Gateway M305 Service Manual

Hide thumbs Also See for M305:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual
Gateway M305 Notebook
serviceguide
Customizing
Troubleshooting

Advertisement

Table of Contents
loading

Related Manuals for Gateway M305

Summary of Contents for Gateway M305

  • Page 1 Gateway M305 Notebook serviceguide Customizing Troubleshooting...
  • Page 2 Thank you for purchasing this Factory Service Manual CD/DVD from servicemanuals4u.com. Please check out our eBay auctions for more great deals on Factory Service Manuals: servicemanuals4u...

  • Page 4: Table Of Contents

    Contents Replacing Gateway M305 Components ......1 Identifying the notebook model ......... 2 Identifying components .

  • Page 6: Replacing Gateway M305 Components

    © 2003 Gateway, Inc. All rights reserved. Gateway, Gateway Country, the Gateway stylized logo, and the black-and-white spot design are trademarks or registered trademarks of Gateway, Inc. in the United States and other countries. All other brands and product names are trademarks or registered trademarks of their respective...

  • Page 7: Identifying The Notebook Model

    Replacing Gateway M305 Components Identifying the notebook model The label on the bottom of the notebook contains information that identifies the notebook model and its features. Gateway model number Warning It is important that you use the correct service guide for the notebook.

  • Page 8: Identifying Components

    Use this chart to identify the main components of the notebook. For a complete list of replaceable parts, see “Contents” on page LCD panel assembly (see page Keyboard cover (see page Keyboard (see page Cooling assembly (see page Palm rest assembly (see page System board (see page www.gateway.com...

  • Page 9: Preparing Your Work Space

    Replacing Gateway M305 Components Preparing your work space Before performing maintenance on the notebook, make sure that your work space and the notebook are correctly prepared. ■ Wear a grounding (ESD) wrist strap, and use a grounded or dissipative work mat.

  • Page 10: Preventing Static Electricity Discharge

    Touch a bare metal surface on your workbench or other grounded object. ■ Unplug the power cord and the modem and network cables. ■ Remove the battery. For more information, see “Removing the battery” on page ■ Disconnect all peripheral devices and remove any PC Cards. www.gateway.com...

  • Page 11: Preparing The Notebook

    Replacing Gateway M305 Components Before working with notebook components, follow these guidelines: ■ Avoid static-causing surfaces such as carpeted floors, plastic, and packing foam. ■ Remove components from their antistatic bags only when you are ready to use them. Do not lay components on the outside of antistatic bags because only the inside of the bags provide electrostatic protection.

  • Page 12: Preparing The Notebook

    Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook” on page Turn the notebook over so the bottom is facing up. Slide the battery release latch and lift the battery out of the bay. www.gateway.com...

  • Page 13: Adding Or Replacing Memory Modules

    Replacing Gateway M305 Components Adding or replacing memory modules Tools you need to complete this task: Phillips #0 screwdriver Important Use only memory modules designed for the Gateway M305. Memory www.gateway.com...
  • Page 14 Lift the screw side of the cover upward, then slide the cover out. If you are removing a module, gently press outward on the clip at each end of the memory module until the module tilts upward. www.gateway.com...
  • Page 15 Replacing Gateway M305 Components Pull the memory module out of the slot. www.gateway.com...
  • Page 16 Important Use only memory modules designed for the Gateway M305. Gently push the module down until it clicks in place. Replace the memory bay cover and tighten the cover screw.

