Dell™ Latitude™ D620 User's Guide
Finding Information
About Your Computer
Using a Battery
Using the Keyboard
Using the Display
Using Multimedia
Using a Network
Using Cards
Securing Your Computer
Troubleshooting
For information on other documentation included with your computer, see
Notes, Notices, and Cautions
NOTE:
A NOTE indicates important information that helps you make better use of your computer.
NOTICE:
A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION:
A CAUTION indicates a potential for property damage, personal injury, or death.
Abbreviations and Acronyms
For a complete list of abbreviations and acronyms, see the Glossary.
If you purchased a Dell™ n Series computer, any references in this document to Microsoft® Windows® operating systems are not applicable.
Information in this document is subject to change without notice.
© 2005–2006 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, PowerEdge, PowerVault, PowerApp, ExpressCharge, TravelLite, Strike Zone, Wi-Fi
Catcher, Dell MediaDirect, XPS, and Dell OpenManage are trademarks of Dell Inc.; Core and Intel are registered trademarks of Intel Corporation; Microsoft, Outlook, and Windows are
registered trademarks of Microsoft Corporation; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license; TouchStrip is a trademark of
UPEK, Inc.; EMC is a registered trademark of EMC Corporation; ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner,
Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Model PP18L
January 2006 P/N PC979 Rev. A01
System Setup Program
Reinstalling Software
Adding and Replacing Parts
Dell™ QuickSet Features
Traveling With Your Computer
Getting Help
Specifications
Appendix
Glossary
Finding
Information.
Advertisement
Table of Contents
Related Manuals for Dell D620/D820 - LATITUDE PRECISION M65
Summary of Contents for Dell D620/D820 - LATITUDE PRECISION M65
- Page 1 Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
-
Page 2: About Your Computer
Back to Contents Page About Your Computer Dell™ Latitude™ D620 User's Guide Front View Left Side View Right Side View Back View Bottom View Front View display latch display power button device status lights keyboard fingerprint reader (optional) (optional) speaker touch pad buttons/track... - Page 3 The keyboard includes a numeric keypad as well as the Windows logo key. For information on supported keyboard shortcuts, see Using the Keyboard. fingerprint reader (optional) — Helps to keep your Dell™ computer secure. When you slide your finger over the reader, it uses your unique fingerprint to authenticate your user identity. For information on how to activate and use the security management software that controls the fingerprint reader, see Security Management Software. ...
-
Page 4: Left Side View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. -
Page 5: Right Side View
Cards. wireless switch — Turns on/off wireless devices such as Wi-Fi and internal cards with Bluetooth technology and scans for wireless networks. For more information about scanning for wireless networks, see Dell™ Wi-Fi Catcher™ Network Locator. "off" position "on" position "momentary" position Wi-Fi Catcher light ... -
Page 6: Back View
USB connectors media bay — Supports a floppy or an optical drive, second battery, second hard drive, or a Dell TravelLite™ module. See Using Multimedia. device latch release — Use the latch release to eject a device. USB connectors Connect USB devices, such as a mouse, keyboard, or printer. Back View ... -
Page 7: Bottom View
USB connectors Connect USB devices, such as a mouse, keyboard, or printer. serial connector Connects serial devices, such as a mouse or handheld device. video connector Connects video devices, such as a monitor. AC adapter connector — Connects an AC adapter to the computer. - Page 8 Replacing the Battery for instructions. docking-device connector — Lets you attach your computer to the Media Base or other docking device. See the Dell documentation that came with your docking device for more information. air vents — The computer uses an internal fan to create airflow through the fan air vents, which prevents the computer from overheating.
