Portable Basketball System with Elevator

SAFETY INSTRUCTIONS

FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY
RESULT IN SERIOUS INJURY,
PROPERTY DAMAGE AND WILL VOID WARRANTY.
Owner must ensure that all players know and follow these
rules for safe operation of the unit.
To ensure safety, do not attempt to assemble this system without
following the instructions carefully. Check entire box and inside all
packing material for parts. Before beginning assembly, read the
instructions and identify parts using the hardware identifier and parts
list in this document. Proper and complete assembly, use and
supervision is essential for proper operation and to reduce the risk of
accident or injury. A high probability of serious injury exists if this
system is not installed, maintained, and operated properly.
• This equipment is intended for home recreational use only and NOT
excessive competitive play.
• Read and understand the warning label affixed to pole. Label is shown on
page 2.
• The life of your basketball pole depends on many conditions. The climate,
placement of the pole, the location of the pole, exposure to corrosives such
as pesticides, herbicides or salts are all important.
• During assembly, if using a ladder use extreme caution. Two people are
recommended for this operation.
• Seat the pole sections properly. Failure to do so could allow the pole
sections to separate during play and/or transport of the system.
• Climate, corrosion and excessive use or misuse could result in pole
failure.
• Check base regularly for leakage. Slow leaks could cause unit to tip over
unexpectedly.
• If technical assistance is required, contact Huffy Sports.
• Adult supervision is recommended when adjusting height.
• Minimum operational height is 2 m (6'6") to the bottom of backboard.
Most injuries are caused by misuse and/or not following instructions.
Use caution when using this unit.
IMPORTANT!
Have any questions...don't go back to the store.
We appreciate your purchasing one of our many fine products. We are sure that you will be very satisfied with your selection. Although
great care and effort have been taken, problems may occur. To ensure prompt and correct handling of any problems, or to answer any
questions, please contact the Customer Service Center. Service will be quicker if you reference your Model Number (found on carton).
PLEASE WRITE YOUR MODEL NUMBER IN THE SPACE PROVIDED ABOVE.
P/N 205343A
7/97
WRITE IN MODEL NUMBER:
Owners Manual
Internet Address: http://www.huffysports.com
Toll-Free Customer Service Number for Austrailia: 1-800-333061
____________
REQUIRED TOOLS AND
• Two People
• Tape Measure
• Tape
• Wood Board (Scrap)
• Wrenches: (Two) 7/16", 1/2", 9/16", 3/4"
(9/16" Deep Socket w/Ext. Recommended)
Or Large and Small Adjustable Wrenches
• Support Table
• Step Ladder 8 ft. (2.4 m)
• Garden Hose or Sand (102 kg) (225 lb.)
1
Customer Service Center
Annex 89 Larkin Ave.
Essendon Airport
Essendon Airport North
Melbourne, Australia 3041
MATERIALS:

Advertisement

Table of Contents
loading

Summary of Contents for Huffy SKM 3072-U

  • Page 1: Safety Instructions

    • Two People unexpectedly. • Tape Measure • Tape • If technical assistance is required, contact Huffy Sports. • Wood Board (Scrap) • Adult supervision is recommended when adjusting height. • Wrenches: (Two) 7/16”, 1/2”, 9/16”, 3/4” • Minimum operational height is 2 m (6’6”) to the bottom of backboard.
  • Page 2: Height Adjustment

    IMPORTANT! WRITE DOWN MODEL NUMBER FROM BOX ON PAGE 1 OF THIS OWNERS MANUAL WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the unit. See instruction manual for proper installation and maintenance.
  • Page 3: Bottom View Of Base

    Slide strut holder (3) between wheel (2) and Lay base (1) bottom up and set wheel (2) into place. base (1). NOTE: Wheel (1) has spacer snapped in place over axle hole, the spacer should face the strut holder (3). Bottom View of Base With wheel and strut holder in place, insert spacer (6) thru notch in base, strut holder (3) and wheel (2).
  • Page 4: Side View

    Setup base (1) as shown and install strut tubes (8). Line-up hole in strut tube (8) with hole in strut support (3) and install hardware as shown. Repeat for opposite side. IMPORTANT! DO NOT TIGHTEN COMPLETELY AT THIS TIME. Slide collar (12) onto strut tubes. Line up holes in tubes (8) with holes in collar (12).
  • Page 5 Mark poles with tape as shown. IMPORTANT! Bounce middle pole section onto 13 cm (5”) top pole section until they no longer move toward tape reference mark. Upright assembly. HOLES IN TOP AND BOTTOM POLE SECTIONS MUST ALIGN TO CORRECTLY POSITION ELEVATOR SYSTEM.
  • Page 6 IMPORTANT! Test fit bolts into holes of brackets (19) and carefully rock them in a circular motion to ream out paint from holes if necessary. IMPORTANT! Finger tighten nuts and bolts until instructed to fully tighten later. Fit spacer (22) into pawl (23) and fit pin of pawl through end hole of release lever (24).
  • Page 7 Starting with nuts (11) flush against bracket (19), secure goal rim (37) and bracket (19) to backboard. NOTE: Mounting nuts and bolts supplied with goal rim hardware. Fold bracket (19) to line up with holes in backboard and secure. IMPORTANT! For spring loaded goal rim assembly, refer to instructions included...
  • Page 8 Install net (38). Support pole on support table. Attach backboard components under assembly to top pole section (12). NOTE: Two people are recommended for this step, use caution, elevator component under assembly is heavy. Then install pole cap (42). SUPPORT TABLE NOTE: Protecting goal rim with cardboard will prevent scratches.
  • Page 9: Adjusting The Height

    WARNING Roll completed assembled component to DO NOT LEAVE desired position. Fill base with water COMPONENTS UNDER approx. 106 liters (28 gallons) or sand ASSEMBLY UNATTENDED approx. 102 kg (225 lb.) and snap cap WHEN EMPTY, MAY TIP OVER. (43) in place. Secure component to ground using rope (44) and tie down stake (45).
  • Page 10: Parts List

    PARTS LIST Item Qty. Part No. Description Item Qty. Part No. Description 800826 Base, (Gray) 800876 Pawl & Pin Component 202808 Wheel, (Black) 201126 Release Lever 202935 Strut Holder - Right, (Black) 201124 Locknut, Hex Head, 3/8-16 202936 Strut Holder - Left, (Black) 240017 Bolt, Hex Head, 1/4-20 x 2-1/4 Long 202924...
  • Page 11 HARDWARE IDENTIFIER Item #18 (2) Item #20 (1) Item #26 (1) Item #17 (1) Item #27 (1) Item #25 (1) Item #28 (5) Item #30 (2) Item #31 (1) Item #33 (6) Item #35 (4) Item #36 (2) Item #39 (1) Item #41 (4) 11 OF 11 P/N 205343A...