  • Page 17: Replacing The 802.11 Mini Pci Card

    Replacing the 802.11 mini PCI card Caution By law, only approved wireless modules provided by Gateway, or a Gateway authorized representative, explicitly for your Gateway M305 may be installed in this notebook. Tools you need to complete this task: Torx T8 screwdriver To replace the 802.11 mini PCI card:...
  • Page 18 Replacing the 802.11 mini PCI card Loosen the captive screw that secures the mini PCI cover. (The screw cannot be removed.) Mini PCI Lift the screw side of the cover upward, then slide the cover out. www.gateway.com...
  • Page 19 Replacing Gateway M305 Components Unplug the two antenna cables, noting how they are installed for later re-assembly. Move the antenna wires out of the way, then press outward on the clips at both sides of the card until the card tilts upward.
  • Page 20 This card is keyed so it can only be inserted in one direction. If the card does not fit, make sure that the notch in the card lines up with the tab in the card slot. Move the antenna wires out of the way, then press the card down until it clicks into place. www.gateway.com...
  • Page 21 Replacing Gateway M305 Components Reattach the black antenna cable to the connector labelled MAIN or M, then reattach the light gray antenna cable to the connector labelled AUX or A. Replace the mini PCI cover, then tighten the captive screw.
  • Page 22 End users are strictly prohibited from having access to the wireless card. Due to manufacturing process changes, Gateway M305 notebooks require a Torx head security screw to attach the mini-PCI cover.

  • Page 23: Replacing The Hard Drive Kit

    Replacing Gateway M305 Components Replacing the hard drive kit Tools you need to complete this task: Phillips #0 screwdriver Screws removed during this task: 2 chrome 2.5 × 4.7 mm (hard drive kit) To replace the hard drive kit: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook”...
  • Page 24 Replacing the hard drive kit Remove the hard drive kit screws. Screws www.gateway.com...
  • Page 25 Replacing Gateway M305 Components Slide the old hard drive kit out of the notebook. Slide the new hard drive kit into the notebook. Replace the screws that secure the hard drive kit to the notebook. www.gateway.com...

  • Page 26: Replacing The Hard Drive In The Hard Drive Kit

    Replacing the hard drive in the hard drive kit Tools you need to complete this task: Phillips #0 screwdriver Screws removed during this task: 2 chrome 3.0 × 3.5 mm 2 chrome 2.5 × 4.7 mm (hard drive kit) (hard drive kit bracket) www.gateway.com...
  • Page 27 Replacing Gateway M305 Components To replace the hard drive in the hard drive kit: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook” on page Turn the notebook over so the bottom is facing up.
  • Page 28 Insert the new drive into the bracket so the screw holes line up. Replace the two screws that secure the bracket to the drive. Slide the hard drive kit into the notebook. Replace the screws that secure the hard drive kit to the notebook. www.gateway.com...

  • Page 29: Replacing The Keyboard Cover

    Replacing Gateway M305 Components Replacing the keyboard cover Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool To replace the keyboard cover: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook”...
  • Page 30 Pull the cover off the notebook. You will hear small snapping sounds as the cover comes away from the notebook. Be careful not to break off the tabs found on the left end of the cover. www.gateway.com...
  • Page 31 Replacing Gateway M305 Components Slide the two tabs on the left end of the new cover under the notebook frame. Press down on the cover in several places until it clicks in place. The cover is correctly mounted when you can run you finger along the cover and find no loose spots.

  • Page 32: Replacing The Keyboard

    Turn the notebook over so the bottom is facing up. Remove the battery by following the instructions in “Removing the battery” on page Turn the notebook over so the top is facing up. Remove the keyboard cover by following the instructions in “Replacing the keyboard cover” on page www.gateway.com...
  • Page 33 Replacing Gateway M305 Components Remove the four keyboard screws that secure the keyboard to the notebook. Screws www.gateway.com...
  • Page 34 Replacing the keyboard Lift the back edge of the keyboard, then slowly rotate it toward you so it lies keys-down on top of the notebook. Be careful not to damage the LCD panel. www.gateway.com...
  • Page 35 Replacing Gateway M305 Components Use your fingers to unplug the keyboard panel connector from the notebook. Be careful not to touch or damage any other components. Place the new keyboard keys-down on the notebook with the space bar away from you.
  • Page 36 Insert the keyboard plug, on the end of the keyboard cable, onto the keyboard connector. Important The outside of the keyboard plug goes around the keyboard connector. The plug is correctly oriented if the cable is not twisted. Rotate the keyboard toward the LCD panel until the keyboard is almost face-up. www.gateway.com...
  • Page 37 Replacing Gateway M305 Components Insert the tabs on the front of the keyboard under the palm rest. Tabs Gently press the keyboard down until it is flat all the way across. The keyboard should easily fall into place. Be careful not to damage the LCD panel.
  • Page 38 Replacing the keyboard Replace the four keyboard screws. Screws Reassemble the notebook. www.gateway.com...

