Furuno Integrated Heading Sensor PG-1000 Specifications

Introducing an innovative breakthrough in electromagnetic compass technology
INTEGRATED HEADING SENSOR
Electromagnetic compass
poviding a highly accurate
and stable readout of ship's
compass heading
Maintenance free operation
Automatic compensation for
deviation and heeling error
Auto correction of magnetic
variation error with a GPS
receiver input providing
variation data with respect to
the area
Compact waterproof case for
a simple installation
Heading data output in
NMEA 0183 and AD-10
formats
The FURUNO PG-1000 is a new, inexpensive
electromagnetic compass. It provides a highly
accurate and stable readout of the ship's heading
thanks to the sophisticated structure by three-axis
magnetometer, inclinometer and integral vibrating
gyrosensor.
The PG-1000 detects terrestrial magnetism and
produces compass data. The data can be utilized
in serial formats such as NMEA 0183 and FURUNO
AD-10. It is sent to various equipment that need
accurate and stable heading data. Typical
applications include Radar Echo Trail and True
Motion, Video Plotters, Scanning Sonars, etc.
When connected with a GPS navigator, magnetic
variation correction can be made automatically.
A True Heading readout is possible as modern GPS
receivers output compass variation data in memory
with respect to the vessels geographic areas.
Because of its high accuracy, the PG-1000 can be
used as a backup system for the vessel's gyro
compass .
The PG-1000 also has an automatic re-calibration
capability. Once compensated at the time of
installation, the PG-1000 will continue to detect the
magnetic deviation error and carry out automatic re-
calibration while it is in use.
R
The future today with FURUNO's electronics technology.
FURUNO ELECTRIC CO., LTD.
9-52 Ashihara-cho, Nishinomiya City, Japan Telephone: +81 (798) 65-2111
Telex: 5644-325, Telefax: +81 (798) 65-4200, 66-4622, 66-4623
PG-1000
Model
R
Catalogue No. M-374a
