GEMINI MASTER CHEF MULTIFUNCTION THERMOFAN UNDER COUNTER OVEN CONTENTS Introduction Unpacking Cupboard Design Installation Electrical Installation Safety Advice The Control Panel Automatic Oven Timer/Clock The Oven – Functions Solid Plates Ceran Smooth Top Maintenance Problem Check Owner’s Responsibility Service Features and Benefits www.defy.co.za...
Note that the oven door is reversible and may hinge from the left or right. Consult the • nearest Defy Service Centre and they will advise the correct procedure. INSTALLATION Aperture Hob fixing bracket ‘U’...
The hob should be installed in a ventilated cupboard fitted with a sturdy work-top and • must be secured using the fixing brackets provided. Place the oven on the floor in front of the aperture and make the electrical connection •...
THE CONTROL PANEL LEFT RIGHT LEFT RIGHT MULTI- FUNCTION FRONT FRONT BACK BACK AUTOMATIC OVEN THERMOSTAT MULTI- PLATE PLATE PLATE PLATE OVEN TIMER AND INDICATOR FUNCTION CONTROL CONTROL CONTROL CONTROL AND CLOCK LIGHT SELECTOR 1 2 :4 5 STOP GEMINI MULTI - CHEF THE OVEN THERMOSTAT IS MARKED DOWN TO 70°C.
MINUTE MINDER Suppose that you wish to time the boiling of a 5 minute egg. • First boil the water • Press and hold button 1. The display will show 00.00 • Press button 6 until the display shows 00.05 •...
Page 6
The word AUTO will flash until button 4 is pressed and manual control is restored. • Return the multi function selector to the OFF position • The oven thermostat must be turned to the OFF position in an anticlockwise • direction.
MULTI FUNCTION OVEN The Defy multifunction oven allows a choice of 5 distinctly different cooking modes. 1. Fan only (defrosting) THERMOFAN COOKING FAN ONLY – NO HEAT 2. Thermofan cooking 3. Conventional cooking 4. Conventional grilling 5. Turbo grilling THESE ARE SELECTED...
Cooking • Ensure that the timer is set to manual. (Press button 4) RECOMMENDED • Set the multi function knob to Thermofan cooking. • Set the oven thermostat to the required temperature. TRAY POSITIONS • The indicator light will glow and remain on until the oven has reached the selected temperature.
Page 9
4. CONVENTIONAL GRILL The oven door must remain partially open (about 50 mm) • Use only a wire shelf when grilling as the intense heat could warp baking trays. • Ensure that the timer is set to manual mode. • Turn the multi function knob to conventional grill.
To prevent rust, periodically apply some sewing machine oil or electrical hotplate • polish - available from Defy Service Centres. Extra attention is required in areas of high humidity or in close proximity to the sea. NOTE: THE WARRANTY DOES NOT COVER THE REPLACEMENT OR REPAIR OF RUSTED OR CORRODED PLATES.
Clean the hob with a nylon pad and ‘Smooth top cleaner’. A sample of this cleaner is • supplied with the unit. Replenishment cleaner is available from all Defy Service Centres. If necessary stubborn spills may be removed using the blade scraper provided.
MAINTENANCE Cleaning the ovens Switch off the power at the wall switch, open the oven • door and allow the oven to cool down. Remove the oven shelves, side racks, broiler, roast pan, • element guard and baking trays. Wash in soapy water, rinse dry and replace.
• SERVICE If you have followed the instructions and still have a problem, contact the nearest Defy Service Centre. They will be able to advise you on any aspect of the machine or send a qualified technician to repair it.
FEATURES AND BENEFITS FEATURES BENEFITS Multi function A choice of 5 cooking modes Defrost Speeds up defrosting Thermofan cooking Excellent for bulk baking. No flavour transfer Electricity saving Conventional cooking and grilling Traditional baking and grilling at its best Turbo grill Superior grilling- reduced splatter.
