Page 1: Quick Start Guide
DNN9230DAB CONNECTED NAVIGATION SYSTEM Quick Start Guide © 2013 JVC KENWOOD Corporation B59-2164-00/00 (E) -
Page 2: Table Of Contents
Front Panel _________________ 10 specifications and so forth. You can Common Operation _________________ 12 download the latest version of the Instruction Manual from http:// Detaching The Front Panel ____________ 13 manual.kenwood.com/edition/ Login im365. Operation on the Home Screen 14 How to Use NOTE the Navigation System • The panels shown in this guide are... -
Page 3: Precautions
DNN9230DAB Precautions on handling discs recautions • Do not touch the recording surface of the disc. • Do not stick tape etc. on the disc, or use a disc 2WARNING with tape stuck on it. • Do not use disc type accessories. To prevent injury or fire, take • Clean from the center of the disc and move the following precautions: outward. • When removing discs from this unit, pull them • To prevent a short circuit, never put or leave out horizontally. any metallic objects (such as coins or metal • If the disc center hole or outside rim has burrs, tools) inside the unit. use the disc only after removing the burrs with • Do not watch or fix your eyes on the unit’s a ballpoint pen etc. display when you are driving for any extended • Discs that are not round cannot be used. period. • If you experience problems during installation, consult your Kenwood dealer. Precautions on using this unit • 8-cm (3 inch) discs cannot be used. -
Page 4: Cleaning The Unit
Quick Start Guide Acquiring GPS signal How To Reset Your Unit The first time you turn on this unit, you must If the unit or the connected unit fails wait while the system acquires satellite signals to operate properly, reset the unit. for the first time. This process could take up to several minutes. Make sure your vehicle is outdoors in an open area away from tall Press the <Reset> button. buildings and trees for fastest acquisition. The unit returns to factory settings. After the system acquires satellites for the first time, it will acquire satellites quickly each time thereafter. -
Page 5: Safety Precautions And Important Information
DNN9230DAB afety Precautions and Important Information Read this information carefully before starting to 2CAUTIONS operate the Kenwood Car Navigation System and follow the instructions in this manual. Neither Failure to avoid the following potentially Kenwood nor Garmin shall be liable for problems hazardous situations may result in injury or or accidents resulting from failure to observe the property damage. instructions in this manual. The navigation system is designed to provide you with route suggestions. It does not reflect road closures or road conditions, weather conditions, 2WARNINGS or other factors that may affect safety or timing while driving. Failure to avoid the following potentially... -
Page 6: Features Of Navigation Systems
Quick Start Guide eatures of Navigation systems By connecting this navigation system to Internet, you can use various services. Cooperation with Route Collector site • Destinations and routes specified on the PC can be input to this navigation system. • The routes you have traveled and the songs you have listened to can be logged. • By uploading music files to Dropbox and creating a play list on Route Collector site, you can listen to music anywhere through streaming without music files on this navigation system. • Speech to Text (STT) and Text to Speech (TTS). Use of internet service • Streaming service such as YouTube, Aupeo!. • Internet service such as email, Gmail, Google calendar, and social networking service such as Facebook and Twitter. • Information (weather, traffic, RSS, etc.) service. 3G, LTE or EDGE Wi-Fi access point • Connect to Internet using the tethering function of your smartphone or an Internet... -
Page 7: First Step
DNN9230DAB irst Step Touch the corresponding key and set the item. Power on the unit and perform some setup steps before using. Press the <8HOME> button. HOME Language Setup Select the language used for the GUI and input The navigation system is turned on. methods. Default is “English (United States)”. ● To turn off the navigation system: 1 T ouch [Language Setup]. - Page 8 Quick Start Guide ● Types of accounts ● Set Owner Account 1) Touch [Set Owner Account]. Administrator As Administrator, you can create an owner 2) Enter account information. account and perform initial setup. Enter the information registered in You can log in to the system if you have not the Route Collector site. created an owner account. 3) Touch [OK]. Guest An account for guests such as your friends. Touch [Next]. The guest can operate this unit, but cannot use the functions related to mail, social media, and Route Collector site. Touch the corresponding Owner key and set the item.
- Page 9 DNN9230DAB How to prepare the remote Camera control Set the parameters for the camera. After setting, touch [ Insert two “AAA”/“R03”-size batteries Demo mode Set the demonstration mode. Default is “ON”. with the poles aligned properly, following the illustration inside the case. Touch [Finish]. NOTE • For details on operations of each setting, refer to the Instruction Manual. Touch [Administrator]. CAUTION • Put the remote controller in a place where it will not move during braking or other operations.