  • Page 39: Replacing The Optical Drive Kit

    Replacing Gateway M305 Components Replacing the optical drive kit Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver Screws removed during this task: 1 black 2.5 × 4.0 mm 1 chrome 2.0 × 3.0 mm 4 chrome 2.5 ×...

  • Page 40: Replacing The Optical Drive Kit

    Remove the keyboard by following the instructions in “Replacing the keyboard” on page Remove the chrome screw that secures the drive kit to the cooling assembly and the black screw that secures the drive kit to the system board. Screws www.gateway.com...
  • Page 41 Replacing Gateway M305 Components Slide the drive kit out of the notebook. If your replacement optical drive came in a kit, go to Step -OR- If you need to replace the optical drive in the optical drive kit, go to Step www.gateway.com...
  • Page 42 Place the bracket onto the new drive so the screw holes line up and replace the two chrome screws that secure the bracket to the drive. Insert the new drive kit into the notebook, then replace the two screws. Reassemble the notebook. www.gateway.com...

  • Page 43: Replacing The Led Indicator Panel

    Replacing Gateway M305 Components Replacing the LED indicator panel Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver Screws removed during this task: 2 black 2.5 × 4.0 mm 1 chrome 2.0 × 3.0 mm 4 chrome 2.5 ×...
  • Page 44 Insert the small flat-blade screwdriver or non-marring tool under the indicator panel and gently pry it up. Align the new indicator panel’s screw holes with the holes on the notebook, press the panel into place, then replace the screws. Reassemble the notebook. www.gateway.com...

  • Page 45: Replacing The Cmos Battery

    Replacing Gateway M305 Components Replacing the CMOS battery Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver Screws removed during this task: 4 chrome 2.5 × 3.0 mm (keyboard) To replace the CMOS battery:...

  • Page 46: Replacing The Cmos Battery

    Make sure that the positive (+) side of the new battery is facing up, then press the battery into the socket until it snaps into place. Reassemble the notebook. www.gateway.com...

  • Page 47: Replacing The Hinge Covers

    Replacing Gateway M305 Components Replacing the hinge covers Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool To replace the hinge covers: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook”...
  • Page 48 Replacing the hinge covers Insert the small flat-blade screwdriver or non-marring tool under the left hinge cover and gently pry it up. www.gateway.com...
  • Page 49 Replacing Gateway M305 Components Insert the small flat-blade screwdriver or non-marring tool under the right hinge cover and gently pry it up. Snap the new covers into place over the hinges. Reassemble the notebook. www.gateway.com...

  • Page 50: Replacing The Cooling Assembly

    Turn the notebook over so the top is facing up. Remove the keyboard cover by following the instructions in “Replacing the keyboard cover” on page Remove the keyboard by following the instructions in “Replacing the keyboard” on page www.gateway.com...
  • Page 51 Replacing Gateway M305 Components Unplug the cooling fan. www.gateway.com...
  • Page 52 Replacing the cooling assembly Remove the five screws that secure the cooling assembly to the notebook. Screws Screws www.gateway.com...
  • Page 53 Replacing Gateway M305 Components At the same time as you lift, move the cooling assembly to the front of the notebook and remove it. Insert the new cooling assembly into the notebook. The screw tabs should go above the optical drive tab and below the LED indicator panel shielding tab.

