Instructions for use
DISHWASHER
Contents
GB
English, 1
Installation, 4-5-6
Connecting the electricity and water supplies
Loading the racks, 8-9
FDEB 31010 EXPERIENCE
Adjusting the upper rack
Third rack
Start-up and use, 10
Starting the dishwasher
Wash cycles, 11
Table of wash cycles
Cutting off the water and electricity supplies
Troubleshooting, 15
Guarantee, 17
Advertisement
Table of Contents
Related Manuals for Hotpoint FDEB 31010 EXPERIENCE
Summary of Contents for Hotpoint FDEB 31010 EXPERIENCE
-
Page 1: Table Of Contents
Advice regarding the first wash cycle Description of the appliance, 7 Overall view Control panel Loading the racks, 8-9 Lower rack FDEB 31010 EXPERIENCE Upper rack Adjusting the upper rack Third rack Unsuitable crockery Damage to glass and crockery Start-up and use, 10... -
Page 2: Precautions And Safety Advice
Precautions and safety advice • The packaging material should not be used as a toy: The appliance was designed and manufactured in it can become a choking or suffocation hazard. compliance with current international safety standards. The following information has been provided for safety If your family includes children: reasons and should therefore be read carefully. -
Page 3: Recycling & Disposal Information
Recycling & Disposal Information As part of Hotpoint’s continued commitment to helping the environment, Hotpoint reserves the right to use quality recycled components to keep down customer costs and minimise material wastage. Please dispose of packaging and old appliances carefully. -
Page 4: Positioning And Levelling
‘L’ from the use of non-original spare parts. Electrical Connection Changing the Mains Lead Before inserting the plug into the electrical socket, make sure A lead can be ordered from Hotpoint Service that: UK: 08709 066 066 or Republic of Ireland: 1850 302 220 • the socket is earthed and complies with current regulations; - If you have damaged the existing lead or require a longer one • the socket can withstand the maximum load of the appliance,... -
Page 5: Technical Data
The Company shall not be held responsible for any If the inlet hose is not long enough, contact a specialist incidents that occur if these regulations are not observed. (see Assistance) store or an authorised technician The water pressure must be within the values indicated Anti-condensation strip (see Installation). -
Page 6: Advice Regarding The First Wash Cycle
Advice regarding the first wash cycle Ensure the drain hose is securely After the appliance has been installed, immediately before attached, to prevent it coming away running the first wash cycle, completely fill the salt dispenser while the machine is in use and with water and add only then approximately 1 kg of salt ( causing a flood. -
Page 7: Description Of The Appliance
Description of the appliance Overall view Upper rack Upper sprayer arm Tip-up dispensers Rack height adjuster Lower rack Lower sprayer arm Washing filter Salt dispenser Detergent dispenser, rinse-aid dispenser and Active Oxygen device 10. Data plate Control panel Control panel Indicator light Low Salt Button and Button and Cycle selection knob indicator lights indicator light Cycle phases Start/Pause On-Off/Reset... -
Page 8: Loading The Racks
Loading the racks Tips Several dishwasher models are fitted with tip-up sectors Before loading the racks, remove all food residues from the They can be used in a vertical position when arranging dishes crockery and empty liquids from glasses and containers. No or in a horizontal position (lower) to load pans and salad bowls preventive rinsing is needed under running water. -
Page 9: Unsuitable Crockery
Tip-up compartments with adjustable position The upper rack can be adjusted for height based on requirements: The side tip-up compartments can be positioned at three high position to place bulky crockery in the lower rack and low different heights to optimize the arrangement of crockery inside position to make the most of the tip-up compartments/sectors the rack. -
Page 10: Start-Up And Use
Start-up and use Starting the dishwasher Measuring out the detergent A good wash result also depends on the correct amount of 1. Turn the water tap on. detergent being used. Exceeding the stated amount does not 2. Press the ON/OFF button: all the indicator lights on the control result in a more effective wash and increases environmental panel will light up for a few seconds. -
Page 11: Wash Cycles
Wash cycles The number and type of wash cycles and options may vary depending on the dishwasher model. Wash cycles Approximate Instructions on wash-cycle selection and which Wash cycle Options duration of detergent dosage include wash cycles drying Environmentally-friendly wash cycle with low energy consumption levels, suitable for pans and 3:10’... -
Page 12: Special Wash Cycles And Options
Special wash cycles and Options Notes: Optimum performance levels when using the “Fast" and "Express Extra drying* 40’” cycles can be achieved by respecting the specified number To improve the dryness level of the crockery, press the of place settings. EXTRA DRYING button; the indicator light will illuminate. If it is pressed again the option will be deselected. The Eco wash cycle complies with regulation EN-50242. A higher temperature during the final rinsing and a longer Although it has a longer duration than other wash cycles, it uses drying phase improve the dryness level. -
Page 13: Rinse Aid And Refined Salt
Rinse aid and refined salt Only use products which have been specifically designed and optimises washing performance in accordance with the water hardness level in your area. This information can be for dishwashers. obtained from your local water supplier. Do not use table/industrial salt or washing-up liquid. - Switch the machine off using the ON/OFF button and open Follow the instructions given on the packaging. -
Page 14: Care And Maintenance
Care and maintenance Shutting off the water and electricity Cleaning the filters supplies The filter assembly consists of three filters which remove food residues from the washing water and then recirculate the water. • Turn off the water tap after every wash cycle to avoid leaks. They should be cleaned if you wish to achieve the best results • Always unplug the appliance when cleaning it and when in every wash. -
Page 15: Troubleshooting
Troubleshooting Whenever the appliance fails to work, check for a solution from the following list before calling for Assistance. Problem: Possible causes / Solutions: The dishwasher does not start or • Switch off the appliance by pressing the ON/OFF button, switch it back on after cannot be controlled approximately one minute and reset the program. • The appliance has not been plugged in properly. • The dishwasher door has not been shut properly. The door won’t close • The lock was released. Strongly push the door until a “clacking” noise is heard. No water drains out from the • The dishwasher cycle has not yet finished. -
Page 16: After-Sales Service
After Sales Service After Sales Service Appliance Registration No one is better placed to care for your Hotpoint We want to give you additional benefits of Hotpoint appliance during the course of its working life than ownership. To activate your free 5 year parts guarantee us - the manufacturer. -
Page 17: Guarantee
5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time. - Page 20 195112957.00 03/2013 jk - Xerox Fabriano...