-
Page 9: Cleaning Your Computer
Back to Contents Page Appendix Dell™ Latitude™ D620 User's Guide Cleaning Your Computer Macrovision Product Notice FCC Notice (U.S. Only) Cleaning Your Computer CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide. -
Page 10: Macrovision Product Notice
2. This device must accept any interference received, including interference that may cause undesired operation. NOTICE: The FCC regulations provide that changes or modifications not expressly approved by Dell Inc. could void your authority to operate this equipment. These limits are designed to provide reasonable protection against harmful interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. -
Page 11: Using A Battery
For information about the Dell™ warranty for your computer, see the Product Information Guide or separate paper warranty document that shipped with your computer. For optimal computer performance and to help preserve BIOS settings, operate your Dell portable computer with the main battery installed at all times. One battery is supplied as standard equipment in the battery bay. -
Page 12: Conserving Battery Power
Microsoft® Windows® Power Meter The Windows Power Meter indicates the remaining battery charge. To check the Power Meter, double-click the icon on the taskbar. If the computer is connected to an electrical outlet, a icon appears. Charge Gauge Before you insert a battery, press the status button on the battery charge gauge to illuminate the charge-level lights. Each light represents approximately 20 percent of the total battery charge. -
Page 13: Configuring Power Management Settings
NOTE: If you want to use a 9-cell battery to obtain Dell ExpressCharge, you need to use it in conjunction with a 90-W AC adapter. When you connect the computer to an electrical outlet or install a battery while the computer is connected to an electrical outlet, the computer checks the battery charge and temperature. -
Page 14: Replacing The Battery
CAUTION: Using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased from Dell. The battery is designed to work with your Dell™ computer. Do not use a battery from other computers with your computer. NOTICE: You must remove all external cables from the computer to avoid possible connector damage. For information about replacing the second battery, if applicable, see Media Bay. -
Page 15: Using Cards
Back to Contents Page Using Cards Dell™ Latitude™ D620 User's Guide Card Types Installing a PC Card or ExpressCard Removing a Card or Blank NOTE: Electrical and electronic devices are sensitive to electrostatic discharge (ESD). If a substantial ESD occurs, the device may reset and the device software may attempt to reinitialize a connection. -
Page 16: Removing A Card Or Blank
2. Slide the card into the slot until the card is completely seated in its connector. If you encounter too much resistance, do not force the card. Check the card orientation and try again. The computer recognizes most PC Cards and automatically loads the appropriate device driver. If the configuration program tells you to load the manufacturer's drivers, use the floppy disk or CD that came with the PC Card. -
Page 17: Using The Display
NOTE: Use only the Dell-installed video drivers, which are designed to offer the best performance with your Dell-installed operating system. If you choose a resolution or color palette that is higher than the display supports, the settings adjust automatically to the closest supported values. -
Page 18: Swapping Primary And Secondary Displays
You can attach an external monitor or projector to your computer and use it as an extension of your display (known as "dual independent display" or "extended desktop" mode). This mode allows you to use both screens independently and drag objects from one screen to the other, effectively doubling the amount of viewable work space. - Page 19 The ALS is disabled when your computer is shipped to you. If you enable the ALS and then use any of the display brightness key combinations, the ALS is disabled and the display brightness is increased or decreased accordingly. Dell™ QuickSet allows you to enable or disable the ALS feature. You can also adjust maximum and minimum brightness settings that are activated when you enable the ALS feature. For more information about QuickSet, right-click the icon in the taskbar, and click Help.
-
Page 20: Reinstalling Software
A driver acts like a translator between the device and any other programs that use the device. Each device has its own set of specialized commands that only its driver recognizes. Dell ships your computer to you with required drivers already installed—no further installation or configuration is needed. NOTICE: The Drivers and Utilities CD may contain drivers for operating systems that are not on your computer. - Page 21 3. Click System. 4. In the System Properties window, click the Hardware tab. 5. Click Device Manager. 6. Right-click the device for which the new driver was installed and click Properties. 7. Click the Drivers tab. ...