-
Page 10: Basic Operations
Quick Start Guide asic Operations Functions of the Buttons on the Front Panel HOME How to insert an SD card 1) Press < > button for 1 second. Labelled The panel fully opens. side 2) Hold the SD card as the illustration in the right and insert it into the slot until it clicks. - Page 11 DNN9230DAB Number Name Motion fi (Reset) • If the unit or the connected unit fails to operate properly, the unit returns to initial settings when this button is pressed (Instruction Manual P.135). • If the SI function is turned on, this indicator flashes when the vehicle ignition is off (Instruction Manual P.110). • Switches attenuation of the volume on/off. • Pressing for 1 second turns the screen off. ∞, 5 (Vol) Adjusts volume. • Displays the navigation screen. • Pressing for 1 second switches camera view display on/off. MENU • Displays the option menu screen. • Pressing for 1 second switches AV out sources. HOME • Displays the Home screen (P.14). • Pressing for 1 second turns the power off. • When the power off, turns the power on. 6 (Back) • Return to the previously viewed screen. • Pressing for 1 second displays the Hands Free screen (Instruction Manual P.98). 0 (Eject) • Ejects the disc. • When the panel is opened, pressing closes the panel and pressing for 1 second ejects the disc forcibly. • When the panel is closed, pressing for 1 second fully opens the panel to the location of the SD card slot. Remote Receives the remote control signal. Sensor Disc insert A slot to insert a disc media.
-
Page 12: Common Operation
Quick Start Guide Common Operation General There are some functions which can (Mixed Media Search) be operated from most screens. Touch to display the Mixed Media Search screen. (Quick menu) Touch to display the quick menu. The content of the menu are as follows. : D isplays the SETUP Menu screen. : D isplays the Audio Control Menu screen. : D isplays the control screen of current source. Icon feature differs depending on the source. (RETURN) Returns to previous screen. List screen There are some common function (Scroll) keys in the list screens of most... -
Page 13: Detaching The Front Panel
DNN9230DAB Detaching The Front Panel You can detach the front panel to prevent theft. Press the <0> button for 1 second to NOTE open the front panel. • The attaching plate closes automatically Then, detach the panel as the in about 10 seconds after the front panel diagrams below. is released. Remove the panel before this happens. To prevent deterioration, do not touch the terminals of the unit and faceplate with your fingers. -
Page 14: Login
Quick Start Guide ogin Press the <HOME> button to turn the power on. Select the login user. Enter the password. (Password) Enter the registered password. If you selected Administrator or Guest, this screen is not displayed. [Auto Login?] Checking this checkbox allows you to log in to the system automatically from the next time. [Login] Log in to the system. NOTE • If you forgot your password, create your new password on the Route Collector site. http://www. route-collector.com/ peration on the Home Screen Press the <HOME>... - Page 15 DNN9230DAB Allows you select a source. 3 Source launcher panel Allows you to select a network-related application. 4 Network contents panel Source launcher panel (Shortcut) You can register sources you use frequently so that you can start them quickly. (All source list) Displays all sources. ● All source list (All source list) You can scroll the list screen by flicking the screen up/down. (Home) Returns to the Source launcher panel. ● Moving or deleting of an icon on the Source launcher panel 1) Touch and hold the icon.
-
Page 16: How To Use
GPS satellite strength. Finds a destination. Views the map. Uses the Apps such as ecoRoute and Help. Adjusts the settings. NOTE • You can get additional information about using the navigation system from Help. To display Help, touch [Apps] and then touch [Help]. • For more information about your navigation system, download the latest version of the Owner’s Manual from manual.kenwood.com/edition/im365 Enter your destination and start the guidance. ● Finding points of interest NOTE 1) Touch [Where To?]. • To enter letters contained in the name, 2) Select a category and a touch the Search bar and enter the letters. subcategory. 3) Select a destination. - Page 17 Garmin and JVC KENWOOD will not be responsible for any traffic fines or citations that you may receive for failing to follow all applicable traffic laws and signs.
