- Page 1 PASSIVE LOUDSPEAKERS RSX115 RSX215 OWNER'S MANUAL...
-
Page 2: Safety Instructions
Safety Instructions WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain or mois- ture. To reduce the hazard of electrical shock, do not remove cover or back. No user serviceable parts inside. Please refer all servicing to qualified personnel. The lightning flash with an arrow- head symbol within an equilateral triangle, is intended to alert the user to the presence of unin- sulated "dangerous voltage"... -
Page 3: Table Of Contents
Basic Set Up....... . .7 Using Speaker Stands - RSX115 ..... . .8 Permanent Installation . -
Page 4: Introduction
Samson products in the future. Also, be sure to check out our website (www.samsontech.com) for complete information about our full product line. -
Page 5: Key Features
The RSX series two-way loudspeaker systems are per- fectly suited for portable and permanent sound rein- forcement applications. Here are some of their main features: RSX115 • Two-way passive loudspeaker system • High power handling: 600 watts AES / 2400 watts peak •... -
Page 6: Input Connections
Input Connections The RSX has a pair ¼" (TS) phone and Speakon® connectors wired in parallel. This enables you to directly connect an extension cabinet to an RSX speaker. Only use one ¼" or Speakon® connector as an input connector from an amplifier. Typically, you will only connect a single extension cabinet to an RSX cabinet, but it is possible to daisy-chain multiple cabinets. -
Page 7: Basic Set Up
Basic Set Up The RSX loudspeakers are passive cabinets, which means that they need to be connected to a power amplifier to reproduce an audio signal. Each speaker cabinet features two sets of parallel connectors. This enables each cabinet to be daisy chained to an additional loudspeaker. When connecting multiple speaker to a power amplifier or powered mixer, you must pay attention to the minimum load impedance of the amplifier. -
Page 8: Using Speaker Stands - Rsx115
RSX115. Never use a stand with a maximum load weight lower than the RSX115. Do not attempt to mount more than one speaker on a stand at one time. The RSX loudspeakers are heavy, unless you feel confident that you can handle lifting the weight of the cabinet, you should ask for a second person to help place the cabinet on a stand. -
Page 9: Permanent Installation
Permanent Installation The RSX series loudspeakers are a perfect solution for many fixed installations such as live sound venues, discos, schools, houses of worship, convention centers and airport terminals. The enclosure is extremely versatile for installation as it can be suspended in several different posi- tions by using the twelve fly points. -
Page 10: Cable Wiring
Cable Wiring The RSX series speaker connections are made via the rear panel 1/4-inch and/or Speakon® connectors for easy interface with industry standard cables. Standard, unshielded speaker wire, available at your local pro audio or music store, with either 1/4-inch phone or Speakon® con- nectors and wire gauge of 12-14 awg is recommended. -
Page 11: Technical Specifications
Net Weight 56.2 lb (25.5 kg) 87.34 lb (39.7 kg) Shipping Weight 63.5 lb (28.8 kg) 96.58 lb (43.9 kg) At Samson, we are continually improving our products, therefore specifications and images are subject to change without notice. RSX Passive Loudspeakers... -
Page 12: Dimensions
386.7 mm 386.7 mm (15.2”) Dimensions (15.2”) 192.4 mm 442.3 mm 192.4 mm 442.3 mm (7.5”) (17.4”) RSX115 (7.5”) (17.4”) 310.3 mm (12.2”) 334 mm 334 mm (13”) (13”) 386.7 mm 588 mm 588 mm 720 mm (15.2”) 720 mm (40”) - Page 14 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com...