-
Page 22: Resolving Software And Hardware Incompatibilities
See the Windows Help and Support Center for information on using System Restore. NOTICE: Make regular backups of your data files. System Restore does not monitor your data files or recover them. NOTE: The procedures in this document were written for the Windows default view, so they may not work if you set your Dell™ computer to the Windows Classic view. Creating a Restore Point ... -
Page 23: Using The Operating System Cd
The Operating System CD provides options for reinstalling Windows XP. The options can overwrite files and possibly affect programs installed on your hard drive. Therefore, do not reinstall Windows XP unless a Dell technical support representative instructs you to do so. - Page 24 4. Press <F12> immediately after the DELL™ logo appears. If the operating system logo appears, wait until you see the Windows desktop, and then shut down the computer and try again. 5. Follow the instructions on the screen to complete the installation. Back to Contents Page...
-
Page 25: Finding Information
Specifications How to configure system settings Microsoft Windows XP Help and Support Center How to troubleshoot and solve problems 1. Click the Start button and click Help and Support. 2. Click Dell User and System Guides and click System Guides. - Page 26 The Dell Support Utility is an automated upgrade and notification system installed on your computer. This support provides real-time health scans of your computing environment, software updates, and relevant self-support information. Access the Dell Support Utility from the icon in the taskbar.
- Page 27 NOTE: The color of your CD varies based on the operating system you ordered. Back to Contents Page ...
- Page 28 Back to Contents Page Glossary Dell™ Latitude™ D620 User's Guide Terms in this Glossary are provided for informational purposes only and may or may not describe features included with your particular computer. A AC — alternating current — The form of electricity that powers your computer when you plug the AC adapter power cable in to an electrical outlet.
- Page 29 CD-RW — CD rewritable — A rewritable version of a CD. Data can be written to a CD-RW disc, and then erased and written over (rewritten). CD-RW drive — A drive that can read CDs and write to CD-RW (rewritable CDs) and CD-R (recordable CDs) discs. You can write to CD-RW discs multiple times, but you can write to CD-R discs only once.
- Page 30 ExpressCard — A removable I/O card adhering to the PCMCIA standard. Modems and network adapters are common types of ExpressCards. ExpressCards support both the PCI Express and USB 2.0 standard. Express Service Code — A numeric code located on a sticker on your Dell™ computer. Use the Express Service Code when contacting Dell for assistance. Express Service Code service may not be available in some countries.
- Page 31 MB/sec — megabytes per second — One million bytes per second. This measurement is typically used for data transfer ratings. media bay — A bay that supports devices such as optical drives, a second battery, or a Dell TravelLite™ module. memory — A temporary data storage area inside your computer. Because the data in memory is not permanent, it is recommended that you frequently save your files while you are working on them, and always save your files before you shut down the computer.
- Page 32 measured in MHz. modem — A device that allows your computer to communicate with other computers over analog telephone lines. Three types of modems include: external, PC Card, and internal. You typically use your modem to connect to the Internet and exchange e-mail. module bay —...
- Page 33 — An I/O port often used to connect devices such as a handheld digital device or digital camera to your computer. Service Tag — A bar code label on your computer that identifies your computer when you access Dell Support at support.dell.com or when you call Dell for customer service or technical support.
- Page 34 change the settings for this program. T TAPI — telephony application programming interface — Enables Windows programs to operate with a wide variety of telephony devices, including voice, data, fax, and video. text editor — A program used to create and edit files that contain only text; for example, Windows Notepad uses a text editor. Text editors do not usually provide word wrap or formatting functionality (the option to underline, change fonts, and so on).
- Page 35 X XGA — extended graphics array — A video standard for video cards and controllers that supports resolutions up to 1024 x 768. Z ZIF — zero insertion force — A type of socket or connector that allows a computer chip to be installed or removed with no stress applied to either the chip or its socket.