-
Page 18: Other Features
NOTICE • Traffic service is not available in some areas or countries. • Garmin and JVC KENWOOD are not responsible for the accuracy or timeliness of the traffic information. • Your navigation system can receive traffic information using the built-in traffic receiver or a subscription to INRIX Traffic Service. -
Page 19: How To Play Music
DNN9230DAB ow to Play Music You can play audio files from music CD, disc media, USB storage device and iPod. NOTE • For details on playable file format, media format, iPod model, etc., refer to the Instruction Manual. Connect the media you want to play as shown below. Disc 1) Press the <0> button to open the front panel. -
Page 20: Search The Track/File You Want To Listen To
Quick Start Guide Control the music you are listening to on the source control screen. The following symbols indicate the keys on the screen. The functions of the keys are the same despite the difference of the source you are listening to. Basic operations from this screen Plays or pauses: Stops playing:... -
Page 21: How To Play Movie
DNN9230DAB ow to Play Movie You can play DVD video, Video CD (VCD), movie files from disc media, iPod and USB storage device. NOTE • For details on playable file format, device format, etc., refer to the Instruction Manual. Connect the media you want to play. For the method of connecting, see How to Play Music (P.19). -
Page 22: How To Listen To The Radio
Quick Start Guide ow to Listen to the Radio Press the <HOME> button twice to the Source launcher panel. Touch [ ] in the Source launcher panel. Touch [TUNER]. The unit switches to the Radio tuner source. Operate on the source control screen. ●... -
Page 23: How To Make A Phone Call
DNN9230DAB ow to Make a Phone Call You can use your Bluetooth cell-phone when paired to this unit. Register your cell-phone to the unit. Follow as the procedures shown below. For detailed operation, see Registering the Bluetooth Unit (P.95) in the Instruction Manual. -
Page 24: Make Or Receive A Phone Call
Quick Start Guide Make or receive a phone call. See the table below for each operation method. Call by entering a phone number 1 Touch [ 2 Enter a phone number with number keys. 3 Touch [ Call using call records ] (Incoming Calls), [ ] (Outgoing Calls), or [ ] (Missed Calls). 1 Touch [ 2 Select the phone number from the list. 3 Touch [ Call using the phonebook 1 Touch [ 2 Select the name from the list. -
Page 25: Installation Procedure
DNN9230DAB • If the console has a lid, make sure to install nstallation Procedure the unit so that the faceplate will not hit the lid when closing and opening. • If the fuse blows, first make sure the wires aren’t touching to cause a short circuit, Before Installation then replace the old fuse with one with the same rating. Before installation of this unit, please • Insulate unconnected wires with vinyl tape note the following precautions. or other similar material. To prevent a short circuit, do not remove the caps on the ends of the unconnected wires or the terminals. WARNINGS • Connect the speaker wires correctly to the • If you connect the ignition wire (red) terminals to which they correspond. The and the battery wire (yellow) to the car... -
Page 26: Installation Procedure
Quick Start Guide Unit Installation Procedure 1 To prevent a short circuit, remove Supplied accessories the key from the ignition and disconnect the ¤ terminal of the First of all, make sure that all battery. accessories are supplied with the 2 Make the proper input and unit. -
Page 27: Attaching The Front Panel
DNN9230DAB Attaching the front panel GPS antenna Hold the front panel securely so as GPS antenna is installed inside of not to drop it accidentally. Fit the the car. It should be installed as panel onto the attaching plate until it horizontally as possible to allow easy is firmly locked. - Page 28 Quick Start Guide Microphone unit and Push-To- NOTE Talk Switch • Install the microphone as far as possible from the cell-phone. 1) Check the installation position of the microphone (accessory 8) and the Push-To-Talk switch (accessory 9). 2) Clean the installation surface. 3) Install the microphone. 4) Wire the microphone cable up to the unit with it secured at several positions using tape or other desired method.
-
Page 29: Removing Procedure
DNN9230DAB Removing the unit Removing Procedure 1) Remove the trim plate by Removing the trim plate referring to step 1 in “Removing the trim plate”. 1) Engage the catch pins on the 2) Insert the two extraction keys extraction key (accessory3) and... -
Page 30: Connection
Quick Start Guide Connection System connection Accessory 8: Accessory 6: GPS Antenna Bluetooth Microphone Accessory 9: Voice Control Switch FM/AM antenna input M4 x 8mmMAX iPod/ AV-IN/OUT AV-IN2 MIC WI-FI receiver - Reception may drop if there are metal objects near the Bluetooth antenna and AV-OUT AUDIO POWER... -
Page 31: Connecting Wires To Terminals
DNN9230DAB Connecting wires to terminals Fuse (10A) Pin Numbers Cable Color Functions for ISO Connectors M4 x 8mmMAX iPod/ AV-IN/OUT AV-IN2 MIC External Power Connector Yellow Battery Blue/White Power Control AV-OUT AUDIO POWER Orange/White Dimmer Ignition (ACC) Black Earth (Ground) Connection Speaker Accessory 1... -
Page 32: Optional Accessory Connection
Quick Start Guide Optional accessory connection iPod (Video and Music) iPod (Music) (commercially available) (commercially available) KCA-iP202 KCA-iP102 (Optional Accessory) (Optional Accessory) USB maximum power supply current : 5 V AV Output (1.8m) USB terminal (0.8m) USB terminal (0.8m) iPod input (iPod/ AV-IN2 switchable) iPod/ iPhone... - Page 33 DNN9230DAB...
