Clevo 2200C Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Clevo 2200C

Summary of Contents for Clevo 2200C

  • Page 2 Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 3: Table Of Contents

    Contents Chapter 1: Introduction ......1 - 1 System specifications (general) ....1 - 2 Chapter 2: Chipset and Mainboard information ......2 - 1 CPU ............... 2 - 1 Chipsets ............2 - 3 SiS630S ............2 - 3 PC Card Chipset - PCI1410 ......
  • Page 4 Remove the LCD panel from the bracket ... 3 - 20 Appendix A: Mechanical Drawings and Parts Lists ..........A - 1 2200C ............A - 1 Bottom Half assembly and parts list ..... A - 1 LCD panel (12.1”) assembly and parts list ... A - 2 LCD panel (13.1”...
  • Page 5 LCD panel (14.1”) assembly and parts list ... A - 4 Keyboard and Touchpad assembly ..... A - 5 Keyboard and Touchpad assembly parts list ..A - 6 FDD assembly and parts list ....... A - 7 HDD assembly and parts list ....... A - 8 CD-ROM assembly and parts list......

  • Page 6: Chapter 1: Introduction

    Introduction Chapter 1: Introduction This manual covers information you will need to service or upgrade your Notebook Computer. Information about operating the computer (e.g. getting started, etc...) is in the User’s Manual. Driver Information is also found in the User’s Manual. The User’s Manual is shipped with the computer. Operating Systems (Windows ME, Windows 2000, etc.) have their own manuals as do application software.

  • Page 7: System Specifications (General)

    Service Manual System specifications (general) The main unit of the Model 2200C/2700C Notebook PC has the following components: – Intel FC-PGA370 Pentium III with AGP technology-based mainboard, using the SiS630S chipset solution supporting SDRAM with 0MB on-board DRAM, expandable to 32MB, 64MB, 96MB, 128MB, 192MB, 256MB, or 512MB using one or two expansion SODIMMs –...
  • Page 8 Introduction CPU ( FC-PGA370 ) Keyboard Intel Celeron-450 (1.6V) Keys Intel Celeron-500 (1.6V) Fn key support Intel Celeron-550 (1.6V) Integrated numeric keypad Intel Pentium III-600 (1.65V) Inverted “T” layout cursor keys Intel Pentium III-650 (1.65V) Intel Pentium III-700 (1.65V) Intel Pentium III-750 (1.65V) Easy change module 6GB or up...
  • Page 9 Service Manual Transport drawer type load/eject Speaker-out Jack Interface PCI local bus master IDE Microphone-in Jack BIOS Power Supply InSyde 256KB AC adapter AC-in 100-240V/47-63Hz Capacity Display Battery pack NiMH/Li-Ion LCD/CRT (simultaneous) VGA/EGA/CGA/Hercules compatible Power Saving Management AGP 3D graphics accelerator Adjustable brightness YES (standard) Doze mode...
  • Page 10 Introduction External 101/102 keyboard port/ PS/2 mouse x 1 PC Card Standard Type I or Type II Modem (RJ-11) port for MDC x 1 (optional) USB connector speaker-out jack microphone-in jack LAN (RJ45) port Physical Dimension 308 mm(W) 254 mm(D) 37.5 mm(H) Weight 3.2KG (with Lithium-lon battery)
  • Page 11 Notes...

  • Page 12: Chapter 2: Chipset And Mainboard Information

    Chipset and Mainboard information Chapter 2: Chipset and Mainboard information The 2200C/2700C Notebook PC uses the Intel Mobile Pentium III/Celeron (.18) processor in an FC- PGA370 package. The Intel Mobile Pentium III/Celeron (.18) processor features an integrated L2 cache (256KB for Pentium III and 128KB for Celeron (.18)) and a 64-bit high performance system bus.
  • Page 13 Service Manual - 128/256-Kbyte, ECC protected cache data array – Low Power GTL+ system bus interface - 64-bit data bus, 100-MHz operation - Uniprocessor, two loads only (processor and I/O bridge/memory controller) - Short trace length and low capacitance allows for single ended termination –...

