Drive Bays

The following figure shows the drive bays of ReadyNAS Duo v2.
1
Figure 2. ReadyNAS Duo v2 drive bay
1. Drive bay door
2. Disk tray handle
3. Recessed drive tray locking mechanism
4. Drive tray release latch
5. Drive bays
