Sharp R-307KW Service Manual page 37

NO. PARTS CODE
[1] OVEN PARTS
ELECTRIC PARTS
1-1 QSW-MA147WRZZ
1-2 FFS-BA037WRKZ
1-3 FACCDA109WREZ
1-3 FACCDA098WREZ
1-3 FACCDA099WREZ
1-3 FACCDA110WREZ
1-4 FH-DZA109WRKZ
!
1-4 FH-DZA075WRK0
!
1-4 FH-DZA112WRKZ
!
1-5 RC-QZA218WRE0
!
1-5 RC-QZA295WRZZ
!
1-6 RMOTEA433WRZZ
1-6 RMOTEA346WRE0
1-6 RMOTEA356WRE0
1-7 RTHM-A119WRE0
1-7 QFS-TA014WRE0
1-8 RLMPTA087WRZZ
1-8 RLMPTA082WRZZ
1-8 RLMPTA085WRZZ
1-9 RMOTDA264WRZZ
1-9 RMOTDA252WRZZ
1-9 RMOTDA186WRE0
1-10 RTRN-A729WRZZ
!
1-10 RTRN-A730WRZZ
!
!
1-11 RV-MZA288WRE0
*
!
1-11 RV-MZA321WRZZ
*
!
1-11 RV-MZA340WRZZ
*
1-12 QFS-TA014WRE0
1-13 FPWBFA385WRKZ
CABINET PARTS
2-1 GCABUA889WRPZ
2-1 GCABUA883WRPZ
2-2 GDAI-A360WRWZ
2-3 GLEGPA074WRE0
OVEN PARTS
4-1 PHOK-A145WRFZ
*
4-2 LBNDKA163WRPZ
4-3 NFANJA053WRFZ
4-4 *************
*
4-5 MLEVPA233WRF0
4-6 PCUSGA620WRPZ
4-7 PCOVPA394WREZ
4-8 PDUC-A833WRPZ
4-9 PDUC-A853WRWZ
4-10 PPACGA176WREZ
4-11 PCUSGA399WRE0
4-12 PCUSUA278WRP0
4-13 PCUSUA235WRP0
4-14 PCUSGA614WRPZ
4-15 PCUSGA615WRPZ
4-16 MROD-A019WREZ
4-17 PCUSGA616WRPZ
MISCELLANEOUS
6-1 FROLPA101WRKZ
6-2 NTNT-A117WREZ
6-3 TCAUAA292WRRZ
6-4 TCAUAA268WRRZ
SCREWS, NUTS AND WASHERS
7-1 XHPS740P08K00
7-2 LX-CZA070WRE0
7-3 LX-CZA073WRE0
7-4 LX-CZ0052WRE0
7-5 LX-EZA042WRE0
7-6 XHPS730P06000
7-7 XHPS740P08000
7-8 XHTS740P08RV0
7-9 XHTS740P08000
7-10 XOTS740P08000
7-11 XOTS840P08000
7-11 XOTS740P08000
PRICE NEW PART
RANK MARK RANK
AG
Secondary interlock switch / door sensing switch
AN Monitor fuse 20A and monitor switch (D3V-1G-2C25)
AU Power supply cord
-- Power supply cord (Interchangeable) for production
-- Power supply cord (Interchangeable) for production
--
Power supply cord (Interchangeable) for production
AR High voltage rectifier assmebly
AR High voltage rectifier assembly (Interchangeable)
AR High voltage rectifier assembly (Interchangeable)
AW High voltage capacitor
AV
High voltage capacitor (Interchangeable)
AX Fan motor
AV Fan motor (Interchangeable)
-- Fan motor (Interchangeable) for production use
AK Thermal cut-out 145C [oven]
AG
Temperature fuse 150deg.C [oven] (Interchangeable)
AL Oven lamp
AL Oven lamp (Interchangeable)
AH Oven lamp (Interchangeable)
AT Turntable motor
AN
Turntable motor (Interchangeable)
AW Turntable motor (Interchangeable)
BG Power transformer
-- Power transformer (Interchangeable) for production
BK Magnetron
BH
Magnetron (Interchangeable)
--
Magnetron (Interchangeable) for production use
AG
Temperature fuse 150deg.C [Magnetron]
AV Noise filter assembly
BF Outer case cabinet [R-307KK]
BF Outer case cabinet [R-307KW]
AS
Bottom plate
AC Foot
AL Latch hook
AK Capacitor holder
AG
Fan blade
-- Oven cavity [Not a replacement part]
AG Switch lever
AF Cushion
AK Waveguide cover
AM
Air duct
AP Fan duct
AC TTM packing
AF Cushion
AB Cushion
AE
Cushion
AE Cushion
AE Cushion
AN Chassis support
AK Cushion
AR Turntable support
AS Turntable
AE Monitor caution
AF DHHS caution label
AB Screw : 4mm x 8mm
AC Special screw
AC
Special screw
AA Special screw
AB
Special screw
AB Screw : 3mm x 6mm
AB Screw : 4mm x 8mm
AG
Screw : 4mm x 8mm
AC Screw : 4mm x 8mm
AA
Screw : 4mm x 8mm
AB Screw : 4mm x 8mm [R-307KK]
AA Screw : 4mm x 8mm [R-307KW]
3
DESCRIPTION
R307KW
