Page 2
Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. D-Link DWR-512 User Manual...
URL Filter ............39 Manual Internet Connection Setup ....13 Outbound Filter ..........40 Internet Connection ........13 Inbound Filter ........... 41 Static IP ............14 SNMP .............. 42 Dynamic IP (DHCP) ........15 Routing ............43 D-Link DWR-512 User Manual...
Page 5
Using Windows 7 ..........60 Configuring Wireless Security ......62 Using Windows Vista™ ......... 65 Configuring Wireless Security ......66 Using Windows XP ..........68 ® Configure WEP ..........69 Configure WPA-PSK ........71 Troubleshooting ............73 D-Link DWR-512 User Manual...
• Power Adapter • Manual and Warranty on CD • 3G Antenna Note: Using a power supply with a different voltage rating than the one included with the DWR-512 will cause damage and void the warranty for this product. System Requirements •...
The HSUPA 3G Router can be installed quickly and easily almost anywhere. This router is great for situations where an impromptu wireless network must be set up, or wherever conventional network access is unavailable. The DWR-512 can even be installed in buses, trains, or boats, allowing passengers to check e-mail or chat online while commuting.
Ethernet cable. Accepts a standard (U)SIM card for 3G connectivity. Power Connects to the included power adapter. Power Switch Turns the device on or off. Phone (RJ-11) Connects to a telephone through a standard RJ-11 telephone cable. D-Link DWR-512 User Manual...
LAN1 LAN2 LAN3 LAN4 Status WLAN Signal Strength Reset Button WPS Button Button Name Function Reset Press this button with an unfolded paperclip to reset the device. Press this button to initiate a new WPS connection. D-Link DWR-512 User Manual...
Blinking: Data is being transferred via 2G Solid Green: SMS storage is full Blinking Green: There is an unread SMS message WLAN Solid Green: WLAN is active and available Blinking Green: Data is being transferred over the WLAN D-Link DWR-512 User Manual...
Internet connection if the Ethernet WAN is not available. 4. Insert the Ethernet cable into the LAN Port 1 on the back panel of the DWR-512 HSUPA 3G Router and an available Ethernet port on the network adapter in the computer you will use to configure the router.
You can then use your handset to dial out as you typically would with a standard landline phone. Your attached phone will also ring for any incoming voice calls. Note: Calls made will be charged at a rate determined by your mobile service provider. D-Link DWR-512 User Manual...
The key to maximizing the wireless range is to follow these basic guidelines: 1. Minimize the number of walls and ceilings between the D-Link router and other network devices. Each wall or ceiling can reduce your adapter’s range from 3 to 90 feet (1 to 30 meters).
Section 3 - Configuration Configuration This section will show you how to configure your new D-Link mobile router using the web-based configuration utility. Web-based Configuration Utility To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address of the router (192.168.0.1 by default).
If you want to manually configure your settings, click Manual Internet Connection Setup and skip to “Manual Internet Connection Setup” on page 13. Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your D-Link router to connect to the Internet. Click Next to continue.
Page 16
Click Prev to go back to the previous page or click Cancel to close the wizard. Note: The DWR-512 has a WAN Failover feature that allows the router to switch to a 3G connection if the WAN connection is down or unavailable. To configure this feature, please refer to “Internet Connection”...
Page 17
See “L2TP” on page 18 for information about how to configure this type of connection. 3G Connection: Choose this connection if you have installed a SIM card into the DWR-512. See “3G” on page 19 for information about how to configure this type of connection.
Enter an IP address for the router to use to check Internet Host: if it is connected to the Internet. If Auto-Backup is enabled and the IP address cannot be reached, the router will switch over to a 3G connection. D-Link DWR-512 User Manual...
Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. D-Link DWR-512 User Manual...
ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your PC. This feature enables this product to renew the WAN IP Auto-reconnect: address automatically when the lease time has expired. D-Link DWR-512 User Manual...
The amount of time of inactivity before disconnecting established PPPoE session. Set it to zero or enable Auto-reconnect will disable this feature. Maximum The default setting of PPPoE is 1492. Transmission Unit (MTU): Auto-reconnect: The device will dial-up PPPoE connection automatically. D-Link DWR-512 User Manual...