  • Page 14: Chipsets

    Chipset and Mainboard information Chipsets SiS630S The single chipset, SiS630S, provides a high performance/low cost Desktop solution for the Intel Slot 1 and socket 370 series CPU based systems by integrating a high performance North Bridge, ad- vanced hardware 2D/3D GUI engine, Super-South bridge or an external AGP4X Slot. In addition, SiS630S provides a system-on-chip solution that complies with the Easy PC Initiative which sup- ports Instantly Available/OnNow PC technology, USB, Legacy Removal and Slotless Design and FlexATX form factor.
  • Page 15 Service Manual width. The built-in fast PCI IDE controller supports the ATA PIO/DMA, and the Ultra DMA33/66/100 function that supports the data transfer rate up to 100 MB/s. It provides the separate data path for two IDE channels that can eminently improve the performance under the multi-tasking environ- ment.
  • Page 16 Chipset and Mainboard information Integrated A.G.P. Compliant Target/66Mhz Host-to-PCI Bridge – AGP v2.0 Compliant – Supports Graphic Window Size from 4MBytes to 256MBytes – Supports Pipelined Process in CPU-to-Integrated 3D A.G.P. VGA Access – Supports 8 Way, 16 Entries Page Table Cache for GART to Enhance Integrated A.G.P. VGA Controller Read/Write Performance –...
  • Page 17 Service Manual – Native Mode and Compatibility Mode – PIO Mode 0, 1, 2 , 3, 4 – Multiword DMA Mode 0, 1, 2 – Ultra DMA 33/66/100 – Two Independent IDE Channels Each with 16 DW FIFO Virtual PCI-to-PCI Bridge Integrated Ultra AGP VGA for Hardware 2D/3D Video/Graphics Accelerators –...
  • Page 18 Chipset and Mainboard information – Supports YUV-To-RGB Color Space Conversion – Supports Graphic and Video Overlay Function – Supports CD/DVD to TV Playback Mode – Simultaneous Graphic and TV Video Playback Overlay – Supports RGB555, RGB565, YUV422 and YUV420 Video Playback Format –...
  • Page 19 Service Manual – Low Resolution Modes – Supports Virtual Screen up to 4096x4096 – Fully Directx 7.0 Compliant – Efficient and Flexible Power Management with ACPI Compliance Low Pin Count Interface – Forwards PCI I/O and Memory Cycles into LPC Bus –...
  • Page 20 Chipset and Mainboard information – Two 8237A Compatible DMA Controllers – 8/16- bit DMA Data Transfer – Distributed DMA Support Integrated Interrupt Controller – Two 8237A Compatible DMA Controllers – Two 8259A Compatible Interrupt Controllers – Level- or Edge-Triggered Programmable –...
  • Page 21 Service Manual – OpenHCI Host Controller with Root Hub – Two USB Host Controllers – Six USB Ports – Supports Legacy Devices – Over Current Detection C Bus/SMBUS Series Interface Integrated Fast Ethernet Controller and MAC Interface – Plug and Play Compatible –...

  • Page 22: Pc Card Chipset - Pci1410

    Chipset and Mainboard information PC Card Chipset - PCI1410 – The PCI1410 supports the following features: – Ability to wake from D3 hot and D3 cold – Fully compatible with the Intel 430TX (Mobile Triton II) chipset – A 144-Pin Low-Profile QFP (PGE), 144-ball MicroStar Ball Grid Array (GGU) package, or 209-ball MicroStar Ball Grid Array (GHK) package –...
  • Page 23 Service Manual – 16-Bit DMA on the PC Card socket – Ring indicate, SUSPEND, PCI CLKRUN, and CardBus CCLKRUN – Socket activity LED pins – PCI Bus Lock (LOCK) – Advanced Submicron, Low-Power CMOS Technology – Internal Ring Oscillator 2 - 12...

  • Page 24: Ports

    Chipset and Mainboard information Ports 1. Mic-in, headphone 6. External monitor 2. USB 7. Parallel 3. IEEE 1394 8. PS/2 4. TV out 9. AC adapter 5. Dual USB 2 - 13...

  • Page 25: Mainboard

    Service Manual Mainboard Mainboard components list Microphone connector K/B Controller M33867 MDC to RJ-11 connector HDD connector Panel connector K/B connector Invertor power connector CMOS battery Heat sink fan connector Choke (for power) Second Fan connector MDC connector CPU and Memory frequency switch ICS1893 Lan PHY CPU V_Core switch 1394 PHY...

  • Page 26: Mainboard Photo

    Chipset and Mainboard information Mainboard photo 21 22 2 - 15...
  • Page 27 Notes...

