Specifications - ECS H61H2-M2 Manual

4

Specifications

CPU
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
System BIOS
AP support
Form Factor
• LGA1155 socket for latest 2
ily processors
• Supports "Hyper-Threading" technology CPU
• DMI 5.0GT/s
®
• Intel H61 Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 Gen2 slot
• 2 x PCI Express x1 slots
• Supported by Intel
-4 x Serial ATA 3.0 Gb/s devices
• VIA VT1705 6-Ch HD audio CODEC
• Compliant with HD audio specification
• Atheros AR8152-B 10/100 Lan (Optional)
• Atheros AR8152-B Gigabit Fast Ethernet Controller (Optional)
• 4 x USB 2.0 ports
• 1 x D-sub (VGA)
• 1 x DVI port (optional)
• 1 x HDMI port (optional)
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3.0 Gb/s connectors
• 1 x COM header
• 1 x Case Open header
• 1 x SPDIF out header
• 1 x TPM header
• 1 x ME_UNLOCK header
• 1 x Speaker header
• 1 x Clear CMOS header
• AMI BIOS with 32Mb SPI Flash ROM
• Support Multi-language BIOS Utility
• Support ECS M.I.B III Utility
• Support eJIFFY/eBLU/eDLU/eSF
• Micro ATX Size, 225mm x 180mm
Introducing the Motherboard
nd
Generation Intel
®
H61 Express Chipset
®
TM
Core Fam-