  • Page 54: Replacing The Lcd Panel Assembly

    Scribe or non-marring tool Phillips #0 screwdriver Screws removed during this task: 1 chrome 2.5 × 3.0 mm 4 chrome 2.5 × 5.5 mm 4 chrome 2.5 × 3.0 mm (grounding screw) (hinges) (keyboard) 5 chrome 2.0 × 3.0 mm (cooling assembly) www.gateway.com...
  • Page 55 Replacing Gateway M305 Components To replace the LCD panel assembly: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook” on page Turn the notebook over so the bottom is facing up.
  • Page 56 Use your fingers to unplug the LCD panel connector from the notebook. Grasp the large cluster of cables, then pull the connector straight up. Loosen the screw holding the grounding wire, then lift the LCD panel grounding wire to remove the screw. LCD panel grounding screw www.gateway.com...
  • Page 57 Taking care to note the cable routing and positions as they are installed from Gateway, remove the 802.11 antenna wires from under the two retaining clips and pull the antenna out from under the system board.
  • Page 58 Replacing the LCD panel assembly Thread the antenna cables through the retaining clips and then under the system board and into the mini PCI card area. Plug the LCD panel connector into the notebook. Reassemble the notebook. www.gateway.com...

  • Page 59: Replacing The Palm Rest Assembly

    Replacing Gateway M305 Components Replacing the palm rest assembly Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver Screws removed during this task: 2 chrome 2.5 × 4.7 mm 4 chrome 2.5 × 3.0 mm 1 chrome 2.0 ×...
  • Page 60 49. Grasp the large cluster of cables, then pull the connector straight Remove the screw holding the LCD grounding wire by following the instructions in “Replacing the LCD panel assembly” on page Turn the notebook over so the bottom is facing up. www.gateway.com...
  • Page 61 Replacing Gateway M305 Components Remove the twelve chrome screws on the bottom of the notebook. Screws Screws Screws Screws Turn the notebook over so the top is facing up. www.gateway.com...
  • Page 62 Replacing the palm rest assembly Remove the three black screws on the top of the notebook. Screws www.gateway.com...
  • Page 63 Replacing Gateway M305 Components Pull up on the touchpad connector cable to remove it from the connector. Remove the palm rest assembly. Place the new palm rest assembly onto the notebook, and snap the assembly into place. Replace all of the palm rest screws.

  • Page 64: Replacing The Diskette Drive Kit

    Replacing the diskette drive kit Replacing the diskette drive kit Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver www.gateway.com...
  • Page 65 Replacing Gateway M305 Components Screws removed during this task: 2 chrome 2.5 × 4.7 mm 4 chrome 2.5 × 3.0 mm 1 chrome 2.0 × 3.0 mm (hard drive kit) (keyboard) (LED indicator panel) 4 chrome 2.0 × 3.0 mm 2 black 2.5 ×...
  • Page 66 Remove the hinge covers by following the instructions in “Replacing the hinge covers” on page Remove the cooling assembly by following the instructions in “Replacing the cooling assembly” on page Remove the palm rest assembly by following the instructions in “Replacing the palm rest assembly” on page www.gateway.com...
  • Page 67 Replacing Gateway M305 Components Remove the three black screws that secure the diskette drive kit to the notebook. Screws Lift the drive kit and disconnect the diskette drive’s ribbon cable. www.gateway.com...
  • Page 68 Insert the new diskette drive kit into the notebook and plug in the diskette drive’s ribbon cable. Replace the three black screws that secure the diskette drive kit to the notebook. Reassemble the notebook. www.gateway.com...