  • Page 28: Chapter 3: Disassembly

    Disassembly Chapter 3: Disassembly To make the disassembly process easier each section may have a box in the page margin. Informa- This box lists the tools tion contained in the boxes inform you what tools will be needed for a given procedure and the needed and the amount of screws used.

  • Page 29: Disassembly Steps

    Service Manual Disassembly steps From the list below choose the component that you want to disassemble, then follow the steps Note listed and go to the appropriate page for detailed instruction. Remember to wear an anti-static wrist strap and remove all power Steps to remove the CD-ROM/DVD-ROM : sources when working on the computer...

  • Page 30: Steps To Remove The Hdd:

    Disassembly Steps to remove the HDD: Remove the keyboard p 3-6 Remove the HDD assembly p 3-7 Steps to remove the inverter board: Remove the battery p 3-5 Remove the LCD panel frame p 3-17 Remove the LCD panel from the LCD panel case p 3-18 (up to step 4) Steps to remove the LCD panel: Remove the LCD panel frame...

  • Page 31: Steps To Remove The Mainboard:

    Service Manual Steps to remove the mainboard: Remove the battery p 3-5 Remove the keyboard p 3-6 Remove the HDD assembly p 3-7 Remove the CD-ROM/DVD-ROM assembly p 3-8 Remove the Heatsink p 3-9 Remove the CPU p 3-10 Seperate thenotebook base in two p 3-11 Remove the FDD assembly p 3-14...

  • Page 32: Removal Procedures

    Disassembly Removal Procedures Remove the battery 1 Philips screwdriver 1. Remove the 2 screws on the battery cover (figure 3-1). 1 screw 2. Disconnect the battery connector from the computer. 3. Slide the battery out of the computer (figure 3-2). 1) Battery Cover 2) Battery Connector plug...
  • Page 33 Service Manual Remove the keyboard 1. Press the 4 keyboard latches at the top of the keyboard (figure 3-3). 2. Lift the top of the keyboard up and out of the computer (figure 3-4). 3. Remove the keyboard ribbon cable. figure 3-3 figure 3-4 3 - 6...
  • Page 34 Disassembly Remove the HDD assembly 1. Remove 3 screws (D) holding the HDD assembly in place (figure 3-5). 2. Lift the HDD assembly out of the case using the HDD tab (figure 3-6). 1 Philips screwdriver 3 screws 1) HDD assembly 2) HDD tab 3) HDD connector 4) HDD socket...
  • Page 35 Service Manual Remove the CD-ROM\DVD-ROM assembly 1. Remove screw (I) in figure (3-7). 2. Use a small screwdriver to gently push the CD-ROM assembly out of the case figure (3-7). 1 Philips screwdriver 1 screw Note For information on removing the CD-ROM/ DVD-ROM from the CD-ROM/DVD-ROM assembly go to Appendix...

  • Page 36: Remove The Heat Sink

    Disassembly Remove the heat sink 1. Unscrew the 4 screws (P) securing the heat sink to the mainboard (figure 3-8). 2. Lift up the heat sink part way until you see the heat sink cable. Disconnect the cable from the 1 Philips screwdriver mainboard (figure 3-9).

  • Page 37: Remove The Cpu

    Service Manual Remove the CPU 1. Place the CPU tool over the CPU (figure 3-10). 1 Regular screwdriver 2. Place a screw driver in the open slot of 1 CPU tool the CPU socket and move it to the left (figure 3-11).

  • Page 38: Separate The Notebook Base In Two

    Disassembly Separate the notebook base in two With the CPU and heatsink, keyboard, HDD and CD-ROM/DVD-ROM drive removed: 1 Philips screwdriver 1 Hex socket wrench 1. Remove screw (I), the LCD panel ground wire and Inverter power ground wire. When rein- Top: 1 Screw stalling make sure to place the LCD panel 1 Hex nut...
  • Page 39 Service Manual 2. Remove screw (I) (figure 3-15). figure 3-15 3. Close the LCD panel and go to the right side of the computer and remove screw (I) (figure 3-16). figure 3-16 3 - 12...
  • Page 40 Disassembly 4. On the back of the computer just above the ports, remove screws (D) (figure 3-17). figure 3-17 5. Remove all screws (H, K) as shown in (figure 3-18). 6. Run a small screwdriver around the rim where the two halves meet and slowly pry the pieces apart.

