from the standby or hibernation mode, or while the screensaver is active Windows logon screen...
Page 71 When [Removable disk] appears, select [Take no action], then select [OK]. Start the SD card setup program. Select [start] - [All Programs] - [Panasonic] - [SD Card Setup]. If an SD memory card has not been inserted, the following message appears: [Set the SD card in place].
Page 72 SD Memory Card Security Function setting of [SD Setting Method] in [Security] menu after completing the SD Card Setup. ( page 102) Make the settings according to the case to be used. To use when starting the computer An SD memory card will be registered with the computer. (Up to two cards can be registered.) Add the check mark for [Use when starting computer] (B) and select [Next].
Page 73 SD Memory Card Security Function Reenter the password for confirmation. When you add the check mark for [Do not check the user name]: A confirmation message will be displayed. If you select [Yes], you can register a user name and password on the SD memory card that is not set in Windows.
Page 74: Change The Settings
SD Memory Card Security Function • If an SD memory card is already inserted when resuming from the standby or hibernation mode, or while the screensaver is active, reinsert it. When resuming from the standby or hibernation mode, or while the screensaver is active If [Set and eject] was selected as the setting method: Insert the SD memory card, then eject if after you hear a beep indicating card recognition.
Page 75 SD Memory Card Security Function • If you remove the check mark You will not be able to log on to Windows by inserting an SD memory card with a set password. B. Setting for this SD card You can initialize the SD memory card currently inserted or change its settings. If no SD memory card is inserted, none of the fields under [Setting for this SD card] can be selected.
Page 76: Restart The Computer
SD Memory Card Security Function At the confirmation message [The SD card information registered in the Setup Utility will be erased...], select [Yes]. If you add the check mark for [Use when logging on to Windows]: Step of [To use when logging on to Windows] in Step page If you remove the check mark from [Use when logging on to Windows]: Enter the password and select [OK].
Page 77: External Display
Turn on the external display, then turn on your computer. After Windows starts up, the screen is displayed on the display destination set in the following menu. <CF-Y2 series> [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics 2 M] - [Devices] <CF-W2 series>...
Page 78: Extended Desktop
[Advanced] - [Troubleshoot] Also, carefully read the operating instructions of the external display. <Only for CF-Y2 series> Simultaneous display cannot be used until Windows startup is complete (during Setup Utility, Windows logon screen, etc.). When Fn+F3 is pressed, the screen is displayed on the external display or internal LCD.
Page 79 External Display At the confirmation message, select [OK]. NOTE There are some applications that cannot be used in the Extended Desktop. When the button to maximize a window is pressed, one of the displays will show the maximized display. A window that has been maximized cannot be moved to the other display. You cannot switch the display destination by pressing Fn+F3.
Page 80: Control Panel
External Display When there is no display when the Extended Desktop is disabled: The application running is being displayed in the external display. Set the Extended Desktop again, move the application from the external display to the internal LCD and then disable the Extended Desktop.
Page 81: Connecting Usb Devices
USB Devices Connecting/Removing USB devices Connecting USB devices Connect the USB device to the USB port (A) on your computer, referring to the operating instructions of the USB device. You may need to install drivers compatible with the operating system you are using for your USB devices.
Page 82: Removing Usb Devices
USB Devices Removing USB devices CAUTION Do not remove a USB device while your computer is in the standby or hibernation mode. Save important data and close each application. Disable the device function. Select on the taskbar and select the USB device, then select [Stop]. Follow the on-screen instructions.
Page 83 USB Devices Use the write-protect tab (A). This is a must for preserving important data. This prevents your data from being erased or overwritten. The USB floppy disk drive cannot be used at the same time as other floppy disk drives. Do not directly open application files (e.g., Microsoft Word, Microsoft Excel) which are stored on the floppy disk.
Page 84 Modem Connecting the Internal Modem with a Telephone Jack CAUTION Do not use the PBX internal phone lines installed in company offices. Doing so may lead to a fire or electric shock. It is not possible to connect the modem to any of the following lines. •...
