Icom IC-T81E Service Manual page 32

[RF UNIT]
REF ORDER
NO. NO.
C895 4030013850 S.CERAMIC
C896 4030014050 S.CERAMIC
C897 4030014090 S.CERAMIC
C898 4030013850 S.CERAMIC
C899 4030013850 S.CERAMIC
C900 4030014020 S.CERAMIC
4030014090 S.CERAMIC
C901 4030013850 S.CERAMIC
C902 4030013850 S.CERAMIC
C903 4030013970 S.CERAMIC
C904 4030013850 S.CERAMIC
C907 4030013970 S.CERAMIC
C908 4030013850 S.CERAMIC
C911 4030013850 S.CERAMIC
C912 4550002980 S.TANTALUM
C913 4030013850 S.CERAMIC
C914 4030013850 S.CERAMIC
C915 4030013850 S.CERAMIC
C916 4030013980 S.CERAMIC
C921 4030013850 S.CERAMIC
C923 4030013850 S.CERAMIC
C924 4030013970 S.CERAMIC
C928 4030013850 S.CERAMIC
C930 4030013850 S.CERAMIC
C931 4030013850 S.CERAMIC
C932 4030013850 S.CERAMIC
C933 4030013850 S.CERAMIC
C934 4030013850 S.CERAMIC
C935 4030013850 S.CERAMIC
C937 4030013850 S.CERAMIC
C938 4030013970 S.CERAMIC
C939 4030013850 S.CERAMIC
C940 4030013970 S.CERAMIC
C941 4030013850 S.CERAMIC
C942 4030006870 S.CERAMIC
C943 4030013850 S.CERAMIC
C944 4030009350 S.CERAMIC
C945 4030014180 S.CERAMIC
C948 4030013850 S.CERAMIC
C949 4030013850 S.CERAMIC
C950 4030013850 S.CERAMIC
C951 4030006860 S.CERAMIC
4030009500 S.CERAMIC
C952 4030013850 S.CERAMIC
C953 4030013850 S.CERAMIC
C954 4030014250 S.CERAMIC
C955 4030006860 S.CERAMIC
C956 4030006990 S.CERAMIC
C957 4030013850 S.CERAMIC
C958 4030013850 S.CERAMIC
C960 4030004960 S.CERAMIC
C961 4030007080 S.CERAMIC
C962 4030007140 S.CERAMIC
C963 4030007080 S.CERAMIC
C964 4030007010 S.CERAMIC
C965 4030006990 S.CERAMIC
C966 4030007010 S.CERAMIC
C967 4030006860 S.CERAMIC
C968 4030013850 S.CERAMIC
C969 4030005030 S.CERAMIC
C970 4030004960 S.CERAMIC
C971 4030006860 S.CERAMIC
C972 4030013850 S.CERAMIC
C973 4030013850 S.CERAMIC
C974 4030013850 S.CERAMIC
C975 4030013850 S.CERAMIC
C976 4030013850 S.CERAMIC
C977 4030013850 S.CERAMIC
C978 4030013850 S.CERAMIC
C979 4030013850 S.CERAMIC
C980 4030013850 S.CERAMIC
C981 4030013850 S.CERAMIC
C982 4030013850 S.CERAMIC
C983 4030013850 S.CERAMIC
C985 4030013850 S.CERAMIC
C986 4030013850 S.CERAMIC
C987 4030013850 S.CERAMIC
C988 4030013850 S.CERAMIC
C989 4030013850 S.CERAMIC
DESCRIPTION
ECUE1E102KBQ
ECUE1H030BCQ
ECUE1H060CCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H020BCQ
[AUS], [SEA], [USA-1]
ECUE1H060CCQ [EUR], [UK], [ITA]
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
TEMSVA 1C 225M-8L
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H010BCQ
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1608 JB 1H 222K-T-A
ECUE1E102KBQ
C1608 CH 1H 3R5B-T-A
ECUE1H470JCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1H 102K-T-A
[AUS], [SEA], [USA-1]
C1608 CH 1H 0R5B-T-A
[EUR], [UK], [ITA]
ECUE1E102KBQ
ECUE1E102KBQ
GRH708 CH 150J 200PT
C1608 JB 1H 102K-T-A
C1608 CH 1H 080D-T-A
ECUE1E102KBQ
ECUE1E102KBQ
C2012 CH 1H 560J-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 121J-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 080D-T-A
C1608 CH 1H 100D-T-A
C1608 JB 1H 102K-T-A
ECUE1E102KBQ
C2012 CH 1H 221J-T-A
C2012 CH 1H 560J-T-A
C1608 JB 1H 102K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
[RF UNIT]
REF ORDER
NO. NO.