  • Page 41: Remove The Fdd Assembly

    Service Manual Remove the FDD assembly Remove the CD-ROM tray 1. Remove screw (I). 1. Remove screws (I). 1 Philips screwdriver 2. Remove the Hex nut (Q). 2. Remove screw (F) 1 Hex socket wrench 3. Lift the FDD assembly off of the 3.

  • Page 42: Remove The Mainboard And Tray From The Bottom Case

    Disassembly Remove the mainboard and tray from the bottom case 1. Remove screws (F, H) and Hex nut (Q). 2. Lift the mainboard up from the battery side and pull it out of the case. 1 Philips screwdriver 1 Hex socket wrench 2 Screws 1 Hex nut figure 3-20...

  • Page 43: Remove The Mainboard From The Mainboard Tray

    Service Manual Remove the mainboard from the mainboard tray 1. Remove the hex nuts (R) on the parallel port (figure 3-21). 2. Remove the hex nuts (R) on the monitor out port (figure 3-21). 1 Hex socket wrench 3. Lift the mainboard out of the tray. 1 Hex nut figure 3-21 1) parallel port...

  • Page 44: The Lcd Panel

    Disassembly The LCD Panel Remove the LCD panel frame 1. Remove the rubber stoppers in positions D and J (figure 1 Philips screwdriver 3-24). 5 Screws 2. Remove the screws (D, J) (figure 3-24). 3. Run your finger around the middle of the frame and separate the frame from the back (figure 3-25).
  • Page 45 Service Manual Remove the LCD panel and bracket from the LCD panel case 1. Remove the bracket (D) screws on the side of the LCD panel (figure 3-26). 2. Remove the 4 screws at the bottom of the LCD screen 1 Philips screwdriver 3.
  • Page 46 Disassembly 1) Inverter wire cable 2) LCD to inverter wire cable 3) LCD wire cable figure 3-27 4) LCD wire cable connector 4. Lift the LCD inverter and disconnect the 5) LCD bracket inverter wire cable and the LCD to in- verter wire cable (figure 3-27).

  • Page 47: Remove The Lcd Panel From The Bracket

    Service Manual Remove the LCD panel from the bracket 1. Gently lift out the panel. 2. Remove the screws (C) holding the LCD in the bracket (figure 3-29). 1 Philips screwdriver (small) figure 3-29 3 - 20...

  • Page 48: Appendix A: Mechanical Drawings And Parts Lists

    Mechanical Drawings and Parts Lists Appendix A: Mechanical Drawings and Parts Lists 2200C Bottom Half assembly and parts list A - 1...

  • Page 49: Lcd Panel (12.1") Assembly And Parts List

    Service manual LCD panel (12.1”) assembly and parts list A - 2...

  • Page 50: Lcd Panel (13.1" , 15.3") Assembly And Parts List

    Mechanical Drawings and Parts Lists LCD panel (13.1” , 15.3”) assembly and parts list A - 3...

  • Page 51: Lcd Panel (14.1") Assembly And Parts List

    Service manual LCD panel (14.1”) assembly and parts list A - 4...

  • Page 52: Keyboard And Touchpad Assembly

    Mechanical Drawings and Parts Lists Keyboard and Touchpad assembly A - 5...

  • Page 53: Keyboard And Touchpad Assembly Parts List

    Service manual Keyboard and Touchpad assembly parts list A - 6...

  • Page 54: Fdd Assembly And Parts List

    Mechanical Drawings and Parts Lists FDD assembly and parts list A - 7...

  • Page 55: Hdd Assembly And Parts List

    Service manual HDD assembly and parts list A - 8...

  • Page 56: Cd-Rom Assembly And Parts List

    Mechanical Drawings and Parts Lists CD-ROM assembly and parts list A - 9...

  • Page 57: Dvd-Rom Assembly And Parts List

    Service manual DVD-ROM assembly and parts list A - 10...

  • Page 58: 2700C

    Mechanical Drawings and Parts Lists 2700C Bottom half assembly and parts list A - 11...

  • Page 59: Lcd Panel (13.3") Assembly And Parts List

    Service manual LCD panel (13.3”) assembly and parts list A - 12...

  • Page 60: Lcd Panel (14.1") Assembly And Parts List

    Mechanical Drawings and Parts Lists LCD panel (14.1”) assembly and parts list A - 13...

  • Page 61: Keyboard And Touchpad Assembly

    Service manual Keyboard and Touchpad assembly A - 14...