Page 85 Modem Ring Resume Function With this function, if the telephone that is connected to the modem rings in the standby mode, the power of the computer automatically switches ON. This function is convenient when using automatic information receiving applications such as a FAX application.
Page 86 Modem [System standby] elapses even during communications, and cuts off the communications. • If [Never] is set, the computer will not enter the standby mode during communications, but once the computer resumes, the power of the computer will remain on while the user is absent. When the Ring Resume function is being used, some time elapses before a connection is established (equal to the time for the computer to resume).
Page 87 When using the computer as a network computer, some additional settings may have to be made depending on the usage conditions. We recommend asking your system administrator or the person in charge of the network. Connecting LAN CAUTION Do not connect the modem telephone cable into the LAN port. <Only for CF-W2 series>...
Page 88 NOTE If you are unable to connect to the network (when the indicator of your HUB unit does not light): Display [Device Manager] screen. Select [Device Manager] in [start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware]. Select the network adaptor you are using from [Network adapters].
Page 89 The Wake up from LAN function will not operate under the following conditions: • When the computer has been shut down. • When the power switch is slide over for four seconds or longer to turn off the power (e.g., when the computer hangs). •...
Page 90: Wireless Lan
Wireless LAN If you use a wireless LAN, you can use a network without cable connections. CAUTION Communication is performed through the wireless LAN antenna (A). Do not block the antenna area with your hand or otherwise interfere with the passage of the radio signals.
Page 91 Wireless LAN Precautions Do not use wireless LAN on airplanes, in hospitals, or in other locations where wireless LAN signals may affect the operation of devices in the vicinity. Abide by instructions regarding use in airplanes and hospitals. If you intend to use the computer in the environments described above, turn the wireless LAN off using the following method: Double-click on the taskbar.
Page 92 Wireless LAN The Settings To use the wireless LAN, set the profile using the following procedure. The settings will vary for different network environments depending on the network system being used. For more details, ask your system administrator or the person in charge of the network.
Page 93 Wireless LAN Select the profile you have set and select [Connect]. If the setting of the profile that is currently connected is changed, the new setting will not be enabled until you select the profile and then select [Connect]. Select [OK]. Check the Communication Status Open the Intel PROSet using either of the following procedures.
Page 94 Wireless LAN MAC address using the following procedure and register it according to the operating instructions of the access point. Display [Command Prompt]. Select [start] - [All Programs] - [Accessories] - [Command Prompt]. Input [ipconfig /all], and press Enter. Make a note of the 12-digit string of alphanumerics displayed on the wireless LAN's "Physical Address"...
Page 95 Wireless LAN Wireless Connection to Projector <Only for CF-Y2 series> When making a wireless connection to Panasonic Wireless LCD Projector PT-LB10NTU, you can use the Wireless Manager mobile edition for wireless projection without using the CD- ROM that comes with the projector.
Page 96: Setup Utility
Running the Setup Utility Turn on or restart the computer. Press while [Panasonic] boot screen is displayed soon after the computer begins the startup procedure. If [Enter Password] is displayed, enter your password. When the Setup Utility is started with Supervisor Password You can register all items of the Setup Utility.
Page 97: Key Operations
Setup Utility <Only for CF-Y2 series> Cannot display the Setup Utility screen in simultaneous display. By pressing Fn+F3, display destinations can be changed either external display or the internal LCD. Key Operations To display the corresponding "help" file. To display [Exit] menu.
Page 98: Information Menu
MB Primary Master: xx GB Secondary Master: CD/DVD Drive <Only for CF-Y2 series> When [CD/DVD Drive Power] has been set to [Off] in [Main] menu, [Power Off] is displayed. Parameters (Underline indicates settings at the time of factory shipment.) Language...
Page 99: Main Menu
Main Menu System Time: [xx:xx:xx] System Date: [xx/xx/xxxx] Touch Pad: [Enable] Fn/Ctrl Key: [Normal] Display: <CF-Y2 series> [External Monitor] <CF-W2 series> [Simultaneous] Display Expansion: [Enable] [Battery Optimized] Memory/Video Power Save: [On] CD/DVD Drive Power: CD/DVD Drive Speed: [High] Time is shown in 24-hr. style.
