  • Page 1 Operator′s manual 327LS 327LD X-series Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
  • Page 2: Key To Symbols

    KEY TO SYMBOLS Symbols WARNING! Clearing saws, Wear sturdy, non-slip boots. brushcutters and trimmers can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. It is extremely important that you read and understand the contents of the Only use non-metallic, flexible operator’s manual.
  • Page 3: Table Of Contents

    CONTENTS Contents Note the following before starting: KEY TO SYMBOLS Symbols ..............2 Please read the operator’s manual carefully. CONTENTS Contents ............... 3 WARNING! Long-term exposure to noise can result in permanent hearing Note the following before starting: ......3 impairment.
  • Page 4: Introduction

    Congratulations on your choice to buy a Husqvarna product! Husqvarna is based on a tradition that dates back to 1689, when the Swedish King Karl XI ordered the construction of a factory on the banks of the Husqvarna River, for production of muskets.
  • Page 5: What Is What

    WHAT IS WHAT? What is what? Trimmer head 12 Cylinder cover Grease filler cap, bevel gear 13 Starter handle Bevel gear 14 Fuel tank Cutting attachment guard 15 Air filter cover Shaft 16 Air purge Shaft coupling (327LDx) 17 Choke control Loop handle 18 Handle adjustment Throttle control...
  • Page 6: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS Important Personal protective equipment IMPORTANT! IMPORTANT! The machine is only designed for trimming grass. A clearing saw, brushcutter or trimmer can be dangerous if used incorrectly or carelessly, and can The only accessories you can operate with this engine cause serious or fatal injury to the operator or others.
  • Page 7: Machine's Safety Equipment

    GENERAL SAFETY PRECAUTIONS BOOTS control and the throttle lockout both move back to their original positions. This movement is controlled by two Wear sturdy, non-slip boots. independent return springs. This arrangement means that the throttle control is automatically locked at the idle setting.
  • Page 8 GENERAL SAFETY PRECAUTIONS Stop switch Use of incorrectly wound cord or an incorrect cutting attachment increases the level of vibration. See Use the stop switch to switch off the engine. instructions under the heading Cutting equipment. The machine′s vibration damping system reduces the transfer of vibration between the engine unit/cutting equipment and the machine′s handle unit.
  • Page 9: Cutting Equipment

    GENERAL SAFETY PRECAUTIONS Never use a machine that has a faulty muffler. • Extend the life of cutting equipment. IMPORTANT! Only use cutting attachments with the guards we recommend! See the chapter on Technical data. Refer to the instructions for the cutting attachment to check the correct way to load the cord and the correct cord diameter.
  • Page 10: Assembly

    ASSEMBLY Fitting the loop handle • Before using the unit, tighten the knob securely. • Clip the loop handle onto the shaft. Note that the loop handle must be fitted between the arrows on the shaft. Dismantling: • Loosen the coupling by turning the knob (at least 3 times).
  • Page 11: Assembling The Cutting Equipment

    ASSEMBLY Assembling the cutting • Screw on the trimmer head/plastic blades (H) in the opposite direction to the direction of rotation. equipment WARNING! When fitting the cutting attachment it is extremely important that the raised section on the drive disc/support flange engages correctly in the centre hole of the cutting attachment.
  • Page 12: Fuel Handling

    Two-stroke oil • Secure the machine during transport. • For best results and performance use HUSQVARNA • In order to prevent unintentional starting of the engine, two-stroke engine oil, which is specially formulated for the spark plug cap must always be removed during our air-cooled two-stroke engines.
  • Page 13: Fuelling

    FUEL HANDLING Mixing Fuelling • Always mix the petrol and oil in a clean container intended for fuel. • Always start by filling half the amount of the petrol to be used. Then add the entire amount of oil. Mix WARNING! Taking the following (shake) the fuel mixture.
  • Page 14: Starting And Stopping

    STARTING AND STOPPING Check before starting Starting and stopping • Check that the support flange is not cracked due to WARNING! The complete clutch cover fatigue or due to being tightened too much. Discard and shaft must be fitted before the the support flange if it is cracked.
  • Page 15 STARTING AND STOPPING CAUTION! Do not pull the starter cord all the way out and do not let go of the starter handle when the cord is fully extended. This can damage the machine. CAUTION! Do not put any part of your body in marked area.
  • Page 16: Working Techniques

    WORKING TECHNIQUES General working instructions Always hold the machine with both hands. Hold the machine on the right side of your body. IMPORTANT! This section takes up the basic safety precautions for working with a trimmer. If you encounter a situation where you are uncertain how to proceed you should ask an expert.
  • Page 17: Basic Working Techniques

    WORKING TECHNIQUES Basic working techniques Cutting • The trimmer is ideal for cutting grass that is difficult to Always slow the engine to idle speed after each working reach using a normal lawn mower. Keep the cord operation. Long periods at full throttle without any load on parallel to the ground when cutting.
  • Page 18: Maintenance

    Basic setting • The basic carburettor settings are adjusted during Your Husqvarna product has been designed and testing at the factory. The basic setting is richer than manufactured to specifications that reduce harmful the optimal setting and should be maintained for the emissions.
  • Page 19: Cooling System

    MAINTENANCE cause fire if directed against dry and combustible Cooling system material. To keep the working temperature as low as possible the machine is equipped with a cooling system. Some mufflers are equipped with a special spark arrestor mesh. If your machine has this type of muffler, you should clean the mesh at least once a week.
  • Page 20: Two-Piece Shaft (327Ldx)

    See instructions under the heading Oiling the air filter. Oiling the air filter Always use HUSQVARNA filter oil, art. no. 531 00 92-48. The filter oil contains a solvent to make it spread evenly through the filter. You should therefore avoid skin contact.
  • Page 21: Bevel Gear

    However, before using the machine you should check that the bevel gear is filled three-quarters full with grease. Use HUSQVARNA special grease. The grease in the bevel gear does not normally need to be changed except if repairs are carried out.
  • Page 22: Maintenance Schedule

    MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the maintenance and service work described in this Operator’s Manual.
  • Page 23: Technical Data

    TECHNICAL DATA Technical data 327LDx 327LS Engine Cylinder displacement, cm 24,5 24,5 Cylinder bore, mm Stroke, mm Idle speed, rpm 2700 2700 Recommended max. speed, rpm 11000-11700 11000-11700 Speed of output shaft, rpm 8300 8300 Max. engine output, acc. to ISO 8893, kW/ rpm 0,9/8400 0,9/8400 Catalytic converter muffler...
  • Page 24: Ec-Declaration Of Conformity

    537 18 33-17 327LDx Cultivator attachment with shaft CA 150 537 42 54-01 327LDx The following attachments have been developed mainly for the Husqvarna 125LD trimmer, but can also be used with the specified models. Approved accessories Art No. Use with...
  • Page 26 8,5 m 10 cm 4" 4,2 m "Clic" 15 cm 6"...
  • Page 27 4,25 m 4,25 m 15 cm 6" 15 cm 6"...
  • Page 28 T35, T35x 8,5 m 10 cm 4" 4,3 m "Clic" 15 cm 6"...
  • Page 29 6,0 m 10 cm 4" 3,05 m "Clic" 15 cm 6"...
  • Page 36 Original instructions 1155663-26 ´®z+Wb@¶6q¨ ´®z+Wb@¶6q¨ 2013-09-26...