  • Page 62: Keyboard And Touchpad Parts List

    Mechanical Drawings and Parts Lists Keyboard and Touchpad parts list A - 15...

  • Page 63: Fdd Assembly And Parts List

    Service manual FDD Assembly and parts list A - 16...

  • Page 64: Hdd Assembly And Parts List

    Mechanical Drawings and Parts Lists HDD assembly and parts list A - 17...

  • Page 65: Cd-Rom Assembly And Parts List

    Service manual CD-ROM Assembly and parts list A - 18...

  • Page 66: Dvd-Rom Assembly And Parts List

    Mechanical Drawings and Parts Lists DVD-ROM assembly and parts list A - 19...
  • Page 67 Notes...
  • Page 68 Schematic Diagrams Appendix B: Schematic Diagrams VCCT HA#[3..31] HD# [0..63] HD# [0..63] HA# [3..31] HD#[0 ..63] HD# [0 ..63] HA# 3 HD#0 HD# 1 D# 0 AH12 HA# 4 HD#1 HD# 5 D# 1 HA# 5 HD#2 HA#[3 ..31] VCCT HD# 8 C33 7 D# 2...

  • Page 69: Service Manual

    P LL1 Z806 VCC_CORE VREF6 PLL1 AK22 P LL2 4.7UH(0805) VREF7 PLL2 CELEONP3 22U(1206) ÂÅ ¤Ñ ¹q ¸£ CLEVO CO. RTT CTRL R292 Ti t l e Z807 R282 SLEWCTRL R283 Size Document Numbe r Z808 Cu stom R293 71-22C00-D02...