Page 100 When set to [Max Performance], memory/video will operate faster in comparison to [Battery Opti- mized], but the battery operating time will be shortened. <Only for CF-Y2 series> When set to [Off], the next time the computer is started up, you will not be able to boot from the DVD-ROM &...
Page 101: Advanced Menu
Setup Utility Advanced Menu Modem: [Enable] LAN: [Enable] Boot up from LAN: [Enable] Wireless LAN: [Enable] Legacy USB Support: [Enable] NOTE [Advanced] menu cannot be changed when the Setup Utility is started up with the User Password. Parameters (Underline indicates settings at the time of factory shipment.) Modem Disable Enable...
Page 102: Security Menu
Setup Utility Security Menu Password on boot: [Enable] [Enable] SD Startup: [Leave Set] SD Setting Method: [Enter] Clear registered SD card: Set Supervisor Password: [Enter] Setup Utility Prompt: [Enable] Boot First Menu: [Enable] Hard Disk Lock: [Disable] User Password Protection: [No Protection] Set User Password: [Enter]...
Page 103 Setup Utility *2*3 Leave Set SD Setting Method Set and Eject To the sub-menu Clear registered SD card Set Supervisor Password To the sub-menu Setup Utility Prompt Disable Enable Boot First Menu Disable Enable Disable Hard Disk Lock Enable User Password Protection No Protection Protected To the sub-menu...
Page 104: Boot Menu
The device for starting up the operating system can also be selected during computer start-up. After the computer is turned on, and Esc is pressed at [Panasonic] boot screen, [Boot Menu] (the device selection screen) will appear. When the setting of [Boot] menu is changed, the selection screen display will also change.
Page 105: Exit Menu
Setup Utility Exit Menu Save Values & Exit Exit Without Saving Changes Get Default Values Load Previous Values Save Current Values Battery Recalibration This item is not displayed when starting up the Setup Utility with the User Password. Parameters Save Values & Exit Exit the Setup Utility and save your changes to CMOS.
Page 106: Icon Enlarger
Change the screen display after the other application has been closed. Select [start] - [All Programs] - [Panasonic] - [Icon Enlarger]. Select the display size as [Normal Size], [Large Size], or [Extra Large Size].
Page 107: Technical Information
Technical Information Network Connections and Communications Software If the power saving function (standby or hibernation mode) activates while communications software is being used, the network connection may be interrupted, or performance may be adversely affected. If this happens, restart the computer. Be sure to close the communications software before using the power saving function.
Page 108: Dmi Viewer
CPU and memory. Running DMI Viewer Select [DMI Viewer] from [start] - [All Programs] - [Panasonic]. The screen shown at left is displayed. When you select an item, detailed information on that item will be displayed.
Page 109: List Of Error Codes
List of Error Codes When turning on the computer, if one of the following error codes or messages is displayed, follow the instructions shown below. If the problem persists, or if the error code or message displayed is not shown here, contact your technical support office.
Page 110 List of Error Codes Error Code/Message Action Operating System not found The OS is not properly installed on the floppy disk or the hard disk that you are trying to boot from. If the computer cannot be booted from the floppy disk, check the floppy disk drive to ensure that the disk is in fact bootable, and change it to another if not.
Page 111: Dealing With Problems (Advanced)
Dealing with Problems (Advanced) When a problem occurs, refer to this page. If a problem appears to be related to a software application, read the software related manual. If you still cannot troubleshoot the problem, contact your technical support office. You can use the PC Information Viewer to check the computer's usage status ( page 125).
Page 112 Dealing with Problems (Advanced) Starting Up When resuming from the standby or Even when a password has been set in the Setup Utility, [Enter Password] does hibernation mode, [Enter Password] not appear when the computer resumes from the standby or hibernation mode. does not appear even if a password If you want to use the security function when using the standby or hibernation has been set in the Setup Utility...