Maximum Idle Time. Maximum Idle Time: The time of no activity to disconnect your PPTP session. Set it to zero or choose Always-on to disable this feature. D-Link DWR-512 User Manual...
Internet, and disconnect if no traffic after time period of Maximum Idle Time. Maximum Idle Time: The time of no activity to disconnect your L2TP session. Set it to 0 or choose Always-on to disable this feature. D-Link DWR-512 User Manual...
Page 24
Reconnect Mode to disable this feature. Primary DNS Server: (Optional) Fill in if provided by your ISP. If not, keep the default value. Secondary DNS (Optional) Fill in if provided by your ISP. Server: If not, keep the default value. D-Link DWR-512 User Manual...
Page 25
Section 3 - Configuration Keep Alive: Select Disable or Use LCP Echo Request depending on the settings required by your ISP. Bridge Ethernet Ports: Activate this feature to use the Ethernet WAN port as an additional LAN port. D-Link DWR-512 User Manual...
Wi-Fi Protected Setup button. This is described in “Wi-Fi Protected Setup” on page 28. Wireless Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your D-Link router’s wireless . Click Next to continue.
Page 27
10 or 26 digit password using only hex characters (0-9, A-F). If you choose ASCII, the password can be up to 5 or 13 alphanumeric characters. Click Next to continue. This completes the Wireless Connection Setup Wizard. Click Save to save your changes and reboot the router. D-Link DWR-512 User Manual...
Section 3 - Configuration Manual Wireless Connection Setup To set up your wireless connection manually, click Manual Wireless Connection Setup. D-Link DWR-512 User Manual...
Invisible to wireless clients looking for wireless networks. Setting this to Invisible can increase the security of your network by hiding it, but clients will need to manually enter the SSID of your network to connect. D-Link DWR-512 User Manual...
• WPA-Personal: WPA-PSK encryption will be used. This setting is recommended for most users. • WPA-Enterprise: WPA-EAP encryption will be used. This setting is only recommended if you have a RADIUS authentication server. Otherwise, WPA-Personal should be used. D-Link DWR-512 User Manual...
Page 31
Network Key: Enter the key/password you want to use for your wireless network. The key must be 8 to 63 characters long, and may only contain letters and numbers. D-Link DWR-512 User Manual...
Page 32
RADIUS Server IP Enter the IP address of your RADIUS server. Address: RADIUS Server Port: Enter the port used for your RADIUS server. RADIUS Server Shared Enter the Shared Secret/password Secret: for your RADIUS server. D-Link DWR-512 User Manual...
You can also use Windows 7 to do initial configuration of your router by using the Connect to a network wizard in Windows, and entering the WPS PIN/AP PIN of the router when prompted. After modifying any settings, click Save Settings to save your changes. D-Link DWR-512 User Manual...
Page 34
8-digit PIN number that the wireless client need to use to connect to your router. WPS Status: This will show the current WPS connection process status. Click the Trigger button to initiate a WPS connection. D-Link DWR-512 User Manual...
Default Subnet Mask: Enter the Subnet Mask of the router. The default subnet mask is 255.255.255.0. Local Domain Name: Enter the local domain name for your network. D-Link DWR-512 User Manual...
DHCP Server Settings The DWR-512 has a built-in DHCP (Dynamic Host Control Protocol) server. The DHCP server assigns IP addresses to devices on the network that request them. By default, the DHCP Server is enabled on the device. The DHCP address pool contains a range of IP addresses, which is automatically assigned to the clients on the network.
Opens a Create Message window to reply to the selected SMS message. Forward: Opens a Create Message windows to forward the selected SMS message to another recipient. Refresh: Click this button to check for new messages. D-Link DWR-512 User Manual...
Receiver: Type the phone number of the recipient. Text Message: Type the message that you would like to send. Sent Message: Click this button to send the message. Cancel: Click this button to clear the message. D-Link DWR-512 User Manual...
