[LOGIC UNIT]
REF
ORDER
NO.
NO.
R245
7030005080 S.RESISTOR
R246
7030005310 S.RESISTOR
R247
7030005090 S.RESISTOR
R248
7030005170 S.RESISTOR
R249
7030005110 S.RESISTOR
R250
7030005090 S.RESISTOR
R251
7030005600 S.RESISTOR
R252
7030005230 S.RESISTOR
R253
7030005720 S.RESISTOR
R254
7030005720 S.RESISTOR
R267
7030004980 S.RESISTOR
R301
7030005720 S.RESISTOR
R302
7030005050 S.RESISTOR
R303
7030005600 S.RESISTOR
R304
7030005720 S.RESISTOR
R305
7030004980 S.RESISTOR
R306
7030005090 S.RESISTOR
R307
7030007320 S.RESISTOR
R308
7030005310 S.RESISTOR
R309
7030005040 S.RESISTOR
R310
7030005040 S.RESISTOR
R311
7030005530 S.RESISTOR
R312
7030005110 S.RESISTOR
R313
7030005090 S.RESISTOR
R314
7030004980 S.RESISTOR
R315
7030005240 S.RESISTOR
R316
7030005000 S.RESISTOR
R317
7030005110 S.RESISTOR
R318
7030005120 S.RESISTOR
R319
7030007290 S.RESISTOR
R320
7030005060 S.RESISTOR
R321
7030007300 S.RESISTOR
R322
7310003600 S.TRIMMER
R323
7030005720 S.RESISTOR
R324
7030005060 S.RESISTOR
R325
7310003600 S.TRIMMER
R326
7310003600 S.TRIMMER
R327
7310003600 S.TRIMMER
R328
7030005170 S.RESISTOR
R329
7030005170 S.RESISTOR
R330
7030005170 S.RESISTOR
R331
7030005110 S.RESISTOR
R332
7030007350 S.RESISTOR
R333
7030005050 S.RESISTOR
R334
7030005120 S.RESISTOR
R335
7030005120 S.RESISTOR
R336
7030005050 S.RESISTOR
R337
7030005170 S.RESISTOR
R338
7310003600 S.TRIMMER
R339
7030005170 S.RESISTOR
R340
7030005050 S.RESISTOR
R341
7030005050 S.RESISTOR
R342
7030005050 S.RESISTOR
R343
7030005600 S.RESISTOR
R361
7030005040 S.RESISTOR
R362
7030005160 S.RESISTOR
R363
7030005170 S.RESISTOR
R706
7030005050 S.RESISTOR
R713
7030008010 S.RESISTOR
R714
7030008010 S.RESISTOR
R715
7030005040 S.RESISTOR
R716
7030008010 S.RESISTOR
R717
7030005120 S.RESISTOR
R718
7030008010 S.RESISTOR
R719
7030008010 S.RESISTOR
R726
7030005240 S.RESISTOR
R727
7030005220 S.RESISTOR
R729
7030008400 S.RESISTOR
R730
7030005110 S.RESISTOR
R731
7030008300 S.RESISTOR
R732
7030005040 S.RESISTOR
R733
7310003590 S.TRIMMER
R734
7030005220 S.RESISTOR
R735
7030007340 S.RESISTOR
R736
7030007340 S.RESISTOR
R737
7510001040 S.THERMISTOR TBPS1R153K460H5Q
R751
7030005050 S.RESISTOR
R752
7030005230 S.RESISTOR
R753
7030005000 S.RESISTOR
R754
7030005240 S.RESISTOR
R755
7030005120 S.RESISTOR
R756
7030004980 S.RESISTOR
DESCRIPTION
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 225 X (2.2 MΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
EVM-1XSX50 B54 (503)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 333 X (33 kΩ)
EVM-1XSX50 B54 (503)
EVM-1XSX50 B54 (503)
EVM-1XSX50 B54 (503)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 474 X (470 kΩ)
EVM-1XSX50 B54 (503)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 184 X (180 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
EVM-1XSX50 B24 (203)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
[LOGIC UNIT]
REF
ORDER
NO.
NO.