Page 113: Enter Password
[Properties]. Select [Tools] - [Check Now]. Select [Start] after selecting required items in [Check disk options]. At startup, hold down F8 when [Panasonic] boot screen disappears , and release your finger when the Windows Advanced Options Menu is displayed.
Page 114 Dealing with Problems (Advanced) Display The power has not been turned off, but Has the computer been set to the power-saving mode? To resume operation of after a certain period of time, there is your computer from the condition the power of the display is off (for energy no display conservation purposes), press any key unrelated to the direct triggering of a selection, like Ctrl.
Page 115: Shutting Down
When the window display is restored by pressing Alt + Enter, the screen is displayed on both displays. <Only for CF-Y2 series> Simultaneous display cannot be used until Windows startup is complete (during Setup Utility, Windows logon screen, etc.).
Page 116: Standby/Hibernation Function
Dealing with Problems (Advanced) Standby/Hibernation Function Unable to enter standby or hibernation If a USB device is connected to the computer (note: only for some USB mode devices), remove the USB device temporarily. If the problem persists, restart the computer. It may take one or two minutes to enter standby or hibernation mode.
Page 117 Dealing with Problems (Advanced) Battery Indicator The red indicator blinks Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact your technical support office. Possible failure in the battery pack or charging circuit.
Page 118: Connecting Peripherals
Dealing with Problems (Advanced) Network Unable to use wireless LAN Confirm that [Wireless LAN] is set to [Enable] in the Setup Utility. Confirm that is displayed on the taskbar. is not displayed on the taskbar, confirm that [On] is selected for [Switch radio] in [Intel(R) PROSet] - [General].
Page 119 ZV card, SRAM card, FLASH ROM card (except for an ATA interface) and card requiring 12V are not supported. USB floppy disk drives do not work as Only the Panasonic CF-VFDU03 USB floppy disk drive (optional) can be used. a boot drive Make sure [Legacy USB Support] is enable in the Setup Utility.
Page 120: Disk Operations
Poor performance when forwarding Follow the on-screen instructions. data via a PC card (e.g., unstable Select [Performance] in [start] - [Panasonic] - [CPU Idle Setting] and video images when writing videos select [OK], then select [Yes]. to a DV camera using an IEEE1394 The computer will be restarted automatically.
Page 121 49 <CF-Y2 series> Is the disc set correctly? The DVD-ROM & CD-R/RW drive <Only for CF-Y2 series> Is the drive power on? status indicator does not light/blink Slide the drive power/open switch to the left to turn the power on. When the light <CF-W2 series>...
Page 122 Dealing with Problems (Advanced) Disk Operations <Only for CF-Y2 series> Was the drive power/open switch slid in succession? Cannot turn off DVD-ROM & CD-R/ If sliding it in succession, the DVD-ROM & CD-R/RW drive power may not be RW drive power able to turn off.
Page 123: Sd Card Setup (Sd Memory Card Security Function)
Dealing with Problems (Advanced) SD Card Setup (SD memory card security function) Cannot use SD memory card security The SD memory card must be set up in order to use the security function function page 71). Cannot log on with the SD memory Windows logon user name and password are not set in the SD memory card card correctly.
Page 124 Dealing with Problems (Advanced) Others When trying to play back video files Some video files use a Codec that is not installed as a standard. In these ® cases, if you play back the video file after connecting to the Internet, the Codec using Windows Media Player, the may be downloaded automatically, allowing you to play back the file.
Page 125 [Not Found].) Running PC Information Viewer Select [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [PC Information Viewer]. Click on the items to display detailed information for each item.
Page 126 You can also save a copy of the screen to a file using the following procedure. Select [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [Screen Copy]. At the time of purchase, the computer is set so that a copy of the screen can be saved to a file by pressing Ctrl+Alt+F8.
Page 127 Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • WinDVD™ is a trademark of InterVideo, Inc. • Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd. PCE0151B_XP...