  • Page 70: Appendix B: Schematic Diagrams

    Schematic Diagrams L 56 VDDREF Z3 08 R4 79 22(R) VCC3 VDDREF CPUCLKF CPUCLK0 R3 41 HCLKCPU CPUCLK1 HCLKCPU (1) BEAD CPUCLK1 R3 42 HCL K630 S CPUCLK0 C390 10 P(R) CPUCLK2 HCLK630S (4) C4 44 C399 C4 38 CPUCLK1 C398 10 P(R) C3 84...
  • Page 71 Service Manual MDD[0..63 ] MDD[0..63] HA# [3..31] HA# 31 HA#[31] HA# 30 HA#[30] HA# 29 HA#[29] HA# 28 HA#[28] HA# 27 AE24 Z577 TP82 HA#[27] CSA#[5] HA# 26 AG24 Z578 DRAM INTERFACE TP102 ICSA#[0..3 ] (6 ) HA#[26] CSA#[4] HA# 25 AF24 ICSA#3 HA#[25]...
  • Page 72 C400 C198 C408 C406 C404 C407 C405 C403 C401 C402 C197 C194 C19 3 ÂÅ ¤Ñ ¹q ¸£ CLEVO CO. 0.01U 0.01U 0.01U 0.01U 0.01U 0.01U 0.01U 0.01U T i t le SODIM M Si z e Document Number Custom 0200-05.SCH...
  • Page 73 Service Manual MD[0..63] (3 ,5,9) MD[0..63] MDD[0..63] MDD[0..63] VDD3 VCC3 MDD0 RN37 MDD1 R219 R221 8P4R_10 MDD2 IMA[0..14] MA [0..14] MDD3 IMA[0..14] MA[0..14] VDD3 MDD4 0(R) IMA14 MA14 RN38 MDD5 RN17 IMA13 MA13 8P4R_10 MDD6 8P4R_10 IMA11 MA11 MDD7 Z657 RN59 IMA12 MA12...
  • Page 74 0 .01U 0 .01U 0.01U 0.01U CP1 0 8P4C_C 8P4C_C 8P4C_C 8P4C_C ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T i t l e 630(VGA) & LVDS Si z e Document Number Cus tom 0200-07.SCH 71-22C00-D02 Date: Monday, March 05, 2001...
  • Page 75 C511 C512 The two external load capaci tors value is eaqual to 2 x crystal internal cap - 12.5pF ÂÅ ¤Ñ ¹q ¸£ CLEVO CO. Titl e Chrontel CH7005 TV-OUT Size Docu me nt Number Re v Custom 02 00-08.SCH...
  • Page 76 Ma ke sure VIDEOGND is as clean as po ssi b le Al s o , the RED,GREEN,and BLUE sign al traces ÂÅ ¤Ñ ¹q ¸£ CLEVO CO. sho uld b e shie ld ed with VIDEOGND traces. Titl e LCD &...
  • Page 77 Service Manual L PC PUL L-H IGH LAD[0..3] (20) PL ACE NEAR TO W8 362 6F SPKR (24) S PKR P WR_ ON# L AD0 VCC3 (23,24,29) PWR_ON# PSON# LAD0 L AD1 SUSPEND# R250 Z560 (16) SUSPEND# ACPILED LAD1 EX TSMI# L AD2 EXTSMI# EXTSMI#...
  • Page 78 Schematic Diagrams VCC1.8 Z506 R1 09 C112 C1 11 1000 P A D[0..31] (16,25) REQ2# AD31 REQ2# P REQ#[2] AD31 REQ1# AD30 REQ1# P REQ#[1] AD30 REQ0# AD29 (16) REQ0# P REQ#[0] AD29 AD28 AD28 AD27 AD27 AD26 AD26 AE 17 GNT 2# AD25 PDD0...
  • Page 79 Service Manual VCC1.8 VCCT V CC3 GTLVTT R285 R (1 206) R274 0(1 206) VCC 3 V CC3 Default : 1-2 GTLVTT AA11 OV DD V SS AA12 C310 OV DD V SS C339 C342 AA13 OV DD V SS AA18 OV DD V SS...
  • Page 80 CD_VCC CD_VCC SCSEL TP20 Z306 Z305 TP21 R450 CD-ROM conn. 50P ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. PINGND1..2 =GND Ti t le Size Document Numbe r Cus tom 0200-12.SCH 71-22C00-D02 Date : Monda y, March 05 , 2001 Shee t...
  • Page 81 Service Manual VDD3 REF_IN PVCC3 PVCC3 BEAD(1206) REF_OU T C103 C102 VDD3 PVCC3 (10) (10) VDD3 T XD3 (10) T XD3 T XD2 (10) T XD2 VDD3 T XD1 (10) T XD1 PVCC3 T XD0 (10) T XD0 8P4R_22 TXEN NOD/REP C106 C105...
  • Page 82 Schematic Diagrams BEAD(1206 ) BEAD(1206 ) Z521 Z522 US BVCC0 US BVCC1 R262 470K POLYFUSE POLYFUSE USBVCC0 SMDC110 SMDC110 0.01U 0.01U R261 560K OC0# OC0# C267 0.01U USBVCC1 USBVCC0 BEAD(1206 ) BEAD(1206 ) USBP0- Z324 (10) USBP0- 1DATA- R263 470K USBP0+ R232 Z323...
  • Page 83 Service Manual R484 0(R) R485 V CC CN23 B _V CC VCC3_A UX B _V CC C143 C159 C158 C206 C142 C207 C186 C185 C170 C144 C157 C200 B_ CD0 A3 0 V CC B_ CD1 A3 1 V CC B_ CD2 A3 2 B_ CD3...
  • Page 84 PHYSDAT A (16) PHYSDAT A R273 S-24C02 C270 4.7K C271 1U(0805)(K%) 220P ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. TPGND Ti t l e PCMCIA POWER TPGND Si z e Do cument Numbe r Cus tom 0200-16.SCH 71-22C00-D02 Date :...
  • Page 85 1 0 U 10 U(R) 10 0 K MA X 6 03 BEA D (1 20 6) DACGND ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. Title AUDIO CODEC Si z e D oc ume n t Nu mb er R ev Custom 02 0 0-17 .SC H...