R757
7030005220 S.RESISTOR
R758
7030005240 S.RESISTOR
R759
7030005110 S.RESISTOR
R760
7030005160 S.RESISTOR
R901
7030000320 S.RESISTOR
C1
4550005980 S.TANTALUM
C2
4030013850 S.CERAMIC
C3
4030014160 S.CERAMIC
C4
4030014160 S.CERAMIC
C5
4030013850 S.CERAMIC
C6
4550005980 S.TANTALUM
C7
4030013850 S.CERAMIC
C8
4030011600 S.CERAMIC
C9
4030013850 S.CERAMIC
C10
4030009820 S.CERAMIC
C11
4030011600 S.CERAMIC
C12
4030011600 S.CERAMIC
C13
4030013850 S.CERAMIC
C17
4550003260 S.TANTALUM
C75
4550002980 S.TANTALUM
C76
4030013850 S.CERAMIC
C77
4030013850 S.CERAMIC
C82
4030013850 S.CERAMIC
C90
4030013850 S.CERAMIC
C91
4030013850 S.CERAMIC
C92
4030013850 S.CERAMIC
C93
4030013850 S.CERAMIC
C101
4030013850 S.CERAMIC
C102
4030013850 S.CERAMIC
C103
4030013850 S.CERAMIC
C141
4030013850 S.CERAMIC
C142
4550006780 S.TANTALUM
C143
4030013850 S.CERAMIC
C145
4030013850 S.CERAMIC
C146
4030011600 S.CERAMIC
C147
4550006730 S.TANTALUM
C148
4030013850 S.CERAMIC
C149
4550006780 S.TANTALUM
C150
4030009820 S.CERAMIC
C151
4030013850 S.CERAMIC
C152
4030008880 S.CERAMIC
C162
4030013850 S.CERAMIC
C201
4030008920 S.CERAMIC
C202
4550003080 S.TANTALUM
C203
4030014180 S.CERAMIC
C204
4030013850 S.CERAMIC
C205
4510004640 S.ELECTROLYTIC ECEV1CA470SP
C206
4510005320 S.ELECTROLYTIC ECEV0JA101SP
C207
4550005980 S.TANTALUM
C208
4030013850 S.CERAMIC
C209
4030013850 S.CERAMIC
C210
4550006250 S.TANTALUM
C211
4030013850 S.CERAMIC
C212
4510006960 S.ELECTROLYTIC ECEV0JA151WP
C213
4550006680 S.TANTALUM
C214
4550002980 S.TANTALUM
C215
4030011600 S.CERAMIC
C216
4030011600 S.CERAMIC
C217
4030011600 S.CERAMIC
C220
4030011600 S.CERAMIC
C240
4030009980 S.CERAMIC
C241
4030011600 S.CERAMIC
C242
4030008910 S.CERAMIC
C243
4030011600 S.CERAMIC
C244
4030011600 S.CERAMIC
C245
4030011600 S.CERAMIC
C246
4030011600 S.CERAMIC
C247
4030014200 S.CERAMIC
C248
4030011600 S.CERAMIC
C249
4030009820 S.CERAMIC
C250
4030009820 S.CERAMIC
C251
4030013850 S.CERAMIC
C252
4030006870 S.CERAMIC
C253
4030006880 S.CERAMIC
C301
4030006870 S.CERAMIC
C302
4030006880 S.CERAMIC
C303
4030010040 S.CERAMIC
C304
4030013850 S.CERAMIC
C305
4030006870 S.CERAMIC
C306
4550006780 S.TANTALUM
6 - 2
DESCRIPTION
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 105 X (1 MΩ)
MCR10EZHJ 330 Ω (331)
TEMSVA 1A 475M-8L
ECUE1E102KBQ
ECUE1H270JCQ
ECUE1H270JCQ
ECUE1E102KBQ
TEMSVA 1A 475M-8L
ECUE1E102KBQ
C1608 JB 1C 104KT-N
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
ECUE1E102KBQ
TEMSVA 1V 684M-8L
TEMSVA 1C 225M-8L
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
TEMSVB2 0J 476M-8R
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1C 104KT-N
TEMSVB2 0J 226M-8L
ECUE1E102KBQ
TEMSVB2 0J 476M-8R
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
C1608 JB 1C 223K-T-A
ECUE1E102KBQ
C1608 JB 1C 473K-T-A
TEMSVA 1A 335M-8L
ECUE1H470JCQ
ECUE1E102KBQ
TEMSVA 1A 475M-8L
ECUE1E102KBQ
ECUE1E102KBQ
TEMSVA 1A 106M-8L
ECUE1E102KBQ
ECST0JY156R
TEMSVA 1C 225M-8L
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 152K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 393K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
ECUE1H101JCQ
C1608 JB 1C 104KT-N
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
C1608 JB 1H 222K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 222K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 561K-T-A
ECUE1E102KBQ
C1608 JB 1H 222K-T-A
TEMSVB2 0J 476M-8R
S.=Surface mount