Select a schedule to use and copy to the specified rule ID when you click the Copy to button. You may select Always On or use a specific schedule that you have defined. To create and edit schedules, please refer to “Schedules” on page 54. D-Link DWR-512 User Manual...
Page 40
Enable: Tick the checkbox to enable the specified rule. Schedule Rule #: Specify the schedule rule number. To create schedules, please refer to “Schedules” on page 54. D-Link DWR-512 User Manual...
NAT (Network Address Translation). Application Rules allow some of these applications work with the DWR-512 by opening ports after detecting traffic being sent through a trigger port. After modifying any settings, click Save Settings to save your changes.
Select what priority level to use for traffic affected by the rule: Low, Normal, or High. Enable: Tick the checkbox to enable the specified rule. Use Rule #: Specify the schedule rule number. To create schedules, please refer to “Schedules” on page 54. D-Link DWR-512 User Manual...
If this box is ticked, the rule will follow the connection control setting specified in MAC filtering settings specified above. If this box is ticked, the rule will follow the association control setting specified in MAC filtering settings specified above. D-Link DWR-512 User Manual...
Select this box to enable URL Filtering. URL FILTERING RULES This identifies the rule. URL: Enter URL that you would like to block. All URLs that begin with this URL will be blocked. Enable: Tick the checkbox to enable the specified rule. D-Link DWR-512 User Manual...
Enable: Tick the checkbox to enable the specified rule. Schedule Rule #: Specify the schedule rule number. Previous Page: Go back to the previous filter page. Next Page: Advance to the next filter page. D-Link DWR-512 User Manual...
Enable: Tick the checkbox to enable the specified rule. Schedule Rule #: Specify the schedule rule number. Previous Page: Go back to the previous filter page. Next Page: Advance to the next filter page. D-Link DWR-512 User Manual...
SNMP (Simple Network Management Protocol) is a widely used network monitoring and control protocol that reports activity on each network device to the administrator of the network. SNMP can be used to monitor traffic and statistics of the DWR-512. The DWR-512 supports SNMP v1 and v2c.
The number of hops equals the number of routers or gateways that data must pass through before reaching the destination. Enable: Select this box to enable the rule. D-Link DWR-512 User Manual...
TX Rates: Select the basic transfer rates based on the speed of wireless adapters on your wireless network. It is strongly recommended to keep this setting to Auto. D-Link DWR-512 User Manual...
(UPnP™) feature. UPNP provides compatibility with various networking equipment, software, and peripherals. Enable WAN Ping Select the box to allow the WAN port to be Respond: “pinged.” Blocking WAN pings may provide some extra security from hackers. D-Link DWR-512 User Manual...
REMOTE MANAGEMENT Remote Management: Tick this check box to enable remote management. Remote management allows the DWR-512 to be configured over the Internet through a web browser. A username and password will still be required to access the Web-Management interface.
NTP server to update the router’s internal clock. NTP Server Used: Enter an NTP server to use for time synchronization, or use the dropdown box to select one. Click the Update Now button to synchronize the time with the NTP server. D-Link DWR-512 User Manual...
Section 3 - Configuration Syslog The DWR-512 keeps a running log of events and activities occurring on the router. You may send these logs to a syslog server on your network. After modifying any settings, click Save Settings to save your changes.
Enter the e-mail address where you would like the router to send e-mails to. E-mail Subject: Enter a subject for the e-mail. E-mail Log Now: Click this button to send the current logs to the specified e-mail address. D-Link DWR-512 User Manual...
Restore To Factory This option will restore all settings back to their defaults. Default Settings: Any settings that have not been backed up will be lost, including any rules that you have created. D-Link DWR-512 User Manual...
Here, you can upgrade the firmware of your router. Make sure the firmware you want to use is on the local hard drive of the computer and then click Browse to upload the file. You can check for and download firmware updates at the D-Link support site at http://support.dlink.com.
IP address. You can use one of the listed DDNS service, or you can sign up for D-Link’s free DDNS service at www.dlinkddns.com. After modifying any settings, click Save Settings to save your changes. Enable Dynamic DNS: Tick this checkbox to enable the DDNS feature.