C991 4030014200 S.CERAMIC
C992 4030014200 S.CERAMIC
C993 4030013850 S.CERAMIC
C994 4030014200 S.CERAMIC
C995 4030013850 S.CERAMIC
C997 4030013850 S.CERAMIC
J3 6450000870 CONNECTOR
J4 6510019870 S.CONNECTOR AXK5S40045P
J951 6510020400 S.CONNECT
J952 6510020400 S.CONNECT
W1 8900008750 CABLE
EP1 0910051346 PCB
[VCO BOARD]
REF ORDER
NO. NO.
Q301 1530003560 S.TRANSISTOR 2SC5195-T1
Q302 1530003560 S.TRANSISTOR 2SC5195-T1
Q311 1530003560 S.TRANSISTOR 2SC5195-T1
Q312 1530003560 S.TRANSISTOR 2SC5195-T1
Q313 1530003560 S.TRANSISTOR 2SC5195-T1
Q321 1530003560 S.TRANSISTOR 2SC5195-T1
Q322 1530003560 S.TRANSISTOR 2SC5195-T1
Q323 1530003560 S.TRANSISTOR 2SC5195-T1
Q350 1530003260 S.TRANSISTOR 2SC5006-T1
Q351 1530003560 S.TRANSISTOR 2SC5195-T1
Q353 1530003560 S.TRANSISTOR 2SC5195-T1
Q354 1530003560 S.TRANSISTOR 2SC5195-T1
D301 1720000690 S.VARICAP
D302 1790001260 S.DIODE
D311 1750000610 S.VARICAP
D312 1750000360 S.DIODE
D321 1790001260 S.DIODE
D322 1720000370 S.VARICAP
D351 1790001310 S.VARICAP
D352 1790001260 S.DIODE
L301 6200004480 S.COIL
L302 6200008190 S.COIL
L311 6200004480 S.COIL
L312 6200008280 S.COIL
L313 6200008170 S.COIL
L321 6200004480 S.COIL
L322 6200008330 S.COIL
L330 6200008230 S.COIL
L331 6200003640 S.COIL
L332 6200005680 S.COIL
L333 6200005640 S.COIL
L334 6200005640 S.COIL
L335 6200005630 S.COIL
L336 6200005620 S.COIL
L337 6200005640 S.COIL
L338 6200005650 S.COIL
L360 6200003640 S.COIL
R301 7030005700 S.RESISTOR
R302 7030005120 S.RESISTOR
R303 7030004970 S.RESISTOR
R304 7030004990 S.RESISTOR
R305 7030005290 S.RESISTOR
R306 7030005290 S.RESISTOR
R307 7030004980 S.RESISTOR
R308 7030007290 S.RESISTOR
R311 7030004970 S.RESISTOR
R312 7030004990 S.RESISTOR
R313 7030005290 S.RESISTOR
6 - 9
DESCRIPTION
ECUE1H101JCQ
ECUE1H101JCQ
ECUE1E102KBQ
ECUE1H101JCQ
ECUE1E102KBQ
ECUE1E102KBQ
HEC2711-01-020
MM7329-2700
MM7329-2700
OPC-868 (MXFG76FG0400)
B 5140F
DESCRIPTION
1SV282 (TPH2)
MA2S077-(TX)
MA2SV0500L
1SS364 (TE85L)
MA2S077-(TX)
HVU350TRF
1SV270 (TPH3)
MA2S077-(TX)
MLF1608D R82K-T
0.25-1.9-8TL 80N
MLF1608D R82K-T
0.30-1.7-7TL 50N
0.35-1.6-8TL 54N
MLF1608D R82K-T
0.45-1.4-4TL 15N
0.30-1.3-5TL 22N
MLF1608K 100K-T
ELJRE 15NG-F
ELJRE 6N8Z-F
ELJRE 6N8Z-F
ELJRE 5N6Z-F
ELJRE 4N7Z-F
ELJRE 6N8Z-F
ELJRE 8N2Z-F
MLF1608K 100K-T
ERJ2GEJ 274 X (270 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 682 X (6.8 kΩ)
S.=Surface mount