  • Page 69: Replacing The Memory Card Reader Kit

    Replacing Gateway M305 Components Replacing the memory card reader Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool Phillips #0 screwdriver www.gateway.com...
  • Page 70 3 black 2.5 × 4.0 mm 12 chrome 2.5 × 5.0 mm (palm rest top) (palm rest bottom) 5 chrome 2.5 × 3.0 mm 3 black 2.5 × 4.0 mm (memory card reader kit (memory card reader kit) bracket) www.gateway.com...
  • Page 71 Replacing Gateway M305 Components To replace the memory card reader kit: Disconnect the AC adapter and modem and network cables and prepare the notebook by following the instructions in “Preparing the notebook” on page Turn the notebook over so the bottom is facing up.
  • Page 72 Replacing the memory card reader kit Remove the three black screws that secure the memory card reader kit to the notebook. Screws www.gateway.com...
  • Page 73 Replacing Gateway M305 Components Lift the card reader kit and disconnect the card reader’s cable. Remove the card reader kit from the notebook. If your replacement card reader came in a kit, go to Step -OR- If you need to replace the card reader in the card reader kit, go to Step www.gateway.com...
  • Page 74 Remove the two chrome screws from the top of the memory card reader that secure the card reader to the card reader kit bracket. Screws Remove the three chrome screws from the bottom of the memory card reader that secure the card reader to the card reader kit bracket. Screws www.gateway.com...
  • Page 75 Replacing Gateway M305 Components Remove the bracket from the old card reader. Insert the new card reader into the bracket so the screw holes line up and replace the five chrome screws that secure the bracket to the card reader.

  • Page 76: Replacing The System Board

    Replacing the system board Replacing the system board Tools you need to complete this task: Flat-blade driver - OR - Scribe or non-marring tool 5.0 mm hex nutdriver Phillips #0 screwdriver Torx T8 screwdriver www.gateway.com...
  • Page 77 Replacing Gateway M305 Components Screws removed during this task: 1 chrome 2.0 × 3.0 mm and 2 chrome 2.5 × 4.7 mm 4 chrome 2.5 × 3.0 mm 1 black 2.5 × 4.0 mm (hard drive kit) (keyboard) (optical drive) 2 black 2.5 ×...
  • Page 78 Remove the diskette drive kit by following the instructions in “Replacing the diskette drive kit” on page -OR- Remove the memory card reader kit by following the instructions in “Replacing the memory card reader kit” on page www.gateway.com...
  • Page 79 Replacing Gateway M305 Components Unplug the speakers. Turn the notebook over so the bottom is facing up, then remove the two chrome screws from the bottom. Screws www.gateway.com...
  • Page 80 I/O panel. Hex nuts Remove the four black system board screws from the holes marked 2, 7, 19, and 21, and the two hex nuts from the holes marked 5 and 6. Hex nuts Screw Screws www.gateway.com...
  • Page 81 Replacing Gateway M305 Components While pushing in on the PC Card eject button, remove the system board. Make sure the rear I/O panel and PC Card eject button clear the chassis bottom. www.gateway.com...
  • Page 82 Use a flat-blade screwdriver to turn the processor lock screw 1/4-turn counter-clockwise, then remove the processor from the old system board. Turn the old system board over so the bottom is facing up, then remove the screws that secure the modem to the system board. Screws www.gateway.com...
  • Page 83 Replacing Gateway M305 Components Use a flat-blade screwdriver to unplug the modem from the old system board. Unplug the modem cable from the modem. www.gateway.com...
  • Page 84 (indicated by the silk-screened arrow on the corner of the processor) aligns with Pin 1 on the processor socket (indicated by the absence of a pin hole in the processor socket), then use a flat-blade screwdriver to turn the processor lock screw 1/4-turn clockwise. www.gateway.com...
  • Page 85 Replacing Gateway M305 Components Place the new system board into the notebook. Replace the four black system board screws into the holes marked 2, 7, 19, and 21, and the hex nuts into the holes marked 5 and 6. Replace the four hex nuts on the rear I/O panel.

  • Page 86: Replacing The Modem

    Replacing the modem Replacing the modem To replace the modem in the notebook, complete the instructions for “Replacing the system board” on page Tips & Tricks You do not need to remove the processor. www.gateway.com...
  • Page 87 Replacing Gateway M305 Components www.gateway.com...