-
Page 36: Getting Help
Dell's Express Service Code system may not be available in all countries. When prompted by Dell's automated telephone system, enter your Express Service Code to route the call directly to the proper support personnel. If you do not have an Express Service Code, open the Dell Accessories folder, double-click the Express Service Code icon, and follow the directions. -
Page 37: Problems With Your Order
Product Information If you need information about additional products available from Dell, or if you would like to place an order, visit the Dell website at www.dell.com. For the telephone number to call to speak to a sales specialist, see the contact numbers for your region. -
Page 38: Before You Call
NOTE: In certain countries, support specific to Dell XPS™ portable computers is available at a separate telephone number listed for participating countries. If you do not see a telephone number listed that is specific for XPS portable computers, you may contact Dell through the support number listed and your call will be routed appropriately. When you need to contact Dell, use the electronic addresses, telephone numbers, and codes provided in the following table. If you need assistance in determining which codes to use, contact a local or an international operator. - Page 39 Home/Small Business Customer Care 0820 240 530 14 Preferred Accounts/Corporate Customer Care 0820 240 530 16 Country Code: 43 Support for XPS portable computers only 0820 240 530 81 City Code: 1 Home/Small Business Support for all other Dell computers 0820 240 530 14 Preferred Accounts/Corporate Support 0660 8779 Switchboard 0820 240 530 00 Bahamas General Support toll-free: 1-866-278-6818...
- Page 40 Technical Fax 22537 2728 Switchboard 22537 2711 Website: support.euro.dell.com Technical Support for XPS portable computers only 7010 0074 Technical Support for all other Dell computers 7023 0182 Denmark (Copenhagen) Customer Care (Relational) 7023 0184 International Access Code: 00 Home/Small Business Customer Care 3287 5505 Switchboard (Relational) 3287 1200...
- Page 41 Website: support.euro.dell.com E-mail: tech_support_central_europe@dell.com Technical Support for XPS portable computers only 06103 766-7222 Germany (Langen) Technical Support for all other Dell computers 06103 766-7200 International Access Code: 00 Home/Small Business Customer Care 0180-5-224400 Global Segment Customer Care 06103 766-9570 Country Code: 49 Preferred Accounts Customer Care 06103 766-9420...
- Page 42 0120-198-226 Technical Support outside of Japan (Dimension and Inspiron) 81-44-520-1435 Technical Support (Dell Precision, OptiPlex, and Latitude) toll-free:0120-198-433 Technical Support outside of Japan (Dell Precision, OptiPlex, and Latitude) 81-44-556-3894 Japan (Kawasaki) Technical Support (PDAs, projectors, printers, routers) toll-free: 0120-981-690...
- Page 43 Netherlands Antilles General Support 001-800-882-1519 Website: support.euro.dell.com Technical Support for XPS portable computers only 020 674 45 94 Technical Support for all other Dell computers 020 674 45 00 Technical Support Fax 020 674 47 66 Netherlands (Amsterdam) Home/Small Business Customer Care 020 674 42 00 International Access Code: 00 Relational Customer Care 020 674 4325...
- Page 44 E-mail: Tech_support_central_Europe@dell.com Switzerland (Geneva) Technical Support for XPS portable computers only 0848 33 88 57 Technical Support (Home and Small Business) for all other Dell products 0844 811 411 International Access Code: 00 Technical Support (Corporate) 0844 822 844 Country Code: 41 Customer Care (Home and Small Business) 0848 802 202...
- Page 45 0870 907 4006 Uruguay General Support toll-free: 000-413-598-2521 Automated Order-Status Service toll-free: 1-800-433-9014 AutoTech (portable and desktop computers) toll-free: 1-800-247-9362 Hardware and Warranty Support (Dell TV, Printers, and Projectors) for toll-free 1-877-459-7298 Relationship customers Consumer (Home and Home Office) Support for all other Dell products toll-free: 1-800-624-9896 Customer Service toll-free: 1-800-624-9897 Employee Purchase Program (EPP) Customers toll-free: 1-800-695-8133 Financial Services website: www.dellfinancialservices.com ...