Host Name or IP Enter a host name or the IP address that you want to ping Address: and click the Ping button. The results of the ping attempt will be displayed in the PING RESULT section below. D-Link DWR-512 User Manual...
Enter the time at which you would like the schedule to become active. End Time (hh:mm): Select the time at which you would like the schedule to become inactive. After making your changes, click Save Settings to save the schedule. D-Link DWR-512 User Manual...
Displays the 3G connection details of the router. LAN: Displays the LAN connection details of the router. Wireless LAN: Displays the wireless LAN connection details of the router LAN Computers: Displays the list of clients connected to the router. D-Link DWR-512 User Manual...
Clear Logs: Click this button to clear the system log. Link To Log Settings: Click this button to go to the Log Settings page. For more, refer to “Log” on page 56. D-Link DWR-512 User Manual...
Here you can view the packets transmitted and received passing through your router on both WAN and LAN ports. The traffic counter will reset if the device is rebooted. Click the Refresh button to refresh the WAN statistics. D-Link DWR-512 User Manual...
Wireless This table displays a list of wireless clients that are connected to your wireless router. It also displays the connection time and MAC address of the connected wireless clients. Click Refresh to refresh the list. D-Link DWR-512 User Manual...
Section 3 - Configuration Support The SUPPORT pages provide help information for each section of the device’s interface. To view the Support pages, click on SUPPORT at the top of the screen. D-Link DWR-512 User Manual...
If you receive the Wireless Networks Detected bubble, click on the center of the bubble to access the utility. You can also click on the wireless icon in your system tray (lower-right corner). Wireless The utility will display any available wireless networks in your area. D-Link DWR-512 User Manual...
Page 66
Connect button. If you get a good signal but cannot access the Internet, check your TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DWR-512 User Manual...
If you are joining an existing network, you will need to know the security key or passphrase being used. 1. Click on the wireless icon in your system tray (lower-right corner). Wireless 2. The utility will display any available wireless networks in your area. D-Link DWR-512 User Manual...
Page 68
Section 4 - Connecting to a Wireless Network 3. Highlight the wireless network (SSID) you would like to connect to and click the Connect button. 4. The following window appears while your computer tries to connect to the router. D-Link DWR-512 User Manual...
Page 69
It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DWR-512 User Manual...
(displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check the TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DWR-512 User Manual...
Wireless Utility by right-clicking on the ® ™ wireless computer icon in your system tray (lower right corner of screen). Select Connect to a network. 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-512 User Manual...
Page 72
It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DWR-512 User Manual...
(displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check the TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DWR-512 User Manual...
X P W i r e l e s s U t i l i t y b y r i g h t - ® clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-512 User Manual...
Page 75
It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WEP settings are correct. The WEP key must be exactly the same as on the wireless router. D-Link DWR-512 User Manual...
(lower-right corner of screen). Select View Available Wireless Networks. 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-512 User Manual...
Page 77
It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router. D-Link DWR-512 User Manual...
1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website on the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.
Page 79
• • Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your the web management.
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers.
D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. How does wireless work? Wireless works similar to how cordless phone work, through radio signals to transmit data from one point A to point B.
Page 82
PDAs, headphones, laptops, speakers, and other devices that operate on batteries. Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home •...
The wireless connection in public places is usually called “hotspots”. Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.
An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point. An Ad-Hoc network contains only clients, such as laptops with wireless cardbus adapters. All the adapters must be in Ad-Hoc mode to communicate. D-Link DWR-512 User Manual...
Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.
Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step 5 Click OK twice to save your settings. D-Link DWR-512 User Manual...
WPA & WPA2 (Wi-Fi Protected Access) Dimensions (L x W x H) Firewall 190 x 119 x 22 mm Network Address Translation (NAT) Stateful Packet Inspection (SPI) Operating Temperature 0 to 40 ˚C (32 to 104 ˚F) D-Link DWR-512 User Manual...
Page 88
Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. D-Link DWR-512 User Manual...