  • Page 86 Schematic Diagrams CN22 R_OUT+ R_OUT - L _OUT - L_OUT+ VS OUND_ L 1 0K 1 0K 0.22U VSOUND_R 0.22U SPEAKERS CONN. 4P L_LINE IN R_LINE IN 1 0K 1 0K 0.22U 0.22U C101 L_HP IN R_HP IN CN13 1 0K 1 5K INT _ MIC L5 4...
  • Page 87 4.7K SA15 W83626F 10P 8R_10K VCC3 10P8R_R BEAD VCC3 C424 C430 ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T i t l e LPC-ISA BRIDGE Size Document Number Custom 0200-19.SCH 71-22C00-D02 Date: Monday, March 05, 2001 Sheet B - 20...
  • Page 88 FDDVCC BEAD(1206 ) 37N869 C219 C220 C221 C453 100 U/10V ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. Ti t l e S I/O Size Docu ment Numbe r 0200-20.SCH Cus tom 71-22C00-D02 Date : Monday, March 05 , 2 001...
  • Page 89 (21) PINIT# PSLIN# R234 (21) PSLIN# RN49 8P 4R_0 PRT _PORT ÂÅ ¤Ñ ¹q ¸£ CLEVO CO. Title I/O CON Si z e Documen t Nu mbe r Custom 020 0-21 .SCH 71-22C00-D02 Date : Monday, March 05, 20 01...
  • Page 90 Schematic Diagrams Z149 B EA D(0805) CN17 ROW16 KBV 3 ROW16 ROW15 ROW15 ROW11 EMCLK BEAD(0803) Z150 ROW11 EMCL K ROW10 E MDA BEAD(0803) Z151 ROW10 E MDA ROW9 ROW9 ROW8 E KDA BEAD(0803) Z152 ROW8 E KDA COL2 EK CLK BEAD(0803) Z153 RP 18...
  • Page 91 Service Manual SA[0 ..16 ] S A[0..16] (20,21,23) 2N70 02 PWR_ON# PWRLED# (10,23,29) PWR_ON# PWRLED# (13) C418 C417 R4 40 .1 U .1 U SA 0 LOOP Z5 86 (20,21,23) V CC3 SA 1 (20,21,23) SA 2 (20,21,23) SA 3 2N70 02 (20,21,23) SA 4...
  • Page 92 R379 C43 5 2 N7002 SUSPEND 15K_1% 1 00K .22U(080 5)(K%) (1 0,24) SUSPEND ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T i t l e FAN CONTROLLER Size Document Number 0200-24.SCH 71-22C00-D02 Date: Monday, March 05, 2001 Sheet B - 25...
  • Page 93 0(0805) 1SS 355 R387 R379 C435 2N7002 SUSPEND 15K_1% 100K .22U(0805)(K%) (10,24) SUSPEND ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T itle FAN CONTROLLER Si z e Document Number 0200-24.SCH 71-22C00-D02 Date: Monday, March 05, 2001 Sheet B - 26...
  • Page 94 Z760 (28,29) PWR_ON+ (28,29) PWR_ON+ PC129 PR53 3025LS 0.1U 45.3K/F PR15 100K VR_ON VCC3+ VR_ON ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T i t l e VCC_CORE,V_IO,VCCT Size Document Number 0200-26.SCH Custom 71-22C00-D02 Date: 02:10:04 Sheet B - 27...
  • Page 95 PC 117 0.1U PR 172 Z695 (27,29) PWR_ON+ PQ46 PQ47 2N7002 2N7002 ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T i t le VDD3,VCC3,VCC,12V Si z e Document Number 0200-27.SCH Cus tom 71-22C00-D02 Date: Friday, N ovember 10, 2000 Sheet...
  • Page 96 PC1 23 100K 0.1U PD32 1S S355 PQ43 PR170 Z762 Z683 2N70 02 330K PR169 PC109 100K ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. T itle VDD1.8,VCC1.8 Size Document Number 0200-28.SCH Custom 71-22C00-D02 Date: 0 3:17:15 Sheet B - 29...
  • Page 97 PQ34 PR140 PC104 2N7 002 Z468 2N7002 100K/F (31 ) LI_HI AC_IN ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. Ti t le CHARGER-1 Size Do cument Numbe r Cus tom 0200-29.SCH 71-22C00-D02 Date : Shee t 02:10:04 B - 30...
  • Page 98 3.3K PC83 1U(R) Z58 4 PR15 6 PR15 5 PR16 3 PR16 4 27K/F 12K/F Z71 3 ÂÅ ¤ Ñ ¹q ¸£ CLEVO CO. PQ4 0 2N700 2 T itle LI_HI (30) CHARGER-2 Size Document Number Cu stom 0200-30.SCH 71-22C00-D02...
  • Page 99 100K SCRD LED# CAP LED# NVM LED# 470p 750/F IDE LED# FDD LED# CLEVO CO. Title CCFL Smart Inv erter Size Document Number 2200 , 2200S , 2200C , 2700S Date: Thursday , December 14, 2000 Sheet B - 32...

  • Page 100: Appendix C: Switch Settings

    Switch Settings Appendix C: Switch Settings Clock Settings (SW6) C - 1...

  • Page 101: Panel Id Settings (Sw7)

    Service Manual Panel ID Settings (SW7) " 3 " 1 C - 2...