-
Page 46: Using The Keyboard
Key Combinations System Functions <Ctrl><Shift><Esc> Opens the Task Manager window Battery <Fn><F3> Displays the Dell™ QuickSet Battery Meter (see Dell™ QuickSet Battery Meter). Display Functions <Fn><F8> Switches the video image to the next display option. The options include the integrated display, an external monitor, and both displays simultaneously. -
Page 47: Touch Pad
<Fn><Esc> Activates a power management mode. You can reprogram this keyboard shortcut to activate a different power management mode using the Advanced tab in the Power Options Properties window. <Fn><F1> Puts the computer into hibernate mode. Dell QuickSet is required (see Dell™ QuickSet Features). Microsoft® Windows® Logo Key Functions Windows logo key and <m>... -
Page 48: Changing The Track Stick Cap
3. Click OK to save the settings and close the window. Changing the Track Stick Cap You can replace your track stick cap if it wears down from prolonged use or if you prefer a different color. You can purchase additional caps by visiting the Dell website at www.dell.com. -
Page 49: Using Multimedia
Back to Contents Page Using Multimedia Dell™ Latitude™ D620 User's Guide Playing CDs or DVDs Adjusting the Volume Adjusting the Picture Playing CDs or DVDs NOTICE: Do not press down on the CD or DVD tray when you open or close it. Keep the tray closed when you are not using the drive. -
Page 50: Adjusting The Picture
Volume Control Buttons You can adjust the volume with the volume control buttons on your computer. See volume control buttons. Volume Control Keys You can adjust the volume by pressing the following keys: Press <Fn> <PageUp> to increase volume. Press <Fn>... -
Page 51: Adding And Replacing Parts
Hold a component such as a processor by its edges, not by its pins. NOTICE: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is not covered by your warranty. -
Page 52: Hinge Cover
2. Turn off your computer (see Turning Off Your Computer). 3. If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions. NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug it from the network wall connector. ... - Page 53 NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such as the back panel) on the computer. 1. Follow the instructions in Before You Begin. 2. Turn the computer right-side up and open it. hinge cover keyboard ...
-
Page 54: Internal Card With Bluetooth® Wireless Technology
6. If the keyboard cable is held in place by a keyboard lock arm next to the keyboard connector, carefully pivot the lock arm upward to uncover the cable. 7. Pull up on the pull-tab to disconnect the keyboard cable connector from the keyboard connector on the system board. NOTE: When you replace the keyboard, ensure that the keyboard tabs are completely in place to avoid scratching the palm rest. - Page 55 If you remove your original memory modules from the computer during a memory upgrade, keep them separate from any new modules that you may have, even if you purchased the new modules from Dell. If possible, do not pair an original memory module with a new memory module.
- Page 56 memory module (DIMM A) securing clips (2) NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips. 4. If you are replacing a memory module, ground yourself and remove the existing module: a.
- Page 57 memory module cover captive screw NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips. 3. If you are replacing a memory module, ground yourself and remove the existing module: a.
-
Page 58: Wireless Local Area Network (Wlan) Card
7. Turn on the computer. As the computer boots, it detects the additional memory and automatically updates the system configuration information. To confirm the amount of memory installed in the computer, click Start®Help and Support, and then click Computer Information. ... -
Page 59: Mobile Broadband Card
WLAN card metal securing tabs (2) 5. To install a WLAN card: a. Move any antenna cables out of the way to make space for the WLAN card. b. Align the WLAN card with the connector at a 45-degree angle, and press the card into the connector until you feel a click. WLAN card antenna cable connectors NOTICE:... - Page 60 2. Remove the hinge cover (see Hinge Cover). 3. Remove the keyboard (see Keyboard). Mobile Broadband card antenna wires (2) NOTICE: To prevent damage to the connector, do not use tools to spread the securing clips. 4. If a Mobile Broadband card is not already installed, go to step 5. If you are replacing a Mobile Broadband card, remove the existing card: a.
-
Page 61: Subscriber Identity Module (Sim) Card
Mobile Broadband card antenna wires (2) NOTICE: To avoid damaging the Mobile Broadband card, never place cables on top of or under the card and ensure that you route the cables properly. NOTE: For more specific information about which cable to connect to which connector, see the documentation that came with your Mobile Broadband card. -
Page 62: Media Bay
Hard drives are extremely fragile; even a slight bump can damage the drive. NOTE: Dell does not guarantee compatibility or provide support for hard drives from sources other than Dell. To replace the hard drive in the hard drive bay: ... - Page 63 2. If the computer is running, double-click the Safely Remove Hardware icon on the taskbar, click the device you want to eject, and click Stop. 3. Press the device latch release. 4. Pull the device out of the media bay. To install a device, push the new device into the bay until it clicks into place.
