ATEN CS64A Manual

CS64A
4-Port PS/2 KVM Switch
CS64A KVM Switch has a handy design integrating with 6 feet of cables.
It can control 4 servers via a single console.
Features
• One PS/2 console controls four PS/2 computers
• Compact design, built-in 1.8 m (6 feet) cables
• All-in-one design
• With speaker support
• Superior video quality – up to 2048 x 1536; DDC2B
• Auto Scan function to monitor computer operation
• Non-powered
Headquarters
ATEN International CO., Ltd.
3F, No.125, Sec. 2, Datung Rd. Sijhih City, Taipei 221, Taiwan
Tel: 886-2-8692-6789
© Copyright 2010ATEN® International Co., Ltd. All brand names and trademarks are the registered property of their respective owners.
Win, Linux
Fax: 886-2-8692-6767 E-mail : online@aten.com.tw
Setup
Speakers
Keyboard
PC3 PC4
Specifications
Function
Computer Connections
Port Selection
Keyboard
Video
Console
Ports
Mouse
Speaker
Connectors
Keyboard
Video
KVM Ports
Mouse
Speaker
LEDs Selected
Cable Length Computers
Emulation Keyboard/Mouse
Video Resolution
Scan Interval
Operating Temp
Environment Storage Temp
Humidity
Housing
Physical
Weight
Properties
Dimensions (L x W x H)
* The specifications and pictures are subject to change without notice.
Console
Monitor
Mouse
PS/2
CS64A
PC1 PC2
CS64A
4
Hotkeys
1 x 6-pin Mini-DIN Female (Purple)
1 x HDB-15 Female (Blue)
1 x 6-pin Mini-DIN Female (Green)
1 x Mini Stereo Jack Female (Green)
4 x 6-pin Mini-DIN Male (Purple)
4 x HDB-15 Male (Blue)
4 x 6-pin Mini-DIN Male (Green)
4 x Mini Stereo Plug Male (Green)
4 x Green
1.8m
PS/2
2048 x 1536; DDC2B
5 Seconds
0-50ºC
-20-60ºC
0-80% RH Non-condensing
Plastic
0.83 kg
8.95 x 7.19 x 2.60 cm
2010. Version 1.0