-
Page 34: About This Unit
DivX Video-on-Demand (VOD) movies. To obtain your Other trademarks and trade names are those of their registration code, locate the DivX VOD section in your respective owners. device setup menu. Go to vod.divx.com for more • The “AAC” logo is a trademark of Dolby Laboratories. information on how to complete your registration. • “Made for iPod” and “Made for iPhone” mean that an • DivX®, DivX Certified® and associated logos are electronic accessory has been designed to connect trademarks of Rovi Corporation or its subsidiaries and specifically to iPod or iPhone, respectively, and has are used under license. been certified by the developer to meet Apple ■ ■ KENWOOD Route Network Service performance standards. Apple is not responsible for the operation of this device or its compliance with “Route Collector” User’s Agreement safety and regulatory standards. Please note that the This KENWOOD Route Network Service “Route use of this accessory with iPod or iPhone may affect Collector” User’s Agreement (“Agreement”) sets forth wireless performance. the terms and conditions for use of the KENWOOD • iPhone, iPod, iPod classic, iPod nano, and iPod touch Route Network Service “Route Collector” provided by are trademarks of Apple Inc., registered in the U.S. and JVCKENWOOD Corporation (“Service”) to the users who other countries. - Page 35 DNN9230DAB (2) W e shall assume no responsibility for any loss or with the Service, we reserve the right to claim from damage that may be incurred by the User due to the concerned User any damages, costs and expenses its use of or inability to use the Service, regardless which we may incur (including compensation, attorney of whether such loss or damage is direct or indirect, fees and legal costs). foreseeable or unforeseeable, including but not 6. Ownership of Intellectual Property Rights limited to special damages. All intellectual property rights (including but not (3) W e shall not be involved in nor assume responsibility limited to copyrights, design rights, patent, utility for any acts, problems, and other issues between model rights, trademark, trade secrets, and know-how), Users. the portrait rights, privacy, publicity rights and other (4) S hould any third parties suffer losses or damages personal rights, and proprietary rights or other property as a result of the User’s use of the Service, we shall rights of the information, text, image, program, layout, assume no responsibility therefor. design, architecture, and others related to the Service (5) S hould the User suffer losses or damages from are owned by us, or provided to us under license from misuse by any third parties of the User’s registered the rights holder except for the rights of the thing user account name or password for the Service, we which are made by User. The unauthorized copying, shall assume no responsibility therefor.
-
Page 36: Laser Product
Quick Start Guide ■ ■ The marking of products using lasers CLASS 1 LASER PRODUCT The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit. ■ ■ Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable for EU countries that have adopted separate waste collection systems) Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste. - Page 37 DNN9230DAB Declaration of Conformity with regard to the EMC Directive 2004/108/EC Declaration of Conformity with regard to the R&TTE Directive 1999/5/EC Manufacturer: JVC KENWOOD Corporation 3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa 221-0022, JAPAN EU Representative’s: Kenwood Electronics Europe BV Amsterdamseweg 37, 1422 AC UITHOORN, The Netherlands English Suomi Hereby, JVC KENWOOD declares that this unit DNN9230DAB is in JVC KENWOOD vakuuttaa täten että DNN9230DAB tyyppinen laite compliance with the essential requirements and other relevant on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien provisions of Directive 1999/5/EC. direktiivin muiden ehtojen mukainen. Français Slovensko Par la présente JVC KENWOOD déclare que l’appareil DNN9230DAB S tem JVC KENWOOD izjavlja, da je ta DNN9230DAB v skladu z...
- Page 39 Instruction Manual Specifications 2 CAUTION IEEE Standard: Changes or modifications not approved by us 802.11b/g/n could void the user’s authority to operate the Security Support: equipment. 64/128 bit WEP /WPA & WPA2 Frequency Range: • This adapter has been designed exclusively for 2.401 GHz – 2.483 GHz use with Kenwood car receivers. Do not use this Transfer rates (MAX.): adapter with any other car receiver. 802.11n (150 Mbps) • The Wi-Fi CERTIFIED Logo is a certification mark 802.11g (54 Mbps) of the Wi-Fi Alliance. 802.11b (11 Mbps) Output Power: 16 – 18dBm (CCK) 13 – 15dBm (OFDM) Power Consumption: 5 V/100 mA (MAX.) Dimensions (L × W × H): 15 mm × 19 mm × 5.6 mm...
- Page 40 Slovensko Par la présente JVC KENWOOD déclare que l’appareil W02-5617 est S tem JVC KENWOOD izjavlja, da je ta W02-5617 v skladu z osnovnimi conforme aux exigences essentielles et aux autres dispositions pertinentes zahtevami in ostalimi ustreznimi predpisi Direktive 1999/5/EC.