-
Page 64: Dell™ Quickset Features
Network connectivity Power management Display System information Depending on what you want to do in Dell™ QuickSet, you can start it by either clicking, double-clicking, or right-clicking the QuickSet icon, , in the Microsoft® Windows® taskbar. The taskbar is located in the lower-right corner of your screen. For more information about QuickSet, right-click the QuickSet icon and select Help. -
Page 65: Securing Your Computer
Back to Contents Page Securing Your Computer Dell™ Latitude™ D620 User's Guide Security Cable Lock Using Smart Cards Passwords Trusted Platform Module (TPM) Security Management Software Computer Tracking Software If Your Computer Is Lost or Stolen Security Cable Lock NOTE: Your computer does not ship with a security cable lock. - Page 66 1 gold contact pad 2 smart card (top) 2. Slide the smart card into the smart card slot until the card is completely seated in its connector. The smart card will protrude approximately 1/2 inch from the slot. The smart card slot is located below the PC Card slot. If you encounter too much resistance, do not force the card.
-
Page 67: Trusted Platform Module (Tpm)
PC Cards with encryption features. If you forget any of your passwords, contact Dell (see Contacting Dell). For your protection, Dell technical support staff will ask you for proof of your identity to ensure that only an authorized person can use the computer. ... - Page 68 To secure your TPM data and encryption keys, follow the backup procedures documented in the Broadcom Secure Foundation Getting Started Guide. In the event of these backups being incomplete, lost, or damaged, Dell will be unable to assist in the recovery of encrypted data.
-
Page 69: Computer Tracking Software
If possible, give the name of the investigating officer. The Dell customer service representative will log your report under the computer Service Tag and record the computer as missing or stolen. If someone calls Dell for technical assistance and gives your Service Tag, the computer is identified automatically as missing or stolen. -
Page 70: System Setup Program
System security and hard-drive password settings NOTICE: Unless you are an expert computer user or are directed to do so by Dell technical support, do not change the system setup settings. Certain changes might make your computer work incorrectly. Viewing the System Setup Screens ... - Page 71 4. Turn on the computer. When the DELL logo appears, press <F12> immediately. If you wait too long and the Windows logo appears, continue to wait until you see the Windows desktop. Then shut down your computer and try again.
-
Page 72: Specifications
Back to Contents Page Specifications Dell™ Latitude™ D620 User's Guide Processor Processor types Intel® Core™ Solo and Intel Core Duo processors L1 cache 64 KB (internal) L2 cache 2 MB (on die) External bus frequency 667 MHz System Information System chipset Intel 945GM or 945PM Data bus width 64 bits... - Page 73 Intel High Definition Audio bus Network adapter 1 Gb Ethernet LAN on system board Wireless WLAN card, wireless switch with Dell™ Wi-Fi Catcher™ technology, internal card with Bluetooth® wireless technology, and Dell Mobile Broadband card. NOTE: The availability of the Dell Mobile Broadband card may vary by region. Video NOTE: Your Dell™ Latitude™ D620 computer has both integrated and discrete video options.
- Page 74 Stereo conversion 24-bit (stereo digital-to-analog), 24-bit (stereo analog-to-digital) Interfaces: Internal PCI bus/High Definition Audio External microphone miniconnector, stereo headphones/speakers miniconnector Speaker one 4-ohm speaker Internal speaker amplifier 2-W per channel into 4 ohms Volume controls keyboard shortcuts or program menus ...
- Page 75 Size protrudes 0.5 mm higher than surrounding keycaps Battery Type: 9-cell lithium-ion battery 85 WHr NOTE: You cannot use an auto/air adapter with a 9- cell battery. 6-cell lithium-ion battery 56 WHr 4-cell lithium-ion battery 35 WHr Dimensions:185.22 ...
- Page 76 Weight (without cables) 0.36 kg (0.79 lb) (65 W) 0.46 kg (1.01 lb) (90 W) Temperature range: Operating 0° to 35°C (32° to 95°F) (both) Storage –40° to 65°C (–40° to 149°F) (both) Physical Height 32 mm (1.26 inches) Width 337 mm (13.3 inches) Depth 238 mm (9.3 inches) Weight: ...
- Page 77 Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
-
Page 78: Traveling With Your Computer
Write down your Service Tag and store it in a safe place away from the computer or carrying case. Use the Service Tag if you need to report a loss or theft to law enforcement officials and to Dell. Create a file on the Microsoft® Windows® desktop called if_found. Place information such as your name, address, and phone number in this file. - Page 79 Prior to entering the airplane, verify that using a computer is permitted. Some airlines forbid the use of electronic devices during flight. All airlines forbid the use of electronic devices during takeoff and landing. Back to Contents Page ...
-
Page 80: Troubleshooting
Dell Technical Update Service The Dell Technical Update service provides proactive e-mail notification of software and hardware updates for your computer. The service is free and can be customized for content, format, and how frequently you receive notifications. To enroll for the Dell Technical Update service, go to support.dell.com/technicalupdate. - Page 81 Contacting Dell). NOTE: The Service Tag for your computer is located at the top of each test screen. If you contact Dell, technical support will ask for your Service Tag. 3. If you run a test from the Custom Test or Symptom Tree option, click the applicable tab described in the following table for more information.
-
Page 82: Dell Support Utility
4. When the tests are completed, if you are running the Dell Diagnostics from the Drivers and Utilities CD, remove the CD. 5. When the tests are complete, close the test screen to return to the Main Menu screen. To exit the Dell Diagnostics and restart the computer, close the Main Menu screen. - Page 83 Check the cable connections Check for hardware incompatibilities — Resolving Software and Hardware Incompatibilities. Run the Dell Diagnostics — Dell Diagnostics. CD and DVD drive problems NOTE: High-speed CD or DVD drive vibration is normal and may cause noise, which does not indicate a defect in the drive or the CD or DVD.
-
Page 84: E-Mail, Modem, And Internet Problems
Internet, your computer might be infected with spyware. Use an anti-virus program that includes anti-spyware protection (your program may require an upgrade) to scan the computer and remove spyware. For more information, go to support.dell.com and search for the keyword... -
Page 85: Error Messages
The computer cannot identify the drive type. Shut down the computer, remove the hard drive (see Hard Drive), and boot the computer from a CD. Then shut down the computer, reinstall the hard drive, and restart the computer. Run the Hard-Disk Drive tests in the Dell Diagnostics (see Dell Diagnostics). - Page 86 No boot sector on hard drive — The operating system may be corrupted. Contact Dell (see Contacting Dell). No timer tick interrupt — A chip on the system board may be malfunctioning. Run the System Set tests in the Dell Diagnostics (see Dell Diagnostics). ...
-
Page 87: Keyboard Problems
System configuration settings are corrupted. Connect your computer to an electrical outlet to charge the battery. If the problem persists, try to restore the data by entering the system setup program. Then immediately exit the program. If the message reappears, contact Dell... -
Page 88: Lockups And Software Problems
5. Type some characters on the internal keyboard and verify that they appear on the display. If the characters appear now but did not with the external keyboard, you may have a defective external keyboard. Contact Dell (see Contacting Dell). - Page 89 Cannot play some media files — Because Dell MediaDirect provides access to media files outside the Windows XP operating system environment, access to licensed content is restricted. Licensed content is digital content that has Digital Rights Management (DRM) applied to it. The Dell MediaDirect environment...
-
Page 90: Memory Problems
Internet, your computer might be infected with spyware. Use an anti-virus program that includes anti-spyware protection (your program may require an upgrade) to scan the computer and remove spyware. For more information, go to support.dell.com and search for the keyword spyware. -
Page 91: Pc Card Or Expresscard Problems
Searching – The Dell Mobile Broadband Card Utility has not yet located a Mobile Broadband network. If the searching state persists, ensure that the signal strength is adequate. No service – The Dell Mobile Broadband Card Utility did not locate a Mobile Broadband network. Ensure that the signal strength is adequate. Restart the Dell wireless utility or contact your Mobile Broadband network provider. -
Page 92: Power Problems
Docking Power Considerations Due to the extra power consumption when a computer is docked to the Dell D/Dock, normal computer operation is not possible on battery power alone. Ensure that the AC adapter is connected to your computer when the computer is docked to the Dell D/Dock. -
Page 93: Printer Problems
Docking While the Computer Is Running If a computer is connected to the Dell D/Dock or Dell D/Port while the computer is running, presence of the docking device is ignored until the AC adapter is connected to the computer. ... -
Page 94: Sound And Speaker Problems
Reinstall the audio driver — Reinstalling Drivers and Utilities. Run the Dell Diagnostics — Dell Diagnostics. NOTE: The volume control in some MP3 players overrides the Windows volume setting. If you have been listening to MP3 songs, ensure that you did not turn the player volume down or off. -
Page 95: Touch Pad Or Mouse Problems
Test the mouse controller — To test the mouse controller (which affects pointer movement) and the operation of the touch pad or mouse buttons, run the Mouse test in the Pointing Devices test group in the Dell Diagnostics (see Dell Diagnostics). - Page 96 1. Shut down your computer and connect an external monitor to the computer. 2. Turn on the computer and the monitor and adjust the monitor brightness and contrast controls. If the external monitor works, the computer display or video controller may be defective. Contact Dell (see Contacting Dell).
-
Page 97: Using A Network
Physically Connecting to a Network or Broadband Modem Network Setup Wizard Wireless Local Area Network (WLAN) Mobile Broadband Network Managing Your Network Settings Through the Dell QuickSet Location Profiler Dell™ Wi-Fi Catcher™ Network Locator Internet Connection Firewall Physically Connecting to a Network or Broadband Modem Before you connect your computer to a network that is not wireless, the computer must have a network cable connected to it. - Page 98 waves. What You Need to Establish a WLAN Connection Before you can set up a WLAN, you need: High-speed (broadband) Internet access (such as cable or DSL) A broadband modem that is connected and working A wireless router or access point A wireless network card for each computer that you want to connect to your WLAN A network cable with the network (RJ-45) connector ...
- Page 99 If the software is removed or corrupted, follow the instructions in the user documentation for your wireless network card. Verify the type of wireless network card installed in your computer and then search for that name on the Dell Support website at support.dell.com. For information on the...
-
Page 100: Mobile Broadband Network
Thereafter, whenever you log on to your computer within the range of the wireless network that you selected, the same pop-up notifies you of the wireless network connection. NOTE: If you select a secure network, you must enter a WEP or WPA key when prompted. Network security settings are unique to your network. Dell cannot provide this information. NOTE: Your computer can take up to 1 minute to connect to the network. -
Page 101: Managing Your Network Settings Through The Dell Quickset Location Profiler
Dell Mobile Broadband Card Utility, see the user's guide available through the Windows Help and Support Center. To access the Help and Support Center, see "Windows Help and Support Center" on page 13. The user's guide is also available on the Dell Support website at support.dell.com and on the CD included with your Mobile Broadband card if you purchased the card separately from your computer. -
Page 102: Internet Connection Firewall
Because the Wi-Fi Catcher Network Locator is disabled and not configured for use when your computer is shipped to you, you must first use Dell QuickSet to enable and configure the switch to control Wi-Fi network connections. For more information on the Wi-Fi Catcher Network Locator and to enable the feature through QuickSet, see the Dell QuickSet Help. To access the Help file, right-click the icon in the taskbar.
